DEV 2404 Operator's manual

Customer Documentation
DEV 2404 (4:1)
DEV 2408 (8:1)
DEV 2416 (16:1)
DEV 2428 (2*8:1)
DEV 2432 (32:1)
DEV 2461 (16*2:1)
DEV 2462 (8*4:1)
DEV 2463 (4*8:1)
DEV 2405 (1:4)
DEV 2409 (1:8)
DEV 2417 (1:16)
DEV 2441 (16*1:2)
DEV 2442 (8*1:4)
DEV 2443 (4*1:8)
Passive CATV-Band Combiners/Splitters
DEV Systemtechnik GmbH
Grüner Weg 4A
61169 Friedberg
GERMANY
Tel: [phone]
Fax: [phone]
[email protected]
www.dev-systemtechnik.com
Revision: 2017-12-13
DEV 91-0013-M

Customer Documentation DEV 24xx
2 Copyright DEV Systemtechnik GmbH 2003-2017
TABLE OF CONTENTS
1REVISION HISTORY -------------------------------------------------------------------------------3
2INTRODUCTION ------------------------------------------------------------------------------------3
2.1 Warranty-----------------------------------------------------------------------------------------------3
2.2 Limitation of Warranty ------------------------------------------------------------------------------3
3PRODUCT DESCRIPTION -----------------------------------------------------------------------4
3.1 Product Drawings------------------------------------------------------------------------------------4
3.1.1 DEV 2404 –4:1 Passive Combiner--------------------------------------------------------------4
3.1.2 DEV 2405 –1:4 Passive Splitter -----------------------------------------------------------------5
3.1.3 DEV 2408 –8:1 Passive Combiner--------------------------------------------------------------5
3.1.4 DEV 2409 –1:8 Passive Splitter -----------------------------------------------------------------5
3.1.5 DEV 2416 –16:1 Passive Combiner------------------------------------------------------------5
3.1.6 DEV 2417 –1:16 Passive Splitter----------------------------------------------------------------6
3.1.7 DEV 2428 –2*8:1 Passive Combiner-----------------------------------------------------------6
3.1.8 DEV 2432 –32:1 Passive Combiner------------------------------------------------------------6
3.1.9 DEV 2441 –16*1:2 Passive Splitter-------------------------------------------------------------7
3.1.10 DEV 2442 –8*1:4 Passive Splitter --------------------------------------------------------------7
3.1.11 DEV 2443 –4*1:8 Passive Splitter --------------------------------------------------------------7
3.1.12 DEV 2461 –16*2:1 Passive Combiner ---------------------------------------------------------8
3.1.13 DEV 2462 –8*4:1 Passive Combiner-----------------------------------------------------------8
3.1.14 DEV 2463 –4*8:1 Passive Combiner-----------------------------------------------------------8
4INSTALLATION INSTRUCTIONS---------------------------------------------------------------9
4.1 Scope of Delivery------------------------------------------------------------------------------------9
4.2 Installation of the Product--------------------------------------------------------------------------9
4.2.1 Mechanical Integration of the Product in a 19" Rack----------------------------------------9
4.2.2 Grounding ---------------------------------------------------------------------------------------------9
4.2.3 Connection of RF Signal Cables --------------------------------------------------------------- 10
4.3 Maintenance Of the Product --------------------------------------------------------------------10
5OPERATION OF THE PRODUCT ------------------------------------------------------------ 11
6TECHNICAL DATA ------------------------------------------------------------------------------- 11
7CONFORMANCE DECLARATIONS --------------------------------------------------------- 11
7.1 Certificate of Conformance---------------------------------------------------------------------- 11
7.2 EU Declaration of Conformity-------------------------------------------------------------------13
8GLOSSARY----------------------------------------------------------------------------------------- 14
9NOTES----------------------------------------------------------------------------------------------- 14

Customer Documentation DEV 24xx
Copyright DEV Systemtechnik GmbH 2003-2017 3
1 REVISION HISTORY
Revision (Date)
Author
Short Description
A (08-Jun-2003)
JS
Initial version
B (03-Jun-2008)
WP
Complete rework to new document format
C (04-Sep-2008)
WP
Minor corrections
(…)
K (12-Aug-2014)
WP
Excluded DEV 2465 (separate documentation)
L (02-Apr-2015)
WP
Documentation rework
M (13-Dec-2017)
WP
Minor changes, eliminated DEV 2444
2 INTRODUCTION
Thank you for purchasing a DEV 24xx Passive Combiner or Splitter.
This customer documentation is intended to familiarize you with the
installation and with the operation of the product.
The products of this series were developed to combine, or to distribute
signals for digital TV and broadcasting applications in the frequency range of
the CATV-Band.
DEV Systemtechnik GmbH declares that this equipment meets all relevant
standards and rules. The unit carries a CE mark.
Please read all instructions before installation or usage of the product!
2.1 WARRANTY
The product has a warranty against defects in material and workmanship for
a period of two years from the date of shipment. During the warranty period
DEV Systemtechnik will, at its option, either repair or replace the product if it
turns out to be defective.
For warranty, service, or repair, the product must be returned to DEV
Systemtechnik. The customer has to pay shipping charges to DEV
Systemtechnik and DEV Systemtechnik will pay shipping charges to return
the product to the customer. However, the customer is obliged to pay all
duties, all taxes, and all other additional costs arising from the shipment of
the product.
2.2 LIMITATION OF WARRANTY
The preceding warranty does not apply to defects resulting from:
improper site preparation or site maintenance;
improper or inadequate interfacing of the product;
unauthorized modification or misuse of the product;
improper or inadequate maintenance of the product;
operation beyond the environmental conditions specified for the product.

Customer Documentation DEV 24xx
4 Copyright DEV Systemtechnik GmbH 2003-2017
3 PRODUCT DESCRIPTION
The DEV 24xx products being subject of this customer documentation
provide 1, 2, 4, 8, or 16 passive combiner units or passive splitter units; each
unit with one common port and with 2, 4, 8, 16, or 32 input or output ports.
The impedance of the products is 75 Ohm with precision F connectors; all
ports are DC free and DC blocked.
This manual comprises the following 8 combiner and 7 splitter products:
DEV 2404: 4:1 Passive Combiner; 10…1006 MHz; 75 Ohm, F (f)
DEV 2408: 8:1 Passive Combiner; 10…1006 MHz; 75 Ohm, F (f)
DEV 2416: 16:1 Passive Combiner; 10…1006 MHz; 75 Ohm, F (f)
DEV 2428: 2*8:1 Passive Combiner; 10…1006 MHz; 75 Ohm, F (f)
DEV 2432: 32:1 Passive Combiner; 10…1006 MHz; 75 Ohm, F (f)
DEV 2461: 16*2:1 Passive Combiner; 10…1006 MHz; 75 Ohm, F (f)
DEV 2462: 8*4:1 Passive Combiner; 10…1006 MHz; 75 Ohm, F (f)
DEV 2463: 4*8:1 Passive Combiner; 10…1006 MHz; 75 Ohm, F (f)
DEV 2405: 1:4 Passive Splitter; 10…1006 MHz; 75 Ohm, F (f)
DEV 2409: 1:8 Passive Splitter; 10…1006 MHz; 75 Ohm, F (f)
DEV 2417: 1:16 Passive Splitter; 10…1006 MHz; 75 Ohm, F (f)
DEV 2441: 16*1:2 Passive Splitter; 10…1006 MHz; 75 Ohm, F (f)
DEV 2442: 8*1:4 Passive Splitter; 10…1006 MHz; 75 Ohm, F (f)
DEV 2443: 4*1:8 Passive Splitter; 10…1006 MHz; 75 Ohm, F (f)
A monitor port is provided at the rear side of the combiner products
DEV 2404, DEV 2408, DEV 2416, DEV 2428 and of the splitter products
DEV 2405, DEV 2409, and of the DEV 2417 carrying the combined output
signal or the split input signal at a reduced level. Except the DEV 2404 and
the DEV 2405, these products are delivered in a compact 1 RU chassis.
The housings of the combiner units or of the splitter units applied for the
DEV 2404, DEV 2405, DEV 2441, DEV 2442, DEV 2443, DEV 2461,
DEV 2462, and DEV 2463 are assembled directly at a 1 RU front panel, thus
providing minimum depth of the device.
3.1 PRODUCT DRAWINGS
