Preface 6
devolo Magic 2 LAN
1Preface
Welcome to the fantastic world of devolo Magic!
In no time at all, devolo Magic transforms your house into a
multimedia home that is ready for the future today.
devolo Magic gives you noticeably higher speeds, more stabi-
lity and greater range, providing the perfect Internet experien-
ce as a result!
1.1 About this manual
Carefully read all instructions before setting up the device and
store the manual and/or installation guide for later reference.
After a brief introduction to „devolo Magic“ and to the
devolo Magic 2 LAN in Chapter 2, Chapter 3 tells you how to
successfully start using the adapter in your network.
Chapter 4 describes in detail the setting options of the built-in
configuration interface.
Tips for bandwidth optimisation, information about environmen-
tal compatibility of the device, as well as our warranty terms, can
be found in Chapter 5 at the end of the manual.
Description of the icons
This section contains a brief description of the icons used in this
manual and/or on the rating plate, the device connector, as well
as the icons used on the package:
Icon Description
Very important safety symbol that warns
you of imminent electrical voltage which if
not observed can result in serious injury or
death.
An important safety symbol that warns you
of a potentially dangerous situation involv-
ing a burn hazard which can result in minor
injuries or damage to property.
An important note that should be observed
which can potentially lead to material dam-
ages.
The device may only be used indoors in dry
conditions.

7 Preface
devolo Magic 2 LAN
1.2 Intended use
Use devolo products, devolo software and the provided accesso-
ries as described to prevent damage and injury.
Products
devolo products are communication devices designed for in-
doors.* Depending on the product, they are equipped with a
PLC-(PowerLine Communication) and/or a Wi-Fi module. Com-
puters, laptops, smartphones, tablets, smart TVs and other de-
vices connected this way are integrated into a home network over
the existing electrical wiring and/or Wi-Fi without any complica-
ted wiring. devolo devices must never be used outdoors because
the high temperature fluctuations and moisture can damage both
the product and the power line. devolo products may not be in-
stalled at a height above two metres unless an additional fas-
tening mechanism is available. The products are intended for
operation in the EU, Switzerland and Norway.
* The only exceptions are devolo outdoor products, which are sui-
ted for the outdoor use thanks to their IP certification.
Software
devolo devices can be used only with the free, downloadable
programs approved and available on devolo AG's website
(www.devolo.com) and in app stores (iOS and Google Play). Any
modifications to the product-specific firmware or software could
damage the products and, in the worst-case scenario, render
them unusable and negatively affect conformity.
Always use the most up-to-date software version to make sure
you have the latest security functions and device updates. The in-
stalled devolo software notifies you automatically if a new soft-
ware version is available.
The manufacturer/distributing company
uses the CE marking to declare that the
product meets all applicable European reg-
ulations and has been subjected to the pre-
scribed conformity assessment procedures.
It is used to prevent the occurrence of waste
electrical and electronic equipment and to
reduce this type of waste through reuse,
recycling and other forms of utilisation. The
European Community WEEE Directive estab-
lishes minimum standards for handling
waste electrical and electronic equipment in
the EU.
Additional information, background mate-
rial and configuration tips for your device.
Indicates a completed course of action
Icon Description

Preface 8
devolo Magic 2 LAN
Accessories
Use only the provided accessories:
쎲Network cable: RJ45-RJ45 Cat-5e UTP
1.3 CE Conformity
This product complies with the technical requirements
of the directives 2014/35/EU, 2014/30/EU, 2011/65/
EU und 2009/125/EC.
This product is designed for use in the EU,
Switzerland and Norway.
A printout of the simplified CE declaration of this product is sepa-
rately included and can also be found under
www.devolo.com/support/ce.
1.4 Safety notes
It is essential to have read and understood all safety and opera-
ting instructions before the devolo device is used for the first time;
keep them safe for future reference.
DANGER!
Electrical shock caused by electricity
Do not reach into the electrical socket, do not open
the device and do not insert any objects into the
electrical socket or into the ventilation openings
Users do not need to carry out any maintenance on devolo de-
vices. In the event of damage, disconnect the devolo device from
the mains supply by pulling it or its plug out of the electrical soc-
ket. Then contact qualified specialist personnel (after-sales ser-
vice) exclusively. Damage is deemed to have occurred, for
example,
쎲if the power plug is damaged.
쎲if the devolo device has been showered with liquid (such as
rain or other water).
쎲if the devolo device is inoperable.
쎲if the housing of the devolo device is damaged.
Do not plug devolo devices directly into each other. De-
vices that are plugged into each other can experience a
decrease in transmission rate.
DANGER!
Electric shock caused by electricity
Device must be plugged into a power socket with a
connected earth wire
devolo devices may be operated only on a mains power supply
as described on the rating plate.
To disconnect devolo devices from the mains supply, unplug the
device from the electrical socket.
The power socket and all connected network devices should be
easily accessible so that you can pull the power plug quickly if
needed.

9 Preface
devolo Magic 2 LAN
CAUTION!
Heat development during operation
Certain housing components can become very hot in
certain situations. Attach device so that it is touch-
proof, observing optimal positioning
devolo devices should only be installed at locations that
guarantee adequate ventilation. Slots and openings on
the housing are used for ventilation:
쎲Do not cover devolo devices during operation.
쎲Do not place any objects on devolo devices.
쎲Do not insert any objects into the openings of devolo
devices.
쎲devolo devices must not be placed directly next to a naked
flame (such as fire or candles).
쎲devolo devices must not be exposed to direct heat
radiation (e.g. radiator, direct sunlight).
CAUTION!
Damage to housing from cleaning agents
containing solvents
Clean only electroless and with dry cloth
1.5 devolo on the Internet
For detailed information on our products and devolo Magic, visit
www.devolo.com.
There you will find product descriptions and documentation, and
also updates of devolo software and your device's firmware.
If you have any further ideas or suggestions related to our prod-
ucts, please don't hesitate to contact us at [email protected]!

Introduction 10
devolo Magic 2 LAN
2Introduction
2.1 devolo Magic
Home is where devolo Magic is – in no time at all,
devolo Magic transforms your house or flat into a multimedia
home of the future with noticeably higher speed, more stability
and greater range, providing the perfect Internet experience as a
result!
Be inspired by products that are astonishingly easy to install, with
impressive, innovative technology and unbeatable performance.
The product name concept
The devolo Magic 2 LAN 1-1 name concept has the following
structure:
Be ready for the technology of the future today
devolo Magic embodies the new generation of the tried-and-test-
ed Powerline technology (PLC) based on the cutting-edge G.hn
architecture. G.hn was developed by the International Telecom-
munication Union (ITU) with ongoing development provided pri-
marily by the HomeGrid Forum industry association.
devolo Magic products are certified according to HomeGrid
standards and are compatible with other HomeGrid-certified
products.
Like the HomePlug AV technology used in established devolo
dLAN devices, devolo Magic uses the household mains supply for
data transmission and secures ideal performance and stability in
locations where network cables are not viable or desired and/or
the WiFi frequently falls short due to ceilings and walls.
Fig. 1 devolo Magic throughout the home
Product family devolo Magic
Performance category 2
Transmission type LAN (Ethernet)
Number of sockets 1
Integrated electrical socket 1 (= yes)

11 Introduction
devolo Magic 2 LAN
To set up a devolo Magic network, you need at least two
devolo Magic devices. For technical reasons, devices
from the devolo Magic series are not compatible with
dLAN devices.
2.2 The devolo Magic 2 LAN
A brief introduction to the devolo Magic adapter:
Unpack – plug in – get started and be ready for the new gen-
eration of tried-and-tested Powerline technology:
쎲Speed and stability – thanks to consistent data transmis-
sion speed at up to 2400 Mbps over distances of up to
500 meters, the devolo Magic 2 LAN promises entertain-
ment at the highest level.
쎲Security – with 128-bit AES Powerline encryption
쎲Energy-efficiency – the integrated PowerSave mode cuts
energy consumption automatically during low data traf-
fic.
쎲A devolo Magic 2 LAN transforms any electrical socket in
your household electrical wiring into a Gigabit LAN Internet
access point.
쎲Its integrated electrical socket can be used (like a normal
wall socket) to supply power to an additional network device
or a power strip.
쎲The Gigabit LAN port on the devolo Magic 2 LAN lets you
connect a stationary network device – such as a game con-
sole, television or media receiver – to your Internet access
point over the Powerline network (e.g. Internet router).
The devolo Magic 2 LAN features
쎲One Gigabit network connection
쎲One indicator light
The LED status display can be disabled. You can find more
information about this in Chapter 4 Configuration or in
the product manual for the devolo Cockpit software
available online at www.devolo.com/cockpit.
쎲One PLC/reset button (next to the network connection)
쎲One integrated electrical socket
Fig. 2: devolo Magic 2 LAN with country-specific connector
and power socket throughout the home

Introduction 12
devolo Magic 2 LAN
2.3 Pairing
devolo Magic adapters that are in factory default condition, i.e.
have been purchased or successfully reset (see Chapter Reset-
ting a devolo Magic adapter or removing it from a
devolo Magic network), automatically start to attempt to pair
with another devolo Magic adapter when reconnected to the
mains supply.
Starting up a new devolo Magic network
After plugging the devolo Magic adapters into available power
sockets, a new devolo Magic network is established automatical-
ly within 3 minutes.
Expanding an existing devolo Magic network by adding
another devolo Magic adapter
In order to use a new devolo Magic 2 LAN in your devolo Magic-
network, first you have to connect it to your existing
devolo Magic adapters devices as a network. This is accom-
plished by using a shared password, which can be assigned in
various ways:
쎲Using devolo Cockpit or the devolo app (see Chapter 3.4
Installation of devolo software)
쎲Using the web interface (see Chapter 4.2.2 PLC)
쎲Using the PLC/reset button as described below.
햲To do so, plug the new devolo Magic adapter into an availa-
ble power socket and, for approximately 1 second, press the
PLC/reset button on a devolo Magic adapter in your existing
devolo Magic network.
For each pairing operation, only one additional
devolo Magic adapter can be added at a time.
햳Within 3 minutes, press the PLC/reset button on the
devolo Magic adapter that you want to add to your existing
devolo Magic network. The LED of this adapter now also
flashes white.
After a short time, the flashing LED becomes a steady
white light. The devolo Magic adapter has been suc-
cessfully integrated into your existing devolo Magic
network.
You can find detailed information about installing
devolo Magic adapters in Chapter 3.3 Connecting the
devolo Magic 2 LAN.
Resetting a devolo Magic adapter or removing it from a
devolo Magic network
햲To remove a devolo Magic adapter from your devolo Magic
network and successfully restore its entire configuration to
the factory default settings, press and hold the reset button
longer than 10 seconds.
햳Wait until the LED flashes white and then disconnect the
devolo Magic adapter from the mains supply.

13 Introduction
devolo Magic 2 LAN
Keep in mind that all settings that have already been
made will be lost!
2.3.1 Reading the indicator light
The integrated indicator light (LED) shows the status for the
devolo Magic 2 LAN by illuminating and/or flashing:
LED Flashing behaviour Meaning LED status display (web
interface*)
1 Red LED Lights up for up to
2 sec.
Start-up process Cannot be dis-abled
2 Red LED Flashes at intervals
of 0.5 sec. (on/off)
Status 1: The reset of the devolo Magic adapter was
successful. The PLC/reset button has been pressed and
held for 10 seconds.
Status 2: The devolo Magic adapter (once again) has
the factory default settings. Since the last reset, no pair-
ing with another devolo Magic adapter has taken place.
Connect the adapter with another devolo Magic adapter
to create a full-fledged PLC network as described in
Chapter 2.3 Pairing.
Cannot be dis-abled

Introduction 14
devolo Magic 2 LAN
3 Red LED Lights up steady Status 1: The other network nodes are in standby mode
and cannot currently be accessed over the mains supply.
The PLC LEDs of the other devolo Magic adapters flash
white only for a short time.
Status 2: The connection to the other network nodes
has been interrupted. There may be electromagnetic or
radio frequency interference on the power line. In this
case, put the devolo Magic adapters closer to each
other or try to shut off the source of interference.
Can be disabled
4Redand
white LED
Flashes at intervals
of 0.1 sec. red/2
sec. white
Data transmission rate not in optimum range ** Can be disabled
5 White LED Status 1: Flashes
at intervals of
0.5 sec.
Status 2: Flashes
at intervals of
1 sec.
Status 1: This devolo Magic adapter is in pairing mode
and the system is searching for new devolo Magic
adapters.
Status 2: Someone has triggered the "Identify device"
function on the web interface or in the devolo app. This
function identifies the devolo Magic adapter being
sought.
Cannot be dis-abled
LED Flashing behaviour Meaning LED status display (web
interface*)

15 Introduction
devolo Magic 2 LAN
* Information about the web interface can be found in Chapter 4
Configuration.
** Information on improving the transmission rate can be found
in Chapter 5.2 Bandwidth optimization.
***A devolo Magic adapter switches to standby mode after ap-
proximately 10 minutes if no active network device (e.g. comput-
er) is connected to the network interface. In this mode, the
devolo Magic adapter cannot be accessed over the electrical wir-
ing. As soon as the network device (e.g. computer) connected to
the network interface is switched on again, your devolo Magic
adapter can also be accessed over the electrical wiring again.
Check whether the adapter is connected to the mains
supply correctly and whether the pairing operation has
been carried out successfully. For more information about
this, refer to 3.3 Connecting the devolo Magic 2 LAN.
2.3.2 Network connection
You can use the network connection on the devolo Magic adapt-
er to connect it to a PC or television using a standard network ca-
ble.
2.3.3 Integrated electrical socket
Always use the integrated electrical socket on the devolo Magic
adapter when connecting other consumers to the mains supply.
6 White LED Lights up steady The devolo Magic connection does not have any issues
and the devolo Magic adapter is ready to operate.
Can be disabled
7 White LED Flashes at intervals
of 0.1 sec. on /
5sec.off
The devolo Magic adapter is in standby mode.*** Can be disabled
8Redand
white LED
Flashes at intervals
of 0.5 sec. red/
0.5 sec. white
The devolo Magic adapter is carrying out a firmware
update.
Cannot be dis-abled
LED Flashing behaviour Meaning LED status display (web
interface*)

Introduction 16
devolo Magic 2 LAN
In particular, electronic devices with mains adapter can negative-
ly affect PLC performance.
The integrated mains filter in the devolo Magic adapter filters any
such external interference and reduces any impairment of PLC
performance.

17 Initial use
devolo Magic 2 LAN
3Initialuse
This chapter tells you everything you need to know to set up and
use your devolo Magic 2 LAN. We describe how to connect the
adapter and briefly describe the devolo software.
3.1 Package contents
Please ensure that the delivery is complete before beginning with
the installation of your devolo Magic 2 LAN:
쎲Starter Kit:
쑗Two devolo Magic 2 LAN
쑗Two network cables
쑗Hard copy of installation guide
쑗Hard copy security flyer
쑗CE declaration
or
쎲Extension:
쑗devolo Magic 2 LAN
쑗Network cable
쑗Hard copy of installation guide
쑗Hard copy security flyer
쑗CE declaration
devolo AG reserves the right to change the package contents
without prior notice.
3.2 System requirements
쎲Operating systems supported by devolo Cockpit
from:
쑗Windows 7 (32-bit/64-bit),
쑗Ubuntu 13.10 (32-bit/64-bit),
쑗Mac (OS X 10.9)
쎲Network connection
Please note that your computer or other device must have
a network card or network adapter with a network inter-
face.
To set up a devolo Magic network, you need at
least two devolo Magic adapters.

Initial use 18
devolo Magic 2 LAN
3.3 Connecting the devolo Magic 2 LAN
CAUTION! Damage to the device caused by
ambient conditions
Only use device indoors in dry conditions
In the following sections we describe how to connect the
devolo Magic 2 LAN and integrate it into a network. We clarify
the exact procedures based on potential network scenarios.
For the permitted voltage range for operating the device
and the power consumption, refer to the type plate on the
rear of the device. For additional technical information on
our products, refer to the product area at
www.devolo.com.
3.3.1 Starter Kit – Automatic set-up for a new
devolo Magic network
햲Connect one devolo Magic 2 LAN to your Internet access
device's network connection (e.g. your Internet router).
햳Connect the other devolo Magic 2 LAN to the network con-
nection of your computer or another network device using a
network cable.
CAUTION!
Tripping hazard
Lay the network cable in a barrier-free manner and
ensure that the electrical socket and the connected
network devices are easily accessible
햴Plug both devolo Magic adapters into available power sock-
ets within 3 minutes. As soon as the LEDs on both adapters
flash white at regular intervals of 0.5 sec., they are ready to
operate and automatically start the process of establishing
an encrypted connection to each other (see Chapter 2.3.1
Reading the indicator light).
If the LEDs on both devolo Magic adapters light up in
white, then your devolo Magic network has been set up
according to your individual specifications and is pro-
tected from unauthorised access.

19 Initial use
devolo Magic 2 LAN
3.3.2 Addition – Expanding an existing network
by adding another devolo Magic adapter
Before you can use the devolo Magic 2 LAN in your devolo Magic
network, first you have to connect it to your existing
devolo Magic adapters as a network. This is accomplished by
using a shared password.
햲Connect the devolo Magic 2 LAN to the network connection
of your computer or another network device using a network
cable.
햳Plug the devolo Magic 2 LAN into an available power
socket. As soon as the LED flashes white at regular intervals
of 0.5 seconds, the adapter is ready to operate but not yet
integrated into a devolo Magic network (see Chapter 2.3.1
Reading the indicator light).
햴Within 3 minutes, press the PLC/reset button on a
devolo Magic adapter in your existing devolo Magic network
for approximately 1 sec.
If the LEDs light up white on both devolo Magic adapt-
ers, the new adapter has been successfully integrated
into your existing devolo Magic network.
For each pairing operation, only one additional adapter
can be added at a time.
3.3.3 Changing the network password
A network password can also be changed in the following ways:
쎲Using the web interface of the devolo Magic adapter (see
Chapter 4.2.2 PLC)
or
쎲Using devolo Cockpit or the devolo app. For more infor-
mation, refer to the following chapter.
3.4 Installation of devolo software
Installing devolo Cockpit software
devolo Cockpit finds all accessible devolo Magic adapters in your
devolo Magic network, displays information about these devices
and encrypts your devolo Magic network individually. You can
use the software to navigate to the integrated web interface.
Operating systems supported by devolo Cockpit (Version 5.0 or
later) from:
쑗Windows 7 (32-bit/64-bit) or later,
쑗Ubuntu 13.10 (32-bit/64-bit),
쑗Mac (OS X 10.9)
You can find the product manual, software and additional
information on devolo Cockpit online at
www.devolo.com/cockpit.
Downloading the devolo App
The devolo App is devolo's free app also for checking and con-
figuring WiFi, Magic and LAN connections for the devolo Magic

Initial use 20
devolo Magic 2 LAN
adapter (using a smartphone or tablet). The smartphone or tablet
connects to the devolo Magic adapter at home over WiFi.
햲Download the devolo App to your smartphone or tablet
computer from the corresponding store.
햳The devolo App is placed in your smartphone's or tablet's
app list as usual. Tapping on the devolo App icon brings you
to the start menu.
You can find more information about the devolo App on-
line at www.devolo.com/devolo-app.
3.5 Removing the devolo Magic adapter
from a network
To remove a devolo Magic adapter from your network and suc-
cessfully restore its entire configuration to the factory default set-
tings, press the PLC/reset button longer than 10 seconds. Wait
until the LED flashes white and then disconnect the adapter from
the mains supply.
Keep in mind that all settings that have already been
made will be lost!
To integrate the mains supply into another network, proceed as
described in Chapter 3.3.2 Addition – Expanding an existing
network by adding another devolo Magic adapter.
