Wireless network and Internet access in every room
of the house
The new dLAN Wireless extender offers the advantages of both dLAN
and WLAN in a single device. With transfer rates of up to 85 Mbit/s
via dLAN and up to 54 Mbit/s via WLAN, the handy adapter enables
wireless surfing in every room of the house. The combination of the
two network technologies enables the dLAN Wireless extender to
create a complete network within your own four walls with no limits
caused by inaccessible places. Thanks to the 54 Mbit/s wireless
connection, the dLAN Wireless extender can reach even hidden-
away corners where cable networks come up against their physical
limits. And the dLAN Wireless extender uses the power circuit for
transmission where wireless networks previously failed – for example
for data transmission over several floors.
It is possible to change the location to a different floor or corner
of the house in seconds. All you need to do is remove the adapter
and plug it into another socket. Regardless of whether you use a
notebook, desktop PC or game console, access to the network or
internet is child's play. In this way, dLAN Wireless extender
combines two worlds of network technology.
The dLAN Wireless extender can be integrated simply by plugging it
into an existing dLAN network. As a bundle together with a dLAN
Highspeed adapter, it is also available as a practical Starter Kit.
HPCol
HPAct
HPLink
WLAN
dLAN Ethernet
HIGHSPEED 85
HPCol
HPAct
HPLink
WLAN
dLANEthernet
HIGHSPEED85
•Highspeed HomePlug adapter &WLAN access point for
wireless network and Internet access via wireless LAN
•Especially versatile: every socket
can be a WLAN connection
Modem (Ethernet) Notebook (WLAN)
Notebooks (WLAN)
Router (Ethernet)
dLAN Highspeed
Ethernet
dLAN Highspeed
Ethernet
dLAN Wireless
extender
dLAN Wireless
extender

Overview of technical data
Product highlights
•Use as access point: Every socket becomes a WLAN access
point – optimum WLAN coverage throughout the house
•Up to 85 Mbit/s transfer rate via the power circuit, up to
54 Mbit/s via wireless LAN
•200 metre range via the power circuit, 300 metre range
via wireless LAN – wireless network and Internet access
in every room of the house
•Ethernet interface for direct connection of a PC
•Use as client: Data transmission from an access point to
the internal power circuit and thus connection of remote
PCs to the WLAN network
•3 year manufacturer’s warranty
Simple start-up and operation
•Fast connection of the adapter, even for inexperien
ced users
•No new cables, no drilling, no mess, simply plug into
the socket and you're ready to go!
•No more problems with thick walls: now you can really
have wireless LAN in every room and on every floor
of your house
•Free network connection or wireless LAN interface to PC,
notebook, modem or other network equipment
•Run the user-friendly, self-explanatory and multilingual
configuration software to assign a password, and you're
done.
Security features
•dLAN Wireless extender guarantees a high degree of data
security via the power circuit thanks to powerful DESpro
encryption.
•There is also secure WEP, WPA, WPA2 encryption via WLAN
Complete package contents
•dLAN Wireless extender
•Starter Kit also with dLAN Highspeed Ethernet and
Ethernet cable
•Printed instruction manual
•CD-ROM with PDF manual, configuration software for
Windows®XP/Vista32BIT, Mac OS®X and Linux®
•3 year manufacturer’s warranty
The dLAN Wireless extender transmits data using
the existing 230V power circuit as well as via wire-
less LAN. With the dLAN Wireless extender, every
power socket becomes a WLAN connection – even
through thick concrete walls. Ideal if you want to
extend your Internet connection wirelessly, or
expand your home network. Several PCs and note-
books can access the network wirelessly at the
same time using dLAN Wireless extenders (used as
an access point). Similarly, the wireless connection
can be transmitted from one WLAN router using
the dLAN Wireless extender in the power circuit
(used as client bridging).
The exchange of data and surfing on the Internet
are possible with up to 85 Mbit/s via the power
circuit and with up to 54 Mbit/s via wireless LAN.
Ultimate security is provided through DESpro
encryption on the power circuit and WEP, WPA or
WPA2 encryption via WLAN. It couldn't be more
versatile or secure!
Simple installation
WLAN throughout the house
dLAN®Wireless extender
123
dLANEthernet
HIGHSPEED85
DSLETH
Factory
Default 9VDC
MODEM
dLANEthernet
HIGHSPEED85
4
Connect PC, router or Modem
via the WLAN interface or
Ethernet interface
Each socket in your
home becomes a
network interface
dLANEthernet
HIGHSPEED85
dLANEthernet
HIGHSPEED85
Modem-Router
dLAN
Highspeed Ethernet
Connect
Power
DSL
ETH
USB
dsl+1100duo
dLAN
Highspeed
Ethernet
dLAN Wireless
extender
devolo AG Deutschland
Sonnenweg 11, 52070 Aachen
Tel. : [phone]
Fax : [phone]
E-Mail: [email protected]
Web: www.devolo.com
Connection of dLAN and WLAN
