DeVorm Big Modular Table System User manual

p. 1
Big Modular Table System
Installation Guide

p. 2
Mounting materials
Tools
Center
grooved pin
Bolt plate 2xM8
Tabletop
connector
Self-tapping
screw M3x10
Butt connector
Adjustable foot
Bolt M8x16
Domino
Screw M5x16
Allen key
BZK6
Allen key
BZK5
Screwdriver
PZ2

p. 3
Frame parts
Leg options
Frame profile
1200mm
Frame cover 46
460mm
Crossbar
230mm
Aluminium legs
Big 74 - Big 95 - Big 110
Steel legs
Big 74 - Big 95 - Big 110
Wooden legs
Big 74
Frame profile
1800mm
Frame cover 68
680mm
Crossbar
450mm
Frame profile
2400mm
Frame cover 98
980mm
Crossbar
750mm
The size and amount of frame parts depends on the chosen table size.
Legs are delivered according to the chosen type and height of the table.

p. 4
Preparation
Assembling table frame
Connect frame profiles
2
Place one center-grooved
pin in the opposing slots of
the frame profiles
Stirdly press the frame
profiles together.
Make sure the surface you are working on is flat and use protective
blanket on the floor to prevent damage.
1

p. 5
Place the two butt
connectors in the
corresponding cavities
Use the allen key to tighten
the butt connectors
and secure the frame
connection
Make sure that the
connecting lines on the
opposing sides of the
frame are not aligned.

p. 6
Insert crossbars
3
The crossbars should be
equally spaced between the
two frame profiles
When the table has more
than 4 legs, please,
consider the crossbar
layout carefully. The
crossbar utilizes the same
slots as the table legs

p. 7
Tighten crossbars
4
Tighten the bolts in the
crossbar to secure them to
the frame
Make sure the frame ends
are perfectly aligned with
each other
x

p. 8
Assembling table legs
Connect the outer legs to the frame
5
The table legs on the edges
need to be mounted with 2
bolt plates.
Fasten the legs to the frame
using the bolts and the
allen key.

p. 9
Connect the middle legs to the frame
Only applicable to tables with 6 or 8 legs
6
Push in the sliding nut
(spring side first)
and rotate it 90º inside
the slot
The table legs in the
middle of the frame are
mounted with 4 sliding
nuts

p. 10
Please, take into account
that adjustable feet are
intended for levelling the
tabletop and not for height
adjustment.
Screw the feet in properly
to make sure the table is
stable.
Attach adjustable feet
7
x
Place the frame on its legs
8

p. 11
Mount frame covers
9
Use the self-tapping screws
to mount the frame cover
on both sides of the frame

p. 12
Connecting tabletops
Place the domino’s in one part of the tabletop and connect it with
another part
10

p. 13
Insert table connectors underneath the tabletop
11
Make sure the tabletop
parts align perfectly before
tightening the tabletop
connectors
Please, double check the
tabletop alignment before
proceeding to the
next step
x
Align the tabletop parts
12

p. 14
Tighten the tabletop
connectors when both
tabletops are perfectly
aligned
Tighten the tabletop connectors
13
Attach the tabletop to the frame
14 Fasten the tabletop to the
frame with the tabletop
screws M5X16

p. 15
You are all set!
15
