DeWalt D25614 User manual

D25614

B
Copyright DeWALT
English (original instructions) 3

1
Fig. A
Fig. B Fig. C
2
13
14
56
3
2
6
5
1
7
4
11 810
9
XXXX XX XX
12

2
4
13
Fig. D

ENGLISH
3
EC-Declaration of Conformity
Machinery Directive
Heavy-Duty Rotary Hammerdrill
D25614
DeWALT declares that these products described under Technical
Data are in compliance with:
2006/42/EC, EN62841-1:2015+AC:2015 +A11:2022, EN62841-2-
6:2020 +A11:2020.
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact DeWALT at
the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf ofDeWALT.
Markus Rompel
Vice-President Engineering, PTE-Europe
DeWALT, Richard-Klinger-Straße 11,
65510, Idstein, Germany
30.12.2022
DECLARATION OF CONFORMITY
THE SUPPLY OF MACHINERY SAFETY
REGULATIONS 2008
Heavy-Duty Rotary Hammerdrill
D25614
DeWALT declares that these products described under“technical
data”are in compliancewith:
The Supply of Machinery (Safety) Regulations, 2008, S.I.
2008/1597 (as amended),
EN62841-1:2015+AC:2015 +A11:2022, EN62841-2-6:2020
+A11:2020.
These products also conform to the following UK Regulations:
Electromagnetic Compatibility Regulations, 2016, S.I.2016/1091
(as amended).
The Restriction of the Use of Certain Hazardous Substances
in Electrical and Electronic Equipment Regulations 2012, S.I.
2012/3032 (as amended).
English (original instructions)
Congratulations!
You have chosen a DeWALT tool. Years of experience, thorough
product development and innovation make DeWALT one of the
most reliable partners for professional power toolusers.
Technical Data
HEAVYDUTY ROTARY HAMMERDRILL
D25614
D25614
Voltage VAC 230
(U.K. & Ireland only) VAC 230/115
Type 1
No-load speed min-1 190–380
No-load beats per minute bpm 1450–2900
Power input W1350
Single impact energy (EPTA 05/2009) J10.5
Optimum drilling range into concrete mm 16–32
Maximum drilling range in concrete mm 45
Maximum core drilling range in concrete mm 125
Tool holdler SDSMAX
Weight kg 7.8
Noise values and/or vibration values (triax vector sum) according to
EN62841-2-6:
LPA (emission sound pressure level) dB(A) 98
LWA (sound power level) dB(A) 106
K (uncertainty for the given sound level) dB(A) 3
Drilling
Vibration emission value a
h, HD
= m/s² 10.7*
Uncertainty K = m/s² 1.5
Chiselling
Vibration emission value a
h
,
Cheq
= m/s² 9.2*
Uncertainty K = m/s² 1.5
*Measured at the side handle. Side handle vibration is higher than vibration at
the mainhandle.
The vibration and/or noise emission level given in this information
sheet has been measured in accordance with a standardised test
given in
EN IEC
62841 and may be used to compare one tool with
another. It may be used for a preliminary assessment ofexposure.
WARNING: The declared vibration and/or noise
emission
level represents the main applications of the tool. However,
if the tool is used for different applications, with different
accessories or is poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase the
exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/or
noise should also take into account the times when the tool is
switched off or when it is running but not actually doing the
job. This may significantly reduce the exposure level over the
total workingperiod.
Identify additional safety measures to protect the operator
from the effects of vibration and/or noise such as: maintain
the tool and the accessories, keep the hands warm (relevant
for vibration), organisation of workpatterns.

4
ENGLISH
GENERAL POWER TOOL SAFETY WARNINGS
WARNING: Read all safety warnings, instructions,
illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below
may result in electric shock, fire and/or seriousinjury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTUREREFERENCE
The term “power tool” in the warnings refers to your
mains‑operated (corded) power tool or battery‑operated (cordless)
powertool.
Work Area Safety
a ) Keep work area clean and well lit. Cluttered or dark
areas inviteaccidents.
b ) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
WARNING: To reduce the risk of injury, read the
instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result in
propertydamage.
Denotes risk of electricshock.
Denotes risk offire.
For more information, please contact DeWALT at the following
address or refer to the back of the manual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf of DeWALT.
Karl Evans
Vice President Professional Power Tools EANZ GTS
DeWALT UK,
270 Bath Road, Slough
Berkshire SL1 4DX
England
30.12.2022
liquids, gases or dust. Power tools create sparks which
may ignite the dust orfumes.
c ) Keep children and bystanders away while operating
a power tool. Distractions can cause you to losecontrol.
Electrical Safety
a ) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of
electricshock.
b ) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if
your body is earthed orgrounded.
c ) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electricshock.
d ) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electricshock.
e ) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electricshock.
f ) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electricshock.
Personal Safety
a ) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personalinjury.
b ) Use personal protective equipment. Always wear eye
protection. Protective equipment such as a dust mask,
non‑skid safety shoes, hard hat or hearing protection used
for appropriate conditions will reduce personalinjuries.
c ) Prevent unintentional starting. Ensure the switch
is in the off position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on
invitesaccidents.
d ) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached
to a rotating part of the power tool may result in
personalinjury.
e ) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpectedsituations.
f ) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can be
caught in movingparts.

5
ENGLISH
Hammer Safety Warnings
• Wear ear protectors. Exposure to noise can cause
hearingloss.
• Use auxiliary handle(s) if supplied with the tool. Loss of
control can cause personalinjury.
• Hold the power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring or its own cord.
g ) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can
reduce dust‑relatedhazards.
h ) Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause severe
injury within a fraction of asecond.
Power Tool Use and Care
a ) Do not force the power tool. Use the correct power
tool for your application. The correct power tool
will do the job better and safer at the rate for which it
wasdesigned.
b ) Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must berepaired.
c ) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the
power toolaccidentally.
d ) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrainedusers.
e ) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by
poorly maintained powertools.
f ) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier tocontrol.
g ) Use the power tool, accessories and tool bits, etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardoussituation.
h ) Keep handles and grasping surfaces dry, clean and
free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the
tool in unexpectedsituations.
Service
a ) Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool ismaintained.
Cutting accessory contacting a "live" wire may make exposed
metal parts of the power tool "live" and could give the operator
an electricshock.
Safety Instructions When Using Long
DrillBits with Rotary Hammers
• Always start drilling at low speed and with the bit tip
in contact with the workpiece. At higher speeds, the bit is
likely to bend if allowed to rotate freely without contacting the
workpiece, resulting in personalinjury.
• Apply pressure only in direct line with the bit and do not
apply excessive pressure. Bits can bend causing breakage or
loss of control, resulting in personalinjury.
Additional Safety Instructions for
RotaryHammer Drills
• Use clamps or other practical way to secure and support
the workpiece to a stable platform. Holding the work by
hand or against your body is unstable and may lead to loss
ofcontrol.
• Wear safety goggles or other eye protection. Hammering
operations cause chips to fly. Flying particles can cause
permanent eye damage. Wear a dust mask or respirator
for applications that generate dust. Ear protection may be
required for mostapplications.
• Keep a firm grip on the tool at all times. Do not attempt
to operate this tool without holding it with both hands. It
is recommended that the side handle be used at all times.
Operating this tool with one hand will result in loss of control.
Breaking through or encountering hard materials such as
re‑bar may be hazardous as well. Tighten the side handle
securely beforeuse.
• Do not operate this tool for long periods of time.
Vibration caused by hammer action may be harmful to your
hands and arms. Use gloves to provide extra cushion and limit
exposure by taking frequent restperiods.
• Do not recondition bits yourself. It should be done by an
authorized specialist. Improperly reconditioned bits could
causeinjury.
• Wear gloves when operating tool or changing bits.
Accessible metal parts on the tool and bits may get extremely
hot during operation. Small bits of broken material may
damage barehands.
• Never lay the tool down until the bit has come to a
complete stop. Moving bits could causeinjury.
• Do not strike jammed bits with a hammer to dislodge
them. Fragments of metal or material chips could dislodge
and causeinjury.
• Keep the power cord away from the rotating bit. Do not
wrap the cord around any part of your body. An electric cord
wrapped around a spinning bit may cause personal injury and
loss ofcontrol.
• When working above the floor, make sure that the area
below is clear. Falling parts can cause injuries to bystanders.

6
ENGLISH
Description (Fig. A)
WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1 Trigger switch
2 Front Barrel (Collar)
3 Mode selector switch
4 Main handle
5 Bit holder
6 Locking sleeve
7 Lock-on switch
8 Electronic speed and
impact control dial
9 Red anti-rotation system
indicator LED
10 Yellow brushwear indicator
LED
11 DeWALT tool tag mounting
holes
12 Date code
Intended Use
Your heavy-duty rotary hammerdrill is designed for professional
masonry drilling and chisellingapplications.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
Your heavy-duty rotary hammerdrill is a professional powertool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
Soft Start Feature
The soft start feature allows the tool to accelerate slowly, thus
preventing the drill bit from walking off the intended hole
position whenstarting.
The soft start feature also reduces the immediate torque
reaction transmitted to the gearing and the operator if the
hammer is started with the drill bit in an existinghole.
Date Code Position (Fig.A)
The production date code 12 consists of a 4-digit year followed
by a 2-digit week and is extended by a 2-digit factory code.
Package Contents
The package contains:
1 Rotary hammerdrill
1 Side handle
1 Instruction manual
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Electrical Safety
The electric motor has been designed for one voltage only.
Always check that the power supply corresponds to the voltage
on the ratingplate.
iYour DeWALT tool is double insulated in accordance
with EN62841; therefore no earth wire isrequired.
If the supply cord is damaged, it must be replaced only by
DeWALT or an authorised service organisation.
Mains Plug Replacement
(U.K.& Ireland Only)
If a new mains plug needs to be fitted:
• Safely dispose of the oldplug.
• Connect the brown lead t o the live terminal in theplug.
• Connect the blue lead to the neutralterminal.
WARNING: No connection is to be made to the
earthterminal.
Follow the fitting instructions supplied with good quality plugs.
Recommended fuse: 13A.
Using an Extension Cable
If an extension cable is required, use an approved 3–core
extension cable suitable for the power input of this tool (see
Technical Data).The minimum conductor size is 1.5 mm2; the
maximum length is 30m.
When using a cable reel, always unwind the cablecompletely.
WARNING: We recommend the use of a residual current
device with a residual current rating of 30mA or less.
Residual Risks
The following risks are inherent to the use of rotary hammers:
• Injuries caused by touching the rotating parts or hot parts of thetool.
In spite of the application of the relevant safety regulations
and the implementation of safety devices, certain residual risks
cannot be avoided. These are:
• Impairment ofhearing.
• Risk of squeezing fingers when changing theaccessory.
• Health hazards caused by breathing dust developed when
working in concrete and/ormasonry.
• Risk of personal injury due to flyingparticles.
• Risk of burns due to accessories becoming hot
duringoperation.
• Risk of personal injury due to prolongeduse.
SAVE THESE INSTRUCTIONS
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual before use.
Wear ear protection.
Wear eye protection.

7
ENGLISH
Side Handle (Fig.A, B)
WARNING: To reduce the risk of personal injury, ALWAYS
operate the tool with the side handle properly installed.
Failure to do so may result in the side handle slipping
during tool operation and subsequent loss of control. Hold
tool with both hands to maximizecontrol.
The side handle13 clamps to the front of the gear case and
may be rotated 360˚ to permit right- or left-hand use.
Mounting the Straight Side Handle (Fig.B)
1. Widen the ring opening of the side handle 13 by rotating
itcounterclockwise.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
Active Vibration Control (AVC) System
For best vibration control, hold the tool as described in Proper
Hand Position and apply just enough pressure so the damping
device on the main handle is approximately midstroke.
The active vibration control neutralises rebound vibration from
the hammer mechanism. Lowering hand and arm vibration,
it allows more comfortable use for longer periods of time and
extends the life of theunit.
The hammer only needs enough pressure to engage the active
vibraton control. Applying too much pressure will not make
the tool drill or chip faster and active vibration control will
notengage.
DeWALT Tool Tag Ready (Fig. A)
Optional Accessory
Your hammer comes with mounting holes 11 and fasteners
for installing a DeWALT Tool Tag. You will need a T15 bit tip to
install the tag. The DeWALT Tool Tag is designed for tracking and
locating professional power tools, equipment, and machines
using the DeWALT Tool Connect™ app. For proper installation of
the DeWALT Tool Tag refer to the DeWALT Tool Tagmanual.
Lock-On Switch (Fig. A)
Chipping mode only
The lock-on switch 7 offers increased comfort in extended use
applications. To lock the tool on, depress the lock-on switch
while the tool is running. The tool will continue to run after the
switch is released. To unlock and turn off the tool, depress and
release theswitch.
Electronic Speed and Impact Control (Fig.A)
The electronic speed and impact control allows the use of
smaller drill bits without the risk of bit breakage, hammerdrilling
into light and brittle materials without shattering and optimal
tool control for precisechiselling.
To set the electronic speed and impact control dial 8, turn the
dial to the desired level. The higher the number, the greater
the speed and impact energy. Dial settings make the tool
extremely flexible and adaptable for many different applications.
The required setting depends on the bit size and hardness of
material beingdrilled.
• When chiselling or drilling in soft, brittle materials or when
minimum break-out is required, set the dial to a low setting;
• When breaking or drilling in harder materials, set the dial to
a highsetting.
Overload Clutch
In case of jamming of a drill bit, the drive to the drill spindle is
interrupted. Because of the resulting forces, always hold the
tool with both hands and take a firmstance. After the overload,
release and depress the trigger to re-engagedrive.
Mechanical Clutch
These tools are fitted with a mechanical clutch. The indication
that the clutch has activated will be an audible ratcheting
together with increasedvibration.
Anti-Rotation System
In addition to the clutch, an anti-rotation system offers increased
user comfort through an on-board, anti-rotation technology
capable of detecting if the user loses control of the hammer.
When a jam is detected, the torque and speed are stopped
instantly. This feature prevents self rotation of the tool.
The anti-rotation system indicator 9 will illuminate to
indicatestatus.
Anti-Rotation System and Service Indicator LED
(Fig. A)
Your rotary hammerdrill has two LEDs, indicating the
Anti-rotation system and a service indicator. Refer to the table
for more information on LEDfunctionality.
LED Function Description
Red
(flashing)
Lock-on/Service
The red anti-rotation system
indicator LED 9 flashes if the
lock-on switch 7 is used in
any mode except the chipping
mode or if there is a fault with
the tool or the brushes have
completely wornout.
Red
(permanently on)
Anti-rotation system
Anti-rotation system isengaged.
Yellow
(permanently on)
Brush Service
The yellow brushwear indicator
LED 10 lights up when the
carbon brushes are nearly worn
out, indicating that the tool
needs servicing within the next
8 hours ofuse.

8
ENGLISH
Proper Hand Position (Fig.D)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the side handle13,
with the other hand on the main handle4.
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions and
applicableregulations.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
SDS plus® and SDS max® are registered trademarks of
RobertBoschGmbH.
Bit and Bit Holder
WARNING: Burn Hazard. ALWAYS wear gloves when
changing bits. Accessible metal parts on the tool and bits
may get extremely hot during operation. Small bits of
broken material may damage barehands.
The rotary hammer can be fitted with various drill and chisel
bits. depending on the desired application. Use sharp drill and
chisel bitsonly.
Inserting and Removing SDSmax®Accessories
(Fig.C)
This machine uses SDSmax®bits and chisels (refer to the inset
in FigureD for a cross-section of an SDSmax®bitshank).
1. Clean the bitshank.
2. Pull back the locking sleeve6 and insert the bitshank.
3. Release the locking sleeve and turn the bit slightly until the
sleeve snaps intoposition.
4. Pull on the bit to check if it is properly locked. The
hammering function requires the bit to be able to move
axially several centimetres when locked in the bitholder.
5. To remove a bit pull back the bit holder locking sleeve/
collar6 and pull the bit out of the bit holder5.
2. Slide the assembly onto the nose of the tool, through the
steel ring 14 and onto the collar 2, past the chisel holder
andsleeve.
3. Rotate the side handle assembly to the desired position. For
hammerdrilling horizontally with a heavy drill bit, place the
side handle assembly at an angle of approximately 20° to
the tool for optimumcontrol.
4. Lock the side handle mounting assembly in place by
securely tightening the handle 13 rotating it clockwise so
that the assembly will notrotate.
Operation Modes (Fig.A)
WARNING: Do not select the operating mode when the
tool isrunning.
CAUTION: Never use in Rotary Drilling or Rotary
Hammering mode with a chisel bit in the bit holder.
Personal injury and damage to the the tool mayresult.
Your tool is equipped with a mode selector dial3 to selectthe
mode appropriate to desiredoperation.
Symbol Mode Application
Rotary
Hammering
Drilling into concrete
andmasonry
Hammering only Lightchipping
Bit Adjustment Chisel bit position adjustment
To Select an Operating Mode
• Rotate the mode selector switch so that the arrow points to
the symbol corresponding for the desiredmode.
NOTE: The arrow on the mode selector switch3 must be
pointing at a mode symbol at all times. There are no operable
positions inbetween. It may be necessary to briefly run the
motor after having changed from 'hammering only' to 'rotary'
modes in order to align thegears.
Indexing the Chisel Position (Fig.A)
The chisel can be indexed and locked into 18differentpositions.
1. Rotate the mode selector switch3 until it points towards
the position.
2. Rotate the chisel to the desiredposition.
3. Set the mode selector switch3 to the“hammering
only”position.
4. Twist the chisel until it locks inposition.
Performing an Application (Fig.A)
WARNING: TO REDUCE THE RISK OF PERSONAL
INJURY, ALWAYS ensure workpiece is anchored or
clamped firmly. If drilling thin material, use a wood
“backup” block to prevent damage to thematerial.
Switching On and Off (Fig.A)
To turn the tool on, depress the trigger switch1.
To stop the tool, release the triggerswitch.
Drilling with a Solid Bit (Fig.A)
1. Insert the appropriate drillbit.
2. Set the mode selector switch3 to the
hammerdrillingposition.
3. Set the electronic speed and impact control dial8.
4. Fit and adjust the side handle13.
5. Mark the spot where the hole is to bedrilled.
6. Place the drill bit on the spot and switch on thetool.
7. Always switch off the tool when work is finished and
beforeunplugging.

9
ENGLISH
Protecting the Environment
wSeparate collection. Products marked with this symbol
must not be disposed of with normal householdwaste.
Products contain materials that can be recovered or
recycled, reducing the demand for raw materials. Please
recycle electrical products according to local provisions. Further
information is available at
www.2helpU.com.
Optional Accessories
WARNING: Since accessories, other than those offered
by DeWALT, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only DeWALT recommended
accessories should be used with thisproduct.
Various types of SDSmax® drill bits and chisels are available as
anoption. Accessories and attachments used must be regularly
lubricated around the SDSmax®fitment.
Consult your dealer for further information on the
appropriateaccessories.
D
Cleaning
WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.
WARNING: Never use solvents or other harsh chemicals
for cleaning the non‑metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
C
Lubrication
Your power tool requires no additionallubrication.
MAINTENANCE
Your power tool has been designed to operate over a long
period of time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and
regularcleaning.
Drilling with a Core Bit (Fig.A, B)
1. Insert the appropriate corebit.
2. Assemble the centerdrill into the corebit.
3. Set the mode selector switch3 to the rotary
hammerdrillingposition.
4. Turn the electronic speed and impact control dial8 to a
medium or high speedsetting.
5. Fit and adjust the side handle13.
6. Place the centerdrill on the spot and switch on the tool. Drill
until the core penetrates into the concrete approximately
1cm.
7. Stop the tool and remove the centerdrill. Place the core bit
back into the hole and continuedrilling.
8. When drilling through a structure thicker than the depth of
the core bit, break away the round cylinder of concrete or
core inside the bit at regularintervals.
To avoid unwanted breaking away of concrete around
the hole, first drill a hole the diameter of the centerdrill
completely through the structure. Then drill the cored hole
halfway from eachside.
9. Always turn the tool off when work is finished and
beforeunplugging.
Chipping and Chiselling (Fig.A, B)
1. Insert the appropriate chisel and rotate it by hand to
lock it into one of 24positions. Refer to Indexing the
ChiselPosition.
2. Set the mode selector switch3 to the 'hammering
only'position.
3. Set the electronic speed and impact control dial8.
4. Fit and adjust the side handle13.
5. Turn the tool on and startworking.
6. Always turn the tool off when work is finished and
beforeunplugging.
Recommendations for Tool Operation
• When drilling, always apply pressure in a straight line with
the bit, but do not push hard enough to stall the motor or
deflect thebit. A smooth even flow of material indicates the
proper drillingrate.
• If drilling thin material or material that is prone to splinter,
use a wood“back-up”block to prevent damage to
theworkpiece.
WARNING:
• Do not use this tool to mix or pump easily combustible
or explosive fluids (benzine, alcohol,etc.).
• Do not mix or stir inflammable liquids
labelledaccordingly.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.

NA216027 01/23
Belgique et
Luxembourg België en Luxemburg
DeWALT - Belgium BVBA
EgideWalschaertsstraat 16
2800Mechelen
Tel: NL 3215473763
Tel: FR 3215473764
Fax: 3215473799
www.dewalt.be
enduser[email protected]
Danmark DeWALT (Stanley Black&Decker AS)
Roskildevej 22
2620Albertslund
Tel: 70201510
Fax: 70224910
www.dewalt.dk
Deutschland DeWALT
Richard-Klinger-Str. 11
65510Idstein
Tel: 06126-21-0
Fax: 06126-21-2770
www.dewalt.de
Ελλά DeWALT (Ελλάς) Α.Ε.
EΔΡΑ-ΓΡΑΦΕΙΑ : Στράβωνος 7
& Λ. Βουλιαγμένης, Γλυφάδα 16674, Αθήνα
SERVICE : ΗμεροςΤόπος 2(Χάνι Αδάμ) – 19300Ασπρόπυργος
Τηλ: 00302108981616
Φαξ: 00302108983570
www.dewalt.gr
España DeWALT Ibérica, S.C.A.
Parc de Negocios“Mas Blau”
Edificio Muntadas, c/Bergadá, 1, Of. A6
08820El Prat de Llobregat (Barcelona)
Tel: 934797400
Fax: 934797419
www.dewalt.es
France DeWALT (Stanley Black & Decker France SAS)
62Chemin de la Bruyère
69570Dardilly, France
Tel: 0472203920
Fax: 0472203900
www.dewalt.fr
Schweiz
Suisse
Svizzera
DeWALT
In der Luberzen 42
8902Urdorf
Tel: 044- 7556070
Fax: 044- 7307067
www.dewalt.ch
Ireland DeWALT
Building 4500, Kinsale Road
Cork Airport Business Park
Cork, Ireland
Tel: 00353-2781800
Fax: 012781811
www.dewalt.ie
Italia DeWALT
via Energypark 6
20871Vimercate (MB), IT
Tel: 800-014353
39039-9590200
Fax: 39039-9590311
www.dewalt.it
Nederlands DeWALT
Netherlands BVPostbus 83,
6120AB BORN
Tel: 31164283063
Fax: 31164283200
www.dewalt.nl
Norge DeWALT
Postboks 4613
0405Oslo, Norge
Tel: 45251300
Fax: 45250800
www.dewalt.no
Österreich DeWALT
WerkzeugVertriebsges m.b.H
Oberlaaerstrasse 248, A-1230Wien
Tel: 01- 66116- 0
Fax: 01- 66116- 614
www.dewalt.at
Portugal DeWALT
Ed. D Dinis, Quina da Fonte
Rua dos Malhoes 2 2A 2ºEsq.
Oeiras e S. Juliao da Barra, paço de Arcos e Caxias
2770071Paço de Arcos
Tel: +351 214667500
Fax: +351214667580
www.dewalt.pt
Suomi DeWALT
PL47
00521Helsinki, Suomi
Puh: 0104004333
Faksi: 0800411340
www.dewalt.fi
Sverige DeWALT
BOX 94
43122Mölndal
Sverige
Tel: 031686160
Fax: 031686008
www.dewalt.se
Türkiye Sanayi veTicareet Bakanlığı tebliğince kullanim ömrü 7yıldır.
Stanley Black & DeckerTurkey Alet Üretim San.Tic. Ltd.Şti.
AND Kozyataği - İçerenköy Mah. Umut Sok. AND Ofis Sit. No: 10-12 / 82-83-84
Ataşehir/İstanbul,Türkiye
Tel: +90 2166652900
Faks: +90 2166652901
www.dewalt.com.tr
United Kingdom DeWALT, 270Bath Road;
Slough, Berks SL1 4DX
Tel: 01753-567055
Fax: 01753-572112
www.dewalt.co.uk
Australia / New Zealand DeWALT
810Whitehorse Road Box Hill
VIC 3128Australia
Tel: Aust 1800654155
Tel: NZ 0800339258
www.dewalt.com.au
www.dewalt.co.nz
Middle East Africa DeWALT
P.O. Box - 17164,
Jebel Ali Free Zone (South), Dubai, UAE
Tel: 97148127400
Fax: 97142822765
www.dewalt.ae
Other manuals for D25614
5
Table of contents
Other DeWalt Drill manuals

DeWalt
DeWalt XR DCD701 User manual

DeWalt
DeWalt 384292-00 User manual

DeWalt
DeWalt DW006 User manual

DeWalt
DeWalt XR Li-Ion DCD732 User manual

DeWalt
DeWalt DW152 User manual

DeWalt
DeWalt DW116 User manual

DeWalt
DeWalt DCD785 User manual

DeWalt
DeWalt D0727 User manual

DeWalt
DeWalt DW511 User manual

DeWalt
DeWalt XR DCH072N-XJ User manual

DeWalt
DeWalt DWD522 User manual

DeWalt
DeWalt XR DCH172 User manual

DeWalt
DeWalt DC988 Heavy Duty XRP User manual

DeWalt
DeWalt DW133 User manual

DeWalt
DeWalt DC980 Heavy Duty XRP User manual

DeWalt
DeWalt DW217 User manual

DeWalt
DeWalt D25303K User manual

DeWalt
DeWalt D21583 User manual

DeWalt
DeWalt DCD796NT User manual

DeWalt
DeWalt DCD791 User manual
