DeWalt DCR029 User manual

DCR029
Final page size: A5 (148mm x 210mm)

B
Copyright
DeWALT
English (original instructions) 2

1
Fig. A
Fig. B
7
3
1
17
18
18
17
19
13
6
12
8
4
11
20
14
2
5
5
9
16
15
10
XXXX XX XX
21

2
ENGLISH
Chargers
DeWALT
chargers require no adjustment and are designed to be
as easy as possible tooperate.
Electrical Safety
Always check that the battery pack voltage corresponds to the
voltage on the rating plate. Also make sure that the voltage of
your charger corresponds to that of yourmains.
Safety Instructions for Radios
• Do not abuse cord. Never carry the radio by its cord. Never
pull the cord to disconnect from the socket. Keep the cord
away from heat, oil and sharpedges.
• Remove the battery pack. Switch off before leaving it
unattended. Remove the battery pack when not in use, before
changing accessories or attachments and beforeservicing.
• This appliance is intended to be used in moderateclimates.
• This appliance is not intended for use by persons(including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for theirsafety.
• Socket and extension cord must have an operative
protectiveconductor.
• When operating the radio in damp environments is
unavoidable, use a residual current device (RCD). The
use of a residual current device (RCD) reduces the risk of
electricshock.
• Children should be supervised to ensure that they do not play
with theappliance.
• Radio shall not be exposed to dripping or splashing; no objects
filled with liquids, such as vases, shall be placed onit.
• No exposed flame sources, such as lighted candles, should be
placed on theradio.
• Mains plug is used as the disconnect device; the disconnect
device (plug) shall remain readilyoperable.
• Do not operate the apparatus with a damaged cord orplug.
SAVE THESE INSTRUCTIONS
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result in
propertydamage.
Denotes risk of electricshock.
Denotes risk offire.
Congratulations!
You have chosen a
DeWALT
tool. Years of experience, thorough
product development and innovation make
DeWALT
one of the
most reliable partners for professional power toolusers.
Technical Data
DCR029
Type 1
Input (AC adapter output) VDC 24
Battery type Li-Ion
Input (Battery) VDC 12/18
Weight (without battery pack) kg 3.53
Max. operating temperature °C 40
AC Adapter
Input voltage VAC 220–240
Input AC frequency Hz 50–60
Output voltage VDC 24
Output current A1.875
Output power W45
Average active efficiency %88.5
Efficiency at low load (10%) %84.3
No-load power consumption W< 0.1
EU-Declaration of Conformity
Radio Equipment Directive
Radio
DCR029
DeWALT
hereby declares that the
DeWALT
Radio DCR029 is in
compliance with the Directive 2014/53/EU and to all applicable
EU directiverequirements.
The full text of the EU declaration of conformity can be
requested at
DeWALT
, Richard- Klinger-Straße 11, D-65510,
Idstein, Germany or is available at the following internet address:
www.2helpu.com Search by the Product and Type Number
indicated on thenameplate.
WARNING: To reduce the risk of injury, read the
instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.
English (original instructions)
RADIO
DCR029

3
ENGLISH
Your
DeWALT
charger is double insulated in
accordance with EN60335; therefore no earth wire
isrequired.
If the supply cord is damaged, it must be replaced by a
specially prepared cord available through the
DeWALT
serviceorganisation.
Mains Plug Replacement
(U.K. & Ireland Only)
If a new mains plug needs to be fitted:
• Safely dispose of the oldplug.
• Connect the brown lead to the live terminal in theplug.
• Connect the blue lead to the neutralterminal.
WARNING: No connection is to be made to the
earthterminal.
Follow the fitting instructions supplied with good quality plugs.
Recommended fuse: 3A.
Using an Extension Cable
An extension cord should not be used unless absolutely
necessary. Use an approved extension cable suitable for
the power input of your charger (see Technical Data). The
minimum conductor size is 1mm2; the maximum length
is30m.
When using a cable reel, always unwind the cablecompletely.
Important Safety Instructions for All Battery
Chargers
SAVE THESE INSTRUCTIONS: This manual contains important
safety and operating instructions for compatible battery
chargers (refer to TechnicalData).
• Before using charger, read all instructions and cautionary
markings on charger, battery pack, and product using
batterypack.
WARNING: Shock hazard. Do not allow any liquid to get
inside charger. Electric shock mayresult.
WARNING: We recommend the use of a residual current
device with a residual current rating of 30mA orless.
CAUTION: Burn hazard. To reduce the risk of injury,
charge only
DeWALT
rechargeable batteries. Other types of
batteries may burst causing personal injury anddamage.
CAUTION: Children should be supervised to ensure that
they do not play with theappliance.
NOTICE: Under certain conditions, with the charger
plugged into the power supply, the exposed charging
contacts inside the charger can be shorted by foreign
material. Foreign materials of a conductive nature such
as, but not limited to, steel wool, aluminum foil or any
buildup of metallic particles should be kept away from
charger cavities. Always unplug the charger from the
power supply when there is no battery pack in the cavity.
Unplug charger before attempting to clean
• DO NOT attempt to charge the battery pack with any
chargers other than the ones in this manual. The charger
and battery pack are specifically designed to worktogether.
• These chargers are not intended for any uses other than
charging
DeWALT
rechargeable batteries. Any other uses
may result in risk of fire, electric shock orelectrocution.
• Do not expose charger to rain orsnow.
• Pull by plug rather than cord when disconnecting
charger. This will reduce risk ofdamage to electric plug
andcord.
• Make sure that cord is located so that it will not be
stepped on, tripped over, or otherwise subjected to
damage orstress.
• Do not use an extension cord unless it is absolutely
necessary. Use of improper extension cord could result in risk
of fire,electric shock, orelectrocution.
Batteries Chargers/Charge Times (Minutes)
Cat # VDC Ah Weight (kg) DCB104 DCB107 DCB112 DCB113 DCB115 DCB118 DCB132 DCB119
DCB546 18/54 6.0/2.0 1.05 60 270 170 140 90 60 90 X
DCB547 18/54 9.0/3.0 1.46 75* 420 270 220 135* 75* 135* X
DCB548 18/54 12.0/4.0 1.44 120 540 350 300 180 120 180 X
DCB181 18 1.5 0.35 22 70 45 35 22 22 22 45
DCB182 18 4.0 0.61 60/40** 185 120 100 60 60/40** 60 120
DCB183/B 18 2.0 0.40 30 90 60 50 30 30 30 60
DCB184/B 18 5.0 0.62 75/50** 240 150 120 75 75/50** 75 150
DCB185 18 1.3 0.35 22 60 40 30 22 22 22 X
DCB187 18 3.0 0.54 45 140 90 70 45 45 45 90
DCB189 18 4.0 0.54 60 185 120 100 60 60 60 120
DCB122 12 2.0 0.22 30 90 60 50 30 X30 60
DCB124 12 3.0 0.25 45 140 90 70 45 45 45 90
DCB125 12 1.3 0.20 22 60 40 30 22 X22 40
DCB127 12 2.0 0.20 30 90 60 50 30 X30 60
*Date code 201811475B or later
**Date code 201536 or later
Batteries
Chargers/Charge Times (Minutes)
Cat #
DC
Weight
*Date code 201811475B or later
**Date code 201536 or later

4
ENGLISH
• Do not place any object on top of charger or place
the charger on a soft surface that might block the
ventilation slots and result in excessive internal heat.
Place the charger in a position away from any heat source. The
charger is ventilated through slots in the top and the bottom
of thehousing.
• Do not operate charger with damaged cord or plug—
have them replacedimmediately.
• Do not operate charger if it has received a sharp blow,
been dropped, or otherwise damaged in any way. Take it
to an authorised servicecentre.
• Do not disassemble charger; take it to an authorised
service centre when service or repair is required. Incorrect
reassembly may result in a risk of electric shock, electrocution
orfire.
• In case of damaged power supply cord the supply cord must
be replaced immediately by the manufacturer, its service agent
or similar qualified person to prevent anyhazard.
• Disconnect the charger from the outlet before
attempting any cleaning. This will reduce the risk of
electric shock. Removing the battery pack will not reduce
thisrisk.
• NEVER attempt to connect two chargerstogether.
• The charger is designed to operate on standard
230V household electrical power. Do not attempt to
use it on any other voltage. This does not apply to the
vehicularcharger.
Charging a Battery (Fig. B)
1. Plug the charger into an appropriate outlet before inserting
batterypack.
2. Insert the battery pack 17 into the charger, making sure the
battery pack is fully seated in the charger. The red (charging)
light will blink repeatedly indicating that the charging
process hasstarted.
3. The completion of charge will be indicated by the red
light remaining ON continuously. The battery pack is fully
charged and may be used at this time or left in the charger.
To remove the battery pack from the charger, push the
battery release button 18 on the batterypack.
NOTE: To ensure maximum performance and life of lithium-ion
battery packs, charge the battery pack fully before firstuse.
Charger Operation
Refer to the indicators below for the charge status of the
batterypack.
Charge Indicators
Charging
Fully Charged
Hot/Cold Pack Delay*
*The red light will continue to blink, but a yellow indicator light
will be illuminated during this operation. Once the battery pack
has reached an appropriate temperature, the yellow light will
turn off and the charger will resume the chargingprocedure.
The compatible charger(s) will not charge a faulty battery pack.
The charger will indicate faulty battery by refusing tolight.
NOTE: This could also mean a problem with acharger.
If the charger indicates a problem, take the charger and battery
pack to be tested at an authorised servicecentre.
Hot/Cold Pack Delay
When the charger detects a battery pack that is too hot or too
cold, it automatically starts a Hot/Cold Pack Delay, suspending
charging until the battery pack has reached an appropriate
temperature. The charger then automatically switches to the
pack charging mode. This feature ensures maximum battery
packlife.
A cold battery pack will charge at a slower rate than a warm
battery pack. The battery pack will charge at that slower rate
throughout the entire charging cycle and will not return to
maximum charge rate even if the battery packwarms.
The DCB118 charger is equipped with an internal fan designed
to cool the battery pack. The fan will turn on automatically
when the battery pack needs to be cooled. Never operate the
charger if the fan does not operate properly or if ventilation slots
are blocked. Do not permit foreign objects to enter the interior
of thecharger.
Electronic Protection System
XR Li-Ion tools are designed with an Electronic Protection
System that will protect the battery pack against overloading,
overheating or deepdischarge.
The tool will automatically turn off if the Electronic Protection
System engages. If this occurs, place the lithium-ion battery
pack on the charger until it is fullycharged.
Wall Mounting
These chargers are designed to be wall mountable or to sit
upright on a table or work surface. If wall mounting, locate the
charger within reach of an electrical outlet, and away from a
corner or other obstructions which may impede air flow. Use
the back of the charger as a template for the location of the
mounting screws on the wall. Mount the charger securely using
drywall screws (purchased separately) at least 25.4mm long
with a screw head diameter of 7–9mm, screwed into wood to
an optimal depth leaving approximately 5.5mm of the screw
exposed. Align the slots on the back of the charger with the
exposed screws and fully engage them in theslots.
Charger Cleaning Instructions
WARNING: Shock hazard. Disconnect the charger
from the AC outlet before cleaning. Dirt and grease
may be removed from the exterior of the charger using a
cloth or soft non-metallic brush. Do not use water or any
cleaning solutions. Never let any liquid get inside the tool;
never immerse any part of the tool into aliquid.
Battery Packs
Important Safety Instructions for All Battery
Packs
When ordering replacement battery packs, be sure to include
catalogue number andvoltage.

5
ENGLISH
The battery pack is not fully charged out of the carton. Before
using the battery pack and charger, read the safety instructions
below. Then follow charging proceduresoutlined.
READ ALL INSTRUCTIONS
• Do not charge or use battery in explosive atmospheres,
such as in the presence of flammable liquids, gases or
dust. Inserting or removing the battery from the charger may
ignite the dust orfumes.
• Never force battery pack into charger. Do not modify
battery pack in any way to fit into a non-compatible
charger as battery pack may rupture causing serious
personalinjury.
• Charge the battery packs only in
DeWALT
chargers.
• DO NOT splash or immerse in water or otherliquids.
• Do not store or use the tool and battery pack in locations
where the temperature may fall below 4 ˚C (34 ˚F) (such
as outside sheds or metal buildings in winter), or reach
or exceed 40 ˚C (104 ˚F) (such as outside sheds or metal
buildings insummer).
• Do not incinerate the battery pack even if it is severely
damaged or is completely worn out. The battery pack can
explode in a fire. Toxic fumes and materials are created when
lithium-ion battery packs areburned.
• If battery contents come into contact with the skin,
immediately wash area with mild soap and water. If
battery liquid gets into the eye, rinse water over the open eye
for 15 minutes or until irritation ceases. If medical attention
is needed, the battery electrolyte is composed of a mixture of
liquid organic carbonates and lithiumsalts.
• Contents of opened battery cells may cause respiratory
irritation. Provide fresh air. If symptoms persists, seek
medicalattention.
WARNING: Burn hazard. Battery liquid may be flammable
if exposed to spark orflame.
WARNING: Never attempt to open the battery pack for
any reason. If battery pack case is cracked or damaged,
do not insert into charger. Do not crush, drop or damage
battery pack. Do not use a battery pack or charger that
has received a sharp blow, been dropped, run over or
damaged in any way (i.e., pierced with a nail, hit with
a hammer, stepped on). Electric shock or electrocution
may result. Damaged battery packs should be returned to
service centre forrecycling.
WARNING: Fire hazard. Do not store or carry the
battery pack so that metal objects can contact
exposed battery terminals. For example, do not place
the battery pack in aprons, pockets, tool boxes, product kit
boxes, drawers, etc., with loose nails, screws, keys,etc.
Transportation
WARNING: Fire hazard. Transporting batteries can
possibly cause fire if the battery terminals inadvertently
come in contact with conductive materials. When
transporting batteries, make sure that the battery
terminals are protected and well insulated from materials
that could contact them and cause a shortcircuit.
NOTE: Lithium-ion batteries should not be put in
checkedbaggage.
DeWALT
batteries comply with all applicable shipping
regulations as prescribed by industry and legal standards which
include UN Recommendations on the Transport of Dangerous
Goods; International Air Transport Association (IATA) Dangerous
Goods Regulations, International Maritime Dangerous Goods
(IMDG) Regulations, and the European Agreement Concerning
The International Carriage of Dangerous Goods by Road (ADR).
Lithium-ion cells and batteries have been tested to section 38.3
of the UN Recommendations on the Transport of Dangerous
Goods Manual of Tests andCriteria.
In most instances, shipping a
DeWALT
battery pack will be
excepted from being classified as a fully regulated Class 9
Hazardous Material. In general, only shipments containing a
lithium-ion battery with an energy rating greater than 100 Watt
Hours (Wh) will require being shipped as fully regulated Class 9.
All lithium-ion batteries have the Watt Hour rating marked on
the pack. Furthermore, due to regulation complexities,
DeWALT
does not recommend air shipping lithium-ion battery packs
alone regardless of Watt Hour rating. Shipments of tools with
batteries (combo kits) can be air shipped as excepted if the Watt
Hour rating of the battery pack is no greater than 100Whr.
Regardless of whether a shipment is considered excepted
or fully regulated, it is the shipper's responsibility to consult
the latest regulations for packaging, labeling/marking and
documentationrequirements.
The information provided in this section of the manual is
provided in good faith and believed to be accurate at the time
the document was created. However, no warranty, expressed or
implied, is given. It is the buyer’s responsibility to ensure that its
activities comply with the applicableregulations.
Transporting the FLEXVOLTTM Battery
The
DeWALT
FLEXVOLTTM battery has two modes: Use
andTransport.
Use Mode: When the FLEXVOLTTM battery stands alone or is in
a
DeWALT
18V product, it will operate as an 18V battery. When
the FLEXVOLTTM battery is in a 54V or a 108V (two 54V batteries)
product, it will operate as a 54Vbattery.
Transport Mode: When the cap is attached to the FLEXVOLTTM
battery, the battery is in Transport mode. Keep the cap for
shipping.
When in Transport mode, strings
of cells are electrically
disconnected within the pack
resulting in 3 batteries with a
lower Watt hour (Wh) rating as compared to 1 battery with a
higher Watt hour rating. This increased quantity of 3 batteries
with the lower Watt hour rating can exempt the pack from
certain shipping regulations that are imposed upon the higher
Watt hour batteries.
For example, the Transport
Wh rating might indicate
3x36 Wh, meaning 3
Example of Use and Transport Label Marking

6
ENGLISH
batteries of 36 Wh each. The Use Wh rating might indicate
108Wh (1batteryimplied).
Storage Recommendations
1. The best storage place is one that is cool and dry away
from direct sunlight and excess heat or cold. For optimum
battery performance and life, store battery packs at room
temperature when not inuse.
2. For long storage, it is recommended to store a fully charged
battery pack in a cool, dry place out of the charger for
optimalresults.
NOTE: Battery packs should not be stored completely
depleted of charge. The battery pack will need to be recharged
beforeuse.
Labels on Charger and Battery Pack
In addition to the pictographs used in this manual, the labels
on the charger and the battery pack may show the following
pictographs:
Read instruction manual beforeuse.
See Technical Data for chargingtime.
Do not probe with conductiveobjects.
Do not charge damaged batterypacks.
Do not expose to water.
Have defective cords replacedimmediately.
Charge only between 4 ˚C and 40 ˚C.
Only for indooruse.
Discard the battery pack with due care for
theenvironment.
Charge
DeWALT
battery packs only with designated
DeWALT
chargers. Charging battery packs other
than the designated
DeWALT
batteries with a
DeWALT
charger may make them burst or lead to
other dangeroussituations.
Do not incinerate the batterypack.
USE (without transport cap). Example: Wh rating
indicates 108 Wh (1 battery with 108 Wh).
TRANSPORT (with built-in transport cap). Example:
Wh rating indicates 3 x 36 Wh (3batteries of 36Wh).
Battery Type
The DCR029 operates on any 12 or 18 volt battery pack.
These battery packs may be used: DCB122, DCB124, DCB125,
DCB127, DCB181, DCB182, DCB183, DCB183B, DCB184,
DCB184B, DCB185, DCB187, DCB546, DCB547, DCB548. Refer to
Technical Data for moreinformation.
Package Contents
The package contains:
1 Radio
1 AC adapter
1 Li-Ion battery pack (C1, D1, L1, M1, P1, S1, T1, X1, Y1 models)
2 Li-Ion battery packs (C2, D2, L2, M2, P2, S2, T2, X2, Y2 models)
3 Li-Ion battery packs (C3, D3, L3, M3, P3, S3, T3, X3, Y3 models)
1 Instruction manual
NOTE: Battery packs, chargers and kitboxes are not included
with N models. Battery packs and chargers are not included with
NT models. Bmodels include Bluetooth® batterypacks.
NOTE: The Bluetooth® word mark and logos are registered
trademarks owned by the Bluetooth®, SIG, Inc. and any use of
such marks by
DeWALT
is under license. Other trademarks and
trade names are those of their respectiveowners.
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Markings on Radio
The following pictograms are shown on the radio:
Read instruction manual beforeuse.
Date Code Position (Fig. B)
The date code 21, which also includes the year of manufacture,
is printed into thehousing.
Example:
2020 XX XX
Year of Manufacture
Description (Fig. A, B)
WARNING: Never modify the power radio or any part of it.
Damage or personal injury couldresult.
1 ON/OFF button/Volume
knob
2 Antenna
3 Seek/tuner/arrow buttons
4 Mode button
5 Radio preset buttons
6 Mute button
7 Menu button
8 LCD display
9 Bluetooth button
10 Enter/display button
11 AUX audio port
12 USB charging port
13 Carry handle
14 Roll cage
15 AC adapter
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.

7
ENGLISH
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions and
applicableregulations.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
Inserting and Removing the Battery Pack
from the Radio (Fig. B)
NOTE: Make sure your battery pack17 is fullycharged.
To Install the Battery Pack into the Radio
1. Align the battery pack17 with the rails inside the battery
receptacle20.
2. Slide it into the receptacle until the battery pack is firmly
seated in the tool and ensure that you hear the lock snap
intoplace.
To Remove the Battery Pack from the Radio
1. Press the release button18 and firmly pull the battery pack
out of the batteryreceptacle.
2. Insert battery pack into the charger as described in the
charger section of thismanual.
Fuel Gauge Battery Packs (Fig. B)
Some
DeWALT
battery packs include a fuel gauge which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge
button19. A combination of the three green LED lights will
illuminate designating the level of charge left. When the level
of charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-userapplication.
Powering with the AC Adapter (Fig. B)
WARNING: Use only the AC adapter supplied with
this product. Use of any other external power supply
could damage the radio or powersupply.
To power the radio using the AC adapter15 , plug the cord
into the radio's AC power input16 found on the back of the
radio, then plug the 230V AC cord end into the wall outlet or
an appropriate-sized extension cord that is plugged into a wall
outlet. Always fully extend the cord before eachuse.
To prevent interference, locate the adapter as far from the radio
aspossible.
NOTE: The battery pack must be removed before the AC
adapter can be plugged into the AC powerinput.
Power/Volume Adjustment
1. To turn the radio on, press the ON/OFF button/Volume
knob1.
NOTE: When the radio is first used it will enter 'DAB' mode
and automatically scan for stations. It will then start playing
the first station itfinds.
2. Turn the ON/OFF button/Volume knob1 clockwise
to increase the volume. To decrease the volume, turn
anti-clockwise.
Mode Function
To choose one of the mode functions('DAB', 'FM', or 'AUX' or
Bluetooth®) push the mode button4 until the desired function
isfound.
NOTE: Pressing the Bluetooth® button9 also puts the radio
into Bluetooth®mode.
DAB Mode
Tuning
When the unit is first switched on the unit will start in
'DAB'/'DAB+' mode and will 'Auto Scan' to find broadcast
stations in the local area. Once 'Auto Scan' is complete, use the
left or right arrow buttons3 to scroll through thestations.
NOTE: When moving locations or if reception was poor
in the original scan(possible if the antenna was not up),
this may result in an empty or incomplete list of available
stations. Manually running an 'Auto Scan' will find all available
broadcaststations.
To Perform an Auto Scan:
1. Press the Menu button7, scroll through the options
by pressing the right arrow button3 until you reach
'AutoScan'.
2. Press the Enter/Display button10 to perform the
'AutoScan'.
Once 'Auto Scan' is complete the radio will play the first station
itfinds.
Display
Press the Enter/Display Button10 to alternate between
scrolling text, date and stationinformation.
Station Prune
Some stations once received by your radio which are no longer
available may display with a ?after the stationname.
To remove these stations from the station list, use the
'Prune'function:
1. Press Menu7 and scroll right to the 'Prune'option.
2. Press Enter/Display10 toselect.
Tune or Seek Function (FM)
There are two tuning methods and one seek method for finding
the desiredfrequency.

8
ENGLISH
To tune:
Press and release the right or left arrow button3. Repeat until
the desired frequency isfound.
To seek:
Press and hold the right or left arrow button3 for 2 seconds.
The tuner frequency will change to the first radio station with
acceptable clarity and stop at thatstation.
To Program the Preset/Memory Buttons
Five 'DAB' and five 'FM' radio stations may be independently
set. After programming the buttons, pressing 1, 2, 3, 4, or 5 will
instantly change the frequency to the presetstation.
1. Set the radio to desired station (see Tune or SeekFunction).
2. Press and hold one of the desired radio preset buttons5
until the preset number begins flashing in the LCD
display8. Release the button and wait for the preset display
to stopflashing.
To Adjust the EQ
Bass and treble can be adjusted by changing the
Equalisation(EQ) settings of theradio.
1. Press the menu button7 and use the arrow keys to select
'Sound EQ' then press the Enter/Display button10.
2. To adjust the bass, rotate the ON/OFF button/Volume
knob1 clockwise to increase, and counterclockwise
todecrease.
3. To adjust treble, press enter after adjusting the bass, use the
ON/OFF button/Volume knob1 to adjust the treble level,
4. Press enter to exit 'Sound EQ'.
Mute Button
The mute button6, located on the front panel, can be used to
mute thevolume.
Playing Audio from an External
Device(Fig.A)
Audio can be played through the radio via a wireless Bluetooth®
connection to a compatible Bluetooth® device or by connecting
audio device or mobile phone using a 3.5 mm audio cable to
the AUX audio port11 located on the frontpanel.
Pairing Radio with a Bluetooth® Audio Device
1. Place the radio and the Bluetooth® audio source within 1m
of eachother.
2. Turn radio on by pressing the ON/OFF button/Volume
knob1 .
3. Press the Bluetooth® button9 or use the mode button to
put the unit into Bluetooth® (BT) mode. During this time, the
radio is trying to find a previously paired device. If found the
radio will connect to yourdevice.
4. If another device is to be paired, press and hold the
Bluetooth® button to enter pairingmode.
5. Confirm pairing on your device. (Please consult your device's
instruction manual for specific pairing instructions.)
6. Once pairing is successful, the radio is now able to stream
audio from yourdevice.
NOTE: When the radio is paired to a Bluetooth® device the right
and left arrow buttons3 can be used to skip or go to previous
tracks on the audiodevice.
Connecting a Previously Paired Bluetooth® Audio Device
If a Bluetooth® device has been previously paired to the radio,
and within range, it should automatically reconnect when in
Bluetooth® (BT) mode. If connection does not occur and you
are unable to stream music please follow the instructions for
Pairing Radio with a Bluetooth® AudioDevice.
Timeout Functionality (Fig. A)
To conserve battery life the radio is designed to power off
automatically after 15 minutes of inactivity. This inactivity could
be due to the device being unpaired for 15 minutes or in the
case of the Bluetooth® connection being broken for the same
period of time. If the radio powers off due to inactivity of any
kind refer to Connecting a Previously Paired Bluetooth®
AudioDevice.
NOTE: Optimum Bluetooth® streaming range is roughly 9m
(line of sight) to the radio but distances up to 30m are possible.
Physical obstacles, other wireless devices or electromagnetic
devices may affect the connectionquality.
If Bluetooth® connection is lost due to exceeding time of
separation, exceeding the optimum distance, obstacles or
otherwise, reconnecting your device with the radio may
benecessary.
Charging a Mobile Device via USB (Fig.A)
Your mobile device can be charged (up to 2AMPS) using the
USB charging port12 on the radio. This charging is possible
when unit is on, running off of AC power or the batterypack.
Important Radio Notes
1. Reception will vary depending on location and strength of
radiosignal.
2. Running the radio while connected to certain generators
may cause backgroundnoise.
MAINTENANCE
Your
DeWALT
power tool has been designed to operate
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regularcleaning.
Service Notes
This product is not user serviceable. There are no user
serviceable parts inside the radio. Servicing at an authorised
service centre is required to avoid damage to static sensitive
internalcomponents.
Cleaning
WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.

9
ENGLISH
WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
Optional Accessories
WARNING: Since accessories, other than those offered
by
DeWALT
, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only
DeWALT
recommended
accessories should be used with thisproduct.
Consult your dealer for further information on the
appropriateaccessories.
Protecting the Environment
Separate collection. Products and batteries marked
with this symbol must not be disposed of with normal
householdwaste.
Products and batteries contain materials that can
be recovered or recycled reducing the demand for raw
materials. Please recycle electrical products and batteries
according to local provisions. Further information is available at
www.2helpU.com.
Rechargeable Battery Pack
This long life battery pack must be recycled when it fails to
produce sufficient power on jobs which were easily done
before. At the end of its technical life, discard it with due care for
our environment:
• Run the battery pack down completely, then remove it from
thetool.
• Li-Ion cells are recyclable. Take them to your dealer or a
local recycling station. The collected battery packs will be
recycled or disposed ofproperly.

Belgique et
Luxembourg België en Luxemburg
DeWALT - Belgium BVBA
Egide Walschaertsstraat 16
2800 Mechelen
Tel: NL 32 15 47 37 63
Tel: FR 32 15 47 37 64
Fax: [phone]
www.dewalt.be
[email protected]
Danmark DeWALT (Stanley Black&Decker AS)
Roskildevej 22
2620 Albertslund
Tel: [phone]
Fax: [phone]
www.dewalt.dk
[email protected]
Deutschland DeWALT
Richard Klinger Str. 11
65510 Idstein
Tel: [phone]
Fax: [phone]
www.dewalt.de
[email protected]
Ελλάς DeWALT (Ελλάς) Α.Ε.
EΔΡΑ-ΓΡΑΦΕΙΑ : Στράβωνος 7
& Λ. Βουλιαγμένης, Γλυφάδα 166 74, Αθήνα
SERVICE : Ημερος Τόπος 2 (Χάνι Αδάμ) – 193 00 Ασπρόπυργος
Τηλ: 00302108981616
Φαξ: 00302108983570
www.dewalt.gr
[email protected]
España DeWALT Ibérica, S.C.A.
Parc de Negocios “Mas Blau”
Edificio Muntadas, c/Bergadá, 1, Of. A6
08820 El Prat de Llobregat (Barcelona)
Tel: [phone]
Fax: [phone]
www.dewalt.es
[email protected]
France DeWALT (Stanley Black & Decker France SAS)
62 Chemin de la Bruyère
CS 60105,
69574 DARDILLY Cedex
Tel: [phone]
Fax: [phone]
www.dewalt.fr
[email protected]
Schweiz
Suisse
Svizzera
DeWALT
In der Luberzen 42
8902 Urdorf
Tel: 044 - 755 60 70
Fax: 044 - 730 70 67
www.dewalt.ch
[email protected]
Ireland DeWALT
Building 4500, Kinsale Road
Cork Airport Business Park
Cork, Ireland
Tel: [phone]
Fax: [phone]
www.dewalt.ie
[email protected]
Italia DeWALT
via Energypark 6
20871 Vimercate (MB), IT
Tel: [phone]
39 039-9590200
Fax: [phone]
www.dewalt.it
Nederlands DeWALT
Netherlands BVPostbus 83,
6120 AB BORN
Tel: [phone]
Fax: [phone]
www.dewalt.nl
Norge DeWALT
Postboks 4613
0405 Oslo, Norge
Tel: [phone]
Fax: [phone]
www.dewalt.no
[email protected]
Österreich DeWALT
Werkzeug Vertriebsges m.b.H
Oberlaaerstrasse 248, A-1230 Wien
Tel: 01 - 66116 - 0
Fax: 01 - 66116 - 614
www.dewalt.at
[email protected]
Portugal DeWALT
Ed. D Dinis, Quina da Fonte
Rua dos Malhoes 2 2A 2º Esq.
Oeiras e S. Juliao da Barra, paço de Arcos e Caxias
2770 071 Paço de Arcos
Tel: [phone]
Fax: [phone]
www.dewalt.pt
[email protected]
Suomi DeWALT
PL47
00521 Helsinki, Suomi
Puh: 010 400 4333
Faksi: 0800 411 340
www.dewalt.fi
[email protected]
Sverige DeWALT
BOX 94
43122 Mölndal
Sverige
Tel: [phone]
Fax: [phone]
www.dewalt.se
[email protected]
Türkiye Sanayi ve Ticareet Bakanlığı tebliğince kullanim ömrü 7 yıldır.
Stanley Black & Decker Turkey Alet Üretim San. Tic. Ltd.Şti.
AND Kozyataği - İçerenköy Mah. Umut Sok. AND Ofis Sit. No: 10-12 / 82-83-84
Ataşehir/İstanbul, Türkiye
Tel: [phone]
Faks: [phone]
www.dewalt.com.tr
[email protected]
United Kingdom DeWALT, 270 Bath Road;
Slough, Berks SL1 4YD
Tel: [phone]
Fax: [phone]
www.dewalt.co.uk
[email protected]
Australia DeWALT
810 Whitehorse Road Box Hill
VIC 3128 Australia
Tel: Aust 1800 338 002
Tel: NZ 0800 339 258
www.dewalt.com.au
www.dewalt.co.nz
Middle East Africa DeWALT
P.O. Box - 17164,
Jebel Ali Free Zone (South), Dubai, UAE
Tel: [phone]
Fax: [phone]
www.dewalt.ae
[email protected]
N848143 02/20
