DexWeb Telecom VOIP-9001 User manual

VOIP-9001 SIP Phone Spec and Install
VOIP-9001 SIP Phone Spec and Install
Ø Appearance: ....................................................................................................................2
Ø Function Keys : ...............................................................................................................3
Ø Features ...........................................................................................................................3
Ø Standard and Protocol ...................................................................................................5
Ø Operating requirements: ................................................................................................5
Ø Electric requirements: ....................................................................................................6
Ø Size： ...............................................................................................................................6
Ø Installation: .......................................................................................................................6

VOIP-9001 SIP Phone Spec and Install
2
ØAppearance:
●VOIP-9001 SIP Phone Front Illustration (Refer to Fig 1.1):
Fig 1.1 VOIP-9001 Phone Front Illustration
●
1.1
Local IP
LOCAL
HF
LCD Display
Missed
RVD
Out
Back
Vol
+
Vol -
Phone book
电话簿
Hold
Transfer
Redial
SPEED DIAL
Call
MG IP

VOIP-9001 SIP Phone Spec and Install
3
ØFunction Keys:
Keys
Function
Keys
Function
Local IP
With handset hung, press this key
to display local IP address on LCD.
Missed
With handset hung, press this
key to review missed number.
LOCAL
With handset hung, press this key
to display phone number on LCD.
RVD
With handset hung, press this
key to review received number.
HF
With handset hung, press this key to
menu mode. Enter the menu mode,
press this key to next menu and confirm.
Out
With handset hung, press this
key to review dialed number.
LOCAL
IP
Enter the menu mode，press this key
becomes to modify the appearance.
Redial
While reviewing missed,
received or dialed number,
press this key to dial current
number. Enter the menu mode;
press this key to back upper
menu
Back
Enter the menu mode; press this key to
back upper menu or delete.
HF
Press this key to have a call
without lifting the handset.
Vol+
With handset picked，press this key to Increase the volumes of handset；With pressing
speaker，press this key to Increase the volumes of speaker.
With pressing “missed” or“received” or “out” and then press this key to turn over the
record backward.
Enter the menu mode; press this key to turn over the item backward.
Vol -
With handset picked，press this key to decrease the volumes of handset；With pressing
speaker，press this key to decrease the volumes of speaker.
With pressing “missed” or“RVD” or “out” and then press this key to turn over the record
forward.
Enter the menu mode; press this key to turn over the item forward.
ØFeatures
ØHardware
●Main chip—PA1688 50MHz
●Data Memory—2MB SDRAM
●Program Memory—2 MB Flash memory

VOIP-9001 SIP Phone Spec and Install
4
●Ethernet Port—2X 10/100M Connectors
●AC/DC adapter—Input AC100--- 230V，Output 9V DC, 1A
ØSoftware
●DHCP support for LAN or Cable modem
●PPPoE support for ADSL or Cable modem
●Set phone by HTTP web browser or Telnet
●Upgrade by HTTP;FTP;TFTP
●Support major G.7XX ;GSM610;iLBC audio codec
●VAD(Voice active detect)
●CNG (Comfort noise generation)
●Dynamic voice jitter buffer
●G.168/165 compliant 16ms echo cancellation
●Tone generation and Local DTMF re-generation according with ITU-T
●Support the Inband audio; RFC2833; SIP INFO etc DTMF transmission
method
●E.164 dial plan and customized dial rules
●100 entries for speed dial
●80 entries each for missed calls, answered calls and dialed calls
●Adjustable volume for both handset and speaker
●Voice prompt
●Hotline
●Support adjustable user password and super password

VOIP-9001 SIP Phone Spec and Install
5
ØStandard and Protocol
VOIP-9001 SIP Phone supports following standard and protocol:
● IEEE 802.3 /802.3 u 10 Base T / 100Base TX
● Major G.7XX; GSM610;iLBC audio codec
● SIP RFC3261
● TCP/IP: Internet transfer and control protocol
● RTP: Real-time Transport Protocol
● RTCP：Real-time Control Protocol
● VAD/CNG save bandwidth
● DHCP：Dynamic Host Configuration Protocol
● PPPoE：PPP Protocol over Ethernet
● DNS：Domain Name Server
● Telnet：Internet's remote login protocol
● FTP：File Transfer protocol
● TFTP：File Transfer protocol (optional)
● HTTP：Hyper Text Transfer protocol
ØOperating requirements:
●Operation temperature: 0 to 50° C (32° to 122° F)
●Storage temperature: -30° to 65° C (-22° to 149° F)
●Humidity: 10 to 90% no dew

VOIP-9001 SIP Phone Spec and Install
6
ØElectric requirements:
●Voltage: 9V DC
●Power: 9W (max.)
●Power adapter: AC/DC input 100-230V，Output 9V 1A
●Network interface:2X RJ-45 Ethernet Connectors
ØSize：
200 x 180 x 85 mm (L x W x H)
ØInstallation:
1． Connect handset to base: insert handset cord into handset cord jack at the
left side of the base.
2． Connect IP phone to Internet: plug the RJ-45 Ethernet cable into the
Ethernet Jack. Plug the other end of the cable into HUB or switch.
3． Power on IP phone: plug the power cord adapter into the Power Jack.
Then plug the other end of the power cord adapter into the appropriate
wall outlet.
With the installation done, users can chose the telephone keyboard，HTTP or
Telnet orders according the preference of each, and set the respective
parameters. Details may refer to the related chapters in the manual.

VOIP-9001 SIP Phone Spec and Install
7
Reserves the right to make changes in technical and product specification
without prior notice.
