G7S600-B

System Board

User’s Manual

935-G7S601-000G

A00300701

This publication contains information that is protected by copyright.

No part of it may be reproduced in any form or by any means or

used to make any transformation/adaptation without the prior writ-

ten permission from the copyright holders.

This publication is provided for informational purposes only. The

manufacturer makes no representations or warranties with respect to

the contents or use of this manual and specifically disclaims any ex-

press or implied warranties of merchantability or fitness for any par-

ticular purpose.The user will assume the entire risk of the use or the

results of the use of this document. Further, the manufacturer re-

serves the right to revise this publication and make changes to its

contents at any time, without obligation to notify any person or en-

tity of such revisions or changes.

Trademarks

Product names or trademarks appearing in this manual are for iden-

tification purpose only and are the properties of the respective own-

ers.

FCC and DOC Statement on Class B

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC rules.

These limits are designed to provide reasonable protection against

harmful interference when the equipment is operated in a residential

installation.This equipment generates, uses and can radiate radio fre-

quency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communi-

cations. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined

by turning the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following meas-

ures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

• Consult the dealer or an experienced radio TV technician for

help.

Notice:

1. The changes or modifications not expressly approved by the

party responsible for compliance could void the user's authority

to operate the equipment.

2. Shielded interface cables must be used in order to comply with

the emission limits.

Table of Contents

About this Manual................................................................................

Warranty.................................................................................................

Static Electricity Precaution................................................................

Safety Measures.....................................................................................

About the Package...............................................................................

Before Using the System Board.........................................................

Chapter 1 - Introduction....................................................................

Specifications...................................................................................................................................

Features..............................................................................................................................................

Chapter 2 - Hardware Installation....................................................

System Board Layout ..........................................................................................................

System Memory..........................................................................................................................

CPU.......................................................................................................................................................

Jumper Settings............................................................................................................................

Rear Panel I/O Ports.............................................................................................................

I/O Connectors..........................................................................................................................

Chapter 3 - BIOS Setup......................................................................

Award BIOS Setup Utility.................................................................................................

Updating the BIOS..................................................................................................................

Chapter 4 - Supported Softwares.....................................................

Drivers, Utilities and Software Applications......................................................

Installation Notes.......................................................................................................................

Appendix A - Enabling Hyper-Threading Technology......................

Appendix B - Watchdog Timer.............................................................

Appendix C - System Error Messages...............................................

POST Beep.................................................................................................................................

Error Messages.........................................................................................................................

Appendix D - Troubleshooting..........................................................

Troubleshooting Checklist...............................................................................................

111

112

115

116

118

About this Manual

An electronic file of this manual is included in the CD. To view the

user’s manual in the CD, insert the CD into a CD-ROM drive. The

autorun screen (Main Board Utility CD) will appear. Click “User’s

Manual” on the main menu.

Warranty

1. Warranty does not cover damages or failures that arised from

misuse of the product, inability to use the product, unauthorized

replacement or alteration of components and product specifica-

tions.

2. The warranty is void if the product has been subjected to physi-

cal abuse, improper installation, modification, accidents or unau-

thorized repair of the product.

3. Unless otherwise instructed in this user’s manual, the user may

not, under any circumstances, attempt to perform service, adjust-

ments or repairs on the product, whether in or out of warranty.

It must be returned to the purchase point, factory or authorized

service agency for all such work.

4. We will not be liable for any indirect, special, incidental or

consequencial damages to the product that has been modified

or altered.

Introduction

Static Electricity Precautions

It is quite easy to inadvertently damage your PC, system board,

components or devices even before installing them in your system

unit. Static electrical discharge can damage computer components

without causing any signs of physical damage. You must take extra

care in handling them to ensure against electrostatic build-up.

1. To prevent electrostatic build-up, leave the system board in its

anti-static bag until you are ready to install it.

2. Wear an antistatic wrist strap.

3. Do all preparation work on a static-free surface.

4. Hold the device only by its edges. Be careful not to touch any of

the components, contacts or connections.

5. Avoid touching the pins or contacts on all modules and connec-

tors. Hold modules or connectors by their ends.

Important:

Electrostatic discharge (ESD) can damage your processor,

disk drive and other components. Perform the upgrade in-

struction procedures described at an ESD workstation

only. If such a station is not available, you can provide

some ESD protection by wearing an antistatic wrist strap

and attaching it to a metal part of the system chassis. If a

wrist strap is unavailable, establish and maintain contact

with the system chassis throughout any procedures requir-

ing ESD protection.

Safety Measures

To avoid damage to the system:

• Use the correct AC input voltage range.....

To reduce the risk of electric shock:

• Unplug the power cord before removing the system chassis

cover for installation or servicing. After installation or servicing,

cover the system chassis before plugging the power cord.

Battery:

• Danger of explosion if battery incorrectly replaced.

• Replace only with the same or equivalent type recommend

the manufacturer.

• Dispose of used batteries according to the battery manufactur-

er’s

instructions.

Introduction

About the Package

The system board package contains the following items. If any of

these items are missing or damaged, please contact your dealer or

sales representative for assistance.

;The system board

;A user’s manual

;One IDE cable

;One FDD cable

;One Serial ATA data cable

;One Serial ATA power cable

;One bracket mounted with 2 serial ports

;One USB port cable

;One “Main Board Utility” CD

;One I/O shield

The system board and accessories in the package may not come

similar to the information listed above.This may differ in accordance

to the sales region or models in which it was sold. For more infor-

mation about the standard package in your region, please contact

your dealer or sales representative.

Before Using the System Board

Before using the system board, prepare basic system components.

If you are installing the system board in a new system, you will need

at least the following internal components.

•A CPU

•Memory module

•Storage devices such as hard disk drive, CD-ROM, etc.

You will also need external system peripherals you intend to use

which will normally include at least a keyboard, a mouse and a video

display monitor.

Introduction

• Intel®Prescott processor

- Intel®Pentium®D

- Intel®Pentium®4

- Intel®Celeron D

- Hyper-Threading Technology

- 800MHz/533MHz system data bus

• Processor socket: Socket 775

• Intel®chipset

- Intel®865G Graphics Memory Controller Hub (GMCH)

- Intel®82801EB I/O Controller Hub (ICH5)

• Four 184-pin DDR DIMM sockets

• Supports dual channel (128-bit wide) memory interface

• Supports up to 4GB system memory

• Synchronous operation with processor system bus

- PC2700/PC3200 (DDR333/DDR400) with 800MHz FSB

CPU. DDR333 will run at 320MHz memory frequency when

used with 800MHz FSB CPU.

- PC2100/PC2700 (DDR266/DDR333) with 533MHz FSB

CPU

• Supports non-ECC (x64) DIMM using 128Mb, 256Mb or

512Mb

• Supports unbuffered DIMMs

• Award BIOS

• 4Mbit flash memory

• Supports ACPI specification and OS Directed Power Management

• Supports ACPI STR (Suspend to RAM) function

• Wake-On-Events include:

- Wake-On-PS/2 Keyboard/Mouse

- Wake-On-USB Keyboard

- Wake-On-Ring (external modem)

- Wake-On-LAN

- RTC timer to power-on the system

• System power management supported

• CPU stopped clock control

• Microsoft®/Intel®APM 1.2 compliant

• Soft Power supported - ACPI v1.0a specification

• AC power failure recovery

• Auto power-on function

• Watchdog timer function

• Graphics memory

- Shares 1MB/4MB/8MB/16MB/32MB of the system memory in

DOS mode

- Uses Dynamic Video Memory Technology (DVMT) in

Windows mode

Processor

Chipset

System Memory

BIOS

Energy Efficient

Design

Graphics

Chapter 1 - Introduction

Specifications

Introduction

Audio

LAN

IDE

Serial ATA

Rear I/O

• Graphics controller

- Core frequency of 266MHz

- 350MHz integrated 24-bit RAMDAC

- Analog display up to 2048x1536 @ 60Hz refresh

- 3D setup and render engine - Discrete, Triangles, Strips and

fans

- Per pixel perspective corrected texture mapping

- Software DVD at 30fps, full screen

• 2D graphics features

- Optimized 256-bit BLT engine

- 32-bit alpha blended cursor

- Programmable 3-color transparent cursor

• 3D graphics features

- 200 megapixels/sec fill rate

- Maximum 3D resolution: 1600x1200x32 @ 85Hz

- Flat and Gouraud shading

- 16- and 24-bit Z-buffering and 16- and 24-bit W-buffering

- Vertex and programmable pixel fogging and atmospheric effects

- Double and triple render buffer

• Realtek audio CODEC

• 16-bit stereo full-duplex codec with 48KHz sampling rate

• High quality differential CD input

• True stereo line level outputs

• S/PDIF-out interface

• 6-channel audio output

• Realtek RTL8110SC Gigabit LAN PCI interface

• Integrated power management functions

• Supports 10Mbps, 100Mbps and 1Gbps data transmission

• IEEE 802.3 (10/100Mbps) and IEEE 802.3ab (1Gbps)

compliant

• Supports up to UltraDMA 100Mbps hard drives

• PIO Mode 4 Enhanced IDE (data transfer rate up to 14MB/sec.)

• Supports two SATA (Serial ATA) interfaces which are compliant

with SATA 1.0 specification (1.5Gbps interface)

• 1 mini-DIN-6 PS/2 mouse port

• 1 mini-DIN-6 PS/2 keyboard port

• 1 DB-25 parallel port

• 1 DB-9 serial port

• 1 DB-15 VGA port

• 4 USB 2.0/1.1 ports

• 1 RJ45 LAN port

• 3 audio jacks: mic-in, line-in and line-out

Introduction

I/O Connectors

Expansion Slots

Compatibility

Temperature

Humidity

PCB

• 2 connectors for 4 additional external USB 2.0/1.1 ports

• 1 connector for 1 external serial port

• 1 Digital I/O connector

• 1 Digital I/O power connector

• 1 front audio connector for external line-out and mic-in jacks

• 1 CD-in internal audio connector

• 1 speaker-out connector

• 1 S/PDIF-out connector

• 1 connector for IrDA interface

• 2 Serial ATA connectors

• 2 IDE connectors

• 1 floppy connector

• 1 24-pin ATX power connector

• 1 4-pin 12V ATX power connector

• 1 Wake-On-LAN connector

• 3 fan connectors

• 1 AGP slot

• 6 PCI slots

• PCI 2.2 and AC ’97 compliant

• Intel AGP version 3.0

•0

oC to 60oC

• 10% to 90%

• 4 layers, ATX form factor

• 30.5cm (12") x 24.4cm (9.6")

Introduction

Features

The Watchdog Timer function allows your

application to regularly “clear” the system at

the set time interval. If the system hangs or fails to function, it will

reset at the set time interval so that your system will continue to

operate.

The system board supports Intel proces-

sors with Hyper-Threading Technology. Ena-

bling the functionality of Hyper-Threading

Technology for your computer system requires ALL of the following

platforms.

Components:

• CPU - an Intel®Pentium®4 Processor with HT Technology

• Chipset - an Intel®chipset that supports HT Technology

• BIOS - a BIOS that supports HT Technology and has it enabled

• OS - an operating system that includes optimizations for HT

Technology

Please refer to Appendix A for information about enabling the func-

tionality of the Hyper-Threading Technology. For more information on

Hyper-Threading Technology, go to: www.intel.com/info/hyperthreading.

Double Data Rate SDRAM (DDR SDRAM) is a

type of SDRAM that doubles the data rate through

reading and writing at both the rising and falling edge of each clock.

This effectively doubles the speed of operation therefore doubling

the speed of data transfer.

The Intel 865G northbridge chip comes integrated

with the Intel®Extreme Graphics 2 technology

providing 3D graphics with sharp images, fast rendering, smooth

motion and extreme detail. It supports the latest 2D and 3D APIs,

delivering real-life environment and character effects.

watchdog timer

graphics

hyper-threading

technology

DDR

Introduction

The audio jacks at the rear panel will

support 5.1-channel audio only when the

audio utility is configured to support this function. The mic-in at the

rear will be disabled. Use the front audio’s mic-in jack.

S/PDIF is a standard audio file transfer format that

transfers digital audio signals to a device without

having to be converted first to an analog format. This prevents the

quality of the audio signal from degrading whenever it is converted

to analog. S/PDIF is usually found on digital audio equipment such as

a DAT machine or audio processing device.The S/PDIF connector on

the system board sends surround sound and 3D audio signal out-

puts to amplifiers and speakers and to digital recording devices like

CD recorders.

Serial ATA is a storage interface that is compliant

with SATA 1.0 specification. With speed of up to

1.5Gbps, it improves hard drive performance faster than the stand-

ard parallel ATA whose data transfer rate is 100MB/s.

The Realtek RTL8110SC PCI Gigabit LAN con-

troller support up to 1Gbps data transmission.

AGP is an interface designed to support high per-

formance 3D graphics cards. It utilizes a dedicated

pipeline to access system memory for texturing, z-buffering and alpha

blending.The AGP slot supports AGP 8x (0.8V) with up to 2.13GB/

sec. bandwidth and AGP 4x (1.5V) with up to 1066MB/sec. band-

width for 3D graphics applications. It handles large amounts of

graphics data with the following features:

• Pipelined memory read and write operations that hide

memory access latency.

• Demultiplexing of address and data on the bus for nearly

100 percent efficiency.

AGP in this system board will deliver faster and better graphics to

your PC.

SERIAL ATA

gigabit lan

S/PDIF

5.1-channel audio

AGP

Introduction

The system board is equipped with an IrDA connec-

tor for wireless connectivity between your computer

and peripheral devices.The IRDA (Infrared Data Association) specifi-

cation supports data transfers of 115K baud at a distance of 1

meter.

The system board supports USB 2.0 and USB 1.1

ports. USB 1.1 supports 12Mb/second bandwidth

while USB 2.0 supports 480Mb/second bandwidth providing a

marked improvement in device transfer speeds between your com-

puter and a wide range of simultaneously accessible external Plug

and Play peripherals.

This feature allows the system that is in the

Suspend mode or Soft Power Off mode to

wake-up/power-on to respond to calls coming from an external mo-

dem or respond to calls from a modem PCI card that uses the PCI

PME (Power Management Event) signal to remotely wake up the

PC.

Important:

The 5V_standby power source of your power supply must sup-

port

≥

720mA.

This feature allows the network to remotely

wake up a Soft Power Down (Soft-Off) PC.

It is supported via the onboard LAN port, via a PCI LAN card that

uses the PCI PME (Power Management Event) signal or via a LAN

card that uses the Wake-On-LAN connector. However, if your sys-

tem is in the Suspend mode, you can power-on the system only

through an IRQ or DMA interrupt.

Important:

The 5V_standby power source of your power supply must sup-

port

≥

720mA.

This function allows you to use the PS/2 key-

board or PS/2 mouse to power-on the sys-

tem.

Important:

The 5V_standby power source of your power supply must sup-

port

≥

720mA.

USB

wake-on-lan

wake-on-ring

wake-on-PS/2

irda

Introduction

This function allows you to use a USB key-

board or USB mouse to wake up a system

from the S3 (STR - Suspend To RAM) state.

Important:

If you are using the Wake-On-USB Keyboard/Mouse function for

2 USB ports, the 5V_standby power source of your power sup-

ply must support

≥

1.5A. For 3 or more USB ports, the

5V_standby power source of your power supply must support

≥

2A.

The RTC installed on the system board allows your

system to automatically power-on on the set date

and time.

The system board is designed to meet the ACPI

(Advanced Configuration and Power Interface) speci-

fication. ACPI has energy saving features that enables PCs to imple-

ment Power Management and Plug-and-Play with operating systems

that support OS Direct Power Management. Currently, only Win-

dows®®

®®

®98/2000/ME/XP supports the ACPI function. ACPI when

enabled in the Power Management Setup will allow you to use the

Suspend to RAM function.

With the Suspend to RAM function enabled, you can power-off the

system at once by pressing the power button or selecting “Standby”

when you shut down Windows®®

®®

®98/2000/ME/XP without having to

go through the sometimes tiresome process of closing files, applica-

tions and operating system. This is because the system is capable of

storing all programs and data files during the entire operating session

into RAM (Random Access Memory) when it powers-off.The oper-

ating session will resume exactly where you left off the next time you

power-on the system.

Important:

The 5V_standby power source of your power supply must sup-

port

≥

720mA.

When power returns after an AC power fail-

ure, you may choose to either power-on the

system manually or let the system power-on

automatically.

Power failure

recovery

wake-on-USB

rtc timer

ACPI STR

Hardware Installation

System Board Layout

Chapter 2 - Hardware Installation

2Hardware Installation

Warning:

Electrostatic discharge (ESD) can damage your system board, proces-

sor, disk drives, add-in boards, and other components. Perform the

upgrade instruction procedures described at an ESD workstation only.

If such a station is not available, you can provide some ESD protec-

tion by wearing an antistatic wrist strap and attaching it to a metal

part of the system chassis. If a wrist strap is unavailable, establish

and maintain contact with the system chassis throughout any proce-

dures requiring ESD protection.

System Memory

Warning:

When the DRAM Power LED lit red, it indicates that power is

present on the DDR sockets. Power-off the PC then unplug the

power cord prior to installing any memory modules. Failure to do so

will cause severe damage to the motherboard and components.

The system board supports DDR SDRAM DIMM. Double Data

Rate SDRAM (DDR SDRAM) is a type of SDRAM that doubles the

data rate through reading and writing at both the rising and falling

edge of each clock. This effectively doubles the speed of operation

therefore doubling the speed of data transfer.

DDR-1

DDR-2

DDR-3

DDR-4

DRAM Power LED

Hardware Installation

The four DDR DIMM sockets on the system board are divided into 2

channels:

Channel A - DDR-1 and DDR-2

Channel B - DDR-3 and DDR-4

The system board supports the following memory interface.

Single Channel (SC)

Data will be accessed in chunks of 64 bits (8B) from the memory

channels.

Dual Channel (DC)

Dual channel provides better system performance because it doubles

the data transfer rate.

BIOS Setting

Configure the system memory in the Advanced Chipset Features

submenu of the BIOS.

•DIMMs are on the same channel.

•DIMMs in a channel can be identical or

completely different. However, we highly rec-

ommend using identical DIMMs.

•Not all slots need to be populated.

•DIMMs of the same memory configura-

tion are on different channels.

Single Channel

Dual Channel

2Hardware Installation

The table below lists the various optimal operating modes that should

be configured for the memory channel operation.

Config

No memory

Single channel A

Single channel B

Dual channel

DDR 1

P(*)(1,3)

DDR 2

P(*)(2,4)

DDR 3

P(*)(1,3)

DDR 4

P(*)(2,4)

P - denotes populated

E - denotes empty

* - denotes DIMMs are identical

Hardware Installation

Installing the DIMM

A DIMM simply snaps into a DIMM socket on the system board.

Pin 1 of the DIMM must correspond with Pin 1 of the socket.

1. Pull the “tabs” which are at the ends of the socket to the side.

2. Position the DIMM above the socket with the “notch” in the

module aligned with the “key” on the socket.

3. Seat the module vertically into the socket. Make sure it is com-

pletely seated.The tabs will hold the DIMM in place.

Pin 1

Notch

Key

Tab Tab

2Hardware Installation

CPU

Overview

The system board is equipped with a surface mount LGA 775

socket. This socket is exclusively designed for installing a LGA 775

packaged Intel CPU.

Important:

1. Before you proceed, make sure (1) the LGA7751. Before you proceed, make sure (1) the LGA775

1. Before you proceed, make sure (1) the LGA775

socket comes with a protective cap, (2) the capsocket comes with a protective cap, (2) the cap

socket comes with a protective cap, (2) the cap

is not damaged and (3) the socket’s contact pinsis not damaged and (3) the socket’s contact pins

is not damaged and (3) the socket’s contact pins

are not bent. If the cap is missing or the capare not bent. If the cap is missing or the cap

are not bent. If the cap is missing or the cap

and/or contact pins are damaged, contact yourand/or contact pins are damaged, contact your

and/or contact pins are damaged, contact your

dealer immediatelydealer immediately

dealer immediately.....

2.2.

2. Make sure to keep the protective cap. RMA re-Make sure to keep the protective cap. RMA re-

Make sure to keep the protective cap. RMA re-Make sure to keep the protective cap. RMA re-

Make sure to keep the protective cap. RMA re-

quests will be accepted and processed only if thequests will be accepted and processed only if the

quests will be accepted and processed only if the

LGA775 socket comes with the protective cap.LGA775 socket comes with the protective cap.

LGA775 socket comes with the protective cap.

Installing the CPU

1. Make sure the PC and all other peripheral devices connected to

it has been powered down.

2. Disconnect all power cords and cables.

3. Locate the LGA 775 CPU socket on the system board.

Table of contents

Popular Motherboard manuals by other brands

American Megatrends

American Megatrends 386DX-AD5 user manual

MSI

MSI B450M BAZOOKA quick start

Biostar

Biostar M5VNB manual

TYAN

TYAN TOMCAT K8E manual

Shift838

Shift838 838-IO PLUS manual

Asus

Asus P7F-E - Motherboard - ATX user manual

ASROCK

ASROCK H61M-DP3 Quick installation guide

MSI

MSI 850 Pro2 manual

Albatron

Albatron KX18DS PRO II user manual

DTronics

DTronics DT7 user manual

Supero

Supero X7SBU user manual

ASROCK

ASROCK G41M-S3 user manual

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY Z690 AERO G user manual

Gigabyte

Gigabyte B560 DS3H AC user manual

Asus

Asus PRIME Intel 500 Series manual

ECS

ECS 945GCT-D manual

SOLTEK

SOLTEK SL-85DR-C user manual

ASROCK

ASROCK H61M-VS R2.0 user manual

DFI G7S600-B User manual

Popular Motherboard manuals by other brands
