BT101 BATTERY TESTER
BT201 BATTERY/CHARGING/STARTING
SYSTEM ANALYZER
TEST PROCEDURES / OPERATING INSTRUCTIONS
IMPORTANT:
1. For testing 12 volts batteries (BT101/BT201), and
for testing 12 volts charging/Starting system (BT201).
The capacity range:
SAE : 200~1200 CCA
DIN : 110~670 CCA
IEC : 130~790 CCA
EN : 185~1125 CCA
CA(MCA) : 240~1440 CA(MCA)
2. Suggested operation range 32℉(0℃) to 122℉(50℃) in ambient
temperature.
WARNING:
1. Working in the vicinity of a lead acid battery is dangerous.
Batteries generate explosive gases during normal battery operation.
For this reason, it is of utmost importance, if you have any doubt,
that each time before using your tester, you read these instructions
very carefully.
2. To reduce risk of battery explosion, follow these instructions and
those published by the battery manufacturer and manufacturer of
any equipment you intend to use in the vicinity of the battery.
Observe cautionary markings on these items.
3. Do not expose the tester to rain or snow.

- GB.2-V1 -
PERSONAL SAFETY PRECAUTUONS:
1. Someone should be within range of your voice or close enough to
come to your aid when you work near a lead acid battery.
2. Have plenty of fresh water and soap nearby in case battery acid
contacts skin, clothing or eyes.
3. Wear safety glasses and protective clothing.
4. If battery acid contacts skin or clothing, wash immediately with
soap and water. If acid enters eye, immediately flood eye with
running cold water for at least ten minutes and get medical
attention immediately.
5. NEVER smoke or allow a spark or flame in vicinity of battery or
engine.
6. Be extra cautious to reduce risk of dropping a metal tool onto the
battery. It could spark or short-circuit the battery or other electrical
parts and could cause an explosion.
7. Remove personal metal items such as rings, bracelets, necklaces
and watches when working with a lead acid battery. It can produce
a short circuit current high enough to weld a ring or the like to
metal causing a severe burn.
PREPARING TO TEST:
1. Be sure area around battery is well ventilated while battery is being
tested.
2. Clean battery terminals. Be careful to keep corrosion from coming
in contact with eyes.
3. Inspect the battery for cracked or broken case or cover. If the
battery is damaged, do not use tester.
4. If the battery is not sealed maintenance free, add distilled water in
each cell until battery acid reaches level specified by the
manufacturer. This helps purge excessive gas from cells. Do not
overfill.
5. If necessary to remove battery from vehicle to test, always remove
ground terminal from battery first. Make sure all accessories in the
vehicle are off to ensure you do not cause any arcing.

- GB.3-V1 -
OPERATION & USE:
BATTERY TEST - BT101/BT201 (Test for 12V batteries)
1. Before you test a battery in a vehicle, turn off the ignition, all
accessories and loads. Close all the vehicle doors and the trunk lid.
2. Make sure the battery terminals are clean. Wire brush them if
necessary. Clamp the black load lead to the vehicle negative battery
terminal. Clamp the red load lead to the vehicle positive battery
terminal.
3. Make sure you have put 9V battery into the battery chamber. If the
9V battery runs out of power, screen will show ibtL (INTERNAL
BATTERY LOW). Replace 9V battery before starting the test.
Note: Nothing will show on the display until the tester is
connected to a vehicle battery.
4. LED display will light on and show the voltage of the battery
XX.XX on the screen. Press "ENTER" to the next step.
NOTE: If you see HI / ---- / Blank appeared on the screen or
screen flickers, please refer to TROUBLESHOOITING.
BT201- Please press ▲\▼key to select the battery test : bAtt.
Press “ENTER” to the next step.
5. Please press ▲\▼key to select the battery type of SLI or SEAL :
SLI : Standard SLI flooded batteries.
SEAL : VRLA/GEL/AGM etc sealed /MF batteries.
6. Press "ENTER" to the next step.
7. Please press ▲\▼key to select the battery rating of
SAE , din , IEC , En or CA (MCA).
8. Press "ENTER" to the next step.

- GB.4-V1 -
9. Please press ▲\▼key to input the battery capacity of CCA or CA
(MCA):
SAE: 200~1200 CCA
DIN: 110~670 CCA
IEC: 130~790 CCA
EN: 185~1125 CCA
CA (MCA): 240~1440 CA (MCA)
Press "ENTER" to begin the test.
10. Test the battery within 1 second.
11. If the display shows CHA- (Is tested battery charged?). Please
press "ENTER" & select ▲\▼key to choose yES or no , then
Press "ENTER" to the next step. (BT101/BT201 tester will judge
the tested battery status & decide to show out Step11 or not.)
12. When the test is complete, the LED display shows the actual CCA.
One of following five results will be displayed on LED lamps:
Green LED light
The battery is good & capable of holding a charge.
XXXX (CCA value) SAE
Green & Yellow LED lights
The battery is good but needs to be charged.
XXXX (CCA value) SAE
Yellow & Red LED lights
Battery is discharged. The battery condition cannot be
determined until it is fully charged. Recharge & retest the
battery. If reading is the same, the battery should be
replaced immediately.
XXXX (CCA value) SAE

- GB.5-V1 -
Red LED light
–The battery cannot hold a charge. It should be replaced
immediately. Or
–The battery has at least one cell short circuit .It should
be replaced immediately.
XXXX (CCA value) SAE
Err on the screen & Second Red light
–The clamps are not connected properly. Please check if
the clamps are connected properly. Or
–The tested battery is bigger than maximum testing
CCA capacity.
13. Press <<ENTER>> return to Step 4 or remove the test clamps from
the battery posts after completion of testing.
14. All selected data will be memorized after test, including battery
type, battery CCA standard, capacity of CCA, etc.
SYSTEM TEST - BT201 (Test for 12V system)
FOR STARTER SYSTEM TEST
1. LED display will light on and show the voltage of the battery
ХХ.ХХ on the screen. Press “ENTER” to the next step.
NOTE : If you see HI / Blank/ ---- appeared on the screen or
screen flickers, please refer to TROUBLESHOOTING.
2. Please press ▲\▼key to select the system test: SySt. Press
“ENTER” to the next step.
3. Turn off all vehicle accessory loads such as light, air conditioning,
radio, etc. before starting the engine.
4. The screen shows CrAn. Press “ENTER” bottom to read the
minimum voltage of the battery.
5. Start the engine. Read the voltage after cranking the starter.


- GB.6-V1 -
A. Green LED lights.
= Starting system ok.
B. Yellow LED lights.
= Starting system weak. Check connections, wiring, and starter.
C. Red LED lights, the screen shows blank or the screen shows
the voltage of the battery ХХ.ХХ
= Starting system problem. Check connections, wiring, and
starter immediately.
FOR CHARGING SYSTEM TEST
1. After starter test, press “ENTER” bottom to go to charging system
test, the screen shows CHAr. Press “ENTER” bottom to read live
voltage.
2. Run up the engine to 1200 ~ 1500 rpm. Read the voltage while the
car is running.
A. Green LED lights.
= Charging system ok.
B. Red LED lights.
= Charging voltage high. Check regulator.
C. Yellow LED lights.
= Charging voltage low. Check connections, wiring and
alternator.
3. Following the charging system at idle, continue the charging
system test with accessory loads. Turn on the blower to high (heat),
high beam headlights, and rear defogger. Do not use cyclical loads
such as air conditioning or windshield wipers.
A. Green LED lights.
= Charging system ok.
B. Red LED lights
= Charging voltage high.. Check regulator.
C. Yellow LED lights.

- GB.7-V1 -
= Charging voltage low. Check connections, wiring and
alternator.
4. Turn engine off and remove the test clamps from the battery posts
after completion of testing to end test.
TROUBLESHOOTING
–If the screen shows HI :
Voltage of the tested battery is over 15.00V & too high for 12V
battery. BT101/BT201 won't work under this situation. Please
re-check if the tested battery is 12 volts.
–Voltage of the tested battery is under 1.5 Volts. BT101/BT201 won't
work under this situation. Please recharge the battery & retest. If
reading is the same, the battery should be replaced immediately.
–If the screen shows blank :
The voltage of the tested battery is too low to serve the BT101/
BT201. Please recharge the battery retest. If reading is the same, the
battery should be replaced immediately. Or the clamps are connected
reversely. Please check & re-connect it.
–The screen shows ---- :
The voltage is unstable. For a just completely the charged battery or
other factors cause the battery’s voltage unstable, the LED display
shows ----. Please wait 15~30 minutes to let the battery voltage
stable and test the battery or eliminate the factors to test the battery.

- GB.8-V1 -
