DHP 5440096 User manual

STOP
DO NOT RETURN PRODUCT TO THE
STORE
Individual stores do not stock parts.
If a part is missin or dama ed, call our
toll-free customer service line. We will
ladly ship your replacement parts FREE
of char e.
Need Parts or Assistance?
1-800-267-1739
www.dhpfurniture.com
For prompt, reliable service; please have your assembly
manual ready.
5440096
B34544009600
Date of Purchase
___ / ___ / ___
Lot Number
_________
or access our website
WARNING
• WARNING FOR YOUNG CHILDREN - This product contains small components, please ensure that they are kept away from small children.Children under the a e of 6,
small infants and babies must not sleep on this bed for safety reasons. To prevent injury and dama e to this unit, PROHIBIT jumpin on it.
• Recommended # of people needed for assembly 2 (however it is always better to have an extra hand.) Estimated assembly time is 2 hour.
• THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE
Wei ht Limits: 150 Lbs
68 K s
BLACK METAL X-LOFT BED - MX
0 29986 544018
100 Lbs
45 K s

3 /15
HARDWARE
KING SUPPORT
T905600
QTY: 2 BOTTOM BRACE
T905610
QTY: 2
UPPER BRACE
T905620
QTY: 2
A
B
CD
NOTE: PARTS , , HAVE PROTECTIVE END CAPS PRE-INSTALLED
DJE
RIGHT BASE
T905630
QTY: 1
LEFT BASE
T905690
QTY: 1
E
HOLE
AGUJERO
RIGHT GUARD RAIL
T905640
QTY: 1
F
LEFT GUARD RAIL
T905650
QTY: 1
HOLE
AGUJERO
HOLE
AGUJERO
B
A
C
D
E
F
UPPER SIDE RAIL
T905660
QTY: 1
G
G
HOLE
AGUJERO
HOLE
AGUJERO
H
LADDER SIDE RAIL
T905670
QTY: 1
H
HOLE
AGUJERO
LOWER SIDE RAIL
T905680
QTY: 1
I
J
I
F
B34544009600
NO HOLES
0 AGUJEROS
J
SAFETY BRACKET
T391730
QTY: 2
V

4 /15
HARDWARE
B34544009600
K
L
FRONT GUARD RAIL
T905700
QTY: 1
KL
REAR GUARD RAIL
T905710
QTY: 1
SLATS PA K
T905720
QTY: 1
M
M
N
DESK SUPPORT
T905730
QTY: 1
N
O
O
REAR STRET HER
T905740
QTY: 2
PP
REAR BRA E
T905750
QTY: 2
P
Q
Q
DESK
T905760
QTY: 1
R
R
LADDER
T905770
QTY: 1
S
SD
ADJUSTABLE GLIDE
T905780
QTY: 4
T
T
KNOB
T320420
QTY: 8
O
NOTE: PARTS & HAVE PROTE TIVE END APS PRE-INSTALLED
OR
Please respect the
direction of the arrow
when assembling

5 /15
HARDWARE
HEX KEY
4mm
T290110
QTY: 1
8
HARDWARE NOTE:
Please do not completely tighten any screws until the
entire assembly is complete. Once assembly is
complete, please be sure tighten all hardware.
NOTA : Favor de no apretar completamente los
tornillos hasta que el ensamble haya sido completado.
Una vez que haya terminado el ensamblado asegúrese
de apretar bien todas las partes.
BOLT
M6 X 60 mm
T136110
QTY: 6
1
2
BOLT
M6 X 45 mm
T136090
QTY: 3
BOLT
M6 X 40 mm
T136070
QTY: 1
34
BOLT
M6 X 35 mm
T136050
QTY: 2
5
BOLT
M6 X 15 mm
T136130
QTY: 48
6
BOLT
M6 X 12 mm
T136010
QTY: 6
7
S REW 4 X 13 mm
T115390
QTY: 2
B34544009600
9
BOLT
M6 X 25 mm
T136030
QTY: 4
