DHR 220 User manual

Rev. 1.3
Den Haan Rotterdam B.V.
Fascinatio Boulevard 1182
2909 VA Capelle a/d Jssel
The Netherlands
Phone: +31 (0)10 – 413 07 55
Fax: +31 (0)10 – 413 54 87
E-mail: [e-mail]
MANUAL
Searchlights
DHR UC
220/210/180/150
Remote controlled

Den Haan Rotterdam Rev. 1.3
Page 2 of 13
The electrical construction of the searchlight is manufactured in accordance with international standard EC 60598-1, conform the directives
73/23/EEC and 93/68/EEC.
3 December 2006
Introduction
Den Haan Rotterdam, specialist in developing and manufacturing navigation lights for ships
since 1922. Besides, 40 years active in producing searchlights for pleasure craft, inland trade
and seagoing vessels.
Co-workers of Den Haan Rotterdam got more and more interest in a wider assortment of high
quality searchlights. Much attention has been paid to the wishes of our very valued customers
After a time-consuming development, the use of exclusive seawater resistant materials, and
electrical construction conform the directives 73/23/EEC and 93/68/EEC, now the searchlight is
ready to put on the market.
Voorwoord
Den Haan Rotterdam, specialist in het ontwikkelen en produceren van navigatieverlichting sinds
1922. Daarnaast reeds 40 jaar actie in de abricage van zoeklichten voor de plezier-, binnen- en
zeevaart.
Bij de medewerkers van Den Haan ontstond een steeds grotere interesse voor een breder
assortiment kwalitatie hoogwaardige zoeklichten. Veel aandacht is besteed aan de geuite wensen
van onze zeer gewaardeerde a nemers.
Na een tijdrovende ontwikkeling, het gebruik van uitsluitend zeewaterbestendige materialen, de
elektrische constructie volgens de richtlijnen 73/23/EEG en 93/68/EEG, achten wij het zoeklicht
thans geschikt om op de markt te brengen.
Den Haan Rotterdam BV
M. den Haan
Managing director / Directeur

Den Haan Rotterdam Rev. 1.3
Page 3 of 13
The electrical construction of the searchlight is manufactured in accordance with international standard EC 60598-1, conform the directives
73/23/EEC and 93/68/EEC.
able of contents
Introduction .......................................................................................................................2
Table of contents...............................................................................................................3
Safety notes......................................................................................................................4
Mounting instructions ........................................................................................................4
Mechanical ...................................................................................................................4
Electrical......................................................................................................................4
Maintenance......................................................................................................................5
Lamp replacement.........................................................................................................5
Preventive maintenance ................................................................................................5
Technical specification......................................................................................................6
Control panel................................................................................................................6
Motor housing ..............................................................................................................6
Searchlight head...........................................................................................................7
Guarantee.........................................................................................................................9
Annex 1 - Dimensions.....................................................................................................10
Annex 2 - Wire diagram DHR UC 12V – 24V with control panel.....................................11
Annex 3 - Wire diagram DHR UC 115V – 230V with control panel .................................12

Den Haan Rotterdam Rev. 1.3
Page 4 of 13
The electrical construction of the searchlight is manufactured in accordance with international standard EC 60598-1, conform the directives
73/23/EEC and 93/68/EEC.
Safety notes
WARNING
- Turn power off before inspection, installation or removal
Risk of fire
- Keep combustible materials away from lamp
- Use eye protection when handling lamp
- Do not touch glass with bare hands
- Do not exceed 105% of rated voltage
CAU ION
Risk of burn
- Allow lamp/fixture to cool before handling
- Turn power off before installing lamp
Lamp may shatter and cause injury if broken
- Do not use lamp if outer glass is scratched or broken
- Dispose of lamp in a closed container
- Wear safety glasses and gloves when handling lamp
Mounting instructions
Mechanical
Place the searchlight horizontal with plenty of space for the head to move in any direction. For
dimensions see annex 1
Electrical
nstall the electrical wiring according to annex 2.
Keep the distance between the power supply and lamp as sort as possible. Long wires will
increase the voltage drop near the sealed beam lamp, decreasing the light output.
Warning
Den Haan Rotterdam accepts no responsibility for any damage if the searchlight is
installed and / or used improper. When in doubt consult a qualified electrical
technician.

Den Haan Rotterdam Rev. 1.3
Page 5 of 13
The electrical construction of the searchlight is manufactured in accordance with international standard EC 60598-1, conform the directives
73/23/EEC and 93/68/EEC.
Maintenance
Lamp replacement
1. Switch off the main power
Caution – hot lamp. Let the lamp cool down, wait for at least 10 minutes before going
further
2. Open the drum
3. Pull the lamp out
4. Ensure that the replacement lamp is of the same type
5. Take a clean cloth to place the new lamp
(Do not touch the lamp with bare fingers, remove any fingertips with alcohol and rub it
dry)
6. Check the neoprene sealing of the front glass and rub it in with talcum powder
7. Close the drum
8. The searchlight is ready to use
Preventive maintenance
Clean the searchlight with clean water regularly. Do not use any aggressive cleaning agents.

Den Haan Rotterdam Rev. 1.3
Page 6 of 13
The electrical construction of the searchlight is manufactured in accordance with international standard EC 60598-1, conform the directives
73/23/EEC and 93/68/EEC.
echnical specification
Control panel
•P
nom.
: 15 W
•U
nom.
input : 12 – 24 VDC
•U
nom.
output motor (2x) : 4 – 10 VDC
•U output lamp : See input
•Protection class : P 20
•Electrical insulation class :
•Ambient temperature : 0 - 40°C
Motor housing
•P
nom.
motor : 6 W
•U
nom.
motor : 4 – 10 VDC
•Gear box motor : 1 : 370
•Tilt : + 15° / - 30°
•Max. Speed left / right approximate : 32 degree / sec
•Max. Speed up / down approximate : 5 degree / sec
•Housing:
- Material : Stainless steel 316
- Finish : Brushed
- Sealing : Neoprene, black
•Electrical insulation class :

Den Haan Rotterdam Rev. 1.3
Page 7 of 13
The electrical construction of the searchlight is manufactured in accordance with international standard EC 60598-1, conform the directives
73/23/EEC and 93/68/EEC.
Searchlight head
•Housing 180/150:
- Material : Stainless steel 316
- Finish : Brushed
- Sealing : Silicone, black
•Electrical insulation class :
•Optics : Sealed beam mirror reflector
•Protection class : P X6
•Ambient temperature : -25°C / + 40°C
•P
max.(lamp)
: 250W
•U
nom.
: 12 - 24VDC
•Housing 220/210:
- Material : Chromated seawater resistant aluminium
- Finish : UV-resistant powder coating, white RAL 9016
- Sealing : Silicone, black (220 only)
•Electrical insulation class :
•Optics : 210 - Sealed beam mirror reflector
220 – Aluminium reflector
•Protection class : 210 - P X5 / 220 – P66, c/w membrane vent
•Ambient temperature : -25°C / + 40°C
•P
max.(lamp)
: 210 - 1000W / 220 – 300W
•U
nom.
: 12V (220 only) / 24V / 115 /230 V
DHR 220
•Halogen lamp 230V – 300W
- Light intensity : 120.000 cd
- Angle of divergence : 15,5 x 21°
- Range : 345 metre
•Halogen lamp 24V – 250W
- Light intensity : 441.000 cd
- Angle of divergence : 10 x 14°
- Range : 664 metre
•Halogen lamp 12V – 100W
- Light intensity : 131.000 cd
- Angle of divergence : 9 x 16°
- Range : 362 metre

Den Haan Rotterdam Rev. 1.3
Page 8 of 13
The electrical construction of the searchlight is manufactured in accordance with international standard EC 60598-1, conform the directives
73/23/EEC and 93/68/EEC.
DHR 210
•Sealed beam lamp PAR64 230V - 1000W
- Light intensity : 400.000 cd
- Angle of divergence : 17 x 20°
- Range : 630 metre
•Sealed beam lamp PAR64 115V - 1000W
- Light intensity : 400.000 cd
- Angle of divergence : 10 x 24°
- Range : 630 metre
•Sealed beam lamp PAR46 24V – 250W
- Light intensity : 500.000 cd
- Angle of divergence : 7 x 8°
- Range : 700 metre (at 28V)
DHR 180
•Sealed beam lamp PAR56 26V – 170W
- Light intensity : 230.000 cd
- Angle of divergence : 9 x 8°
- Range : 480 metre (at 26V)
•Sealed beam lamp PAR56 12V – 100W
- Light intensity : 225.000 cd
- Angle of divergence : 9 x 5°
- Range : 475 metre
DHR 150
•Sealed beam lamp PAR46 28V – 250W
- Light intensity : 300.000 cd
- Angle of divergence : 12 x 11°
- Range : 550 metre (at 28V)
•Sealed beam lamp PAR46 12V – 100W
- Light intensity : 200.000 cd
- Angle of divergence : 11 x 6°
- Range : 450 metre

Den Haan Rotterdam Rev. 1.3
Page 9 of 13
The electrical construction of the searchlight is manufactured in accordance with international standard EC 60598-1, conform the directives
73/23/EEC and 93/68/EEC.
Guarantee
For this DHR remote controlled searchlight we grant a guarantee of 2 years. The guarantee
begins with the day when the equipment is sold or before, when it is operated for the first time.
The presentation of your invoice is your warranty.
Our guarantee covers faults in material or defects of fabrication. Our guarantee does not apply
to claims of which the cause is due to installation and operation faults, inexpert attempts to
repair, as well as to all damages due to wear and tear on parts subject to wear.
n our fabrication first quality, seawater resistant material is worked. f nevertheless, the unit
should give reason for a justified complaint, then you have, after our choice, a claim for the
retouching or replacement of the defective parts free of charge. Repair work under guarantee
will only be performed at our facilities or a company, duly authorized by us.
f you have to claim to our guarantee, send the defective unit or part of the unit with the
receipt or copy of invoice and statement of the defect free of charge to us.
Claims for damages on the transport shall not be recognized. The shipment risks are for account
of the purchaser, unless otherwise agreed with Den Haan Rotterdam.
Garantie
Op dit op a stand bedienbaar zoeklicht wordt een garantie gegeven van 2 jaar. De garantieperiode
begint op de dag van aanscha , o wanneer het zoeklicht is geïnstalleerd. De actuur is uw
garantiebewijs.
Onze garantie geldt voor abricage outen en materiaal gebreken. De garantie geldt niet indien door
installatie outen, verkeerd gebruik en / o slecht onderhoud gebreken ontstaan. Evenzo op slijtage
en normale veroudering.
Voor de abricage van dit zoeklicht zijn alleen zeewaterbestendige materialen gebruikt. Mocht
desondanks, het zoeklicht toch reden geven tot terechte klachten, dan kunt u het zoeklicht o de
de ecte onderdelen na overleg onder garantie laten repareren o vervangen. Reparatie vinden alleen
plaats door een medewerker van Den Haan Rotterdam o een door ons geautoriseerde persoon o
onderneming.
Als u een garantie claim hee t, dan kan het de ecte onderdeel o gehele zoeklicht, met een kopie
van de actuur met duidelijke omschrijving van de klacht, ge rankeerd naar ons worden opgestuurd.
Beschadigingen door transport vallen niet onder de garantie. Het transportrisico is voor de a nemer,
tenzij anders overeengekomen met Den Haan Rotterdam.

Den Haan Rotterdam Rev. 1.3
Page 10 of 13
The electrical construction of the searchlight is manufactured in accordance with international standard EC 60598-1, conform the
directives 73/23/EEC and 93/68/EEC.
Annex 1 - Dimensions

Den Haan Rotterdam Rev. 1.3
Page 11 of 13
The electrical construction of the searchlight is manufactured in accordance with international standard EC 60598-1, conform the
directives 73/23/EEC and 93/68/EEC.
Annex 2 - Wire diagram DHR UC 12V – 24V with control panel

Den Haan Rotterdam Rev. 1.3
Page 12 of 13
The electrical construction of the searchlight is manufactured in accordance with international standard EC 60598-1, conform the
directives 73/23/EEC and 93/68/EEC.
Annex 3 - Wire diagram DHR UC 115V – 230V with control panel
