EasyPro Stratus SRC Series User manual

Remove new piston cup(s) from protective
cardboard packaging. Set new piston cups
onto retainer plate, these parts will sit at
against each other.
6.
Remove old cylinders and discard.
3.
Remove screws from the head of compres-
sor using T25 Torx driver, remove the head
WARNING: Electrical shock hazard. Disconnect electrical
supply before performing maintenance. Vent all air lines
to release vacuum or pressure. Failure to follow these
instructions may result in death, re or electrical shock.
WARNING: Injury hazard. Product surfaces become very hot during
operation, allow surfaces to cool before handling.
WARNING: Do not use oil to lubricate parts. SRC compressors use
an oil less design. Using oil may result in failure of the unit.
1.
Mark the orientation of head plate(s) and re-
move. Mark the orientation of valve plate(s),
remove valve plate(s). Clean valve plates
with water based solvent, take care not to
scratch valve seats.
2.
Set new cylinder(s) on piston(s).
5.
Remove screws from cup retainer plate
with T15 Torx driver. Discard old cups and
retainer screws.
4.
Stratus SRC Series Repair Kit Instructions
Repair Kit
1. Piston Cups
2. Cylinders
3. Cyliner O-rings
4. Head O-rings
5. Cup Retainer Screws
*Repair kit contents may vary depending on your
compressor. The SRC50K contents are shown,
SRC25K will have half the components shown
for single cylinder repair.
Before beginning, you will need:
1. T15 and T25 Torx driver
2. Torque driver
3. Utillity knife
4. Clean work space
1.
2.
4.
3.
5.
Reinstall head over valve plate(s) checking
that orientation with ports is correct. Torque
screws to 50 inch-pounds
Remove old and install new head o-rings in
the o-ring grooves on top of valve plate
Press retainer plate with piston cup into cyl-
inder all the way to the piston. The cylinder
can be rotated to align the screw holes. Ap-
ply thread locking compound (Loctite®222)
to retainer screws, torque screws to 10-13
inch-pounds.
Check that orientation of the valve plate(s)
with ports is correct and place over
cylinders.
7.
10.
Stratus SRC Series Repair Kit Instructions
(800) 448-3873 • Grant, MI 49327 • www.easypropondproducts.com 9156 - 5/17
Unit must be unplugged
before servicing
Inspect the leaf valves for damage or wear.
NOTE: There is one intentionally “bent”
leaf valve per set. If leaf valves need to be
replaced, a complete leaf valve plate can be
ordered. The screws holding the leaf valves
are susceptible to breaking which makes in-
dividual leaf valve replacement very dicult.
Remove the cylinder o-ring(s) from the bot-
tom of valve plate(s) and install new o-rings.
9.
8.
12.11.
Visit easypropondproducts.com/resources for more information
Check that all external accessories such as relief valves and gauges are not damaged before re-operating product.
