UFO Illuminator 150 CDMXG User manual

Compact DMX Illuminator
Models covered by this manual:
UFO 150 CDMXG-A Glass, DMX - 120V
UFO 150 CDMXP-A Plastic, DMX - 120V
Universal Fiber Optics LLC,
6119A Clark Center Avenue | Sarasota | Florida 34238
Tel : 1 (800) UFO 5554 | Tel : [phone]
www.fiberopticli htin .com
Illuminator User Guide
Issue 2 | Revised: 24072013

Compact DMX Illuminator Ran e
1
INTRODUCTION
Thank you for purchasin this UFO illuminator.
Please read these instructions fully before connectin your unit to the electrical
supply, and keep them for future reference.
The UFO Compact DMX are a ran e of low profile illuminators which use 150W metal
halide dischar e lamps to ive much reater bri htness than those powered by
halo en lamps.
These models have a fast re-lampin feature (the lamp is mounted on a pull out
hatch at the rear) and are fitted with a DMX controller allowin a ran e of in-built
effects or control via a standalone controller.
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE
INSTALLATION CODE BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND
OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED
IMPORTANT
Do not operate without complete lamp enclosure in place or if lens is dama ed.
KEEP HARNESS IN PLACE WHEN IN OPERATION.
CAUTION: Hot surface. Keep away from curtains and other combustible materi-
als.
WARNING: RISK OF FIRE/INJURY TO PERSONS. Keep away from
combustibles. Unplu to chan e lamp. Do not touch lamp.
WARNING: RISK OF FIRE. Do not place lamp where the overhead surface is closer
than 0.2m to the illuminator.

Universal Fiber Optics 2
IMPORTANT SAFETY INFORMATION
1. Unplu and allow to cool before replacin lamp.
2. Lamp ets HOT quickly! Only contact plu when turnin on.
3. Do not touch hot lens, uard, or enclosure.
4. Do not remain in li ht if skin feels warm.
5. Do not look directly at li hted lamp.
6. Keep lamp away from materials that may burn.
7. Use only with a 150W or smaller lamp.
8. Do not touch the lamp at any time. Use a so cloth. Oil from skin may dama e
lamp.
9. Do not operate product with missin or dama ed uard, lamp containment
barrier, lens or fibre-optic harness.
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK OR INJURY TO
PERSONS
IMPORTANT SAFETY INSTRUCTIONS
Li hted Lamp is HOT:
WARNING – To reduce the risk of FIRE, ELECTRIC SHOCK OR INJURY TO PERSONS:
• Always disconnect the unit from the power supply before openin or attemptin to
perform any work on it.
• UNIT MAY GET HOT - always allow unit to cool down before handlin or
movin it.
• Do not touch or attempt to remove the lamp while it is hot.
• Ensure that the power supply is correct for the unit before powerin it up.
• Always ensure that the unit is properly EARTHED.
• Do not expose the unit to rain or moisture.
• Keep away from all combustible materials.
• Never attempt to tamper with the wirin or other internal components.
• Keep the unit away from as, oil and any other flammable or explosive materials.
• Indoor use only.
SAVE THESE INSTRUCTIONS

Compact DMX Illuminator Ran e
3
ILLUMINATOR LAYOUT
Item Description
1 Fibre port connector
2 Control button
3 Control button
4 Display
5 Microphone
6 Coolin fan rille
7 XLR socket
8 XLR socket
9 Lamp holder
10 Mains input socket & fuse holder and power LED
11 Hole with cover to access fibre optic connector retainin screw

Universal Fiber Optics 4
INSTALLATION GUIDE
In order for the Compact illuminator to function safely and efficiently it must be
installed accordin to this user manual. Please read all sections thorou hly before
switchin on the illuminator.
POWER SUPPLY REQUIREMENTS
Before plu in in the unit, please make sure that the supply is correct. Failure to do
so could cause the unit to malfunction. The unit requires a 120VAC 60Hz supply and
it MUST BE EARTHED. The illuminator units are provided with a cordset fitted with a
standard 3-pin plu .
POSITIONING THE UNIT
The illuminator can be mounted horizontally, vertically or upside-down on any flat
surface. Keyhole slots are provided on the base of the unit to allow for securin to a
surface. The illuminator is only suitable for use in a dry area.
If the unit is bein mounted at a hi her than the round level, block access below
the work area before installin .
Verify that any screws or bolts can safely bear the wei ht of the illuminator.

Compact DMX Illuminator Ran e
5
INSTALLATION GUIDE (Continued)
Verify that the supportin structure can safely bear the wei ht of all installed units,
cables and any other equipment. The minimum thickness of the mountin surface
must be no less than 19mm.
For horizontal mountin , it is recommended that the illuminator is secured to a solid
surface usin 4 x M4 or M5 screws or bolts and the keyhole slots. This is particularly
important if the illuminator location is not at round floor level.
To mount the illuminator vertically, first securely install 4 x M4 or M5 screws or bolts
at the required distances so that they will line up with the keyhole slots. The
illuminator can then be mounted onto them and slid into position. The bolts or
screws MUST then be fully ti htened.
To mount the illuminator under a surface, first securely install 4 x M4 or M5 screws or
bolts at the required distances so that they will line up with the keyhole slots. The
illuminator can then be mounted onto them and slid into position. The bolts or
screws MUST then be fully ti htened.
It is recommended that a ap of 200mm (8”) or more is le around the unit. This is to
allow air to circulate and prevent overheatin . The location must have free ventila-
tion.
CLEARANCE / VENTILATION

Universal Fiber Optics 6
INSTALLATION GUIDE (Continued)
CONNECTION
There are 3 main connections required, the fibre port, the mains power and the DMX
connections. Connect and secure the fibre optic connector to the fibre port before
connectin the electrical supply. Never run the illuminator with the fibre connector
unplu ed. The fibre optic connector is secured into the port by removin the small
cover on the top of the illuminator (see item 11 on pa e 3), and ti htenin the
retainin screw. The cover should then be replaced.
DMX data connections are provided at the rear of the illuminator, connection details
as follows
Like all data networks the DMX cable should be terminated on the DMX OUT of the
last illuminator on the network usin a terminator plu
OPERATION
This illuminator can be operated in stand alone mode, or can be connected to a
compatible DMX controller.
In Standalone Mode the Compact DMX can be used as a sin le independent
illuminator or in a Master Slave confi uration with several illuminators connected
to ether usin DMX leads. In Master Slave confi uration all addresses are set the
same and whatever pro ramme is selected on the “Master” DMX illuminator will also
be observed on the “Slave” illuminators.
In DMX mode the DMX controller can be pro rammed to control Compact DMX
illuminators either in a block (all same addresses) or independently (all different
addresses).

Compact DMX Illuminator Ran e
INSTALLATION GUIDE (Continued)
OPERATION (Continued)
When the DMX illuminator is powered up the unit will RESET durin which, the
followin flashin messa e will be displayed on the front panel display
(Item 4 Pa e 1):
When the illuminator is RESET the followin messa e will be displayed:
This indicates the illuminator has been set to address 001 by default.
PROGRAMMING
At any sta e durin pro rammin , when chan es are made the DMX may o
throu h the RESET phase as described above – this is normal.
Chan in Address
To chan e the address press the 2 buttons to the le of the display (Items 2 & 3 Pa e
1) simultaneously once the small indicator in the bottom ri ht of the display will o
out. Scroll for the required address as follows:
Once the selected address is found, there will be a short delay (may RESET) until the
small indicator illuminates confirmin the address is set.
7

Universal Fiber Optics
INSTALLATION GUIDE (Continued)
PROGRAMMING (Continued)
Color Wheel Built in Pro ams
To access the built in pro rammes as described in the User Guide proceed as
follows. Press the 2 buttons to the le of the display (Items 2 & 3 Pa e 1)
simultaneously twice and the followin messa e will be displayed:
Aer a short delay (may RESET) the small indicator will flash confirmin pro ramme
mode P01 is set as shown below. The illuminator will display white li ht:
Scroll throu h the Built in Pro rams until the desired pro ramme is reached there
will be a short delay (may RESET) until the small indicator flashes confirmin the
address is set. The set pro ramme will now run. The pro ramme will only run if le
in this mode, returnin to the Address Mode will stop the pro ram runnin .
To return to Address Mode press the 2 buttons to the le of the display (Items 2 & 3
Pa e 1) simultaneously three times.
Note 1: There is an Auxiliary mode which may be displayed as shown below. This is
not used. If in this mode press the 2 buttons simultaneously twice to return to
Address mode:
Note 2: In Master/Slave and Remote DMX controller operation the small indicator
flashes to indicate DMX data transmission
8

Compact DMX Illuminator Ran e
9
BUILT IN PROGRAMS
Program n mber F nction
P01 White
P02 Yellow
P03 Green
P04 Oran e
P05 Ma enta
P06 Blue
P07 Cyan
P08 Jade
P09 W,Y,G,O,M,B,C,J - flash chan e 2 seconds
P10 W,Y,G,O,M,B,C,J - flash chan e 5 seconds
P11 W,Y,G,O,M,B,C,J - flash chan e 10 seconds
P12 W,Y,G,O,M,B,C,J - flash chan e 30 seconds
P13 W,Y,G,O,M,B,C,J - flash chan e 60 seconds
P14 W,Y,G,O,M,B,C,J - flash chan e 2 seconds
P15 W,Y,G,O,M,B,C,J - flash chan e 5 seconds
P16 W,Y,G,O,M,B,C,J - flash chan e 10 seconds
P17 W,Y,G,O,M,B,C,J - flash chan e 30 seconds
P18 W,Y,G,O,M,B,C,J - flash chan e 60 seconds
P19 W,Y,G- flash chan e 2 seconds
P20 W,Y,G- flash chan e 5 seconds
P21 W,Y,G- flash chan e 10 seconds
P22 W,Y,G- flash chan e 30 seconds

Universal Fiber Optics 10
BUILT IN PROGRAMS
Program n mber F nction
P23 W,Y,G- flash chan e 60 seconds
P24 W,Y,G,O - flash chan e 2 seconds
P25 W,Y,G,O - flash chan e 5 seconds
P26 W,Y,G,O - flash chan e 10 seconds
P27 W,Y,G,O - flash chan e 30 seconds
P28 W,Y,G,O - flash chan e 60 seconds
P29 8 colors slow chan e (0.2 RPM)
P30 8 colors slow chan e (0.5 RPM)
P31 8 colors slow chan e (1.0 RPM)
P32 8 colors slow chan e (2.0 RPM)
P33 8 colors slow chan e (3.0 RPM)
P34 8 colors slow chan e (5.0 RPM)
P35 8 colors slow chan e (8.0 RPM)
P36 8 colors slow chan e (12.0 RPM)
P37 8 colors chasin slow chan e (1.0 RPM)
P38 8 colors chasin slow chan e (2.0 RPM)
P39 8 colors chasin slow chan e (3.0 RPM)
P40 8 colors chasin slow chan e (5.0 RPM)
PS1 W,Y,G,O,M,B,C,J - audio control
PS2 W,Y,G,O,M,B,C,J - audio control
PS3 W,Y,G- audio control
PS4 W,Y,G,O - audio control

Compact DMX Illuminator Ran e
11
DMX ADDRESSES
Channel
No.
F nction Address Val e Effect
(Colorwheel
versions)
Effect
(Dimmer wheel
versions)
01 Snap to color 0-15 Clear (white) Dim level 1
01 Snap to color 16-31 Color 1 (yellow) Dim level 2
01 Snap to color 32-47 Color 2 ( reen) Dim level 3
01 Snap to color 48-63 Color 3 (oran e) Dim level 4
01 Snap to color 64-79 Color 4
(ma enta)
Dim level 5
01 Snap to color 80-95 Color 5 (blue) Dim level 6
01 Snap to color 96-111 Color 6 (cyan) Dim level 7
01 Snap to color 112-127 Color 7 (jade) Dim level 8
01 9 color sequence 5
seconds
128-143 C,Y,G,O,M,B,C,J
5 seconds
N/A
01 9 color sequence 7
seconds
144-159 C,Y,G,O,M,B,C,J
7 seconds
N/A
01 9 color sequence
12 seconds
160-175 C,Y,G,O,M,B,C,J
12 seconds
N/A
01 9 color sequence
15 seconds
176-191 C,Y,G,O,M,B,C,J
15 seconds
N/A
01 9 color sequence
20 seconds
192-207 C,Y,G,O,M,B,C,J
20 seconds
N/A
01 9 color sequence
60 seconds
208-223 C,Y,G,O,M,B,C,J
60 seconds
N/A

Universal Fiber Optics 12
MAINTENANCE
1) Unplu unit from electrical supply and allow
to cool.
2) On the rear of the unit, unscrew the two
knurled securin nuts (A) which hold the lamp
holder in position.
3) Use the handle (B) to withdraw the lamp
holder(C) from the illuminator.
4) Unplu the old lamp from its ceramic holder.
5) Plu the new lamp into the holder, makin
sure that you use a bulb of the same
specification as to that which was removed.
Also make sure not to touch the lass part of
the lamp.
6) Slide the lamp holder plate back into
position and ti hten the two retainin nuts.
1) Unplu unit from electrical supply and allow
to cool.
2) The fuse is located in a drawer under the mains
input connector.
3) Open the fuse drawer.
4) Withdraw fuse from its holder
5) Replace with identically specified fuse - see
specification table in this manual.
6) Close the fuse drawer and power up the
illuminator.
LAMP REPLACEMENT
FUSE REPLACEMENT

Compact DMX Illuminator Ran e
13
MAINTENANCE (Continued)
Disconnect unit from power supply and allow to cool before attemptin any
cleanin of the unit.
The body of the unit can be cleaned with a so, damp cloth - do not use any
abrasives on the unit.
The fans and vents should be kept clear by periodically blowin them out with
compressed air.
Non-abrasive lass cleaner can be used to clean the lass lens inside the unit.
CLEANING THE UNIT
Date Maintenance Undertaken
Please note that a record of all maintenance MUST be kept in the table below,
indicatin what maintenance was undertaken and when.

Universal Fiber Optics 14
TROUBLESHOOTING
Problem Probable ca se(s) Remedy
Unit is completely dead -
Lamp and LED power
indicator are not
illuminated
Main fuse blown Check and replace fuse.
No power to unit Check that power is switched on and
power supply is plu ed in.
LED power indicator & fan
are on, but no li ht is out-
put
Lamp blown Replace lamp
Thermal switch activated
Allow unit to cool for 5 to 10
minutes and investi ate reason for
overheatin
Lamp wires are not
connected
Check plu connection - ensure lamp
is properly seated in its holder and
the pins are fully mated
Poor li ht output
Lamp needs replacin Replace lamp
Unit needs cleanin Clean lass lens
Incorrect power supply Ensure power supply is 120VAC 60Hz
Fibre port connector not
plu ed in correctly
Ensure fibre port connector is
plu ed in correctly, and that the
screw is ti htened up properly
Lamp oin on & off
randomly Unit is overheatin
Allow unit to cool for 5 to 10
minutes and investi ate reason for
overheatin

Compact DMX Illuminator Ran e
15
TECHNICAL SPECIFICATIONS
Description 150W DMX
Port connector size 30mm diameter
Fibre type Glass / polymer
Supply volta e 120VAC 60Hz
Lamp power 150W
Input power 180VA @ 120VAC
Start up current 0.3A @ 120VAC
Runnin current 0.75A @120VAC
Min. ambient temp. -20°C
Max. ambient temp. 40°C
Thermal protection Thermal switch
Ballast type Electronic
Fan tye (polymer fibre) Papst 8800N
Fan type ( lass fibre) Papst 8830N
Power cord IEC mains cable
Main fuse 4 Amp
Lamp type Metal halide
Lamp model Philips CDM-SA/T
or CDM
Lamp life c. 9000h
Lamp colour temp. 4200K (SA/T)
3000K (CDM)
Lamp CRI 96 (SA/T)
85 (CDM)
Control options DMX, standalone, master/slave
DMX channels 1
Protocol DMX 512
Colour wheel 7 colours plus white
Standard colours Green, blue, yellow, ma enta, jade, cyan, oran e
Acoustic ratin (polymer fibre) 38.0dB(A)
Acoustic ratin ( lass fibre) 23.0dB(A)
Operatin environment Indoor / dry
Protection ratin IP20
Material Sheet steel
Colour Black
Size 298x232x144 mm
Wei ht 4.4k

Universal Fiber Optics
NOTES
16

Compact DMX Illuminator Ran e
NOTES
17

Universal Fiber Optics 18
NOTES

Universal Fiber Optics LLC,
6119A Clark Center Avenue | Sarasota | Florida 34238
Tel : 1 (800) UFO 5554 | Tel : [phone]
www.fiberopticli htin .com
