Diall 2931 Quick setup guide

Safety & Assembly Instructions
Rechargeable 1Million Candle Power
Spotlight
Model no.2931
These instructions are for your safety. Please read through them
thoroughly before use and retain for future reference.
Parts Supplied
Ref
Description
Rechargeable
1M Candle
Power
Spotlight
AC-DC
Battery
Charger
C _ t^ar adaptor
Carrying belt
Illustration
Qty
<&
Before you start
• Checkthe pack and make sure youhave allofthe partslistedabove. Ifnot, contact
yourlocalB&Q store who will be able to help you.
Features
1. Powerful quartz halogen spotlight.
2. Twoposition handle to ensure comfortablegrip.
3. Dual recharge, either AC/DC chargeror 12V DC car plug adaptor(included).
B&Qpic.Chandlers Ford.Hampshlre.S053 3YX
Visilusatwww.dly.com
04054979
110721

Operating Instructions
• Push the handle button and turn the handle to upper or lower position. Upper pistol
for pin pointing long range objects, lower lantern profile for searching around
• Charge the battery prior to initial use (see CHARGINGTHE BATTERY).
• Turn the lantern ON and OFF by the switch on the main body.
Charging the Battery
The spotlight must be switched "OFF" whilst charging.
• AC/DC adaptor charging the battery
Plug the charger into the wall outlet. Insert the charger plug into the DC jack of the
spotlight; Time required to fully
charge the battery is approximately 20 hours.
•Car plug adaptor charging the battery
Plug the included car plug adaptor into the cigarette lighter socket on your car (truck
or boat ),insert the adaptor plug into the DC jack of the spotlight. This method is
recommended for
emergencies or for a quick charge only.This method should not
be
used for long-term charging. Charge the spotlight for no longer than 2 hours.
CHANGING THE HALOGEN BULB: Replacement bulb type:H3 6V 35W
1. Remove the reflector assembly by turning the head cover anticlockwise.
2. Lifeout the reflector assembly taking care not to pullon the wires.
3. Remove cable tie.
4. Slide sleeve downwards.
5. Slide clear plastic insulation sleeve downwards.
6. Disconnect spade connector.
7. To remove the bulb, squeeze the wire clipand slide itout through it's slot. Note which
way round it faces.
8. Life out the old bulb.
9. Replace the bulb with a new H3 6V 35W halogen bulb.
Do not touch the
glass with your bare hands as finger grease will significantly reduce
the life of the bulb. In the
case of inadvertent finger contact, simply clean the glass
thoroughly with a cloth moistened with methylated spirit.
10.Re-connect the connector with that of the new bulb ensuring the insulation fully covers
the connector.
11.Clip the spring wire back into place.
12.Refit the reflector assembly ensuring correct alignment.
mw*
W-S-H-HHS
B&Q pic, Chandlers Ford.Hampshire.S053 3YX
Visit us at www.diy.com
04054979
110721

To Replace Fuse in the Car Adaptor
Current Fuse Rating:(2A/250V)
1 .Remove the car adaptor head cover by turning the outer ring anti-clockwise.
2.Pick out the fuse from fuse holder and replace a new one.
3.Refit the car adaptor cover by turning the outer ring clockwise.
To Replace Rechargeable Battery
Battery Type:(6V 4AH)
1.Remove the lamp hood by turning it counter-clockwise.
2.Screw off the battery cover, pull out battery and it's terminals, replace the 6V 4AH
lead acid battery with a new one.
3.Refit the battery cover, and head cover.
Care and Cleaning
Warnings
• Lens becomes very hot during operation. This is designed for intermittent use only
Continuous use is specifically not recommended and may cause damage to the unit.
•
Never block lens and reflector during operation.
• Do not
shine directly into eyes.
• Tc-reduce the risk of electric shock, unplug the unit and allow to cool before
attempting any cleaning and replacement.
• To avoid
the risk of damage, replace the bulb, fuse and battery with same rating
only.
Note:
• The female connectors must be connected to the leads of the battery correctly, red
wire to positive(+)
lead and black wire to negative(-) lead. REVERSE POLARITY
WILL DAMAGE THE UNIT.
Important:
•Never leave the battery discharged, recharge battery immediately afterdischarging.
• Recharge battery every 3 months even if the unit is not used.
• When the lead acid battery supplied with the product expires, it should be removed
from the spotlight for recycling. Please contact your local authority for recycling
information.
B&Qpic, Chandlers Ford,Hampshire,S053 3YX
Visit usat www.diy.com 04054979
110721

Conformity with Directives
• This product is CE marked to denote conformitywithDirectives89/336/EEC(EMC
Directive).73/23/EEC(Low voltage Directive) and 95/54/EC (Automotive EMC
Directive).
• Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local Authority or
retailer for recycling advice.
Information on Waste Disposal for Consumers of Electrical & Electronic Equipment
This mark on a product and/or accompanying documents indicates that when it is to be
disposed of, it must be treated as Waste Electrical &Electronic
Equipment(WEEE).Any WEEE marked waste products must not
be mixed with
general household waste, but kept Separate for the
treatment, recovery and recycling of the materials used. For proper
treatment, recovery and recycling .please take all WEEE marked
waste to your Local Authority Civic waste site, where it willbe
accepted free of charge.If all consumers dispose of Waste Electrical
&Electronic
Equipment correctly, they willbe helping to save valuable resources and
preventing any potential negative effects upon human health and the environment, of
any hazardous materials that the waste may contain.
Please Recycle Your Spent Batteries
Batteries should not be disposed of in unsorted municipal waste, but separately collected
to facilitate the correct treatment and recycling of the
substances they contain. The
recyclingof batteries ensures the recovery of these valuable materials and prevents any
potentially harmful effects upon both the environment and human health. Please contribute
to battery recycling by segregating all spent batteries and actively participating in their
collection
and recycling .Various battery collection schemes willbe in operation in different
areas of the country. However, battery collection bins will be available at the retail stores
that sell batteries as well as schools, libraries and other public buildings.
