Diamatic BMGP-600 User manual

Grinding & Polishing
MODEL BMGP-600 GRINDER
SECTION 2 SAFETY INSTRUCTIONS
1
OPERATING MANUAL
JANUARY 2008
Grinding & Polishing
MODEL
BMGP-600 Grinde
r
Technical Data 1
Safety Instructions 2
General 3
Transport 4
Initial Operation 5
Operation 6
Maintenance 7
Electrical Systems 8
Fault Diagnosis 9
Spare Parts and Tooling 10

MODEL BMGP-600 GRINDER
SECTION 1 TECHNICAL DATA
1
OPERATING MANUAL
DECEMBER 2008
Grinding & Polishing
1.1 Rating
1.2 Unit specifications
1.3 Operative range and correct usage
1.4 Stand-by power supply
1.5 Machine type designation
CONTENTS – SECTION 1

MODEL BMGP-600 GRINDER
SECTION 1 TECHNICAL DATA
2
OPERATING MANUAL
DECEMBER 2008
Grinding & Polishing
Unit / Designation: Diamatic Grinding Machine
Machine Type: BMGP-600
Manufacturer:
Technical Data:
Grinding Machine BMGP-600
Dimensions:
BMGP-600
Length (with handle extended) 63 in / 1600 mm
Length (with handle down) 42.5 in / 1080 mm
Width 26 in / 660 mm
Height 47.5 in / 1207 mm
Weight 700 lbs / 318 kg
Diamatic US Diamatic BV
13201 North Santa Fe Utrechthaven 12
Oklahoma City, OK 73114 3433 PN Nieuwegein
United States of America THE NETHERLANDS
Local: 405-478-3440 T +31(0)30 – 601 88 66
toll-free: 800-256-3440 F +31(0)30 – 601 83 33
1.1 RATING
1.2 UNIT SPECIFICATIONS

MODEL BMGP-600 GRINDER
SECTION 1 TECHNICAL DATA
3
OPERATING MANUAL
DECEMBER 2008
Grinding & Polishing
Motor HP: 7.5 HP
Power Source: 208-230 VAC, single phase, 60 Hz
Current: 29.5 – 32 FLA
Motor RPM: 1725 RPM
Power Cord Length: 55 feet
Vacuum hose port: 3 inch diameter
Weight: 700lbs
Tool RPM: 400 RPM
Tools Available: Various diamond tools and optional slicer kit with tungsten
carbide cutters. See section 10.2 for a listing.
Cleaning path: 23" width
Recommended
vacuum: Model BDC-1324 or Model BDC317P
1.3 OPERATIVE RANGE AND CORRECT USAGE
The BMGP-600 is exclusively designed to process horizontal
surfaces. The machine must not be used for other purposes. The
manufacturer will not be liable for damage resulting from
incorrect usage. In these cases, the user takes responsibility for
all risks.
1.4 STAND-BY SUPPLY (GENERATO
R
)
If the BMGP-600 may be operated using power from a
generator, the generator must be operated in accordance with
the current U. S. National Electric Code guidelines (this
applies, but is not limited to, the protective earth conductor in
particular) in order to ensure that all safety devices are
functioning and to eliminate possible damage to electrical
components.

MODEL BMGP-600 GRINDER
SECTION 1 TECHNICAL DATA
4
OPERATING MANUAL
DECEMBER 2008
Grinding & Polishing
1.5 MACHINE TYPE DESIGNATION
Product Type
*POD Technolo
gy
Workin
g
width in mm
BMG P - 600
*Note: POD = Point Of Development

MODEL BMGP-600 GRINDER
SECTION 2 SAFETY INSTRUCTIONS
5
OPERATING MANUAL
DECEMBER 2008
Grinding & Polishing
2.1 Warnings and symbols
2.2 Organizational measures
2.3 Personnel selection and qualification
2.4 Safety precautions applicable to some operating sequences
2.5 Special work within the scope of use of the equipment and maintenance
activities as well as repairs during operation
2.6 Definition of the safety off position
2.7 General Safety Considerations
2.8 Electrical engineering regulations
CONTENTS – SECTION 2

MODEL BMGP-600 GRINDER
SECTION 2 SAFETY INSTRUCTIONS
6
OPERATING MANUAL
DECEMBER 2008
Grinding & Polishing
The following denominations and symbols are used in the Operating
Instructions to highlight areas of particular importance:
2.1 WARNINGS AND SYMBOLS
Symbol of operational safety.
In these Operating Instructions this symbol will be
shown next to all safety precautions that are to be
followed to maximize safety and equipment
performance. Follow these instructions and take
special care in these circumstances. In addition to
these instructions, the general safety precautions and
accident prevention guidelines are also to be followed.
Particular details regarding the economical use of the
equipment.
Information, instructions and restrictions with regard to
possible risks to persons, property or equipment.
Warning of dangerous voltages.
Indicates protective devices in electrical appliances.

MODEL BMGP-600 GRINDER
SECTION 2 SAFETY INSTRUCTIONS
7
OPERATING MANUAL
DECEMBER 2008
Grinding & Polishing
In addition to these Operating Instructions, general and legal regulations
regarding accident prevention and environmental protection must be complied
with per local regulations.
Such duties may, for example, relate to the handling of hazardous substances,
or the provision and wearing of personal protection equipment, as well as
compliance with traffic regulations.
The Operating Instructions must be supplemented by other instructions,
including the duty to supervise and report incidents relating to particular
working practices, for example work organization, work procedures and
personnel safety.
Personnel entrusted with working with the machine must read and understand
the Operating Instructions before starting work, paying specific attention to the
Safety information. To read these instructions after work has commenced is too
late. This particularly applies to incidental activities such as setting up the
equipment, carrying out maintenance work or training staff to work with the
Indicates where consultation with the manufacturer is
required.
Instructions relating to periodic checks.
2.2 ORGANIZATIONAL MEASURES
These Operating Instructions are to be kept with the machine, and
must be within reach at all times!
Reference to important instructions contained in the
Operating Instructions.

MODEL BMGP-600 GRINDER
SECTION 2 SAFETY INSTRUCTIONS
8
OPERATING MANUAL
DECEMBER 2008
Grinding & Polishing
machine. Personnel must also read all supplemental manuals from other
manufacturers.
From time to time the working practices of the operators are to be checked by a
supervisor, especially regarding awareness of safety and hazards.
Observe all applicable local, state and Federal safety regulations that pertain to
the equipment, the products being operated and the substances being removed
from the surface.
Operators must tie back long hair and avoid wearing loose clothing or jewelry,
including rings. There is a risk of injury by items getting caught, or being drawn
into moving machinery.
The use of appropriate gloves and non-skid footwear are recommended when
working with this machine.
Follow the OSHA and other applicable regulations for approved respiratory
protection standards when operating this machine in a dry operation with a dust
collector to avoid possible airborne contaminants. Grinding and cutting
concrete produces dust that may generate airborne respirable crystalline silica
which can lead to silicosis and death.
Do not use in dry operation without an approved dust collector system to
reduce or eliminate the escape of potentially hazardous or nuisance dust into
the environment.
All safety and hazard notices at or on the machine must be kept complete and
legible.
If safety-critical changes occur to the machine or its working method, the
machine must be shut down immediately. The cause of the fault must be
established and remedied.
This applies in particular to the fitting and adjustment of safety devices.
Use personnel protection equipment as required by OSHA and
other local regulations! Take notice of all safety and hazard
notices on the machine!

MODEL BMGP-600 GRINDER
SECTION 2 SAFETY INSTRUCTIONS
9
OPERATING MANUAL
DECEMBER 2008
Grinding & Polishing
Spare parts must comply with the technical requirements specified by the
manufacturer. This is always guaranteed if original spare parts are used.
Intervals for recurring checks and inspections specified in these Operating
Instructions must be complied with.
To perform maintenance work correctly, it is imperative to be equipped with the
proper tools for the task.
The location and the operation of fire extinguishers must be made known on
each work site.
Take note of the facilities for reporting and fighting fires.
Fundamental duties:
Work on the machine may only be undertaken by trained personnel.
Only trained personnel may be employed. Note the statutory minimum age.
Clearly specify the responsibilities of personnel for operation, setting up,
servicing and maintenance work.
Make sure that only authorized personnel operate or work on the machine.
Define responsibilities of the machine operator, with regard to traffic safety
regulations, and inform him not to take instructions from third parties who may
not be complying with the local safety requirements.
Personnel, who are being trained to operate equipment, may only use the
machine under constant supervision of an experienced person.
Changes, additions or conversions to the machine must not be
made, without the manufacturer’s permission!
2.3 PERSONNEL SELECTION AND QUALIFICATION

MODEL BMGP-600 GRINDER
SECTION 2 SAFETY INSTRUCTIONS
10
OPERATING MANUAL
DECEMBER 2008
Grinding & Polishing
.
Do not allow any method of working that impairs safety.
Recognized official procedures have to be used to ensure the machine is
operated in the safest and best conditions.
Check the machine visually for any damage and defects at least once a day.
In the event of operational malfunctions the machine must be shut down
immediately and secured. Some examples of abnormalities include unusual
noise and vibration.
Faults must be immediately remedied.
Carry out the switch on, and switch off, operations in accordance with the
operations manual.
Before turning on the machine verify that no one can be endangered when the
machine starts up.
Do not turn off the dust collector while the machine is running.
Work on electrical equipment may only be performed by a skilled
electrician or by trained persons under the supervision of a skilled
electrician, as well as in accordance with the local electrical
engineering regulations.
2.4 SAFETY PRECAUTIONS APPLICABLE TO SOME
OPERATING SEQUENCES
Only operate the machine when all safety devices, and related
safety equipment, are present and operational!
Secure the work area around the machine in public areas
providing a safety distance of at least 6.5 feet (2 meters) from the
machine.

MODEL BMGP-600 GRINDER
SECTION 2 SAFETY INSTRUCTIONS
11
OPERATING MANUAL
DECEMBER 2008
Grinding & Polishing
Before starting the machine, survey the work area for hidden obstructions
and/or uneven cracks or joints.
Do not expose machine to rain or use in standing water conditions.
Keep work area well lit.
Do not allow machine to cross over the edge of the concrete slab or work
surface.
Keep work area clean. Cluttered work areas and debris buildup on floors
creates an unsafe work environment.
Avoid flammable liquids or gases. Power tools produce sparks during
operation and when starting or stopping electric motors. Never use machinery
in dangerous sites containing materials that are combustible or explosive.
Keep children and visitors away from the work area at all times.
Refer to the MSDS of all substances in and around the machine and follow the
appropriate safety guidelines associated with the use/exposure of the
substance.
Never pull machine by power cord, run over cord with machine or forklift, or pull
on cord by extending machine distance from power source too far. Connect
power cord to power source and power cable extensions with approved plugs
All persons in the proximity of the machine must wear OSHA
approved ear and eye protection, as well as safety shoes. In
addition, the machine operator must wear close fitting protective
clothing.
Use only extension cables, used for extending the main cable, that
are sized and marked in accordance with the overall power
consumption of the machine and valid U. S. National Electric Code
guidelines. See Section 2.8 for electrical information.

MODEL BMGP-600 GRINDER
SECTION 2 SAFETY INSTRUCTIONS
12
OPERATING MANUAL
DECEMBER 2008
Grinding & Polishing
and with machine power switch turned off. If the cord is damaged, disconnect
from power and repair immediately.
Keep proper footing and balance at all times.
Keep machine clean and use sharp cutters or diamond plugs that are in good
condition. Keep handles dry, clean and free from oil and grease. Follow
instructions for lubricating and changing accessories or tools.
Do not carry or transport machine with finger or hand on the power switch while
power cord is connected to power source.
Do not leave the machine running unattended. Turn the power off. Always
have full control of the machine until all machine components have come to a
complete stop.
Check to see that wrenches and tools, or any other loose objects are removed
from machine before turning it on.
Watch what you are doing. Use common sense. Do not operate machine
when you are not fully alert.
Do not operate machine while under the influence of drugs, alcohol, or any
medication.
Before any use of the machine, check for damaged parts that should be
replaced. Check for alignment of moving parts, binding of moving parts,
breakage of parts, mounting of cutter on diamond tools and any other condition
that may affect machine operation. A guard, power switch or other part that is
missing or damaged should be properly repaired or replaced by an authorized
service center. Do not operate machine if power switch does not turn machine
on and off.
Do not remove guards or covers that have been factory mounted. They
perform important safety roles. Keep them in the proper positions.
Extra care must be taken to ensure that tools are correctly mounted on the
correct holders and that tool holders and mounting brackets are secured in their
proper position. Damage to the tools, holders and floor surface and/or injury
can occur if not properly tightened and secured.

MODEL BMGP-600 GRINDER
SECTION 2 SAFETY INSTRUCTIONS
13
OPERATING MANUAL
DECEMBER 2008
Grinding & Polishing
Always keep the motor cooling fan guard uncovered. Do not block vent
openings of the guard over the motor cooling fan. Vent openings are
necessary for adequate motor cooling. Do not operate motor with fan guard
removed.
Never touch moving parts such as tool holders, cutters, diamond plugs, or
motor cooling fan, etc.
Do not modify machine from its original design without written permission of the
manufacturer. Non-authorized modifications can lead to serious injury or death.
Refer to this operations and maintenance manual frequently and use it to
instruct others who may operate the machine.
Verify that the operator controls are working correctly. Do not operate the
machine if the operator controls are not working correctly. Test the stop, start
and emergency stop controls each time you start the machine.
If your machine is equipped with a variable speed drive, make sure the speed is
set at its lowest speed setting before starting the machine.
Mechanical servicing work:
Put the machine in the Safety off position as described in Section 2.6 before
carrying out any service work on the machine.
Follow any special safety instructions in sections on servicing the machine. See
Sections 7.1 – 7.9.
2.5 SPECIAL WORK WITHIN THE SCOPE OF USE OF THE
EQUIPMENT AND MAINTENANCE ACTIVITIES AS WELL
AS REPAIRS DURING OPERATION

MODEL BMGP-600 GRINDER
SECTION 2 SAFETY INSTRUCTIONS
14
OPERATING MANUAL
DECEMBER 2008
Grinding & Polishing
Service and maintenance intervals specified in these Operating Instructions, as
well as information on the replacement of parts must be undertaken and/or
complied with.
These activities may only be undertaken by qualified personnel.
Never attempt to repair machine unless you are completely familiar with proper
procedures and techniques required.
The operator must be given information about maintenance and work
procedures before starting the cleaning process. This includes, but is not
limited to the following:
•Procedures that are related to normal operation
•Methods of tools adjustment on the machine, and its safety devices,
•All “ON and OFF” functions that have to be carried out according to the
operation manual
•Methods for maintenance and repair.
If the equipment is switched off in order to carry out maintenance, repair, or
adjustment, it must be secured against unintended restart.
Switch OFF and disconnect the machine from the power supply.
See Section 2.6 Safety off position for specific details.
Always dispose of the contents of the dust bin or of a connected dust collector
before loading the machine onto a vehicle.
Observe the local waste disposal regulations; in uncertain situations ask the
next higher authority.
Do not use any aggressive cleaning materials.
Only use lint-free cleaning cloths.
Always verify that any bolted connections that were loosened during service
and maintenance work are properly secure and tight.
If safety devices need to be removed or dismantled during service and repair,
these safety devices must be reinstalled, and inspected immediately after
completion of the servicing and repair work.

MODEL BMGP-600 GRINDER
SECTION 2 SAFETY INSTRUCTIONS
15
OPERATING MANUAL
DECEMBER 2008
Grinding & Polishing
Make sure that process materials and replaced parts are disposed of safely and
in an environmentally friendly manner.
Make sure that electrical components used for replacement purposes comply
with the original parts and are correctly adjusted if necessary.
Definition: The machine is in a safe condition where it cannot be a hazard.
Putting the equipment in the Safety off position involves:
•Switching off the machine.
•Switching off the dust collector (if being used).
•Waiting for all drives to stop.
•Disconnect from power source.
•Securing against unintended restart.
Work on electrical equipment may only be performed by a skilled
electrician or by trained persons under the supervision of a skilled
electrician, as well as in accordance with the local electrical
engineering regulations.
2.6 DEFINITION OF THE SAFETY OFF POSITION
2.7 GENERAL SAFETY CONSIDERATIONS
Any machine, if it is not used according to regulations, may be
hazardous during operation, set-up and servicing. The machine
owner is responsible for compliance with the safety regulations
during operation and maintenance, and for the use of safety
devices supplied with the machine, as well as the provision of
appropriate additional safety devices!

MODEL BMGP-600 GRINDER
SECTION 2 SAFETY INSTRUCTIONS
16
OPERATING MANUAL
DECEMBER 2008
Grinding & Polishing
The electrical components of the equipment must be inspected regularly.
Defects such as loose connections or scorched cables must be replaced
immediately. Call a skilled electrician or our Customer Service.
A second person must be in attendance while the electrician is working on the
equipment.
The work area must be secured against any third party entering the work area,
by means of a red and white safety chain and a danger sign. Use only tools that
are insulated against electricity.
Only start work after you are familiar with the electrical engineering regulations
that apply to the local area.
Only use multi-meters that complies with the regulations when troubleshooting.
From time to time check multi-meters to ensure that they are operating
correctly.
Before connecting machine to a power source, be sure the voltage supplied is
the same as that specified on the nameplate of the machine or motor. A power
source with voltage greater than that specified for the machine can result in
serious injury to the user and damage to the machine. If in doubt, do not plug
in machine. Using a power source with voltage less than the nameplate rating
is harmful to the motor.
2.8 ELECTRICAL ENGINEERING REGULATIONS
Work on electrical equipment may only be performed by a skilled
electrician or by trained persons under the supervision of a skilled
electrician, as well as in accordance with the local electrical
engineering regulations.
Use only extension cables, used for extending the main cable, that
are sized and marked in accordance with the overall power
consumption of the machine and the U. S. National Electric Code
guidelines.

MODEL BMGP-600 GRINDER
SECTION 2 SAFETY INSTRUCTIONS
17
OPERATING MANUAL
DECEMBER 2008
Grinding & Polishing
It is important that the operator understands the electrical requirements for
using extension cords. The length of extension cord should be limited to the
electric
supply limitations and should never exceed 100ft in length. In addition, you
should only use (3) three conductor cords on the single-phase machines. Make
sure that any extension cord used is in good condition. Disconnect the power
source and replace or repair damaged cords and plugs before starting the
machine.
When using an extension cord, be sure to use a cord heavy enough to carry the
current the machine will draw. An undersized cord will cause a drop in line
voltage, resulting in loss of power and overheating. See Section 3.0 for the
table showing the correct size and type of conductor to use, depending on cord
length
and nameplate ampere rating. If in doubt, use the next heavier gauge. As the
gauge number decreases, the cord thickness increases.
When a machine is used with any extension cord, be sure to use plugs and
receptacles rated for proper voltage and amperage as prescribed by the
National Electric Code. Make sure that all extension cords are wired the same,
matching wire colors and that the ground wire (green) is secured in its proper
position.

MODEL BMGP-600 GRINDER
SECTION 3 GENERAL
18
Grinding & Polishing
OPERATING MANUAL
DECEMBER 2008
3.1 Range of application
3.2 Scope of supply
3.3 Description of the machine
3.4 Operating elements
3.5 Electric components
3.6 Driving part
3.7 Care and maintenance
CONTENTS – SECTION 3

MODEL BMGP-600 GRINDER
SECTION 3 GENERAL
19
Grinding & Polishing
OPERATING MANUAL
DECEMBER 2008
Typical applications for the BMGP-600 include the removal of thick, horizontal
elastomeric floor coatings and adhesives such as tile mastics or carpet glue. In
addition, the machine is capable of leveling uneven and undulating floors. This
includes the optimization of surfaces, concrete polishing, wood sanding and
removing tiger striping after shot blasting.
Depending on the application, the diamond disc holder can be fitted with
several different types of diamond-grinding discs.
Scope of supply of the machine:
•Grinding machine (BMGP-600)
•Operating manual (1x)
3.1 RANGE OF APPLIC
A
TION
3.2 SCOPE OF SUPPLY
