WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT
Repair instructions
C-SC_CSSM
Version 1.0
2015-07-20
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 1of 55

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT
Contents
C-SC_CSSM
Version 1.0
2015-07-20
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 2of 55
1. Models described
2. Technical data
3. Notes and requirements
4. Tools required
5. Lubricants and auxiliary substances required
6. Removal
7. Fitting
8. Connection diagram

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT
1. Models described
C-SC_CSSM
Version 1.0
2015-07-20
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 3of 55
These repair instructions describe how to repair the following models:
Model Order number
WSG 11-125R 7 221 86 .. .. .
WSG 11-125RT 7 221 87 .. .. .
WSG 11-150R 7 221 88 .. .. .
WSG 11-150RT 7 221 89 .. .. .
WSG 15-125PR 7 221 90 .. .. .
WSG 15-125PRT 7 221 91 .. .. .
WSG 15-150PR 7 221 92 .. .. .
WSG 15-150PRT 7 221 93 .. .. .
WSG 15-70InoxR 7 221 94 .. .. .
WSG 15-70InoxRT 7 221 95 .. .. .
WSG 17-125R 7 222 14 .. .. .
WSG 17-125RT 7 222 15 .. .. .
WSG 17-150R 7 222 16 .. .. .
WSG 17-150RT 7 222 17 .. .. .
WSG 17-125PR 7 222 18 .. .. .

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT
1. Models described
C-SC_CSSM
Version 1.0
2015-07-20
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 4of 55
Model Order number
WSG 17-125PRT 7 222 19 .. .. .
WSG 17-150PR 7 222 20 .. .. .
WSG 17-150PRT 7 222 21 .. .. .
WSG 17-70InoxR 7 222 22 .. .. .
WSG 17-70InoxRT 7 222 30 .. .. .

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT
2. Technical data
C-SC_CSSM
Version 1.0
2015-07-20
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 5of 55
Technical data
All the technical data can be found in the operating instructions for the model.
Test data
Up-to-date test data for all models can be found on the FEIN Extranet (Customer Service →Repair Guides).
Lubricants
The lubricants and container sizes available from FEIN can be found on the FEIN Extranet (Customer Service →Repair Guides).
Lists of spare parts
Lists of spare parts and exploded views are available online at www.fein.com

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT
3. Notes and requirements
C-SC_CSSM
Version 1.0
2015-07-20
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 6of 55
Please note
These instructions are only intended for persons with suitable technical training. It is assumed that the reader has mechanical and
electrical training.
Only use original FEIN spare parts.
Provisions
Please note that power tools may only be repaired, maintained and checked by a trained electrician, as improper repair can result in
serious risks to the user.
The provisions set out in DIN VDE 0701-0702 should be observed after repairs.
The relevant accident prevention regulations of the employer’s liability insurance associations are to be observed when
commissioning.
The German Equipment and Product Safety Act [ProdSG] applies for correct use.
Outside Germany, the regulations applicable in the relevant country must be observed.

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT
4. Tools required
C-SC_CSSM
Version 1.0
2015-07-20
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 7of 55
Standard tools Special tools
Plastic hammer Drawing-off socket cap 6 41 04 150 00 8
Cross-tip screwdriver PH2 Chuck cone 19 mm 6 41 07 019 00 7
Torx screwdriver T15; T20 Chuck cone 26 mm 6 41 07 026 00 0
Punch Drawing-off plate 6 41 02 069 00 7
Arbor press Pipe 6 41 01 002 00 4
Ball bearing support 19 mm; 26 mm Assembly aid 6 41 22 121 01 0
Sleeves •35 mm inner diameter
•14 mm inner diameter
19 mm outer diameter
•30 mm inner diameter
42 mm outer diameter
•15 mm inner diameter
20 mm outer diameter
•15 mm inner diameter
27 mm outer diameter
•26 mm inner diameter
40 mm outer diameter
Pressure piece 6 41 22 003 00 0
4x round material Diameter 20 mm; length = 60 mm
Long-nosed pliers

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT
5. Lubricants and auxiliary substances required
C-SC_CSSM
Version 1.0
2015-07-20
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 8of 55
Lubricants
WSG 11-125R; WSG11-125RT; WSG15-125PR; WSG15-125PRT;
Grease 0 40 101 01 00 4 21 g Gearbox
WSG11-150R; WSG11-150RT; WSG15-150PR; WSG15-150PRT; WSG15-70InoxR; WSG15-70InoxRT
Grease 0 40 101 01 00 4 29 g Gearbox
Auxiliary substances
Loctite 573 Washer

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT
6. Removal
C-SC_CSSM
Version 1.0
2015-07-20
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 9of 55
Removing the handle
1. Unscrew the six screws (1) and remove the handle half shell (2). Tools:
- Torx T15
1
2

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT
6. Removal
C-SC_CSSM
Version 1.0
2015-07-20
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 10 of 55
Removing the handle
1. Unscrew the screw (1).
2. Remove the cable clamping piece (2).
3. Remove the terminals (3).
4. Open the terminals (4) and remove the cables.
5. Remove the switch (5).
6. Loosen the screws (6) on the switch and remove the cables.
7. Remove the handle half shell (7).
Tools:
- Torx T15
- PH2 cross-tip
screwdriver
1
5
2
3
4
6
7

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT
6. Removal
C-SC_CSSM
Version 1.0
2015-07-20
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 11 of 55
Removing the electronics
1. Open the terminals (1) and pull out the cables.
2. Simultaneously press the lugs (2) outward and remove the electronics.
1
Version 1 (WSG15-70InoxR)
Version 2 (WSG15PR)
Version 3+4 (WSG11R)
2

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT
6. Removal
C-SC_CSSM
Version 1.0
2015-07-20
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 12 of 55
Removing the carbon brushes (on both sides)
1. Unscrew the screw (1).
2. Remove the cover (2).
3. Lift the spring (3) to one side.
4. Pull the carbon brush (4) off the brush holder (5) and remove it.
5. Pull the cable (6) off the carbon brush holder.
6. Remove the brush holder (7).
Tools:
- Torx T15
- Long-nosed pliers
- Assembly aid
1
3
2
5
6
4
7

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT
6. Removal
C-SC_CSSM
Version 1.0
2015-07-20
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 13 of 55
Removing the gearbox housing
1. Unscrew the four screws (1).
2. Pull the gearbox housing (2) with armature out of the housing. Tools:
- Torx T15
1
2

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT
6. Removal
C-SC_CSSM
Version 1.0
2015-07-20
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 14 of 55
Removing the stator
1. Remove the air guide ring (1).
2. Remove the stator. Tools:
- Plastic hammer
1

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT
6. Removal
C-SC_CSSM
Version 1.0
2015-07-20
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 15 of 55
Removing the armature
1. Remove the armature (1).
2. Remove the bearing bush (2).
3. Remove the bevel pinion (3).
Tools:
- Plastic hammer
- Arbor press
- Punch
- Drawing-off plate
- Pipe
3
2
3
1

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT
6. Removal
C-SC_CSSM
Version 1.0
2015-07-20
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 16 of 55
Removing the armature
1. Remove the grooved ball bearing (1).
2. Remove the plate (2).
3. Pull off the magnet (3) if one is present.
The magnet is destroyed during removal and must be replaced.
4. Remove the grooved ball bearing (4).
Tools:
- Drawing-off socket cap
- Chuck cone 26 mm
- Chuck cone 19 mm
4
1
2
3

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT
6. Removal
C-SC_CSSM
Version 1.0
2015-07-20
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 17 of 55
Removing the gearbox housing
1. Remove the air guide ring (1).
2. Unscrew the four screws (2).
3. Remove the clamps (3).
4. Take off the bearing plate (4).
5. Remove the washer(s) (5).
Tools:
- Torx T20
1
5
2
3
4

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT
6. Removal
C-SC_CSSM
Version 1.0
2015-07-20
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 18 of 55
Removing the gearbox housing
1. Unscrew the two screws (1).
2. Remove the lever (2).
3. Remove the spiral spring (3).
Tools:
- Torx T20
2
1
3

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT
6. Removal
C-SC_CSSM
Version 1.0
2015-07-20
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 19 of 55
Removing the gearbox housing (applies to: WSG 17)
1. Remove the air guide ring (1).
2. Unscrew the screw (2).
3. Remove the lever (3).
4. Remove the disc (5).
5. Remove the spring (4).
6. Remove the sealing ring (6).
Tools:
- Torx T20
1
6
2
4
3
5

WSG 11 R/RT; WSG 15 PR/PRT; WSG 15-70InoxR/RT; WSG 17 PR/PRT; WSG 17-70InoxR/RT
6. Removal
C-SC_CSSM
Version 1.0
2015-07-20
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 20 of 55
Removing the gearbox housing (applies to: WSG 17)
1. Unscrew the four screws (1).
2. Take off the bearing plate (2).
3. Remove the washer(s) (3).
Tools:
- Torx T20
1
3
2
