Diamond Systems GPIO-MM User manual

GPIO-MM
FPGA-based PC/104
FPGA Pinout Guide V1.01
Copyright 2007
Diamond Systems Corporation
1255 Terra Bella Ave.
Mountain View, CA 94043
Tel [phone]
Fax [phone]
www.diamondsystems.com

Diamond Systems Corporation GPIO-MM FPGA Pinout Guide V1.01 Page 2
TABLE OF CONTENTS
1 GENERAL DESCRIPTION .............................................................................................................................................3
1.1 PC/104 CONNECTORS J1 AND J2...................................................................................................................................3
1.2 EXTERNAL I/O CONNECTORS J3, J4, J5 AND J6.............................................................................................................3
1.3 JUMPER CONFIGURATION BLOCKS J7, J8, J9 AND J10....................................................................................................3
1.4 40MHZ OSCILLATOR,Y1 ..............................................................................................................................................5
1.5 STATUS LED, D1..........................................................................................................................................................5
1.6 XCF02S CONFIGURATION PROM, U9 ..........................................................................................................................5
1.7 256-BYTE 24C04 EEPROM, U12.................................................................................................................................5
1.8 74XX164 SHIFT REGISTER,U11....................................................................................................................................5
1.9 74XX245 BUFFERS,U2-U7 ..........................................................................................................................................5
2 PIN DEFINITIONS ...........................................................................................................................................................6

Diamond Systems Corporation GPIO-MM FPGA Pinout Guide V1.01 Page 3
1 GENERAL DESCRIPTION
The FPGA on the GPIO-MM is connected to the following devices:
1.1 PC/104 connectors J1 and J2
The FPGA connects directly to the PC/104 signals:
Address bus: SA<19:0>
Data bus: SD<15:0>
Control lines: AEN, IOR#, IOW#, SMEMRD#, SMEMWR#, MEMRD#, MEMWR#, TC, RESET
16-bit control: IOCS16#, MEMCS16#, SBHE#
IRQ and DMA signals are routed through configuration blocks J7-J9.
1.2 External I/O connectors J3, J4, J5 and J6
The FPGA I/O lines are connected directly to J3, J5 and J6. DA108S1 chips provide ESD and overvoltage
protection for these lines.
The FPGA I/O lines are connected to J4 through 74XX245 buffers, described below.
J6 is the JTAG port used to program the FPGA and the configuration PROM.
1.3 Jumper configuration blocks J7, J8, J9 and J10
J7 and J9 route IRQs as shown below:
The IRQA and IRQB signals connect to the FPGA and can be routed through jumpers to the IRQx signals
on the PC/104 bus.
The IRQPDA and IRQPDB positions allow the IRQ signals to be used in the IRQ-sharing configuration
outlined by the PC/104 specification. By installing a jumper on these positions, the corresponding IRQ line
is pulled down to ground through a 1Kohm resistor. In this configuration, the FPGA should either place
the IRQ signal in input mode (to indicate an idle IRQ status) or drive the line to the high logic state (to
indicate active IRQ status).

Diamond Systems Corporation GPIO-MM FPGA Pinout Guide V1.01 Page 4
The DMA signals routed through J8 as shown below:
The signals DRQ and DACK# connect to the FPGA. Jumpers determine which PC/104 bus DMA channel
is connected to the FPGA.
The PRT1TIE signal determines the bias level for the I/O on J3 and is not related to the FPGA pinout.
J10 provides user-defined configuration jumpers:
In the drawing above, SP_PS1 = CFG3, SP_PS0 = CFG2, RS4XX# = CFG1 and RS232# = CFG0.
Each of the CFG<9:0> signals are connected to an FPGA input pin. If the jumper is not present on J10,
the signal will be pulled up to +3.3V. If the jumper is present, the signal is pulled low to 0V.
These inputs can be used for any kind of binary user configuration. One common use is for I/O address
selection.

Diamond Systems Corporation GPIO-MM FPGA Pinout Guide V1.01 Page 5
1.4 40MHz oscillator, Y1
The 40MHz oscillator is fed to a FPGA global clock pin.
1.5 Status LED, D1
The FPGA IO pin C15 is connected to the anode of the LED through a 475 ohm resistor. The cathode of
the LED is connected to ground. The LED can be activated by driving the FPGA output high and
deactivated by driving the output low.
1.6 XCF02S configuration PROM, U9
The XCF02S holds the FPGA logic and programs the FPGA during each power-on cycle.
1.7 256-byte 24C04 EEPROM, U12
The 24C04 EEPROM connects to the FPGA through a 2-wire I
2
C bus.
1.8 74XX164 shift register, U11
The eight outputs lines of the 74XX164 each drive one LED on the lower left side of the board. This is
used in the standard logic to display the current “personality ID”, but can be used for any purpose in a
custom FPGA design. It is connected to the FPGA through 2 wires.
1.9 74XX245 buffers, U2-U7
These buffers sit between J4 and the FPGA and provide higher I/O current capability to J4 than the FPGA
could provide alone.
The buffers are situated such that side “A” is connected to the FPGA and side “B” is connected to J4. The
direction control signal is also controlled by the FPGA. When the direction signal is high, the buffers drive
port B with the data on port A (i.e. use this to output data from the FPGA to J4). When the direction signal
is low, the buffers drive port A with the data on port B (i.e. use this to input data from J4 to the FPGA).

Diamond Systems Corporation GPIO-MM FPGA Pinout Guide V1.01 Page 6
2 PIN DEFINITIONS
Signal FPGA Pin FPGA Pin Dir. End Point Function
J3 EXTERNAL SIGNAL GROUP
DIO_J3_1 J3 I/O J3 pin 1 Digital I/O
DIO_J3_2 H3 I/O J3 pin 2 Digital I/O
DIO_J3_3 H4 I/O J3 pin 3 Digital I/O
DIO_J3_4 H1 I/O J3 pin 4 Digital I/O
DIO_J3_5 H2 I/O J3 pin 5 Digital I/O
DIO_J3_6 G1 I/O J3 pin 6 Digital I/O
DIO_J3_7 G2 I/O J3 pin 7 Digital I/O
DIO_J3_8 G3 I/O J3 pin 8 Digital I/O
DIO_J3_9 G4 I/O J3 pin 9 Digital I/O
DIO_J3_10 G5 I/O J3 pin 10 Digital I/O
DIO_J3_11 F5 I/O J3 pin 11 Digital I/O
DIO_J3_12 F3 I/O J3 pin 12 Digital I/O
DIO_J3_13 F4 I/O J3 pin 13 Digital I/O
DIO_J3_14 F1 I/O J3 pin 14 Digital I/O
DIO_J3_15 F2 I/O J3 pin 15 Digital I/O
DIO_J3_16 E1 I/O J3 pin 16 Digital I/O
DIO_J3_17 E2 I/O J3 pin 17 Digital I/O
DIO_J3_18 E3 I/O J3 pin 18 Digital I/O
DIO_J3_19 E4 I/O J3 pin 19 Digital I/O
DIO_J3_20 D1 I/O J3 pin 20 Digital I/O
DIO_J3_21 D2 I/O J3 pin 21 Digital I/O
DIO_J3_22 C1 I/O J3 pin 22 Digital I/O
DIO_J3_23 C2 I/O J3 pin 23 Digital I/O
DIO_J3_24 B1 I/O J3 pin 24 Digital I/O
DIO_J3_25 A2 I/O J3 pin 25 Digital I/O
DIO_J3_26 B3 I/O J3 pin 26 Digital I/O
DIO_J3_27 A3 I/O J3 pin 27 Digital I/O
DIO_J3_28 B4 I/O J3 pin 28 Digital I/O
DIO_J3_29 A4 I/O J3 pin 29 Digital I/O
DIO_J3_30 D5 I/O J3 pin 30 Digital I/O
DIO_J3_31 C5 I/O J3 pin 31 Digital I/O
DIO_J3_32 B5 I/O J3 pin 32 Digital I/O
DIO_J3_33 A5 I/O J3 pin 33 Digital I/O
DIO_J3_34 B6 I/O J3 pin 34 Digital I/O
DIO_J3_35 A6 I/O J3 pin 35 Digital I/O
DIO_J3_36 D6 I/O J3 pin 36 Digital I/O
DIO_J3_37 C6 I/O J3 pin 37 Digital I/O
DIO_J3_38 E6 I/O J3 pin 38 Digital I/O
DIO_J3_39 E7 I/O J3 pin 39 Digital I/O
DIO_J3_40 D7 I/O J3 pin 40 Digital I/O
DIO_J3_41 C7 I/O J3 pin 41 Digital I/O
DIO_J3_42 B7 I/O J3 pin 42 Digital I/O
DIO_J3_43 A7 I/O J3 pin 43 Digital I/O
DIO_J3_44 A8 I/O J3 pin 44 Digital I/O

Diamond Systems Corporation GPIO-MM FPGA Pinout Guide V1.01 Page 7
DIO_J3_45 D8 I/O J3 pin 45 Digital I/O
DIO_J3_46 C8 I/O J3 pin 46 Digital I/O
DIO_J3_47 D9 I/O J3 pin 47 Digital I/O
DIO_J3_48 D10 I/O J3 pin 48 Digital I/O
J4 EXTERNAL SIGNAL GROUP
DIO_J4_1 T14 I/O J4 pin 1 (U2) Digital I/O
DIO_J4_2 R11 I/O J4 pin 2 (U3) Digital I/O
DIO_J4_3 R13 I/O J4 pin 3 (U2) Digital I/O
DIO_J4_4 T11 I/O J4 pin 4 (U3) Digital I/O
DIO_J4_5 T13 I/O J4 pin 5 (U2) Digital I/O
DIO_J4_6 N11 I/O J4 pin 6 (U3) Digital I/O
DIO_J4_7 P13 I/O J4 pin 7 (U2) Digital I/O
DIO_J4_8 P11 I/O J4 pin 8 (U3) Digital I/O
DIO_J4_9 N12 I/O J4 pin 9 (U2) Digital I/O
DIO_J4_10 M11 I/O J4 pin 10 (U3) Digital I/O
DIO_J4_11 P12 I/O J4 pin 11 (U2) Digital I/O
DIO_J4_12 M10 I/O J4 pin 12 (U3) Digital I/O
DIO_J4_13 R12 I/O J4 pin 13 (U2) Digital I/O
DIO_J4_14 N10 I/O J4 pin 14 (U3) Digital I/O
DIO_J4_15 T12 I/O J4 pin 15 (U2) Digital I/O
DIO_J4_16 P10 I/O J4 pin 16 (U3) Digital I/O
DIO_J4_17 T9 I/O J4 pin 17 (U4) Digital I/O
DIO_J4_18 R7 I/O J4 pin 18 (U5) Digital I/O
DIO_J4_19 R9 I/O J4 pin 19 (U4) Digital I/O
DIO_J4_20 T7 I/O J4 pin 20 (U5) Digital I/O
DIO_J4_21 T10 I/O J4 pin 21 (U4) Digital I/O
DIO_J4_22 P7 I/O J4 pin 22 (U5) Digital I/O
DIO_J4_23 R10 I/O J4 pin 23 (U4) Digital I/O
DIO_J4_24 N7 I/O J4 pin 24 (U5) Digital I/O
DIO_J4_25 N9 I/O J4 pin 25 (U4) Digital I/O
DIO_J4_26 M7 I/O J4 pin 26 (U5) Digital I/O
DIO_J4_27 P9 I/O J4 pin 27 (U4) Digital I/O
DIO_J4_28 M6 I/O J4 pin 28 (U5) Digital I/O
DIO_J4_29 P8 I/O J4 pin 29 (U4) Digital I/O
DIO_J4_30 P6 I/O J4 pin 30 (U5) Digital I/O
DIO_J4_31 T8 I/O J4 pin 31 (U4) Digital I/O
DIO_J4_32 N6 I/O J4 pin 32 (U5) Digital I/O
DIO_J4_33 T6 I/O J4 pin 33 (U6) Digital I/O
DIO_J4_34 T2 I/O J4 pin 34 (U7) Digital I/O
DIO_J4_35 R6 I/O J4 pin 35 (U6) Digital I/O
DIO_J4_36 R1 I/O J4 pin 36 (U7) Digital I/O
DIO_J4_37 T5 I/O J4 pin 37 (U6) Digital I/O
DIO_J4_38 P1 I/O J4 pin 38 (U7) Digital I/O
DIO_J4_39 R5 I/O J4 pin 39 (U6) Digital I/O
DIO_J4_40 N2 I/O J4 pin 40 (U7) Digital I/O
DIO_J4_41 P5 I/O J4 pin 41 (U6) Digital I/O
DIO_J4_42 N1 I/O J4 pin 42 (U7) Digital I/O

Diamond Systems Corporation GPIO-MM FPGA Pinout Guide V1.01 Page 8
DIO_J4_43 N5 I/O J4 pin 43 (U6) Digital I/O
DIO_J4_44 M4 I/O J4 pin 44 (U7) Digital I/O
DIO_J4_45 T4 I/O J4 pin 45 (U6) Digital I/O
DIO_J4_46 M3 I/O J4 pin 46 (U7) Digital I/O
DIO_J4_47 T3 I/O J4 pin 47 (U6) Digital I/O
DIO_J4_48 M2 I/O J4 pin 48 (U7) Digital I/O
U2 DIR Control K3 Out U2 Buffer DIR Control
U3 DIR Control K2 Out U3 Buffer DIR Control
U4 DIR Control K1 Out U4 Buffer DIR Control
U5 DIR Control J2 Out U5 Buffer DIR Control
U6 DIR Control J1 Out U6 Buffer DIR Control
U7 DIR Control J4 Out U7 Buffer DIR Control
J5 EXTERNAL SIGNAL GROUP
AUXDIO0
K5
I/O J5 pin 1 Auxiliary DIO
AUXDIO1
L5
I/O J5 pin 2 Auxiliary DIO
AUXDIO2
K4
I/O J5 pin 3 Auxiliary DIO
AUXDIO3
L4
I/O J5 pin 4 Auxiliary DIO
CLOCKS
FPCLK N8 In Y1 40MHz Oscillator Input
SYSCLK R8 In PC/104 B20 PC/104 Bus Clock
PC/104 BUS AND CONFIGURATION GROUP
IOW# C13 In PC/104 B13 I/O Write Strobe
IOR# B13 In PC/104 B14 I/O Read Strobe
IOCS16# A14 I/O PC/104 D2 16-bit I/O Access
AEN H16 In PC/104 A11 Address Enable
SMEMWR# D12 In PC/104 B11 Memory Write (<1MB)
SMEMRD# C12 In PC/104 B12 Memory Read (<1MB)
MEMWR# B12 In PC/104 C10 Memory Write
MEMRD# A12 In PC/104 C9 Memory Read
MEMCS16# A13 I/O PC/104 D1 16-bit Memory Access
SBHE# J13 I/O PC/104 C1 System Byte High Enable
TC A9 I/O PC/104 B27 Terminal Count
DRQ T15 Out J8 DMA Request
DACK# L12 In J8 DMA Acknowledge
SA19 H15 In PC/104 A12 Address Bus
SA18 H14 In PC/104 A13 Address Bus
SA17 H13 In PC/104 A14 Address Bus
SA16 G12 In PC/104 A15 Address Bus
SA15 G14 In PC/104 A16 Address Bus
SA14 G13 In PC/104 A17 Address Bus
SA13 G16 In PC/104 A18 Address Bus
SA12 G15 In PC/104 A19 Address Bus
SA11 F16 In PC/104 A20 Address Bus
SA10 F15 In PC/104 A21 Address Bus
SA9 F14 In PC/104 A22 Address Bus
SA8 F13 In PC/104 A23 Address Bus
SA7 F12 In PC/104 A24 Address Bus
SA6 E14 In PC/104 A25 Address Bus

Diamond Systems Corporation GPIO-MM FPGA Pinout Guide V1.01 Page 9
SA5 E13 In PC/104 A26 Address Bus
SA4 E16 In PC/104 A27 Address Bus
SA3 E15 In PC/104 A28 Address Bus
SA2 D16 In PC/104 A29 Address Bus
SA1 C16 In PC/104 A30 Address Bus
SA0 B16 In PC/104 A31 Address Bus
SD15 M16 I/O PC/104 C18 Data Bus
SD14 M15 I/O PC/104 C17 Data Bus
SD13 M14 I/O PC/104 C16 Data Bus
SD12 M13 I/O PC/104 C15 Data Bus
SD11 N14 I/O PC/104 C14 Data Bus
SD10 N16 I/O PC/104 C13 Data Bus
SD9 P16 I/O PC/104 C12 Data Bus
SD8 R16 I/O PC/104 C11 Data Bus
SD7 K15 I/O PC/104 A2 Data Bus
SD6 K16 I/O PC/104 A3 Data Bus
SD5 K13 I/O PC/104 A4 Data Bus
SD4 K14 I/O PC/104 A5 Data Bus
SD3 K12 I/O PC/104 A6 Data Bus
SD2 J14 I/O PC/104 A7 Data Bus
SD1 J15 I/O PC/104 A8 Data Bus
SD0 J16 I/O PC/104 A9 Data Bus
IRQB L15 Out J9 IRQB Output
IRQA L16 Out J7 IRQA Output
CFG9 D11 In J10 Configuration Input
CFG8 C11 In J10 Configuration Input
CFG7 E11 In J10 Configuration Input
CFG6 B11 In J10 Configuration Input
CFG5 A11 In J10 Configuration Input
CFG4 C10 In J10 Configuration Input
CFG3 B10 In J10 Configuration Input
CFG2 A10 In J10 Configuration Input
CFG1 B8 In J10 Configuration Input
CFG0 C9 In J10 Configuration Input
RESET B9 In PC/104 B2 PC/104 Reset Line
EEPROM GROUP
EEP_SDL L1 I/O U12 pin 5 EEPROM Data Line
EEP_SCL M1 Out U12 pin 6 EEPROM Clock Line
74HC164 GROUP
IDCLK L14 Out U11 pin 8 74HC164 Data
IDDAT L13 Out U11 pin 1 and 2 74HC164 Clock
.
