7starlake SR10M User manual

SR10M
User’s Manual
Revision Date: SEP. 12. 2016
SR10M
MIL-STD Rugged Computer User’s Manual

SR10M User’s Manual
Revision Date: SEP. 12. 2016
1
Safety Information
Electrical safety
To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the
system.
When adding or removing devices to or from the system, ensure that the power cables for the devices are
unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing
system before you add a device.
Before connecting or removing signal cables from the motherboard, ensure that all power cables are unplugged.
Seek professional assistance before using an adapter or extension cord. These devices could interrupt the
grounding circuit.
Make sure that your power supply is set to the correct voltage in your area.
If you are not sure about the voltage of the electrical outlet you are using, contact your local power company.
If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or your local
distributor.
Operation safety
Before installing the motherboard and adding devices on it, carefully read all the manuals that came with the
package.
Before using the product, make sure all cables are correctly connected and the power cables are not damaged. If
you detect any damage, contact your dealer immediately.
To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots, sockets and circuitry.
Avoid dust, humidity, and temperature extremes. Do not place the product in any area where it may become
wet.
Place the product on a stable surface.
If you encounter any technical problems with the product, contact your local distributor
Statement
All rights reserved. No part of this publication may be reproduced in any form or by any means, without prior
written permission from the publisher.
All trademarks are the properties of the respective owners.
All product specifications are subject to change without prior notice

SR10M User’s Manual
Revision Date: SEP. 12. 2016
2
Revision History
Packing list
□ SR10M MIL-STD Rugged Computer
□ XR-DIMM up to 8 GB RAM optional
Accessories Kit
□ M12 4 PIN Connector x 1pcs
□ CD (Driver + User’s Manual)
□ M12 Ethernet Cable x 2pcs optional
□ AC-DC Adapter optional
Ordering information

SR10M User’s Manual
Revision Date: SEP. 12. 2016
3
Table of contents
Safety Information.........................................................................................................................1
Electrical safety ......................................................................................................................1
Operation safety.....................................................................................................................1
Statement ..............................................................................................................................1
Revision History.............................................................................................................................2
Packing list ....................................................................................................................................2
Accessories Kit...............................................................................................................................2
Ordering information.....................................................................................................................2
Chapter 1: Product Introduction ....................................................................................................4
1.1 Key Features................................................................................................................4
1.2 Front Panel Components .............................................................................................7
1.3 Back Panel Components ..............................................................................................7
1.4 Mechanical Dimensions...............................................................................................8
Chapter 2: Jumpers and Connectors Locations ...............................................................................9
2.1 Front Panel Connector Pin Definition .................................................................................9
2.2 Rear Panel Connector Pin Definitions...............................................................................11
2.3 Internal Connector and Jumper Setting............................................................................14
Chapter 3: AMI BIOS UTILITY .......................................................................................................16
3.1 Starting...........................................................................................................................16
3.2 Navigation Keys...............................................................................................................16
3.3 Main Menu.....................................................................................................................17
3.4 Advanced Menu..............................................................................................................18
3.4.1 PCI Subsystem Settings .........................................................................................19
3.4.2 ACPI Settings ........................................................................................................21
3.4.3 CPU configuration.................................................................................................22
3.4.4 SATA Configuration ...............................................................................................28
3.4.5 Intel Rapid Start Technology..................................................................................31
3.4.9 USB Configuration.................................................................................................36
3.4.10 IT8786 Super IO Configuration ............................................................................37
3.4.11 IT8786 HW Monitor............................................................................................39
3.4.12 Serial Port Console Redirection ...........................................................................40
3.5 Chipset ...........................................................................................................................43
3.5.1 PCH IO configuration.............................................................................................44
3.5.2 System AGENT SA .................................................................................................53
3.6 Boot ...............................................................................................................................55
3.7 Security ..........................................................................................................................57
3.8 Save and Exit...................................................................................................................58

SR10M User’s Manual
Revision Date: SEP. 12. 2016
4
Chapter 1: Product Introduction
1.1 Key Features
System
CPU
Intel® 4th Gen Core™ i7-4700EQ (Frequency 2.4GHz, Turbo Boost up to 3.4GHz),
Quad-Core, 8 Thread Support, 6MB SmartCache. Build-in HD Graphics 4600 for excellent
3D, Turbo Boost Technology 2.0, VPro and Hyper-Threading support.
Memory type
1 x SAMTEC XR-DIMM™ Rugged Memory connector (BTH-120-01-L-D-A) with Swissbit®
DDR3 1600MHz XR-DIMM up to 8GB
Chipset
Intel® QM87 Chipset providing integrated USB 3.0 and supporting 4th generation Intel®
Core™ processor families.
Expansion Slot
1 x Full-size miniPCIe (ACES 88911-5204M) co-lay with mSATA, 1 x Onboard SIM Card slot
(ASTRON 5190006-007-R) for 3.5G connectivity 1 x FPE connector (SAMTEC
SEAF-20-06.0-L-10-2-A-K-TR) 1 x StackPC connector (SAMTEC ASP-129637-03)
Display
Display Port
Resolution up to 3840 x 2160@60Hz
DVI-I
Resolution up to 1920 x 1200@60Hz
Storage
mSATA
mSATA Solid State Disk (SSD) - up to 512GB Capacity. Rugged Industrial NAND Flash mSATA
Storage w/ Rugged -40/+85C High Capacity, optional Pre-loaded with Linux or Windows OS.
64 / 128 / 256 / 512GB Innodisk 3MG2-P Series MLC SATA III 6Gb/s Flash SSD, Rated for 520
MB/sec Sequential Read ; 350 MB/sec Write Max.
Ethernet
Ethernet
4 x Intel Gigabit Ethernet LAN Interfaces (10/100/1000Mbps) (2 x Rugged M12 connectors,
2 x RJ45 connectors)
Rear I/O
Display Port
2 x 20Pin External connectors (Female)
DVI-I
1 x 29Pin DVI-I connector (Female)
Ethernet
2 x Rugged M12 connectors, 2 x RJ45 Gigabit Ethernet LAN Interfaces
Audio
2 x 3.5mm Audio Jacks (1 x MIC, 1 x Line-Out)
Serial Port
1 x DB9 connector (RS-232/422/485)
USB Port
2 x USB3.0 standard-A connectors

SR10M User’s Manual
Revision Date: SEP. 12. 2016
5
DC-IN
1 x Rugged M12 connector
Front I/O
Button
Power Button w/cover
Indicator LED
Power, HDD, LAN (Link/Active/Speed)
USB Port
2 x USB3.0 standard-A connectors
Applications, Operating System
Applications
Commercial and Military Platforms Requiring Compliance to MIL-STD-810G Embedded
Computing, Process Control, Intelligent Automation and manufacturing applications where
Harsh Temperature, Shock, Vibration, Altitude, Dust and EMI Conditions. Used in all aspects of
the military.
Operating System
Windows 7 , Windows 8 , Windows 8.1 , Windows 10 Ubuntu13.04, Ubuntu13.10,
Ubuntu14.04, Fedora 20
Physical
Dimension (W x D x H)
308 x 189 x 58 mm
Weight
2.98 Kg (6.57 lbs)
Chassis
Aluminum Alloy, Corrosion Resistant.
Finish
Anodic aluminum oxide (Color Iron gray)
Cooling
Natural Passive Convection/Conduction. No Moving Parts.
Connectors
DC-IN : Amphenol M12S-04BFFB-SL7002 M12
Ethernet : GTC GT234112-11080 RJ45
Ethernet : RTB-19GB9J1A
DVI-I : BANGSON DVI02-0123001-T
DisplayPort : FOXCONN 3VD21203-H7U0-4
Audio : WTJ-035-67S1A01/ WTJ-035-67S1A02
Ingress Protection
Dust Proof (Similar to IP50)
Environmental
MIL-STD-810G Test
Method 507.5, Procedure II (Temperature & Humidity)
Method 516.6 Shock-Procedure V Non-Operating (Mechanical Shock)
Method 516.6 Shock-Procedure I Operating (Mechanical Shock)
Method 514.6 Vibration Category 24/Non-Operating (Category 20 & 24, Vibration)
Method 514.6 Vibration Category 20/Operating (Category 20 & 24, Vibration) Method 501.5,
Procedure I (Storage/High Temperature)
Method 501.5, Procedure II (Operation/High Temperature)

SR10M User’s Manual
Revision Date: SEP. 12. 2016
6
Method 502.5, Procedure I (Storage/Low Temperature)
Method 502.5, Procedure II (Operation/Low Temperature)
Method 503.5, Procedure I (Temperature shock)
Reliability
No Moving Parts; Passive Cooling. Designed & Manufactured using ISO 9001/2000 Certified
Quality Program.
EMC
CE and FCC compliance
Green Product
RoHS, WEEE compliance

SR10M User’s Manual
Revision Date: SEP. 12. 2016
7
1.2 Front Panel Components
1.3 Back Panel Components

SR10M User’s Manual
Revision Date: SEP. 12. 2016
8
1.4 Mechanical Dimensions

SR10M User’s Manual
Revision Date: SEP. 12. 2016
9
Chapter 2: Jumpers and Connectors Locations
This chapter describes the jumpers and connectors on the systems’ motherboard.
2.1 Front Panel Connector Pin Definition

SR10M User’s Manual
Revision Date: SEP. 12. 2016
10

SR10M User’s Manual
Revision Date: SEP. 12. 2016
11
2.2 Rear Panel Connector Pin Definitions

SR10M User’s Manual
Revision Date: SEP. 12. 2016
12

SR10M User’s Manual
Revision Date: SEP. 12. 2016
13

SR10M User’s Manual
Revision Date: SEP. 12. 2016
14
2.3 Internal Connector and Jumper Setting

SR10M User’s Manual
Revision Date: SEP. 12. 2016
15

SR10M User’s Manual
Revision Date: SEP. 12. 2016
16
Chapter 3: AMI BIOS UTILITY
This chapter provides users with detailed descriptions on how to set up a basic system configuration
through the AMI BIOS setup utility.
3.1 Starting
To enter the setup screens, perform the following steps:
•Turn on the computer and press the <Del> key immediately.
•After the <Del> key is pressed, the main BIOS setup menu displays. Other setup screens can be
accessed from the main BIOS setup menu, such as the Chipset and Power menus.
3.2 Navigation Keys
The BIOS setup/utility uses a key-based navigation system called hot keys. Most of the BIOS setup
utility hot keys can be used at any time during the setup navigation process.
Some of the hot keys are <F1>, <F10>, <Enter>, <ESC>, and <Arrow> keys.

SR10M User’s Manual
Revision Date: SEP. 12. 2016
17
3.3 Main Menu
Access Level
Displays the access level of the current user in the BIOS.

SR10M User’s Manual
Revision Date: SEP. 12. 2016
18
3.4 Advanced Menu

SR10M User’s Manual
Revision Date: SEP. 12. 2016
19
3.4.1 PCI Subsystem Settings
