Diamond ADD-60/MX2 User manual

10/2021
Mod: ADD-60/MX2
Production code: TT 50 EI

1
U
US
SE
ER
R
M
MA
AN
NU
UA
AL
L
AUTOMATIC WATER SOFTENER STATION
ADD-60/MX2
Please read the operating manual before startup!
The manufacturer is not responsible for malfunctions caused by faulty operation and
failure to comply with the provisions of this documentation.
Store for later use! This operating manual is an integral part of the device.

2
Table of contents
General instructions................................................................................................................................. 3
Transportation and packaging ................................................................................................................. 3
Liability Exclusion .................................................................................................................................. 3
How it works .......................................................................................................................................... 4
Standards, provisions and statutory regulations ..................................................................................... 4
1. Description of the device ................................................................................................................... 4
1.1 System structure .......................................................................................................................... 4
1.2 Technical description ................................................................................................................. 4
1.3 Control function ........................................................................................................................... 6
2. Preparation for installation ................................................................................................................ 6
2.1 Installation preparation plan ........................................................................................................ 6
2.2 Dismantling and utilization .......................................................................................................... 6
3. Installation ......................................................................................................................................... 7
3.1. Programming device..................................................................................................................... 8

3
General instructions
1. The relevant installation and operation instructions contained in this manual must be read prior to
the installation and operation of this device.
2. The manufacturer will not bear responsibility in case of improper use and incorrect operation of
the device.
3. The system is used only for removing unwanted mineral substances, which accumulate as lime
scale (Calcium and Magnesium). This device is a part of the system protection.
4. It is forbidden to make change in the system without consultation with the manufacturer. The
manufacturer will not bear responsibility in case of any damage caused by this type of
modification.
5. The temperature in the device operating room must be at least 10 C
6. The general regulations and provisions as well as provisions concerning accident prevention
must be observed at the installation location of the device.
7. The installation location of the device must be secured from any damage caused by water (e.g. by
the existing floor drain). The manufacturer is not responsible for any damage caused by water.
8. The appliance in which the filter is used must be free of limescale and gypsum deposits prior to
installation.
9. Do not assemble near sources of heat and open flames.
10. Protect the filter system from mechanical damage.
11. Installation and maintenance of the filter system may only be carried out by trained and authorized
personnel.
12. For cleaning do not use any abrasive chemicals, cleaning solutions or astringent cleaning agents
13. The proper name and serial number of the device must be provided with any enquiries and
ordering of spare parts. Only then an effective and quick reply or order implementation is ensured.
Transportation and packaging
Prior to shipment our systems are carefully packed and controlled.
Damage during transportation cannot be excluded in case of shipment by a shipping company.
It is necessary therefore to check the package at receipt of the product.
1. Check the completeness of the delivery based on the delivery receipt.
2. In case of damaged packaging: perform a visual inspection of the goods and record conclusions in
the shipping documentation provided by the shipping company. Make photographic
documentation of the damaged package and the device. In the shipping documentation place an
annotation of possible claiming of hidden damages, which may be revealed after start-up.
Immediately contact the shipping company because otherwise the shipping insurance will not be
available. Save the package for the purpose of any later inspections by the shipping or insurance
company.
3. In case of returning the package, it must be packed in a way to be protected against any
mechanical damage.
4. Drain water from the system prior to the shipment. This will help reduce shipping costs. It will
also prevent the packaging from damage due to potential water leakage.
After storage and transport below 0 °C, the product must be stored in the open original packaging for
at least 24 hours before it is commissioned at the stated ambient temperatures for operation.
Liability Exclusion
Installation must be performed precisely in accordance with the instructions in this manual.
Manufacturer shall not be held liable for any damage, including subsequent damage, arising from the
incorrect installation or use of the product.

4
How it works
Hard water contains the combination of calcium (Ca), magnesium (Mg). The softening process serves the
removal of the positively charged ions by means of ion-exchanged resin. When the ion-exchanged resin loses its
effectiveness it is regenerated by the reagent.
Regeneration:
The regeneration is based on rinsing the deposits using the tablet salt solution and rinsing out the absorbed
calcium and magnesium ions into the sewage.
Regeneration takes place automatically in a Intelligent mode. User just program tested water hardness (GH) and
system will calculate its efficiency. Regeneration can be also forced in time if capacity will not be reached and
day of override regeneration came system will perform regeneration. During regeneration, hard water is
available.
Regeneration process consist of 4 cycles:
1. Backwashing
2. Brine and Slow Rinses
3. Fast Rinsing
4. Refilling
Standards, provisions and statutory regulations
1. Water supplying the device must comply with the requirements of the utility water use regulation.
2. Parts that are in contact with treated water must be made of material resistant to treated water,
3. In the room for the water treatment floor drainage must be installed. The purchaser is responsible to
ensure the drainage.
4. Maximum temperature of the supply water is 40 ° C
1. Description of the device
1.1. System structure
The system of water purification type ADD-60/MX2 is a device of high quality and precision.
Properly installed and maintained guarantees infallible functioning for many years. The water softener station
of small efficiency type ADD-60/MX2 is used where the water flow does not exceed 45l/min.
System structure:
1. Water softener Type : ADD-60/MX2
2. Drain hose ½”
1.2. Technical description
Quantity of softened water for 20oF /regeneration [liters ] 13 500
Resin Capacity [liters] 50
Electric Connection [ V / Hz ] 230 / 50-60
Power Consumption [W] 3
Salt Consumption [kg] 7,5
Flow Rate [l/min] 1,8-45
Operating pressure [bar] 2,0 - 6,0
Connections [cal] 1“
Height [mm] 1590
Depth [mm] 470
Width [mm] 735
Maximum water temperature [0C] 40
Salt storage capacity [kg] 105

5
TAB. 1. Programming – ADD-60/MX2
System efficiency programming is about to entering the feed water hardness value in German degrees to control
valve. The system will automatically calculate the capacity for the programmed hardness.
Water Hardness
French
degree
German
degrees
18,0 10
19,8 11
21,6 12
23,4 13
25,2 14
27,0 15
28,8 16
30,6 17
32,4 18
34,2 19
36,0 20
37,8 21
39,6 22
41,4 23
43,2 24
45,0 25
46,8 26
48,6 27
50,4 28
52,2 29
54,0 30
55,8 31
57,6 32
59,4 33
61,2 34
63,0 35
64,8 36
66,6 37
68,4 38
70,2 39
72,0 40
The stated capacities were calculated based on standard application and machine conditions. This information
may vary according to external influencing factors (for example, fluctuating raw water quality).

6
1.3. Control function
Steering Valve
Before starting, you should program the time and frequency of regeneration.
The controller is factory programmed for regeneration at 2.00 at night, for 20 oGH.
Depending on water hardness program the value in valve.
2. Preparation for installation
2.1. Installation preparation plan
Picture 1.
On the purchaser’s side:
1. Utility water supply pipe
(cold) 1” with a cut off
valve.
2. Drainage (sewer) at a
max. height of 100 mm,
connection DN 50.
3. Electric socket 230 V /
50 Hz, 16 A
4. Floor drainage must be
in the room.
5. Sediment filter should
be use before water
softener
2.2. Dismantling and utilization
The device is dismantled after it lifetime has expired (for final destruction or scrap).
The reversed assembly steps are to be commenced.
Note!
First clean the system thoroughly with fresh water and drain the tanks and pipes completely!
Comply with workplace safety instructions in this respect!
Different parts of the device must be utilized in accordance with binding regulations of
utilization and waste management!

7
3. Installation
After preparation for mounting, the device is to be placed in the designated room in accordance with the
system structure.
All inlets and outlets are to be connected on the water’s side. The device connections are shown in the
following figure:
· Connect the inlet (1) and outlet (2) to water supply;
· Connect the elastic pipe (1/2’) draining the sewage to the stub connector pipe (3) and to a sewage
grating or a draining installation.
· The sewage draining should be permeable enough to drain 20l/m of the flushing water. The draining
pipe should be stiff enough to avoid its breaking, which may cause blockage and result in the
overflow in the tank with the reagent as well as faulty regeneration process;
· Before water softener should be used mechanical sediment filter to protect device from mechanical
damage caused by sediments from water pipes.
The brine tank of the water softening device is to be filled with salt tablets.
Next add 20 liters of water using buckets ( ONLY FOR FIRST USE – later system automatically refill
the water during regeneration process) .
Check and tighten all fittings connecting the device.
Connect to electric Power socket.
The device is factory adjusted. The fine tuning is done by the user on site.
Before launching the current time should be set and the water hardness in installation place.
The Valve is preset for the regeneration at 2 a.m. for 20oGH. Depending on the water hardness
set the appropriate number of German degrees in valve.
Open the water supply to the water softening device.
The water pressure must be at least 2,0 bars and a maximum of 6,0 bars.
De-aerate system by initiate the regeneration. After first regeneration step BW- backwash skip other
steps by pressing button after each steps of regeneration. When valve will be back in inserv postion,
the device is ready to work.
Picture 2. Steering valve connection
1
Inlet of Raw
water 1”
2
Outlet of Treated
water 1”
3
Drain ½”
4
Power supply

8
3.1 Programming device
3.2. Programming Control head
Display description:
The current time:

9
The Water Hardness and override regeneration:
Manual regeneration:
