Dick KTBG 11 User manual

Operating instructions (translation)
KTBG mod 11
Stunning Device for Small Animals
Prod. No.: 9 0232 000
Friedr. Dick GmbH & Co. KG · Postfach 1173 ·
73777 Deizisau · GERMANY ·
Tel.: [phone] · Fax: [phone]/-219
· Web: www.dick.de · Email: [email protected]
No. 9 0232 3642 Vers.3 / 11-2017
GB

2 Stunning Device for Small Animals
1 Safety instructions
These operating instructions are for the DICK
stunning device for small animals, type KTBG
(hereinafter called KTBG).
• The KTBG may only be used for its
proper intended use.
• The KTBG may only be used by persons
with a certificate of competence
according to EU Regulation 1099/2009/
EC and who are familiar with the
handling, use and accident prevention
regulations and are able to recognise
hazards that occur when working with the
KTBG and can work reliably.
• In addition to the operating instructions,
additional local, generally valid, statutory
and other regulations and provisions
regarding use of the device, accident
prevention and environmental protection
must be observed!
• Before each use the KTBG must be
checked for damage and functional
safety. Do not continue to use a device
that is damaged or not fail-safe.
• In untensioned condition the KTBG must
be kept protected against access by
unauthorised persons, moisture and heat.
• The barrel of the KTBG must never be
pointed at people or parts of their bodies
or animals which are not intended for
slaughter.
• Do not tension the bolt until immediately
before shooting.
• Never hold the KTBG by its muzzle.
• The KTBG must be used and maintained
according to the operating instructions.
• Keep these operating instructions to hand
at all times in the place in which the
KTBG is used. Read these operating
instructions in full before using the KTBG
and always follow the instructions
precisely!

Stunning Device for Small Animals 3
1.1 Meaning of the warnings
In these operating instructions,
a differentiation is made between
warnings depending on the hazard:
2 Intended use
The stunning device for small animals (KTBG)
is solely designed for stunning during the
slaughter and emergency killing of small
rodents up to 5 kg and fattened poultry
(chickens, ducks and turkeys) up to a weight
of approx. 16 kg.
The device is designed for < 100 shots per
year.
Proper intended use also includes observing
the operating instructions.
The KTBG is not suitable for stunning geese
and ratites or larger mammals (e.g. lambs or
piglets).
Any other or additional use is deemed to be
not as intended and therefore misuse.
Friedr. Dick GmbH & Co. KG is not liable for
any resulting losses or damage whatsoever.
The risk is borne solely by the user.
Danger
Imminent risk to life and health of people.
• Causes serious injuries or death.
Warning
Possible imminent risk to life and health
of people.
• Could cause serious injuries or death.
Caution
Possible dangerous situation.
• Could cause minor injuries.
Important
Possible damage to the device.
• Damage to the device can be the
consequence.

4 Stunning Device for Small Animals
Stunning any animals other than those named
or using the device to punch, stamp, form or
drive in objects into any materials is not
permitted. Successful use of the KTBG
requires correct handling and an intact device.
Only original spare parts from Friedr. Dick
GmbH & Co. KG may be used.
3 Technical data
Dimensions: Ø34 x 40 x 230 mm;
Weight: 0.4 kg; Bolt diameter 4.7 mm, Exit
length 25 mm, Stunning energy: 6.7 joule;
A-weighted emission sound pressure
level at a work station according to
EN ISO 11201:2010 on damped surface:
LpA, 1m, max: 75 dB, uncertainty KpA: 3 dB.
4 Device overview
5How it works
• Pulling the bolt [2] at the disc [1] up to
the latching point tensions the spring.
• When the trigger button [3] is pressed the
bolt is accelerated by the spring force,
it passes through the muzzle out of the
device and penetrates the skull of the
animal for slaughter.
• The shot stuns the animal.
1 Disc 4 Headpiece
2 Bolt 5 Handle area
3 Trigger button 6 Muzzle
245
36
1

Stunning Device for Small Animals 5
6 Tension (cock) the device and shoot
Tensioning the device:
1. Clasp the device firmly with one hand in
the handle area [5].
2. Use your other hand to pull the disc [1] on
the bolt [2] outwards until the trigger
button [3] latches into position
automatically.
The KTBG is now ready for use.
Shooting with the device:
1. Hold the device in one hand so that your
thumb can press the trigger button [3].
2. Restrain the head of the animal with
moderate force. Calm down the animal.
• For example, use a killing cone or press
the animal onto a firm surface. The head
of the animal must not be able to move
when the shot is fired.
Warning
A tensioned device can release the shot
spontaneously.
• Do not tension the device until immediately/
directly before shooting.
• Do not hold the device in the muzzle
area [6].
• After tensioning the device, never grip it
between the disc [1] and headpiece [4].

6 Stunning Device for Small Animals
3. Position the device for the shot.
• Position the device
with the muzzle [6] on
the top of the animal’s
head in the middle or
between both ears
(middle of the brain).
• The device must be
positioned at right-
angles and in the
middle for the shot
with pressure.
• The whole muzzle
area of the sleeve must rest on the
animal’s head [6].
• The animal’s head must be still.
• Hold the device safely and firmly for
the shot.
4. Press the trigger button [3].
5. The animal is now stunned. The killing
process must follow within 20s.
7 Cleaning and maintenance
Inadequate cleaning and poor maintenance
reduce the shot capacity, result in premature
wear and worsen hygiene.
Cleaning
Clean the device after each use.
1. Unscrew/dismantle the device.
2. Clean the device carefully on the outside
and inside with a damp cloth or brush.
3. Then leave the device to dry.
4. Wet the movable parts with an acid-free
oil or grease, e.g. Ballistol oil, sewing
machine oil.
5. Screw the device back together.
Warning
If the device is tensioned, the bolt can be
released and cause injuries.
• Always clean and maintain the device
when it is untensioned.

Stunning Device for Small Animals 7
Maintenance
• Check the spring regularly. The wear
limit is reached if, when open, the
distance from the washer and headpiece
is >15 mm.
As soon as the spring has become shorter
or the stunning result is no longer sufficient,
the spring must be replaced.
8 Product liability/Guarantee
The devices are sold with a 12 month
guarantee for the owner, starting from the day
of delivery (verification by means of invoice).
Friedr. Dick GmbH & Co. KG is not liable for
defects or damage caused by incorrect
assembly or improper putting into use,
unsuitable or improper use or use that is not
according to the operating instructions,
changes or repairs which are not listed in the
operating instructions and are made without
the written approval of Friedr. Dick GmbH &
Co. KG, use of third party spare and wearing
parts or third party accessories, overloading
or improper handling as well as usual wear
and tear. The spring, bolt and damping
element (wearing parts) are excluded from the
guarantee.
To maintain the guarantee, please keep the
receipt and send the original copy to us
together with your written complaint. Please
only use the transport packaging provided by
us to return the device; which means it must
be kept.
>15 mm

8 Stunning Device for Small Animals
The guarantee is solely valid for the
improvement of material and production
defects. We choose whether defective parts
are repaired free of charge by our service
department or are replaced with brand-new
parts. Further claims arise only in the
event of refused, failed or unacceptable
supplementary performance in accordance
with our General Terms and Conditions of
Sale, Delivery and Payment. For further
details of the guarantee, please refer to our
General Terms and Conditions of Sale,
Delivery and Payment.
The information in these operating
instructions can be changed without prior
announcement. Complete or partial
reproduction of these operating instructions
and their translation into another language is
not permitted without the prior written consent
of Friedr. Dick GmbH & Co. KG.
Subject to change without notice.
9 Malfunctions
Error Cause Remedy
Force of the shot
bolt diminishes.
Spring is
defective
or worn.
Replace the
headpiece.
Bolt can no
longer be
cocked, or only
by exerting a
very large force.
Bolt is
deformed.
Replace the
headpiece.
Threaded
connection
between the
headpiece and
sleeve loosens,
is tightened again
for the shot.
O-ring is worn.
Replace
O-ring.
Trigger button no
longer latches on
tensioning.
Return spring
or trigger
button is
defective.
Replace the
headpiece.

Stunning Device for Small Animals 9
10 Spare Parts
Attention
Risk of accidents due to wrong spare
parts
Using parts which are not matched with the
device constitutes an unassessable risk.
• Use DICK original spare parts only.
9 0239 3511
9 0239 3208
9 0239 3516
9 0239 2411
Order No. Quantity Name
9 0239 2411 1 piece Absorption element
9 0239 3208 1 piece O-ring
9 0239 3511 1 assembly Complete headpi-
ece incl. bolt (2454)
and spring (2412)
9 0239 3516 1 set Sleeve incl. O-ring

10 Stunning Device for Small Animals
Please send your order for spare parts to
your specialist dealer.
You will find your specialist dealer at
www.fdick.com/dealer
11 Environmental protection
12 EC Declaration of Conformity
Manufacturer
Friedr. Dick GmbH & Co. KG,
Esslinger Str. 4-10,
73779 Deizisau,
Germany
We herewith declare, in sole responsibility,
that the following product:
Stunning device for small animals, Type
KTBG conforms to the listed EC Directives:
• EC Machinery Directive (2006/42/EC)
European standards applied:
• EN ISO 12100:2010.
The authorised representative responsible
for compiling the technical documentation
(technical file) at Friedr. Dick GmbH & Co. KG
is Mr Steffen Uebele, Managing Director.
Waste equipment, replacement parts and
packaging are made of valuable, recyclable
materials. Please dispose of them in an
environmentally friendly way by using the
corresponding suitable collection systems.
