Digga RAMDRILL Series User manual

RAMDRILL
RAMDRILL PHD-XD
3PT LINKAGE
OPERATORS MANUAL
PM-000019B

2PM-000019B - Ramdrill Operators Manual - July 2015

3
Your Ramdrill is a high performance attachment that is designed for Drilling. To avoid premature wear and
failure, and to fulll your terms of warranty please read this statement.
All DIGGA RAMDRILL must have a rst oil change within the rst 30hrs (extreme use) or 50hrs (moderate
use) or 3mths (which ever comes rst) of use to ensure the bed in of the drive unit. For more detailed
information please read page 25.
If the rst oil change is not performed within this period excessive wear within the gearbox will occur that will
cause premature failure. All Warranty will be void.
Oil must then be changed thereafter every 300hrs (extreme use)/500hrs (moderate use) and a full service
every 12mths must be performed by an authorised Digga service agent to ensure Warranty requirements are
met.
In the event of a failure under the warranty period:
• Contact Digga immediately, DO-NOT DISASSEMBLE YOUR DRIVE without rst obtaining written
permission and instructions from Digga.
• Proof of service must be provided in hard copy form of both operational and service history (including serial
number of gearbox and hydraulic motor) records. Service must be performed by an authorised Digga
service agent.
CRITICAL - DO NOT CONNECT OR OPERATE YOUR RAMDRILL
WITHOUT FIRST HAVING READ AND UNDERSTOOD THIS STATEMENT
1 CRITICAL INFORMATION - SERVICE INTERVALS

4PM-000019B - Ramdrill Operators Manual - July 2015
1CRITICAL INFORMATION.............................................................................. 3
2TABLE OF CONTENTS.................................................................................. 4
3TO THE PURCHASER................................................................................... 5
4SERVICE AND PREPARATION FOR USE.................................................... 6
5SAFETY PRECAUTIONS GENERAL USE.................................................... 10
6SAFETY - WORKING WITH THE ATTACHMENT ........................................ 16
7SAFETY - DECAL LOCATION....................................................................... 18
8BEFORE USE................................................................................................ 19
9INSTALLATION AND OPERATION INSTRUCTIONS.................................... 20
10 CONTACT INFORMATION............................................................................. 24
11 MAINTENANCE.............................................................................................. 25
12 TROUBLE SHOOTING................................................................................... 28
13 WARRANTY..................................................................................................... 30
2 TABLE OF CONTENTS
TO BE UPDATED

5
3 TO THE PURCHASER
ABOUT THIS MANUAL
This manual has been designed to help you do a better,
safer job. Read this manual carefully and
become familiar with its contents.Remember;
never let anyone operate this unit without reading the
“Safety Precautions” and “Operating Instructions” sections
of this manual. Unless noted otherwise, right and left sides
are determined from the position of the operator when
behind the product facing forward.
THANK YOU
Congratulations on the purchase of your new DIGGA Ramdrill. This product was carefully designed and manufactured to give you years of
dependable service. It is mandatory that oil changes are performed at the specied interval to keep it in top working condition
(Maintenance - chapter 11).
The complete manual must be read and understood before connecting and operating. Be sure to observe all safety precautions and
maintenance procedures as described in this manual.
Optional Extras are available for special applications or extreme conditions: these are noted throughout the manual. Contact your DIGGA
dealer for any further information pertaining to this product or for further information on other products available in the DIGGA range.
SAFETY ALERT SYMBOL
This is the “Safety Alert Symbol” used by this industry. This symbol is used to warn
of possible injury. Be sure to read all warnings carefully. They are included for your
safety and for the safety of others working with you.

6PM-000019B - Ramdrill Operators Manual - July 2015
MODEL______________________________________
SERIAL NUMBER______________________________
DATE PURCHASED____________________________
The parts department needs this information
to ensure accurate parts can be sent to the
authorised service agent.
Your Digga Ramdrill is a user non serviceable part. Unauthorised disassembly will void warranty.
All service and warranty must be performed by an authorised DIGGA service agent. Contact your local Digga
dealer for details.
To facilitate warranty or service, record the model and serial number of your unit in the space provided on this
page. This information may be obtained from the identication plate located on the product.
4 SERVICE & PREPARATION FOR USE
MODELS COVERED IN THIS MANUAL
PTO PHD-XD 3PT LINKAGE

7
4 SERVICE & PREPARATION FOR USE - PHD FIXED BOOM
To avoid any inconvenience before operation, please check that you have received the following items which you
have ordered.
MAIN COMPONENTS
NO DESCRIPTION
1HYDRAULIC CYLINDER
2PIN - DUAL PIN CAT1 AND CAT2
3TOP LINK BAR
4BOOM ASSEMBLY
5ADJUSTABLE LEGS ASSEMBLY
6A FRAME WELDMENT
7GEARBOX ASSEMBLY
1
4
3
6
7
5
2
NOTE
PHD RAMDRILLS COME WITH
THE FOLLOWING TOP LINK BAR
PART NUMBER
RD-000024
600MM LONG
RAMDRILL - PHD FIXED BOOM

8PM-000019B - Ramdrill Operators Manual - July 2015
NO DESCRIPTION
1RAM ROD
2 PIN - CAT2
3PIN - ADJUSTABLE LEG
4TOP LINK BAR
5A-FRAME WELDMENT
6LEG ASSEMBLY
7BOOM ASSEMBLY
8GEARBOX ASSEMBLY
174
3
6
5
2
8
4 SERVICE & PREPARATION FOR USE - PTO FIXED BOOM
NOTE
PTO RAMDRILLS COME WITH
THE FOLLOWING TOP LINK BARS
PART NUMBER
RD-000025
PART NUMBER
RD-000026
450MM LONG 295MM LONG
RAMDRILL - PTO FIXED BOOM

9
To avoid any inconvenience before operation, please check that you have received the items (covered in this
manual) which you may have ordered.
QTY DESCRIPTION
1BOLT HEX 1/2X4 G8 UNC ZP
1NUT HEX NYLOC 1/2 UNC ZP
2NUT NYLOC 1/4 ZP
2BOLT HEX 1/4”x1” G8.8 UNC ZP
1GREASE NIPPLE 1/4 UNF
2S7-0612-BSPTM JICM-NIP
2QRC POPPET FIRG M 1/2 BSPP
2DOUTY WASHER HYD COUPLINGS
2CAT 1 (B200)-137MMOAL 22MMDIA
2CAT 2 (B202)-140MMOAL 22MMDIA
2LYNCH B7-11MM SHAFT
1OP MANUAL RD
1BOLT KIT RD CLUTCH CVR
2GB SPC PTO
1CHAIN 1M CHAIN SECT 4MM GALV
1CONVERSION BUSH CAT 1 TO 2
1HYDRAULIC CYLINDER
2CLUTCH COVER
1CLUTCH
1HOSE KIT
1GEAR BOX
1450MM TOP LINK BAR
1295MM TOP LINK BAR
QTY DESCRIPTION
2BOLT HEX M10X110 G8.8 ZP
1BOLT HEX 1/2X4 G8 UNC ZP
1NUT HEX NYLOC 1/2 UNC ZP
2NUT NYLOC 1/4 ZP
2NUT HEX NYLOC M10 ZP
2BOLT HEX 1/4”X1” G8.8 UNC ZP
1S90 1212-JICM UNOM - NIP
1REDNIP-MLE S90-1212THRDA+B3/4
4QRC POPPET FIRG M 1/2 BSPP
4DOUTY WASHER HYD COUPLINGS
2CAT 2 (B202)-140MMOAL 22MMDIA
2LYNCH B7-11MM SHAFT
1OP MANUAL RD
2GB PIN 1IN W/TEARDROP
1CHAIN 1M CHAIN SECT 4MM GALV
1CONVERSION BUSH CAT 1 TO 2
1HYDRAULIC CYLINDER
1HOSE KIT
1GEARBOX
1600MM TOP LINK BAR
QTY DESCRIPTION
1DRWB3/4B404-208OAL 186SL 19DIA
1B81-160MM OAL 141MM SL 25MMDIA
3LYNCH B7-11MM SHAFT
2CAT1/2DBL END-1900AL 22MM 28.5
1OP MANUAL RD
1BOLT KIT RD CLUTCH CVR
1CONVERSION BUSH CAT 1 TO 2
1HYDRAULIC CYLINDER
2CLUTCH COVER
1CLUTCH
1HOSE KIT
1GEAR BOX
4 SERVICE & PREPARATION FOR USE
PTO PHD 3PT LINKAGE

10 PM-000019B - Ramdrill Operators Manual - July 2015
SIGNAL WORDS: Note the use of signal words DANGER, WARNING, and CAUTION with the safety messages. The appropriate signal
word for each has been selected using the following guidelines:
DANGER: Indicates an imminently hazardous situation, which if not avoided, will result in death or serious injury. This signal word is to be
limited to the most extreme situations, typically for machine components which, for functional purposes, cannot be guarded.
WARNING: Indicates a potentially hazardous situation, which if not avoided, could result in death or serious injury, and includes hazards
that are exposed when guards are removed. It may also be used to alert against unsafe practices and indicate potential failure or damage
to equipment.
CAUTION: Indicates a potentially hazardous situation, which if not avoided, may result in minor or moderate injury. It may also be used to
alert against unsafe practices.
TAKE NOTE! THIS SAFETY ALERT SYMBOL FOUND THROUGHOUT THIS MANUAL IS USED TO CALL YOUR ATTENTION TO
INSTRUCTIONS INVOLVING YOUR PERSONAL SAFETY OR OTHERS. FAILURE TO FOLLOW THESE INSTRUCTIONS CAN
RESULT IN INJURY OR DEATH.
ATTENTION!
BECOME ALERT!
YOUR SAFETY IS INVOLVED!
THIS SYMBOL MEANS:
This section is composed of various warnings and safety tips. Read and learn all the information in this section before you attempt
to use your attachment. Also read your machines owner’s manual before using your equipment. This knowledge will help you operate
your unit safely. Do not take this information lightly, it is presented for your benet and for the benet of others working around
you.
The “Safety Alert Symbol” will be used throughout this manual. It will appear with the word DANGER, WARNING, or CAUTION,
and a safety message pertaining to the specic topic being covered. Take the time to read these messages as you come across them.
5 SAFETY PRECAUTIONS - GENERAL INFORMATION

11
KNOW WHERE UTILITIES ARE
Observe overhead electrical and other utility lines. Be sure equipment will clear them. When digging, call DIAL
BEFORE YOU DIG ON 1100 (in Australia), or your local UTILITIES location service provider for location of buried utility
lines, gas, water, and sewer, as well as any other hazard you may encounter.
EXPOSURE TO RESPIRABLE CRYSTALLINE SILICA DUST ALONG WITH OTHER HAZARDOUS DUSTS MAY
CAUSE SERIOUS OR FATAL RESPIRATORY DISEASE.
It is recommended to use dust suppression, dust collection and if necessary personal protective equipment during the
operation of any attachment that may cause high levels of dust.
REMOVE PAINT BEFORE WELDING OR HEATING
Hazardous fumes/dust can be generated when paint is heated by welding, soldering or using a torch. Do all work
outside or in a well ventilated area and dispose of paint and solvent properly. Remove paint before welding or heating.
When sanding or grinding paint, avoid breathing the dust. Wear an approved respirator. If you use solvent or paint
stripper, remove stripper with soap and water before welding. Remove solvent or paint stripper containers and other
ammable material from area. Allow fumes to disperse at least 15 minutes before welding or heating.
END OF LIFE DISPOSAL
At the completion of the useful life of the unit, drain all uids and dismantle by separating the different materials (rubber,
steel, plastic, etc.). Follow all federal, state and local regulations for recycling and disposal of the uid and components.
WARNING
WARNING
WARNING
WARNING
5 SAFETY PRECAUTIONS - GENERAL INFORMATION

12 PM-000019B - Ramdrill Operators Manual - July 2015
WARNING
WARNING
WARNING
OPERATING THE RAMDRILL
• An operator must not use drugs or alcohol, which can change his or her alertness or coordination. An operator taking
prescription or over-the-counter drugs should seek medical advice on whether or not he or she can safely operate
equipment.
• All bystanders should be kept a minimum of 6 meters (20 feet) away from the working area of the attachment.
• Do not allow Site workers to climb or ride on a the Ramdrill at any time, including while stationary, in operation or being
moved or rotated.
• Operate only from the operator’s station.
• Avoid steep hillside operation which could cause the machine to overturn. Consult your machines operator’s and safety
manuals for maximum incline allowable.
• Reduce speed when driving over rough terrain, on a slope, or turning, to avoid overturning the vehicle.
• Travel only with the Ramdrill in a safe transport position to prevent uncontrolled movement. Drive slowly over rough
ground and on slopes.
• Tether any auger, anchor or extensions connected to the drive with a chain if necessary, to prevent uncontrolled
swinging of the attachments when moving from position to position.
• Do not drive close to ditches, excavations, etc., cave in could result.
• Before exiting the machine, lower the attachment to the ground, apply the parking brakes, turn off the prime mover’s
engine, and remove the key.
• Flow and pressure gauges, ttings, and hoses must have a continuous operating pressure rating of at least 25% higher
than highest pressures of the system.
• Do not smoke when refueling the prime mover. Allow room in the fuel tank for expansion. Wipe up any spilled fuel.
Secure cap tightly when done.
• Ramdrill shall be used only for their designed intent and shall not be loaded beyond their rated capacity. Overloading or
exceeding the manufacturers specications will void all warranty.
5 SAFETY PRECAUTIONS - GENERAL INFORMATION

13
OPERATING THE RAMDRILL CONT....
• Drill stem rotation must be stopped before adding or removing sections, or making adjustments to the drill stem or
sampling equipment.
• Augers shall be cleaned only when the rotating mechanism is in neutral and the auger stopped; long-handled shovels
shall be used to move cuttings from the auger. Materials heavier than 10kgs must be moved mechanically or by using
at least two people.
• Drilling operations must be stopped in the event of local thunderstorm, or lightning activity. During operation, weather
conditions shall be monitored: operations shall cease during electrical storms or when electrical storms are imminent.
• Open bore holes must be capped and agged.
STORAGE OF THE RAMDRILL
• Seal hydraulic couplers from contaminants and secure all hydraulic hoses off the ground to help prevent damage.
• Clean the unit thoroughly, removing all mud, dirt, and grease.
• Inspect for visible signs of wear, breakage, or damage. Order any parts required and make the necessary repairs to
avoid delays upon removal from storage.
• Check that drive unit motor and hoses are full of clean oil and planetary is full.
• Coat liberally with grease the output shaft and collar, extension shaft and collar, and all connecting pins to prevent rust
and reduce wear.
• Tighten loose nuts, capscrews and hydraulic connections.
• Replace decals that are damaged or in unreadable condition.
• Store unit in a dry and protected place. Leaving the attachment outside will materially shorten its life.
WARNING
WARNING
5 SAFETY PRECAUTIONS - GENERAL INFORMATION

14 PM-000019B - Ramdrill Operators Manual - July 2015
5 SAFETY PRECAUTIONS - GENERAL INFORMATION
MAINTAINING THE RAMDRILL
• Before performing maintenance, lower the attachment to the ground, apply the parking brakes, turn off the
engine, and remove the key.
• Drill rigs must be shut down and properly locked-out and tagged before repairs or maintenance is performed.
Only properly trained and qualied individuals are permitted to perform repairs and maintenance.
• Never adjust a relief valve for pressure higher than recommended by the machine’s manufacturer.
WARNING
WARNING
TRANSPORTING
Follow all local government regulations that may apply along with recommended tie down points and any
equipment safety precautions at the front of this handbook when transporting your attachment.
TIE DOWN POINTS
• Do not attach tie down accessories around cylinders or in any way that may damage hoses or hydraulic
components.
• Check unit stability before transporting.
Verify that all tie down accessories (chains, slings, ropes, shackles and etc.) are capable of maintaining attachment
stability during transporting and are attached in such a way to prevent unintended disengagement or shifting of the
unit. Failure to do so could result in serious personal injury or death.
GROUND PERSONNEL AND BYSTANDERS
• Be alert to others in the work area. Be sure others know when and where you will be working. Make sure no
one is behind equipment or within 6 metres of it operating.
• Loose tting clothing, long hair, jewellery and equipment which might become entangled in moving equipment
are prohibited while working near the Ramdrill.
• Operators, helpers, and other personnel working near the Ramdrill must wear steel-toe safety shoes, safety
glasses, and hard hats as a minimum. Hearing protection, respirators, and personal protective clothing will be
specied in the site-specic Health and Safety Plan.
WARNING
WARNING

15
TO THE OPERATOR
The primary responsibility for safety with this equipment falls to the operator. Make sure that the equipment is operated only by trained
individuals that have read and understand this manual. Don’t hurry the learning process or take the unit for granted.
It is the skill, care, common sense, and good judgement of the operator that will determine how efciently and safely the job is performed.
Know your equipment before you start. Know its capabilities and how to operate all the controls.
Visually inspect your equipment before you start, ensure correct assembly and installation of the attachment and never operate equipment
that is not in proper working order.
Practice the operation of your new attachment and become familiar with the controls and the way it handles on your machine. If there is
any portion of this manual or function you do not understand, contact your local authorized dealer or the manufacturer.
1. Never operate the Attachment without rst reading and understanding the entire operator’s manual.
2. Do not paint over, remove or deface any safety signs or warning decals on your equipment.
3. Follow all safety decals. Keep them clean and replace them if they become worn, damaged or illegible.
4. Know your equipment inside and out. Know how to operate all controls and know emergency shut down procedures.
5. Keep all stepping surfaces, pedals, and controls free from dirt, grease and oil. Keep equipment clean to help avoid injury from
slipping or a fall when getting on or off equipment.
6. Operate the attachment only in daylight or with sufcient articial light.
7. Always carry loads close to the ground. Do not step off machine platform with load raised.
8. Turn off engine before performing maintenance. All maintenance can be performed with the machine arms lowered. If lift arms must
be left raised for any reason, use a positive lift arm lock to secure the arms in place. Serious damage or personal injury could result
from lift arms accidentally lowering.
9. Do not exceed rated operating capacity of the host machine, as machine may become unstable resulting in loss of control.
10. Always lower the loader arms or machine boom to the ground, shut off the engine and remove the key before getting off the unit.
11. Never use the Ramdrill on a machine that is not equipped with a cab or ROPS, and operator restraints (seat belts or equivalent
devices).
5 SAFETY PRECAUTIONS - GENERAL INFORMATION

16 PM-000019B - Ramdrill Operators Manual - July 2015
6 SAFETY - WORKING WITH THE ATTACHMENT
WHEN DEALING WITH HYDRAULICS DURING ANY TYPE OF ASSEMBLY,
OPERATION, MAINTENANCE, OR OTHER WORK ON OR NEAR THIS PRODUCT
● Hydraulic uid under pressure can penetrate the skin and cause serious injury or death. Hydraulic leaks under pressure
may not be visible!
● If any uid penetrates the skin, GET IMMEDIATE MEDICAL ATTENTION!!
● Wear safety glasses, protective clothing, and use a sound piece of cardboard or wood when searching for hydraulic leaks.
DO NOT USE YOUR HANDS!
● Before connecting or disconnecting hydraulic hoses, read your machine or power unit’s operator’s manual for detailed
instructions on connecting and disconnecting hydraulic attachments.
● Make certain that all parts meet the specications for this product when installing or replacing hydraulic hoses or ttings.
● After connecting hydraulic lines:
○ Slowly and carefully raise the boom to check hose clearances and to check for any interference.
○ Operate the hydraulics on this product to ascertain forward and reverse.
○ Make certain that hoses will not be pinched, or get tangled, in any equipment.
● Do not lock the auxiliary hydraulics of your power unit in the “ON” position.
● Refer to your power unit’s operator’s manual and this manual for procedures and intervals, then inspect and maintain the
entire hydraulic system to insure that the uid remains clean, that all devices function properly, and that there are no uid
leaks.

17
WHEN MOUNTING THIS PRODUCT TO YOUR MACHINE
● Refer to the operator’s manual for mounting instructions.
● If this product does not t properly, contact your Digga Dealer before operating.
● Never place any part of your body into the mounting plate, frame, hitch or loader holes. A slight movement of the power unit
and this product could cause serious injury.
● Where ‘Dead Man’ connections are connected or installed it is illegal to disengage, tamper with or remove them.
For additional safety information please see Risk Management booklet. To obtain a copy contact Digga Head Ofce on +61 7 3807 3330
WHEN ADJUSTING, SERVICING OR REPAIRING THIS PRODUCT
● Make no modications to your Ramdrill.
● When making repairs use only authorised Digga service agents, use only genuine Digga parts for the gearbox. For fasten
ers, hydraulic hoses, or hydraulic ttings, use only properly rated parts.
● Replacement parts must also have safety signs attached.
6 SAFETY - WORKING WITH THE ATTACHMENT

18 PM-000019B - Ramdrill Operators Manual - July 2015
7 SAFETY - DECAL LOCATION
PLACEMENT OR REPLACEMENT
OF SAFETY SIGNS
1. Clean the area of application with
non-ammable solvent, then wash
the same area with soap and water.
2. Allow the surface to fully dry.
3. Remove the backing from the safety
sign, exposing the adhesive surface.
4. Apply the safety sign to the position
shown in the diagram above and
smooth out any bubbles.
INSTRUCTIONS
• Keep all safety signs clean and legible.
• Replace all missing, illegible, or damaged
safety signs.
• Replacement parts for parts with safety signs
attached must also have safety signs attached.
• Safety signs are available from your dealer or from
Digga Australia.
13
6
4
5
72
ITEM DESCRIPTION PART. NO QTY
1Caution/ Dial 1100 before you dig. DE-000088 1
2Caution - check oil and read manual DE-000032 1
3 Ram Drill DE-000056 2
Ram Drill PHD DE-000058 2
4 Warning - Do not use draft control DE-000074 1
5Serial Tag DE-000063 1
6 Digga Decal DE-000027 2
7Do not exceed 540 RPM
(3PT LINKAGE and Ramdrill only) DE-000033 1
ITEM 2 ITEM 3
ITEM 4
ITEM 5
ITEM 6
ITEM 7
ITEM 1
WARNING
DO NOT USE DRAFT CONTROL
OR 3 POINT LINKAGE
THIS WILL VOID WARRANTY

19
The key feature of your Ramdrilll is low maintenance, regular oil changes only are required. It contains no user serviceable parts, unauthorised
disassembly will void warranty. WRITTEN PERMISSION FROM DIGGA MUST BE OBTAINED before performing any disassembly.
• Make sure that all nuts and bolts are in place and properly tightened.
• Make sure that all other fasteners are in place and are performing their specied function.
• Make sure that all hydraulic ttings are tightened and that there are no leaks in any ttings or hoses.
• Make sure that all safety signs are in place, are clean, and are legible. (SEE THE SAFETY SIGN SECTION)
• Check for any oil leaks.
• Wear and tear on pins, linkages, clips, bushes and mounting brackets.
• Ensure any damage or excessively worn parts are replaced.
• Always wear safety goggles or glasses when inspecting equipment.
SAFETY FIRST!! READ AND UNDERSTAND THE SAFETY INSTRUCTIONS
BEFORE BEGINNING ANY DRIVE UNIT MAINTENANCE.
BEFORE FIRST USE
BEFORE EACH USE
● Inspect the attachment for shipping damage. If damage does exist, do not operate until the damaged parts have
been replaced or repaired.
8 BEFORE USE
Escaping uid under pressure can have
sufcient force to penetrate the skin
causing serious personal injury. Fluid
escaping from a very small hole can
be almost invisible. Use a piece of
cardboard or wood, rather than hands
to search for suspected leaks. Keep
unprotected body parts, such as
face, eyes, and arms as far away as
possible from a suspected leak. Flesh
injected with hydraulic uid may develop
gangrene or other permanent disabilities.
If injured by injected fluid, see a doctor at
once. If your doctor is not familiar with this
type of injury, ask him to research it
immediately to determine proper treatment.
WARNING!
CARDBOARD
HYDRAULIC HOSE
OR FITTING
MAGNIFYING GLASS

20 PM-000019B - Ramdrill Operators Manual - July 2015
1. Unstrap your Ramdrill from the pallet and open all boxes.
2. Remove the toplink bar from the tractor as per your tractors operating manual.
3. Insert the Dual Cat 1/Cat 2 pin into the A-Frame and secure with a nut and washer (Fig 1).
4. Fit main boom to A-Frame.
5. Pivot the a-frame and boom assembly into a vertical position (Fig 2). Lower the 3pt
linkage arms on your tractor and reverse until lined up.
6. Remove the locking pin for side travel from your tractors 3pt linkage arms and
manoeuvre until secured with lynch pin. Replace the side travel pin.
7. Insert the top link bar supplied and secure to the ramdrill with a nut and bolt (Fig 3).
8. Insert the spacer/bush into the shaft and manoeuvre the tractor and ramdrill until shaft can
safely be secured to the tractor. Secure with pin and lynch pin.
9. Put Draft control in full down position and lock out, Do not use once ramdrill is secured to
tractor. The use of the draft control will damage the ramdrill and or tractor.
10. Remove the clip and pin from your Hydraulic Ram and secure to the boom (Fig 4).
11. Pivot the boom up and position the cylinder into place, secure with pin and clip.
12. Remove the cylinder caps and lower the boom to ground before connecting your
hydraulic ram to the tractor.
13. Operate the boom up and down to charge the hoses (Fig 5).
IMPORTANT: WHEN SUBFRAME IS FITTED - DO NOT OPERATE DRAFT CONTROL -
DAMAGE TO TRACTOR AND OR RAMDRILL WILL RESULT
9 INSTALLATION AND OPERATION INSTRUCTIONS
RAMDRILL ASSEMBLY
FIG 1
FIG 2
FIG 3
FIG 4
FIG 5
This manual suits for next models
3
Table of contents
Other Digga Drill manuals
Popular Drill manuals by other brands

EINHELL
EINHELL TH-ID 550/1 Original operating instructions

Méanail Paris
Méanail Paris PONCEUSE manual

Makita
Makita df330d instruction manual

Bosch
Bosch Professional GWX 18V-15 C Original instructions

Parkside
Parkside PABS 20-Li C3 Translation of the original instructions

Makita
Makita DF330D instruction manual
