Digi-Sense 91100-00 User manual

Thermocouple Thermometer Models
91100-00 (Type J)
91100-10 (Type K)
91100-20 (Type T)
Cole-Parmer Instrument Co.
625 East Bunker Court
VernonHills, IllinoisU.S.A.60061-1844
[phone]
[phone] (Fax)
800-323-4340
www.coleparmer.com
e-mail:[e-mail]
A1299-0628
Edition06
®

ACCESSORYTHERMOCOUPLE PROBES
Cole-Parmeroffers a widevariety ofthermocouple
probes,wire,connectors,extensioncables,switch
boxes,accessories,and calibrationservices.
The popular probes listed below have a nylon
handle, a 5-ft coiled cord and a 316 SS sheath.
General-purpose probes, 5inlong x0.156in dia
with 0.093 in dia tip.3 second time constant.
Type J 08517-55
Type K 08516-55
TypeT 08500-55
Penetration probes,4inlongx0.156 indiasharp
tip.5 second timeconstant.
Type J 08517-65
Type K 08516-65
TypeT 08500-65
Surface probes, 10 in long with 5/8 in dia alumi-
num and ceramic tip.6 second time constant.
Type J 08517-60
Type K 08516-60
TypeT 08500-60
Air/gas probes, 8 in long sheath with 1/4 in dia
radiantheatshield.45second timeconstant.
Type J 08517-75
Type K 08516-75
TypeT 08500-75
39800-98 Carrying case. Hard plastic case with
foaminsertholds onemeterand upto fiveprobes.
Measures 21 in W x 12 in H x 3 in D.
08520-05Softcarryingcase. Water-resistantcloth.
Extraroomfor batteries orsmall probe. Measures
3.5 inW x 10 in H x 2 in D.

1
INTRODUCTION
Thisversatilehand-heldinstrumentprovideshighly
accuratetemperature measurements. Theinstru-
ment is designed for easy operation and includes
thefollowingfeatures:
• Operator selectionofCelsiusorFahrenheit scale
• Resolution of0.1° from–99.9 to299.9°
• Four-digitLCD
• Hold feature for temporarily retainingareading
• Fieldcalibrationcapability
• Lowbattery warning
• Built-in tiltstand for easy hands-freeoperation
• Two bladefemale ANSImini-connector input
• Operates with a wide selection of probes

2
SAFETY PRECAUTIONS
THIS INSTRUMENT IS
DESIGNED TO ACCEPT
LOW LEVEL SIGNALS SUPPLIED BY STAN-
DARD THERMOCOUPLES. UNDER NO CIR-
CUMSTANCES SHOULDTHE INPUTVOLTAGE
EXCEEDTHE SPECIFIED 50V RMS.
DO NOT USE OR STORE
THIS INSTRUMENT IN
MICROWAVE OVENS OR ANY ABNORMALLY
HOT OR COLD AREAS.
WEAKBATTERIES SHOULD
NOT BE LEFT IN THE IN-
STRUMENT. DEADBATTERIESCANLEAKAND
CAUSE DAMAGETO UNIT.
VOLTAGES PRESENT AT
THETHERMOCOUPLEMAY
ALSO BE PRESENT AT THE BATTERY TERMI-
NALS. ALWAYS DISCONNECT THE THERMO-
COUPLEWHEN CHANGING BATTERIES.
TO PREVENT IGNITION OF
A HAZARDOUS ATMOS-
PHERE,BATTERIESMUSTONLYBECHANGED
INANAREAKNOWNTOBENON-HAZARDOUS.
AFIN DE PREVENIR
L'INFLAMMATION
D'ATMOSPHERES DANGEREUSES, NE
CHANGER LES BATTERIES QUE DANS DES
EMPLACEMENTS DESIGNES NON DAN-
GEREUX.
TOPREVENT IGNITIONOF
A HAZARDOUS ATMOS-
PHERE BY ELECTROSTATIC DISCHARGE,
CLEANWITH DAMP CLOTH.
WARNING
WARNING
CAUTION
CAUTION
WARNING
DANGER
AVERTISSEMENT

3
SPECIFICATIONS
THERMOCOUPLE PROBES
Type Temperature Range
Type J: –200°C to 1000°C (–328°F to 1832°F )
Type K: –250°Cto 1372°C(–418°Fto 2501°F)
TypeT: –250°Cto 400°C (–418°Fto 752°F )
Out of range display: - - - -
Resolution: 0.1°/1°autoranging, 0.1°from
–99.9°to299.9°, 1°outsidethis range.
Accuracy
> –99.9°: +(0.2% ofreading+0.5°C)
+(0.2%ofreading +0.9°F)
< –99.9°: +(0.25% ofreading, +1°C)
+(0.25%of reading +2°F)
Display:4-digit LCDwith 0.5in highnumerals.
Display update rate: 0.6sec per update.
Input: Onethermocouple with ANSIconnector.
Input Protection: 50V rms
Battery: Two AA, 1.5V alkaline ANSI-L40,
IEC-LR6.
Battery Life:750hours continuous,typical.
Low battery indication
Battery Symbol on when 8 to 10 hours of
battery liferemains.
Battery symbolblinking:replacebattery
Operating Conditions
Stated accuracy: 18°C to 28°C (64°F to 82°F)
Useful range: 0°C to 40°C (32°F to 104°F)
Storage: –40°C to 65°C (–40°F to 149°F)
Humidity(non-condensing):10% to90%

4
Dimensions
3 cm D x 8.4 cm W x 15.8 cm H
(1.2 in x 3.3 in x 6.2 in)
Weight with batteries: 227 grams (8 ounces)
Ingress protection: MeetsIEC-529 IP-54fordust
andwater-resistantenclosures.
Intrinsic safety
Thisproductisenergylimitedforintrinsicallysafe
operationin hydrogenatmospheresperClass I,
Division 1, Groups A, B, C and D hazardous
(classified)locationsforULperUL913 andCSA
per C22.2 No. 0-M1982 and No. 157-M1987.
Maximum surface temperature:135°C(T4);UL
fileNo.E182612 (1997).
Compliance: (For CE Mark)
EN61326-1/A1:1998 (EUEMC Directive)

5
BATTERY INSTALLATION AND
REPLACEMENT
WEAKBATTERIESSHOULD
NOT BE LEFT IN THE
INSTRUMENT. DEAD BATTERIES CAN LEAK
AND CAUSE DAMAGETO UNIT.
VOLTAGES PRESENT AT
THETHERMOCOUPLEMAY
ALSO BE PRESENT AT THE BATTERY TERMI-
NALS. ALWAYS DISCONNECT THE THERMO-
COUPLEWHEN CHANGING BATTERIES.
TO PREVENT IGNITION OF
A HAZARDOUS ATMOS-
PHERE,BATTERIESMUSTONLYBECHANGED
INANAREAKNOWNTOBENON-HAZARDOUS.
AFIN DE PREVENIR
L'INFLAMMATION
D'ATMOSPHERES DANGEREUSES, NE
CHANGER LES BATTERIES QUE DANS DES
EMPLACEMENTS DESIGNES NON DAN-
GEREUX.
CAUTION
DANGER
WARNING
AVERTISSEMENT

6
If battery indicator turns on, battery life is approxi-
mately8to10hours.Thebattery indicatorwillstart
blinkingwithless than1 hour of life remaining.
ATTHISPOINT,BATTERYMUSTBE CHANGED.
IF BATTERY VOLTAGE GOES TOO LOW, DIS-
PLAYWILL GO BLANK.
SeeSPECIFICATIONS for battery type.
1. Before changingbattery, turninstrumentoffand
disconnectthermocouple.
2. Loosen screw and lift battery cover off back of
case.
3. Removethe twoAAbatteries.
4. Insert twonew batteries observing polarity.
5. Install cover and tighten screw.

7
CONNECTING A THERMOCOUPLE
Usethe correctthermocoupletype foryourinstru-
ment. Using an incorrect thermocouple type will
result in erroneous readings. Thermocouples are
colorcodedbytypeusingtheNorthAmericanANSI
ColorCode asfollows:
TYPE COLOR
JBlack
K Yellow
T Blue
Thermocoupleconnectorshaveonewidebladeand
onenarrowblade.
Donot force connector inback-
wards.
Connectthermocoupleto receptacleattop
ofinstrumentas shownin the followingillustration.
Thermocouple wiring polarity must be correct. If
readings decrease as the temperature increases,
thethermocouplewires maybe reversed. Thered
wire is negative for thermocouple wires manufac-
turedin North America.

8

9

10
2. If athermocouple isnotconnectedor ifthether-
mocouple is defective, the display will indicate
OPEn.
3. Select °C or °F by pressing the °C/°F key.Tem-
peraturescalecanbe switchedatanytime. The
thermometerremembersthelastselectedscale
the next time you turn the power on.
4. For optimum instrument accuracy, allow one
minuteforambient temperaturestabilization. If
theunit hasbeen storedat anextreme ambient
condition,more timewill beneeded.
Thermocouples aresensitive atthe tipormeasur-
ing junction.When taking temperature measure-
ments,allow timefor thereading tostabilize. Mul-
tiplyingthetimeconstant oftheprobeby5willgive
you theapproximatetime required.
Notethatthereadings willautomaticallychangeto
1°resolutionbelow–99.9°orabove 299.9°.
If desired, press the HOLD key to retain the read-
ing on the display.Press HOLD key again for nor-
maloperation.
If the display shows "- - - -" the temperature read-
ing is out of range of the instrument.
OPERATION
Note: Be sure the thermocouple you are using
matchestheinstrument settingindicatedonthe
unit.
1. Press the ON/OFF key.The thermometer per-
forms a self-test and all display digits and indi-
cators, as shown below, should remain on for
approximatelytwoseconds.

11
FIELD CALIBRATION
Thethermometerisfactorycalibratedanddoesnot
require calibration before use. The CAL function
allowssinglepoint calibrationofthe thermometer,
at0°C(32°F)tocompensate forthermocoupleoff-
seterror.It isnot necessary toperform afield cali-
brationto obtainspecifiedmeteraccuracy.Usethe
field calibration feature to improve thermometer/
probeaccuracyortocompensateforthermocouple
drift.
1. Follow steps 1 through 4 in OPERATION sec-
tion.
2. Packsensing endof probein acontainer tightly
packed with crushed ice and filled with distilled
water.Allowtemperatureto stabilize.
3. Press and hold the CAL key for 5 seconds to
enterthecalibrationmode,the CALannunciator
on the display starts blinking. Release the CAL
key.
4. If the measured temperature is from −10°C to
10°C (14 to 50°F), when the temperature read-
ing is stable, press the CAL key.
TheCALindicatorwillstopblinkingandtheread-
ing will be set to 0°C (32°F).The CAL indicator
will remain turned on, indicating a field calibra-
tion is active.
If“Err”isdisplayed,eitherthe displayedreading is
outsidethe abovelimits orthe batteries areweak.
CANCELING A FIELD CALIBRATION
1. Turn thethermometeroff.
2. Hold the CAL key down while pressing the
ON/OFF key.
Thefieldcalibrationis canceledand the thermom-
eter reverts to the default factory calibration. The
CALannunciatoris nowturnedoff.

12
FIELD CALIBRATION LOCKOUT
AND RE-ENABLE
The calibration lockout feature, prevents any field
calibrationchanges. Thelockoutremains ineffect
untilalockout re-enablehasbeenperformed. Use
thefollowingprocedurestolockoutorre-enablethe
fieldcalibrationoperation.
Lockout Procedure
1. Turnthe thermometeroff.
2. SimultaneouslypressandholdtheCAL andthe
°C/°FkeysdownandmomentarilypresstheON/
OFF key. Continue to hold the CAL and °C/°F
keys for at least 5 seconds.
Re-Enable Procedure
1. Turnthe thermometeroff.
2. Simultaneously press and hold the HOLD and
theCAL keys downandmomentarily pressthe
ON/OFF key. Continue to hold the HOLD and
CAL keys until the display blanks.

13
MAINTENANCE
Properly used, the thermometer should maintain
calibrationindefinitelyandnotrequireserviceother
thanoccasionalcleaningofthehousingandchang-
ingof thebatteries.
CLEANING
TOPREVENT IGNITIONOF
A HAZARDOUS ATMO-
SPHERE BY ELECTROSTATIC DISCHARGE,
CLEANWITH DAMP CLOTH.
Do not clean with abrasives or solvents.Use mild
detergents,neverimmersenoruseexcessivefluid.
BATTERIES
If there is no display when the thermometer is
turned on,check condition ofthetwoAA batteries.
Alsocheckthatthebatteryterminalsarecleanand
batteries are properly installed. If replacement is
necessary,refer tothe BATTERY INSTALLATION
AND REPLACEMENT section for replacement
procedure.
WARNING

14
SERVICE
SUBSTITUTION OF COM-
PONENTS MAY IMPAIR
INTRINSICSAFETY.
LA SUBSTITUTION DE
COMPOSANTSPEUTCOM-
PROMETTRELASECURITEINTRINSEQUE.
There are no internal adjustments or user
replaceableparts.
If “Err”followed by the numbers 1 through 9 is
displayed (see example below) return unit for
service. Note that“Err”alone may be displayed
during improper field calibration.
A-1925-32
Rev. F
Printed in U.S.A.
060900
Note:Serialnumberlabel is located inside
battery compartment.
WARNING
AVERTISSEMENT

15
EU DECLARATION
OF CONFORMITY
Name of Apparatus: DIGI-SENSE
®
Thermocouple
Thermometer
Model Numbers: 91100-00, -10 and -20
Description of Apparatus:ElectronicThermometer
using aThermocouple
Probe
91100-00 (Type J),
-10 (Type K)
and -20 (TypeT)
Barnant Company declares that the above models
are in conformity to the following harmonized
standard and directives:
Applicable Applicable Manufacturer’s
Directives Specifications Report Number
89/336/EEC EN61326-1/A1: TR9648
92/31/EEC 1998
93/68/EEC
Manufacturer: Barnant Company Division
Cole-Parmer Instrument Company
28W092Commercial Avenue
Barrington, IL 60010
USA
Tel.:[phone]
Manufacturer’s Signature:
James W.Doll
VicePresident, Engineering
5 October, 2000
Date

WARRANTY
TheManufacturer warrantsthis product tobe free
fromsignificant deviations frompublishedspecifi-
cations. Ifrepair oradjustmentisnecessary within
thewarrantyperiod,the problemwill be corrected
at no charge if it is not due to misuse or abuse on
yourpartas determined bythe Manufacturer. Re-
pair costs outside the warranty period, or those
resulting from product misuse or abuse, may be
invoicedtoyou.
The warranty period for this product is noted
on theWarranty Card.
PRODUCT RETURN
To limit charges and delays, contact the seller or
Manufacturerforauthorizationandshippinginstruc-
tions before returning the product, either within or
outsideofthewarrantyperiod. When returningthe
product,pleasestatethereasonforthereturn. For
your protection, pack the product carefully and in-
sureitagainst possibledamage orloss. Any dam-
ages resulting from improper packaging are your
responsibility.
TECHNICAL ASSISTANCE
Ifyouhaveanyquestionsabouttheuseofthisprod-
uct,contact theManufactureror authorizedseller.
Trademarks bearing the ® symbol in this publication are
registered in the U.S. and in other countries.
A-3477-51
Rev. F
Printed in U.S.A.
060900
