Operator’s Manual DigiPump LP8 Infusion Pump - Digicare Biomedical Technology Inc
CONTENTS
Introduction
A About this manual… ………………………………………………… 2
B Manufacturer’s Responsibility… …………………………………… 2
C Warranty…… …………………………………………………………2
D Unpacking and Accessories…………………………………………… 2
E General Safety………………………………………………………… 3
Chapter I Overview
1 1 Application…………………………………………………………… 4
1 2 Technical specification……………………………………………… 4
1 3 Description…………………………………………………………… 5
1 4 Components and Functions ………………………………………… 6
1 4 1 Front view…………………………………………………… 6
1 4 2 Infusion components…… ………………………………… 6
1 4 3 LCD………………………………………………………… 7
1 4 4 Keyboard…………………………………………………… 7
1 4 5 Rear view………………………………………………………8
1 4 6 Bottom components……………………………… ……… 8
Chapter II Installation
2 1 Packing list…………………………………………………………… 9
2 2 Installation …………………………………………………………… 9
2 2 1 Set the knob bolt firmly……………………………… ……… 9
2 2 2 Set drop detector…………………………………………… …9
Chapter III Basic Operation
3 1 Preparation……………………………………………………… … 9
3 2 Installation……………………………………………………………10
3 2 1 Install the machine…………………………………………… 10
3 2 2 IV Set Installation ………………………………………… 10
3 2 3 Install the drop detector……………………………………… 11
3 3 Select the type of IV set…………………………………………… 12
3 4 Set the adjustment factor…………………………………………… 12
3 5 Set the flow rate and volume to be infused … ………………………14
3 6 Starting infusion………………………………………………………14

Operator’s Manual DigiPump LP8 Infusion Pump - Digicare Biomedical Technology Inc
- 1 -
3 7 Finishing infusion……………………………………………… … 15
3 8 Powering off……………………… ……………………………… 15
3 9 Extended operations…………………………………………… … 15
3 9 1 Pause/ Restart…………………………………………………15
3 9 2 To continue another solution container……………………… 15
3 9 3 Purge Function ………………………………………………16
3 9 4 IV Set Auto-Adjustment………………………………………16
3 9 5 IV Set Manual Adjustment……………………………………17
3 9 6 Occlusion valve adjustment………………………………… 18
3 9 7 Sound volume adjustment…………………………………… 18
3 9 8 Toggle switch………………………………………………… 19
3 9 9 Battery …… ……………………………………………… 19
3 10 Trouble Shooting……………………………………………………19
3 10 1 Alarms and Alarm Codes ………………………………… 19
3 10 2 Other failures……………………………………………… 22
3 11 Daily Check…………………………………………………………22
Chapter IV Maintenance
4 1 Daily Maintenance………………………………………………… 23
4 1 1 DigiPump LP8 enclosure…………………………………… 23
4 1 2 Air detector……………………………………………………23
4 1 3 Linear pump cassette………………………………………… 24
4 1 4 Tube clamp……………………………………………………24
4 1 5 Drop detector………………………………………………… 24
4 2 Battery……………………………………………………………… 24
4 2 1 Recharging…………………………………………………… 24
4 2 2 Replacement………………………………………………… 25
4 3 Periodical replacement of some items……………………………… 25
4 4 Storage……………………………………………………………… 25
4 5 Explanations of symbols…………………………………………… 25
Warranty Terms & Conditions………………………………………………… 27

Operator’s Manual DigiPump LP8 Infusion Pump - Digicare Biomedical Technology Inc
- 2 -
Introduction
A. About This Manual
This operator’s manual has been prepared to provide information on the correct use of the DIGICARE
BIOMEDICAL TECHNOLOGY INC Digipump LP8 Infusion Pump It contains performance
specifications and installation, operation and maintenance information It is intended for trained health
care professionals
Follow each chapter in the manual sequentially if the infusion pump is being used for the first time
B. Manufacturer s Responsibility
• The manufacturer of this equipment is responsible for the effects on safety, reliability, and performance
of the equipment only if:
• The equipment is used in accordance with the instructions in this manual
• The electrical installation complies with all applicable regulations
• Assembly operations, extensions, re-adjustments, or repairs are carried out by personnel authorized by
the manufacturer
• It is up to the user to ensure that any applicable regulations respecting the installation and operation of
the infusion pump be observed The operator should read this manual carefully and thoroughly before
attempting to use the infusion pump
Incorrect operation or failure of the user to maintain the infusion pump in accordance with
proper maintenance procedures relieves the manufacturer or his agent from all consequent
non-compliance, damage or injury
C. Warranty
All products manufactured by Digicare Biomedical Technology Inc are warranted to be free from defects
in material and workmanship and to operate within published specifications, under normal use, for a
period of one year from date of original shipment The warranty on accessories is ninety (90) days
If an examination by Digicare, discloses such products or component parts be been defective, then our
obligation is limited to repair or replacement (at our option)
D. Unpacking and Accessories
Carefully remove the infusion pump and its accessories form the shipping carton Save the packing
materials in case the infusion pump must be shipped or stored Ensure your Digipump LP8 has the items
listed in the SHIPPING LIST inside the carton

Operator’s Manual DigiPump LP8 Infusion Pump - Digicare Biomedical Technology Inc
- 3 -
E. General Safety
E.1 – Indications
The Digipump LP8 infusion pump is a device designed for continuous operation It is intended for use
by person’s trained in professional health care The operator must be thoroughly familiar with the
instructions in this manual before using the instrument
E.2 – Warnings
• The Digipump LP8 infusion pump was designed and tested accordingly to the EMC Standard
IEC601-1-2 However, the operator is responsible to verify if the infusion pump is been affected or affecting others
electrical equipment Equipments like electrocautery and image scanners can generate interference
and cause degradation of the Digipump LP8 infusion pump performance To avoid this
situation, it should be installed as far as possible of those equipment
• The Digipump LP8 infusion pump is NOT intended to be used during MRI (magnetic resonance
imaging)
• The Digipump LP8 infusion pump is NOT suitable for use in the presence of a flammable anaesthetic
mixture with air or with oxygen or nitrous oxide Do not operate this product in the presence of
flammable anesthetics Explosion may result
• Follow the instructions on this manual Set the parameters appropriately and use only the IV set which
has been adjusted for the DigiPump LP8
• Stop the device immediately in case of any abnormal functioning of the infusion pump
• Keep the DigiPump LP8 far, at least 1 meter (3 0 feet) from other generating HF equipments such as
electrosurgical unit and others
• Before using the infusion pump, make sure the AC voltage at your installation site is correct for the
AC rating for the device If the rating is not correct, do not use the infusion pump and contact
Digicare Customer Service for help
• Follow local regulatory recommendations for Battery disposal Do not overheat or place the battery into
fire as it may cause leakage, burning or explosion
• Do not tear or break battery sheath as it may cause explosion or chemical burning
• Hold on the plug firmly when plugging in or pulling out the power cord Do not touch the power plug
with wet hand
• Do not share the same power outlet with other appliances
• Do not disassemble the device or modify it
• Perform daily check before use Make sure all functions perform well if the infusion pump is not being
in use
• Avoid vibration, collision or exposition to the direct sunlight or other strong light
• Avoid the warm or wet air flow coming from heating or cooling apparatus such as air-conditioning,
ventilator, humidifier, etc

Operator’s Manual DigiPump LP8 Infusion Pump - Digicare Biomedical Technology Inc
- 4 -
Chapter I. Overview
1.1. Application
The Digipump LP8 infusion pump is intended to be used in health care facilities for continuous
and accurate infusion of liquids to patients
1.2 Technical Specification
Iv set requirement 10, 15, 20, 60drops/ml (standard PVC with outer diameter: 3 4mm-4 5mm
(0 134” – 0 178”))
Pump type Linear Peristaltic pump
Control method Drop count method
Air detection method Ultrasound (8 levels of sensitivity are available)
Drop detection method Infrared photo-electric beam
KVO (keep vein open) 1ml/hr (the lowest infusion rate to keep vein open)
Maximum flow rate 999 9ml/h - 10,15, 20 drops/ml IV set
Drop rate accuracy ±2% (the specified accuracy is reached after the first 150 drops)
Flow rate accuracy ±5% (the specified accuracy is reached using adjusted IV set and after
continued infusion over 100ml)
Occlusion pressure 40~140Kpa Eight levels of sensitivity available
Volume infused display 0-9999ml
Volume to be infused setting 1-9999ml
Sound and light alarm Air in line, door open, occlusion, pause overtime, infusion complete,
abnormal drops, leakage, tube slope, low battery, damage battery, pump
reversal, empty, abnormal drop detector, linear pump cassette abnormal,
sound abnormal, low volume for adjustment, adjustment failure, adjustment
function finished and cannot restart again, interruption of power supply
Power source ≤25VA
Peristaltic linear pump Detachable
Tube clamp Detachable
Display Color LCD with bright backlight

Operator’s Manual DigiPump LP8 Infusion Pump - Digicare Biomedical Technology Inc
- 5 -
Power source AC: 100V-240V, 50Hz/60Hz
Battery Rechargeable Ni-Hydrogen battery, DC12V, 2000mAh (Battery lasts
approximately 4 hours)
Classification Class II, Internal power supply ,Type CF, IPX4
Net weight 21 KG
Dimensions 151mm × 150mm × 235mm (5 94” x 5 90” x 9 25”)
Operating Ambient temperature ：+5 °C ～ +40°C ( 41°F ～ 104°F)
Operating Relative humidity ：20%～90%
Operating Atmospheric pressure ：70KPa～106Kpa
1.3 Description
• The DigiPump LP8 is designed for precise infusion of both general parental solution and solution with
high surface tension, offering safety, performance and convenience with its easy-to-set adjustment and
compensation functions
• Applications include continuous infusion at operating room, ICU, CCU, chemotherapy, TPN, nutrition,
infusion of oxytoxics and anti-cancer drugs
• It allow the use of general purpose infusion sets Variations in drop size during the infusion flow as
changed by the infusion flow is automatically corrected by a built-in program in the pump to
administer intravenous fluid over a long period of time without error
• Standard IV sets (10,15,20,60drops/mL) can be used (we suggest the use of only high quality infusion
set brand)
• The internal battery provides continuous infusion when moving the patient or in case the AC power
loss (battery operation time is 4 hours if flow rate is below 30drops/min or 90ml/h)
• “Empty” function automatically program the volume to be the whole bottle
• Flow rate selection between “ml/hr” and “drop/min”
• The linear pump cassette is detachable and can be washed in water
• The infusion set clamp is detachable and can be easily washed in water
• Single-handed operation is possible

Operator’s Manual DigiPump LP8 Infusion Pump - Digicare Biomedical Technology Inc
- 6 -
1.4 Components and Functions
1.4.1 Front view
1.4.2 Infusion components
IV guide slot
Tube clamp
Handhold: Easy
single-handed operation
Alarm light: High
intensity Alarm Light
Indicator can be observed
at distance
Handle: Easy to
carry
Keyboard: menu settings
pushbuttons
LCD: Display with Rate
and Volume Indicators,
infusion status and alarm
me
ssages
Pump door switch: Pull
it to open the door
Pump door
Power indicator: Ac and
Battery Charge Indicators
Linear
pump cassette
Air detector
Occlusion sensor

Operator’s Manual DigiPump LP8 Infusion Pump - Digicare Biomedical Technology Inc
- 7 -
1.4.3 LCD
1.4.4 Keyboard
Adjust mode
:
Adjust
Mode Indicator
Select IV set：Set to
10,15,20 or 60d/ml
Alarm
messages
window
Flow rate setting
：
Set
the Flow Rate in
drop/min or ml/h
V
olume setting
:
Set
volume to be infused
and display the total
volume infused
Drop/min
ML/hour
VTBI indicator
Total
Volume
infused indicator
Empty-mode key: Press it to start or stop
the empty-mode when setting infusion
volume
Power
switch
Confirm key: To confirm and store
the data
Start/Stop: It lights when turn on
the pump
Arrow-key: To advance and return
throughout the display menu
settings
Data Input Key: Press it to
increase or decrease the data
Silence switch:
Press to disable and
enable the audio
alarm
Power indicator: When illuminates,
indicate powered by the internal battery
When illuminates, indicates powered
by AC mains
Clear-key: Clear the
alarm or the setting
parameter to zero
Purge rate: Press and hold to
start the purge function Release
to stop

Operator’s Manual DigiPump LP8 Infusion Pump - Digicare Biomedical Technology Inc
- 8 -
1.4.5 Rear view
1.4.6 Bottom components
Drop detector: Place it at
this point when it is not in
use
Adjust for Occlusion
Pressure, Air IN Line
alarm sensitivity and
Alarm volume
AC Power receptacle: Class II
type CF, Drip-proof design
AC power switch: Class
II,type CF, Drip-proof
design
Pole Mount
Auto Adjust: Press the key
to adjust the IV set
automatically
Drop detector
receptacle
Battery compartment
Remove the screw to access
the battery
Battery
Battery Compartment
Fixation nip at the bottom:
when there are many infusion
pumps working at the same
time, you can fix these pumps
on the bar through the nip

Operator’s Manual DigiPump LP8 Infusion Pump - Digicare Biomedical Technology Inc
- 9 -
Receptacle
Chapter II. Installation
2.1 Packing list
When opening the package, verify that the items below are enclosed:
1) Infusion pump ……………1
2) Drop detector ………… ……1
3) Knob bolt …………… …… 1
4) Power cord…………… ……1
5) Operator Manual……………1
2.2 Installation
2.2.1 Set the knob bolt firmly
Attach the knob bolt to the pole holder located on the rear of the pump
2.2.2 Set drop detector
1) As showed in the picture on the right, insert drop
detector plug in the receptacle at the rear panel
Note: If the drop detector is not well connected,
the display will show “ ”
2) When the drop detector is not in use, it shall stay on
the position showed in the picture
Chapter III. Basic Operation
3.1 Preparation
The battery should be charged before using the pump for the first time or if it has been stored for a
long time
1. Connect the power cord to AC power receptacle;
The place where the
drop detector is kept
Knob bolt

Operator’s Manual DigiPump LP8 Infusion Pump - Digicare Biomedical Technology Inc
- 10
-
2. Press “ ”over 0 5 second to turn on the machine The AC power “ ”indicator light will
illuminate and the battery indicator “ ” will flash and the charge will begin;
3. Press “ ” over 0 5 second to turn off the power The “ ” flashing indicates it is in charging
state Approximately 16 hours later the indicator light “ ” stop flashing, indicating the battery
is fully charged
3.2 Installation
3.2.1 Install the machine
1 To attach the pump firmly on the IV pole, please use the knob bolt and pole holder located on the back
panel Place IV pole through the opening and tight knob bolt firmly
2 Connect power cord to receptacle, turn on the switch in the rear panel, press “ ”over 0 5 second
If “ ” flashes it indicates that the power supply is connected
3 The infusion pump will perform self-check automatically after it is turned on This test includes: if the
battery is charged, if the drop detector is attached, if all the system functions are normal If something
is not correct, an alarm will be trigged indicating the error code (such as AIR, LOW BATTERY, Errs
etc )
4 After turning on, the device will check the battery automatically If the charge is low, it will recharge
automatically and “ ” will flash
Note: If the machine is not connected to the AC power or if the power is cut off, the pump will
change automatically to battery operation and the indicator “ ” will come on The indicator
“ ”flashes and sound alarm is triggered indicating AC power loss Press any key to clear the alarm
3.2.2 IV Set Installation:
1 Close of IV set roller clamp Insert IV set drop chamber sharp extremity into the outlet of the solution
container
2 Press drop chamber of IV Set gently between fingers
few times to fill 1/4-1/3 chamber full ,as shown in the picture
Turn the roller clamp
left to close it

Operator’s Manual DigiPump LP8 Infusion Pump - Digicare Biomedical Technology Inc
- 11 -
D
A
B
C
Note: To make sure it can infuse normally, do not leave the chamber full of liquid or the pump will not
be able to detect the drops At the same time, if the chamber is not filled with liquid at least 1/4, the
pump will easily alarm because of the bubble formation in the chamber
3 Open the roller clamp to remove air from IV set tubing
Then close the roller clamp
Note: Make sure the air filter is open and tubing is correctly
placed in the pump or it may cause occlusion and alarm
4. Open the door and pull the tube clamp (D) to the left to insert
the IV set
5 Keep the IV set tube straight and insert it to the guides
A, B and C
6 Release the roller clamp;
Note: Make sure it doesn’t drip in the drop until you start
the infusion
3.2.3 Install the drop detector
Install the drop detector following the instructions below:
1 Place the drop detector at middle point above the liquid level and bellow the chamber drop point
(As show in the picture)
Note: Make sure to install the drop detector correctly according to the above instructions or it may cause
alarms and errors
2 Keep drop chamber straight If it is over sloping, it may cause alarms and errors
Drop
Indicator light of
drop detected : It
will light for each
drop detected
1/4-1/3 of liquid
Keep the drop
detector flat

Operator’s Manual DigiPump LP8 Infusion Pump - Digicare Biomedical Technology Inc
- 12
-
3 Keep drop detector away from direct sun light or other source of strong light or it may cause alarms
4 When there is liquid on the sidewall of the chamber, shake it gently to clear the sidewall and make
sure the drops are detected correctly
3.3 Select the type of IV set
1 Press “ ”or“ ”, set the cursor at “ ” When the “ ”flashes, it means it
is selected;
2 Press“ ”or“ ”to choose the type of IV set which you need, 10, 15, 20 or 60 drop/ml” Press
“ ”to confirm;
NOTE: If the IV set is selected incorrectly it will seriously affect the infusion accuracy Make sure
you set the appropriate IV set
3.4 Setting the adjustment factor
Warning: To keep the highest infusion accuracy, we recommend to use a reliable, standard PVC IV set
(Outer diameter is 3 4mm-4 5mm) If you use one IV set which cannot meet this requirement, it may
affect the accuracy
Possible errors that affect accuracy
Error How to Solve
1. The IV set used
diameter is different
from the default
programmed
The IV set must be adjusted Please refer to the “3 9 4 Auto-adjustment
for IV set ”or “3 9 5 Manual-adjustment for IV set ”to get the IV set
adjustment value
2. Infusion of a liquid
with high surface
tension
High surface tension liquid requires adjustment value referring to the
value sheet (see table 3 4)
Note: Most drug liquid has low surface tension and not need
adjustment Only for the high surface tension liquid need
adjustment factor

Operator’s Manual DigiPump LP8 Infusion Pump - Digicare Biomedical Technology Inc
- 13
-
3. IV set distortion
due to long time use
in the same tube
segment
1) After the IV set has been used over 5-6 hours, we suggest reposition
the IV tubing down or up 20cm for the linear pump cassette act on a
new tube position
2) We suggest the replacement of the IV set when it has been used for
20 hours or more
Table 3.4
Adjustment value of different surface tension liquid (only for reference)
Liquid Adjustment value
Standard (low surface tension) 0%
Dextrose(10%) +5%
Dextrose (50%) +10%
TPN +5~10%
TPN+ fat-soluble vitamin +10~20%
1 Assume that you want to infuse dextrose (10%) solution The corresponding adjustment value is
+5% (table 3 4)
The IV set adjustment value is +3% through “3.9.4 Auto-adjustment for IV set ” or “3.9.5
Manual-adjustment for IV set ”;
2 The total adjustment value = IV set adjustment value (3%) + High Surface Tension liquid adjustment
value (5%), so the value needed as adjustment factor shall be 8%
3 Press“ ”or“ ” to place the cursor at , the flashes;
4 Press“ ”or“ ”, set 8% ,then press “ ”
Warning: Setting a wrong Adjustment Factor will reduce the specified accuracy.

Operator’s Manual DigiPump LP8 Infusion Pump - Digicare Biomedical Technology Inc
- 14
-
3.5 Setting the flow rate and volume to be infused
1. Flow rate setting: press“ ”or “ ”to move the cursor to “ ”or“ ”; At this
time, “ ”or“ ”will light Press “ ”or“ ”to set the digit Move to next digit
pressing “ ”or “ ” and move the cursor on the digit you want to set Continue with this
procedure until you finish the rate value setting, then press “ ”
2. Volume to be infused setting: press “ ”or “ ”, point the cursor on “ ”
The“ ”will light Set the volume digits following the same procedure as above, then press
“ ”
3. Rate and Volume Setting Range
IV set Ml/H Drops/Min Volume Limit
Setting Range
10drops/ML 1 0-999 9 1 0-166 6 1-9999ml
15drops/ML 1 0-999 9 1 0-249 9 1-9999ml
20drops/ML 1 0-999 9 1 0-333 3 1-9999ml
60drops/ML 1 0-150 0 1 0-150 0 1-9999ml
4. Empty bottle mode: When setting the Volume Limit, press the“ ” The volume setting
will indicate and will go to the “Empty” bottle mode, then press” ”to confirm
Pressing “ ” start infusion and the pump will infuse all liquid in the bottle automatically
5. Volume Infused Display : This indicator display the total volume infused To clear this
indicator press“ ”or“ ” and point the cursor on“ ”
The“ ”will flash Press“ ”for 0 5 seconds The device will sound a beep and reset
total volume indicator to “0”, then press to confirm
3.6 Starting Infusion
1 Make sure all settings are correct;
2 Make sure there is no bubble in the IV set , then perform venipuncture ;

Operator’s Manual DigiPump LP8 Infusion Pump - Digicare Biomedical Technology Inc
- 15
-
3 Press“ ” to start infusion The LCD“ ” moves indicating the infusion is running;
Attention: Observe if the drop detector lights for each drop detected
3.7 Finishing Infusion
1 When volume infused display reaches volume to be infused (limit) setting, the pump will display a
“ ” alarm to notify that the infusion is completed The pump will turn to KVO function The
minimum flow rate is maintained to prevent occlusion Press“ ” to stop KVO function
3.8 Powering Off
1 Press“ ”for 0 5 seconds until powered off;
3.9 Extended Operation
3.9.1 Pause/Restart
a) Pause infusion : pressing the “ ” during infusion will pause the pump
b) Restart: pressing the “ ”again, the pump will restart the infusion
NOTES: Pausing for more than 2 minutes will activate the alarm system (Pause Overtime)
Press “ ” to clear the alarm and maintain the pause state
3.9.2 To continue another solution container
1 Change to a new infusion container and make sure that the IV set is connected correctly
2 Change the IV tubing down or up 20cm to make the linear pump cassette act on a new position
of tubing after the IV set has been used over 5-6 hours
3 The total infused volume will add with the new volume to be infused programmed If you want
to clear the total infused volume display:
With the “ ”flashing, press“ ” for 0 5 seconds and the display will reset to 0

Operator’s Manual DigiPump LP8 Infusion Pump - Digicare Biomedical Technology Inc
- 16
-
Notes: Turning power off and back on, reset the total infused volume to “0” automatically The
IV set, flow rate, adjustment value and volume to be infused (limit) will keep the last
programmed settings
The maximum volume displayed is 9999ml If the total volume exceeds this value the
display will stay showing 9999m
4 After all settings for IV set, Flow rate, adjustment factor and volume are done, press “ ” to
restart infusion
3.9.3 Purge Function
This function can be used to fill in, cleaning IV set or remove the air from the IV set quickly In
addition, it can also be used for high rate infusion in a short time such as first aid etc Please follow the
steps below
1 In Stop mode, press“ ” button for 1 0 second to perform the purge function
2 Just release the“ ” to stop the purge function
3 Purge Rate: for 10, 15, 20 drops/ml, IV set purge rate is 600ml/h; for 60 drops/ml, IV set purge
rate is 150ml/h
NOTE: During purge function, air in line alarm will only trigger a visual alarm, and not the audible
alarm, and the infusion will not stop The volume infused is not added to the Total Volume
Infusion indicator
3.9.4 IV Set Auto-adjustment
In order to keep the maximum specified infusion accuracy, we recommend the use of a reliable standard
PVC IV set ( outer diameter is 3 4mm-4 5mm) Use 0 9% standard physiologic solution or pure water for
adjustment following the steps below:
1 Hang the liquid container filled with 200ml (or more) physiologic solution or pure water
2 Close the IV set roller clamp and make sure that no leakage occurs
3 Insert the IV set drop chamber to the liquid container, place the IV set in the pump with the drop
detector attached correctly, then open the roller clamp
4 Connect to AC power and turn on the pump

Operator’s Manual DigiPump LP8 Infusion Pump - Digicare Biomedical Technology Inc
- 17
-
5 Press the “AUTO ADJUST” key on the back panel, the display indicator will
flash and a beep will sound indicating the adjustment mode has been entered
6 Press“ ”or“ ” to move the cursor to and set the type of IV set
7 Press“ ”or“ ”to move the cursor to and set the flow rate to 200ml/h
8 Press“ ”or“ ” to the cursor at and set the volume limit to 200ml
9 Press“ ”to start the auto-adjustment function, pay attention to the drop detector indicator light
whether it flashes at each drop detected
10 During the auto-adjustment procedure, will flash to show it is in the process of
adjustment When 200ml has been infused completely, the pump will stop automatically and alarm
11 The LCD will indicate “ ” after successful auto-adjustment, will flash and
the adjustment factor value will be displayed You can press“ ”to store the value If the process
of adjustment does not run properly and stops (Open, Occlusion etc ), or if the adjustment value is
not in the range of -30% to +30%, the LCD will indicate “ ”alarm to show the failure of the
adjustment process You need to turn off the pump then turn on again and restart the adjustment
process
12 Check whether the solution container has been emptied If not, the adjustment value will be useless
Reset the machine and repeat the steps mentioned above until the valid adjustment value is obtained
13 The will flash and the adjustment value (automatically calculated by system) is
displayed Press to confirm and store the result in the memory which will be used as default
setting on the next power on
Note: If the hospital uses different types of IV sets, you must get their corresponding adjustment
value according to the auto-adjustment function mentioned above Write them down and set
the corresponding value when use, it will ensure the maximum infusion accuracy
3.9.5 IV set Manual Adjustment
The user can calculate the error and manually enter the adjustment factor
1 To verify error in IV sets of different brand or type, use 0 9% standard physiologic solution or pure
water for infusion Set the flow rate to 125ml/hrin (range: 100ml to 150ml/hr)
2 After more than 50ml is infused, calculate the adjustment factor

Operator’s Manual DigiPump LP8 Infusion Pump - Digicare Biomedical Technology Inc
- 18
-
3 The formula for adjustment is:
Note: “Volume Infused Display” is for “ ”volume In order to measure the “Actual Volume
Infused” you need to use a graduated glass or similar to measure the actual infusion volume by yourself
The adjustment for IV set should be in the range of -30% to +30%
3.9.6 Occlusion Valve Adjustment
Use one small flat screwdriver to rotate the potentiometer located on the back panel and adjust the
Occlusion Pressure level to alarm The Pressure range is 40Kpa to 140Kpa divided in
8 levels
Note: When the pressure in the infusion set reaches the Occlusion Limit Pressure,
an alarm is triggered and stop infusion The time to alarm Occlusion is directly related with flow rate
and occlusion limit pressure set
Note: Turning the potentiometer clockwise increase the Pressure limit to alarm Occlusion
3.9.7 Sound Volume adjustment
The alarm sound volume can be adjusted by using a small flat screwdriver to
rotate (clockwise to increase or anticlockwise to decrease) the potentiometer
located on the back panel (as shown in the picture)
Alternatively, no sound alarm can be obtained by pressing the MUTE
on the front panel For security, the alarm sound will be activated again after 3 minutes
Position
indication 1drop/Min 80drops/Min Volume
Position
1
Time to Alarm
5 min 37 s
Time to Alarm
5 6 seconds 0 37mL
Position
8
Time to Alarm
18 min 16 s
Time to Alarm
10 5 seconds 0 7mL
