Digital-Ally DTM-600 User manual

860-00324-00 Rev B 1
DTM-600
User Guide

860-00324-00 Rev B 2
Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact
the dealer.
Disclaimer
No part of this manual may be copied, reproduced, translated, or distributed in any form or by any means without
prior written consent from Uniview.
The manual may be updated from time to time due to version upgrade or other reasons.
The manual is for reference only. All the statements, information, and suggestions contained herein do not
constitute warranties of any kind, express or implied.
Uniview shall not under any circumstances be liable for any special, consequential, incidental or indirect damages
arising from the use of this manual or Uniview's product, including but not limited to any loss of commercial
profits, losses caused by missing data or documents, and anomalies during product running or information leakage
due to cyber attacks, hacker attacks, or virus attacks.
Safety Precautions
CAUTION!
The default password is used for your first login. To ensure account security, please change the password after
your first login. You are recommended to set a strong password (no less than eight characters).
Before performing operations, be sure to carefully read through and observe safety specifications in this manual.
Screenshots provided in this document are used as examples only and the UI layout varies with versions.
This manual applies to multiple models but the models are not completely listed herein. Refer to actual
products while reading this manual.
Zhejiang Uniview Technologies Co., Ltd. (hereinafter referred to as "Uniview") reserves the right to
modify the content in this manual without prior notice or prompt, but Uniview does not ensure that
this manual is completely error-free.
Subject to uncertain factors such as the physical environment, actual values of data may differ from the
reference values described here. In case of any question or dispute, the right of final interpretation
resides with Uniview.
Follow operation instructions in this manual when using the product. Uniview is not responsible for
problems caused by the violation of the instructions. Thank you for your cooperation.
Environmental Protection
This product has been designed to comply with the requirements on environmental protection. For the proper
storage, use and disposal of this product, national laws and regulations must be observed.
Conventions
The figures, charts or photos in this manual are used for illustration only, which may differ from the
actual product.
This manual applies to multiple models but the models are not completely listed herein. Refer to actual
products while reading this manual.

860-00324-00 Rev B 3
Subject to uncertain factors such as the physical environment, actual values of some data may differ
from the reference values described here. In case of any question or dispute, the right of final
interpretation resides with Uniview.
Follow this manual when using the product. Professional guidance is recommended.
Notational conventions used in this document are described as follows:
Format
Description
Boldface
Indicates buttons, menus, tabs, window names, dialog names, and parameter names. For example, click
OK or select Device Management.
" "
Indicates messages. For example, "Hanging Up" is displayed on the interface.
>
Directs you to go to a multi-level menu. For example, go to Device Management > Add Device. In this
example, Add Device is a submenu under Device Management.
The symbols in the following table may be found in this manual. Carefully follow the instructions
indicated by the symbols to avoid hazardous situations and use the product properly.
Symbol
Description
WARNING!
Contains important safety instructions and indicates situations that could cause bodily injury.
CAUTION!
Means reader be careful and improper operations may cause damage or malfunction to product.
NOTE!
Means useful or supplemental information about the use of product.

860-00324-00 Rev B 4
Contents
1 Application Scope of the Manual
····························································································· 1
2 Product Overview
··············································································································· 1
3 Product Appearance
············································································································ 1
4 Product Installation
··········································································································· 4
5 Local Operations
················································································································ 4
5.1 Initial Interface
·············································································································· 4
5.2 Main
Interface ··············································································································· 5
5.3 Ad
Mode ······················································································································ 7
5.4 Mask/Temperature Measurement Interface
········································································ 9
5.5 Activation Config
··········································································································· 14
5.5.1 Basic Info
··········································································································· 15
5.5.2 Device Location
···································································································· 16
5.5.3 Network Setting
··································································································· 17
5.5.4 User
Management ································································································· 18
5.5.5 Activation
Password ······························································································· 21
5.5.6 Admin
Password ··································································································· 22
5.5.7 Authentication Scene
····························································································· 22
5.6 Call Operations on Visual Intercom Face Recognition Terminal
····················································· 24
5.6.1 Call Resident
······································································································· 24
5.6.2 Call Management
Center ························································································· 26
5.7 Door Opening Method
···································································································· 27
5.7.1 Face Scan-based Door
Opening ·················································································· 27
5.7.2 Password-based Door
Opening ·················································································· 29
5.7.3 Card Swiping-based Door
Opening ·············································································· 31
5.7.4 QR Code-based Door
Opening ··················································································· 31
5.7.5 Remote
Opening ··································································································· 31
6 Personnel Management
····································································································· 32
6.1 Personnel Information Input
····························································································· 32
6.1.1 Information Import to the Terminal
············································································ 32
6.2 Personnel
Deletion ········································································································· 33
7 Web Operations
··············································································································· 33
7.1 Login
························································································································· 33

860-00324-00 Rev B 5
7.1.1 Preparation ········································································································· 33
7.1.2 Logging In to the Web Interface ················································································· 35
7.2
Photo ························································································································· 36
7.2.1 Photo List
Sorting ·································································································· 37
7.2.2 Total Capacity/Available
Capacity ··············································································· 37
7.2.1 Photo Naming
Rules ······························································································· 37
7.2.2 Refreshing the Photo Library
···················································································· 38
7.2.3 Exporting Records
································································································· 38
7.2.4 Exporting Photos
·································································································· 38
7.2.5 Deleting a
Photo ··································································································· 38
7.2.6 Exporting and Deleting Photos
·················································································· 39
7.3 Parameter
Configuration ·································································································· 40
7.3.1 Common
············································································································ 40
7.3.2
Network ············································································································· 58
7.3.3
Image ················································································································ 58
7.3.4
Intelligent ··········································································································· 67
7.3.5 Events
··············································································································· 83
7.3.6
Storage ·············································································································· 86
7.3.7 Security
············································································································· 86
7.3.8 System
·············································································································· 88
8 Live View
······················································································································· 91
9 FAQs
····························································································································· 92

860-00324-00 Rev B 6
1 Application Scope of the Manual
Table1-1 Application Scope of the Manual
Model
Name
ThermoVu DTM-600
Face Recognition Access Control Terminal with temperature module
2 Product Overview
Visual intercom face recognition terminal ("the face recognition terminal" for short) is a face
recognition access control product featuring high performance and high reliability. The UNV face
recognition technology is perfectly integrated into the access control device, which relies on deep
learning algorithm, to support face authentication to open the door and achieve precise control of
human. Moreover, using remote control to open the door is also supported via indoor monitor. And it
can be widely applied to the scenarios of building systems, such as smart communities, public security,
parks and other important areas.
3 Product Appearance
The figure below shows the structure of the device. The actual device shall prevail.
OET-213H
Figure3-2 Device Structure

860-00324-00 Rev B 7
1.Light supplement lamp 1
2.Camera 1
3. Infrared light supplement lamp
4.Camera 2
5.Light supplement lamp 2
6.Display screen
7. Pass-through indicator
8.Microphone
9. Card reading area
10.Loudspaker
11.Reset
12.USB2.0
13.Network interface
14.Power input (DC 12V±25%)
15.20-pin interface
16.Tamper proof button

860-00324-00 Rev B 8
4 Product Installation
Installation of OET-213H
For the wiring and installation of the device, refer to the ET-B31H-M@B Face Recognition Access Control Terminal
Quick Guide.
5 Local Operations
5.1 Initial Interface
When the face recognition terminal is used for the first time or the factory defaults are restored, users need to
set the activation password, which is used to log in to the Activation Config interface.
NOTE!
⚫The password must contain at least eight characters (including at least two of the following types: upper case
letters, lower case letters, digits, underscores, and hyphens).
⚫The activation password is consistent with the password for the admin to log in to the Web interface. If the
activation password is changed, use the new password to log in to t h e Web interfa ce .
After the activation password is configured, the main inter face of the visual intercom face recognition ter
minal is displayed. If the activation password needs to be changed later, refer to " Activation Password " to
change the password.
Figure5-1 Activation Password Configuration Interface

860-00324-00 Rev B 9
5.2 Main Interface
The main interface displayed on the face recognition terminal varies with the device type.See Device Info .
Figure5-2 Main Interface (Video Intercom Mode)
Test
No.
Description
1
Displays the current date, time, and connection status of different services.
indicates the following items from left to right:
⚫Whether to enable the face scan mode
⚫Whether an ID card reader is connected properly
⚫Whether server 1 is online
⚫Whether server 2 is online
NOTE!
An icon marked with indicates "No".
2
Total：total number of detected people.
Normal：Number of people with normal temperature
This interface is only displayed when the temperature measurement function is enabled. For detailed
operation description, see “Advanced Setting”.
3
Displays the photo and name of an identified person in the library. Refer to Recognition Result Displayto
enable the face recognition terminal to display one or more registered face pictures.
When Multiple Faces is selected, information about the latest person identified successfully, is displayed
on the left of the screen. The interface can display information about five recent persons identified
successfully at most.

860-00324-00 Rev B 10
4
Calls a resident. For detailed operation description, see "Call Resident".
Enters a password to open the door. For detailed operation description, see
"Password-based Door Opening".
Calls the management center. For detailed operation description, see "Call
Management Center".
QR code used for door opening. For detailed operations, see "QR Code-based
Door Opening".
5
Title bar, which can be defined by users. For detailed operations, see "Custom Logo and Prompt".
6
Logo bar, which can be defined by users. For detailed operations, see "Custom Logo and Prompt".
7
Displays the identification result (such as identified successfully or unregistered person), authentication
mode (such as face scan or card swiping), and other information.
8
Displays the number of people in the employee library and that in the visitor library.
9
Status bar at the bottom
Displays the device IP address, real-time temperature, preset minimum temperature, ambient
temperature, and match time.

860-00324-00 Rev B 11
5.3 Ad Mode
The face recognition terminal supports ads (three pictures at most). For the ad configuration, see "Ad Mode" .

860-00324-00 Rev B 12
Figure5-4 Ad Interface
In ad mode, the system does not exit the ad mode if a person passes the authentication (via face scan or card
swiping). If a person fails the face scan or taps the screen, the system exits the ad mode and the face recognition
terminal displays the Main Inter face .

860-00324-00 Rev B 13
5.4 Mask/Temperature Measurement Interface
In response to the current epidemic, companies, parks, and communities take temperatures and check mask
wearing for people passing through the entrances and exits. The work is performed by people manually, which is
exhausting and increases the risk of cross-infection. The face recognition access control terminal is capable of
checking whether people are wearing masks and taking their temperatures (an intelligent digital detection module
is required, and either the forehead temperature or wrist temperature can be taken). For people with abnormal
temperature (exceeding the preset maximum temperature threshold) or without masks, the face recognition
access control terminal displays an alarm on the GUI, plays a warning sound. and determines whether to open the
door based on actual application scenes, thereby achieving epidemic prevention and control. For detailed
configuration, see Intelligent —Advanced Setting and Authentication Scene.
NOTE!
⚫When the temperature measurement function is enabled to take the forehead temperature, a person needs to
get close to occupy the human shape on the screen and aim the forehead center at the red circle, as shown in
Figu re 5 - 5.When the wrist temperature needs to be taken, a person needs to aim the wrist at the
temperature- measuring point of the digital detection module.
⚫Ensure that the forehead or wrist is at a proper distance from the intelligent digital detection module. For OEP-
BTM32-NB, the recommended distance is 0.5–0.7m. For OEP-BTS1-NB, the recommended distance is 1–2.5cm.
⚫When the forehead temperature needs to be taken, the forehead cannot be covered by fringes, hats, sunglasses,
or other objects. When the wrist temperature needs to be taken, the wrist cannot be covered by sleeves,
watches, bracelets, or other objects. Such objects, if any, need to be removed from the forehead or wrist 0.5 to
1 minute before the temperature can be taken.
⚫The temperature measurement function requires an intelligent digital detection module, which can be connected
to the visual intercom face recognition terminal through RS485. For the configuration, see Serial Po rt .
⚫Do not use the temperature measurement function together with the safety helmet/safety module function.
1. Mask detection and temperature measurement
Enable both the mask detection and temperature measurement functions on the visual intercom face recognition
terminal. When a person (whose information is stored in the library) passes through the terminal, the GUI displays
the detection result.
NOTE!
The following figures show interfaces of forehead temperature measurement. The interfaces of wrist temperature
measurement are basically the same as those of forehead temperature measurement except that no human shape
and red circle are displayed on the GUI. For the wrist temperature measurement interface, see Figu re 5 -
8 .

860-00324-00 Rev B 14
Figure5-5 Normal Temperature and Mask Worn
Measure Forehead Temperature Measure Wrist Temperature
Figure5-6 Mask Worn but Abnormal Temperature
Measure Forehead Temperature Measure Wrist Temperature

860-00324-00 Rev B 15
NOTE!
When both the temperature measurement and mask detection functions are enabled, temperature measurement is
prior to mask detection. Once an abnormal temperature is detected, an "abnormal temperature" alarm is reported
on the GUI and the warning sound is played no matter whether the person wears a mask.
Figure5-7 Normal Temperature but Mask Unworn
Measure Forehead Temperature Measure Wrist Temperature
2. Temperature measurement mode
The visual intercom face recognition terminal supports pure temperature measurement mode, in which the
temperature measurement function is enabled but no authentication mode is configured in the face library (for
details, see Face Library Management ). In this mode, the visual intercom face recognition terminal
determines whether to open the door based on actual scenes for persons with abnormal temperature.
For detailed configuration, see Intelligent —Advance d Setting .

860-00324-00 Rev B 16
Figure5-8 Temperature Measurement Mode
Measure Forehead Temperature Measure Wrist Temperature
Normal Temperature: The temperature of a detected person is normal. For the prompt on the GUI and voice
prompt, see Figure 5 -5 .
Abnormal Temperature: The temperature of a detected person is abnormal. For the prompt on the GUI and
voice prompt, see Figure 5 - 6 .

860-00324-00 Rev B 17
3. Mask detection
The visual intercom face recognition terminal supports mask detection. When a person (whose information is
stored in the library) does not wear a mask, an alarm is reported on the GUI and a warning sound is played. For
those who do not wear masks, the terminal determines whether to open the door based on actual scenes. For
detailed configuration, see Intelligent —Advanced Setting.
Figure5-9 Mask Worn

860-00324-00 Rev B 18
Figure5-10 Mask Unworn
5.5 Activation Config
Hold down the main interface of the face recognition terminal for a long period of time (longer than 3s). In the
displayed password input interface, enter the configured activation password to go to the Activation Config
interface. If you forget the password, contact the local deale to seek help.
NOTE!
The initial activation password is configured on the in itia l interfa ce.If it is changed (on the local d evi ce or on
the
Web inter face ), enter the new activation password.
Figure5-11 Activation Password Input Interface
On the Activation Config interface, you can view basic information about the face recognition terminal, configure
the device location, network, and password, input personnel information, and authentication scene.

860-00324-00 Rev B 19
Figure5-12 Activation Config Interface
5.5.1 Basic Info
The Basic Info interface allows you to view the status of the current device in real time, so as to rapidly know
about the device condition and better maintain the device.
(1) On the Activation Config interface, tap to go to the Basic Info interface.

860-00324-00 Rev B 20
Figure5-13 Basic Info Interface
5.5.2 Device Location
On the Device Location interface, you can configure the community, unit, and management center to which the
device belongs.
(1) On the Activation Config interface, tap to go to the Device Location interface.
Figure5-14 Device Location Interface
(2) Configure device location information by referring to the table below.
