iSAPPOS B User manual

iSAPPOS 9/12 Stand
(Model B and C)

1
Getting ready with
the stand
Package contents
System Overview
Getting started

2
Model B
Aluminum base plate
Aluminum Stand body
Jacket for iPad
5V/4A 20W power adapter
3 x RJ-48 COM port cables
1 x Micro-USB cable (for data-syncing)
2 x Screws for the Stand jacket
2 x thumb screws for the Stand base plate
2 x coin screws for the rear cover
Quick user guide
1. iPad not included. Compatible only with iPad 2017 (2017 Q3), iPad Air 2, 9.7” and 12.9” iPad Pro.
1. iPad not included. Compatible only with iPad 2017 (2017 Q3), iPad Air 2, 9.7” and 12.9” iPad Pro.
Section 1
Package Contents Model C
Aluminum base plate
Aluminum Stand body
Jacket for iPad
19V/4.7A 90W power adapter
2 x RJ-48 COM port cables
1 x RJ-11 cable for cash drawer
1 x Micro-USB cable (for data-syncing)
2 x Screws for the Stand jacket
2 x thumb screws for the Stand base plate
2 x coin screws for the rear cover
Quick user guide
1
1

The Jacket
3
The Stand
Model B
Model B
Section 2
System Overview (unit: mm)
(unit: mm)

4
Model B
Model C
Model C
Model C
I/O Ports
1
2
3
4
Power connector
RJ-48 to COM ports
Micro-USB port (iPad data syncing)
Bluetooth Pair button
1RJ-11 cash drawer port 4Micro-USB port (iPad data syncing)
2RJ-48 to COM ports 5USB port (peripheral charging)
3Power connector 6Bluetooth Pair button
1 2 3 4
1 2 3 4 5 6

1
2
3
1
2
3
Power LED:
Solid green System on
Off: System off
Error LED:
Solid red System error
Off: System normal
Paper LED:
Solid green Printer normal
Solid red: printer error
Model B/C
(rear view of the Stand with rear plastic cover removed)
Model C
LEDs
1
Pairing LED:
Blinking green: Stand
Bluetooth pairing mode on
1
5

6
Getting started
Assemble iPad and the Stand
Tools needed - Phillips(+) #0 Screwdriver
Assemble the stand
1. Secure the base plate and Stand body with M4 thumb screws (x4) found
in the accessory box.
Section 3
Getting started 2. Connect the power adapter for charging.
3. Place the back cover to the back of the stand. Secure the back cover the
base plate using the coin screws (x2) found in the accessory box. Tighten
them with a coin.
* Please make sure the
power adapter is plugged
in before connecting the
3rd party peripherals

7
4. Insert the iPad to the jacket
Slide open the jacket
Insert and align iPad with the jacket (It’s normal to see the side with
the home bottom is higher than the other side)
Place the jacket onto the Stand’s dock. (make sure the lock-unlock switch
is in the unlock position)
Slide close the jacket gently and slowly. While sliding close the jacket,
press down both corners of the iPad like indicated in the picture and
make sure it’s aligned with the jacket.
Remove the paddings of the indicated screw holes. Secure the iPad
and the jacket with Phillips(+) #0 Screwdriver and M2 screws (x2) found
in the accessory box. Place the paddings to cover the indicated screw
holes.
5.
* Undock : Push the button at the bottom of the cradle and lift up the jacket to detach it from the Stand.

8
Unlock Jacket from the Stand Manually
If the jacket is placed on the Stand while the Lock-Unlock slider on the cradle is
in “Lock” position, you can manually override the switch and unlock the jacket
from the Stand by using a paperclip and push up the button hidden at the
bottom of the cradle. Lift up the jacket while the button is pushed up to detach
it from the Stand.
iSATouch Unlock
Install app (Model B and C only)
* The SteakHouse app is only an app to demonstrate the functions of the Stand. It is not suitable to be used
in the actual business environment.
When locked
Override
mechanism to
unlock
iSAPPOS SteakHouse POS

2
Turn on Bluetooth
iSATouch Unlock App
SteakHouse App
Running and using
the app

10
Section 1
Turn on Bluetooth
Pairing with the Stand (For Model B and C only)
The app will essentially help you set up the Stand with your iPad. As the Stand
communicates with your iPad through Bluetooth, please make sure Bluetooth
is enabled on your iPad by before launching the app. You can enable
Bluetooth by going to Settings —> Bluetooth.
After you have Bluetooth enabled, remove the back cover from the Stand
and locate the pair button in the back. Press the button to initiate bluetooth
connection between the Stand and your iPad. The Pairing LED should start
blinking.
Model B
Model C
1
2
Press pairing button
LED blink in green
1
2
Press pairing button
LED blink in green

About the app
The app provides a simple function that allows you to connect to your stand
and unlock the jacket from it by using Apple’s TouchID.
Launching the app (For Model B and C only)
After the app is downloaded and installed, you should be able to locate it on
the home screen. Simply tap on it to launch the app.
11
Section 2
iSATouch Unlock
App
Connect the Stand
Opening the app will start scanning a nearby Stand immediately. Push the pair
button in the back of the Stand will start broadcasting itself to the app.
Once the Stand is found, it will be displayed like shown in the screenshot
below. Simply tap the icon to connect to the stand.
* If your Stand is not found in the app, check the pairing LED in the back of the Stand and make sure it is blinking (in
pairing mode). If not, press the pair button to start pairing again.
* If you have multiple Stands nearby, you can easily locate the Stand you would like to connect to by looking up the
last four digit of the MAC address that is on the label in the back of your Stand. Match those numbers with the one
shown in the app.

12
Once you are successfully connected to the Stand, you should be directed to
When you pair your iPad with the Stand for the rst time, you will be prompted
to enter passcode, simply enter “2234” and tap “Pair” to nish the pairing
process.
another page of the app where you can access the unlock function.
* If a previously connected Stand is disconnected due to reasons such as out of range or powered o, the
icon will be displayed in a semi-transparent color illustrating an inaccessible Stand.
Tapping the icon will unlock the jacket from the Stand through Apple’s
TouchID function in your iPad. The jacket should be unlocked once the
ngerprint matches the one you set up in your iPad.

13
* In order for this function to work, please rst set up ngerprint for the TouchID function in your iPad by going to
Settings > Touch ID & Passcode
You will have a 10 second window to remove the jacket from the stand before
it is locked again. During this period of time, the unlock button will be disabled.
Using iOS Today’s Widget to unlock the jacket
After the app is installed, it also installs an app widget which can be accessed
from iOS Today’s Widget menu. The advantage of providing an app widget is
that the unlock function can be easily accessed anytime with a swipe down
on the screen regardless what app you are currently using.
To enable the widget, pull down anywhere from the top of the iPad screen to
access Today’s Widget menu.
You will need to enable the app widget rst. To do so, tap on the “Edit” button
to add the app widget to the menu.

14
You can now access the app widget in iOS Today’s Widget menu.
Tapping on the icon will allow you to unlock the jacket without leaving
or closing the app you are currently using.
*If your Stand is disconnected when you are unlocking the jacket from the Today’s Widget menu, the iSATouch Unlock
main app will be launched instead so you can pair with the Stand again.
You should see the iSATouch Unlock app widget from the list menu like shown
below. Tap on the green “+” button to add it to the Today’s widget menu.
Tap “Done” to nish.

15
Section 3
SteakHouse App
About the app
The app provides users the ability to connect and congure the Stand as well
as accessing its hardware functions in a form of a simple POS (Point of Sales)
app.
Launching the app (For Model B and C only)
After the app is downloaded and installed, you should be able to locate it on
the home screen. Simply tap on it to launch the app.
Log in the app
You will be prompted to log in after the app is launched.
If you have TouchID congured on your iPad, simply log in with TouchID.

16
If TouchID is not yet congured, tap on the “Enter Password” option to log in by
entering the password manually.
When prompted, enter the password to log in.
Connect the Stand
To connect the Stand with the app, tap on “BLE Cong” in the lower-left hand
corner of the app.
The app will start searching for Stands nearby. Press the “Pair” button in the
back of the Stand for the one you wish to connect with the app. Tap on the
one from the list to connect to the Stand.
Tap to connect
* if you are prompted for password, enter “2234” to connect to the Stand.

17
If you have more than one Stands powered on nearby, use the ID number
from the back of the Stand (with rear plastic cover removed) and match it with
the one from the list shown in the previous step to make sure you are
connecting to the desired Stands.
Once connected, you will be directed back to the main page upon a
successful connection. The connection status with the Stand should now be
“Connected” in the lower-left hand corner of the app.
Conguring the COM ports for peripherals
There are three COM ports in the model B and two COM ports in the model
C in which you can connect compatible peripherals to.
Change settings in the “COM Cong” page according to the peripheral that is
connected to the Stand through the COM interface.
*Do not change settings on Printer Port 3 when using the app with a model C Stand. The built-in printer in model C
is designed to use port 3 at all time.
*To change value of any eld, tap on the blue text in that eld to do so.
You shouldn’t need to change any settings when using a compatible peripheral. Simply connect the peripheral to
the Stand and make sure the Stand is connected to the app.
*

18
Connect and congure compatible printer
You can connect an external compatible printer through the COM port in the
Stand. Change the “Printer Model” in the “COM Cong” page that matches
the one that is connected to the Stand.
* HPRT is the default printer model as it is the one that is built into the model C Stand.
You can alternatively change it “Auto detect” for easier conguration when connecting to an external printer.
*
* The Stand supports COM interface printer from Star as well as Epson (only the models listed in the above
screenshots).
Connect and congure compatible scanner
The Stand supports COM interface scanner from Opticon. Be sure to select
the correct port number based on which port the scanner is being connected
to.
For any changes to take eect, tap “Set” rst and tap “Save” to save the new
settings.
* Should you have interest to purchase Opticon scanners, please contact us at [email protected]

19
Print receipts with the app
To print receipts with the app, add items from the menu rst. Added items
should be shown in the list on the left.
Tap on the “Cash” button should print out the receipt with items added.
Below screen will be shown after tapping on the “Cash” button. Simply tap
“Back” to go back to the main screen.
Tap to add items
