Digital Equipment VAXstation 4000 VLC Operating and installation instructions

VAXstation4000VLC
ServiceInformation
Order Number: EK-V48VB-SV.001

<set_trademark_table>(no_list)
ii

November 1991
<set_fcc_warning>(a)
© Digital Equipment Corporation 1990.
All Rights Reserved.
The following are trademarks of Digital Equipment Corporation: DEC, Digital, the
DIGITAL logo, Ethernet, ThinWire, VAX, VAXstation, and VMS.
This document was prepared using VAX DOCUMENT, Version 2.0.

Contents
Preface ..................................................... xi
1 VAXstation 4000 VLC System Components
1.1 Overview ........................................... 1–1
1.2 Central Processor Unit................................. 1–6
1.2.1 Processor Restart .................................. 1–8
1.2.2 Interrupt Controller ................................ 1–9
1.2.3 Interrupt Sources and Ranking ....................... 1–10
1.2.4 Interrupt Vector Generation .......................... 1–10
1.3 Main Memory........................................ 1–11
1.3.1 Main Memory Requests . . ........................... 1–12
1.3.2 DMA Mapping . ................................... 1–13
1.3.3 Translation ....................................... 1–13
1.4 ROM Memory........................................ 1–14
1.4.1 System ROM . . ................................... 1–14
1.4.2 Network Address ROM . . ........................... 1–14
1.5 Graphics Controller ................................... 1–15
1.5.1 Graphics Controller Screen Formats ................... 1–16
1.5.2 Graphics Controller Communication ................... 1–16
1.6 Serial Line Controller Feature ........................... 1–17
1.6.1 Serial Line Controller Registers ....................... 1–17
1.7 Time-of-Year Clock . ................................... 1–18
1.7.1 Battery Backup ................................... 1–18
1.7.2 TOY Clock Chip Register . ........................... 1–18
1.8 Network Controller Feature . . ........................... 1–20
1.8.1 Packet Format . ................................... 1–20
1.8.2 Network Addresses ................................ 1–21
1.9 SCSI Controller Feature ............................... 1–21
1.9.1 SCSI Bus Signals .................................. 1–22
iii

2 VAXstation 4000 VLC System Configuration
2.1 VAXstation 4000 VLC System Box ........................ 2–1
2.1.1 Mass Storage Device ............................... 2–3
2.1.2 Power Supply . . ................................... 2–3
2.1.2.1 Power Supply Specifications ....................... 2–4
2.1.3 VAXstation 4000 VLC System Controls ................. 2–6
2.1.4 System Box Internal Cabling ......................... 2–7
2.1.5 VAXstation 4000 VLC I/O Panel . . . ................... 2–7
2.1.6 VAXstation 4000 VLC System Box Specifications.......... 2–8
3 VAXstation 4000 VLC Firmware
3.1 Power-Up Initialization Code . ........................... 3–2
3.2 Console Overview . . ................................... 3–3
3.3 Extended Self Test Overview . ........................... 3–4
3.4 Utilities Overview . ................................... 3–5
3.5 System ROM Overview ................................ 3–6
3.5.1 System ROM Part Format ........................... 3–6
3.5.2 System ROM Set Format . ........................... 3–7
3.6 Configuration Table Overview ........................... 3–9
3.6.1 Main Configuration Table ........................... 3–10
3.6.2 Device Configuration Table .......................... 3–11
3.7 Driver Descriptor . . ................................... 3–15
3.8 Interfacing to Diagnostic Drivers ......................... 3–17
3.9 Console Driver Interface ............................... 3–19
3.9.1 Shared Console Interface Area ........................ 3–20
3.9.2 Console Port Driver ................................ 3–22
4 Diagnostic Testing
4.1 Diagnostic Testing . ................................... 4–1
4.1.1 Power-Up Test . ................................... 4–2
4.1.2 Displaying System Configuration . . . ................... 4–4
4.1.3 Displaying System Errors ........................... 4–6
4.2 Running the Self Test ................................. 4–7
4.2.0.1 TOY/NVR Self Test . . ........................... 4–8
4.2.0.2 LCG Self Tests ................................. 4–9
4.2.0.3 DZ Self Test ................................... 4–10
4.2.0.4 Cache Self Test ................................ 4–11
4.2.0.5 System Self Test................................ 4–11
4.2.0.6 Floating Point Unit Self Test . . . ................... 4–11
4.2.0.7 Interval Timer Self Test .......................... 4–12
iv

4.2.0.8 Memory Self Test ............................... 4–12
4.2.0.9 Network Interconnect Self Test . ................... 4–13
4.2.0.10 SCSI Self Test ................................. 4–14
4.2.0.11 Audio Self Test ................................. 4–14
4.3 Utilities . ........................................... 4–15
4.4 System Console . . . ................................... 4–17
4.4.1 SET and SHOW Commands.......................... 4–18
4.4.1.1 SET and SHOW Command Syntax ................. 4–19
4.4.2 SET and SHOW Parameters ......................... 4–19
4.4.2.1 BFLG ........................................ 4–19
4.4.2.2 BOOT ........................................ 4–20
4.4.2.3 CONFIG. . . ................................... 4–20
4.4.2.4 DEVICE . . . ................................... 4–21
4.4.2.5 DIAGENV . ................................... 4–22
4.4.2.6 ERROR . . . ................................... 4–23
4.4.2.7 ETHER . . . ................................... 4–23
4.4.2.8 FBOOT . . . ................................... 4–24
4.4.2.9 HALT........................................ 4–24
4.4.2.10 KBD......................................... 4–25
4.4.2.11 MEM ........................................ 4–25
4.4.2.12 MOP......................................... 4–26
4.4.2.13 PSE and PSWD ................................ 4–26
4.4.2.14 SCSI......................................... 4–27
4.4.2.15 TRIGGER. . ................................... 4–27
4.4.2.16 VER......................................... 4–27
4.4.3 Memory Commands ................................ 4–28
4.4.3.1 DEPOSIT Commands. ........................... 4–28
4.4.3.2 EXAMINE Commands ........................... 4–29
4.4.3.3 FIND ........................................ 4–31
4.4.4 Processor Control Commands......................... 4–31
4.4.4.1 BOOT ........................................ 4–32
4.4.4.2 CONTINUE ................................... 4–33
4.4.5 INITIALIZE and UNJAM ........................... 4–33
4.4.5.1 START....................................... 4–33
4.4.5.2 Miscellaneous Console Commands .................. 4–34
4.4.5.3 HELP or ? . ................................... 4–34
4.4.5.4 LOGIN ....................................... 4–34
4.4.5.5 REPEAT. . . ................................... 4–34
v

5 Removing and Replacing FRUs
5.1 Cautions and Warnings ................................ 5–1
5.2 VAXstation 4000 VLC FRUs . ........................... 5–2
5.3 System Preparation ................................... 5–5
5.4 Mass Storage Drive Removal . ........................... 5–7
5.4.1 Hard Disk Drive Replacement ........................ 5–9
5.5 Power Supply Removal ................................ 5–11
5.5.1 Power Supply Replacement .......................... 5–12
5.6 Removing the LCG Module . . ........................... 5–13
5.7 Removing the System Module ........................... 5–13
5.7.1 System Module (CPU) Replacement . ................... 5–14
5.8 MS40 Memory Module Removal.......................... 5–14
5.8.0.1 MS40 Memory Module Replacement ................ 5–16
5.9 Clearing the System Password........................... 5–17
5.10 Testing the VAXstation 4000 VLC System .................. 5–18
5.10.1 Restore the System ................................ 5–18
5.10.2 Test the System ................................... 5–19
A Self-Test Error Codes
A.1 Self-Test Error Codes .................................. A–1
A.1.1 NVR Self-Test Error Codes .......................... A–1
A.1.2 DZ Self-Test Error Codes . ........................... A–2
A.1.3 Memory Self-Test Error Codes ........................ A–5
A.1.4 Memory Management Unit Self-Test Error Codes ......... A–6
A.1.5 Interval Timer Self-Test Error Codes ................... A–7
A.1.6 System Device Self-Test Error Codes ................... A–7
A.1.7 SCSI Self-Test Error Codes .......................... A–8
A.1.8 Audio Self-Test Error Codes .......................... A–17
A.1.9 Floating Point Unit (FPU) Self-Test Error Codes .......... A–19
A.1.10 Cache Self-Test Error Codes.......................... A–22
A.1.11 LCG Self-Test Error Codes ........................... A–23
A.1.12 NI Self-Test Error Codes . ........................... A–29
B Diagnostic LED Error Codes
B.1 Reading Diagnostic LED Codes .......................... B–1
B.1.1 Powerup/Initialization LED Codes, XXXX zzzz . .......... B–2
B.1.2 TOY/NVR LED Codes, OOOX zzzz. . ................... B–3
B.1.3 DZ LED Codes, OOXX zzzz .......................... B–3
B.1.4 Memory LED Codes, OXOX zzzz . . . ................... B–4
B.1.5 System Device LED Codes, XOOO zzzz ................. B–4
vi

B.1.6 SCSI Device LED Codes, XOXO zzzz ................... B–4
B.1.7 LCG LED Codes, OOXO zzzz ......................... B–5
B.1.8 NI Device LED Codes, XOOX zzzz . . ................... B–6
B.1.9 Synchronous Communication Device LED Codes, XXOO
zzzz . ........................................... B–6
B.1.10 Cache LED Code, OXOO zzzz ........................ B–8
C Troubleshooting
C.1 Troubleshooting Symptoms and Corrective Actions . .......... C–2
D VAXstation 4000 VLC Part Numbers
D.1 Part Numbers ....................................... D–1
Index
Examples
4–1 SHOW DEVICE Command .......................... 4–4
4–2 Sample Show Config Display ......................... 4–5
4–3 Sample Showing System Errors ....................... 4–6
Figures
1–1 System Module Major Components . ................... 1–3
1–2 System Module Internal Connectors ................... 1–5
1–3 VAXstation 4000 VLC System Module Block Diagram ...... 1–7
1–4 Command Packet General Format . . ................... 1–16
1–5 Ethernet Packet Format . ........................... 1–20
2–1 VAXstation 4000 VLC System Box . . ................... 2–2
2–2 Cricket Retaining Clip . . . ........................... 2–3
2–3 Right Side of the System Box......................... 2–6
2–4 VAXstation 4000 VLC I/O Panel . . . ................... 2–8
3–1 System ROM Format ............................... 3–6
3–2 Configuration Tables ............................... 3–9
3–3 Main Configuration Tables ........................... 3–10
3–4 Device Configuration Table .......................... 3–12
3–5 Driver Descriptor Data Structure . . ................... 3–16
vii

3–6 Diagnostic Drive Console Support . . ................... 3–17
3–7 Console Structure ................................. 3–19
3–8 SCIA Data Structure ............................... 3–21
3–9 Console Port Driver Function Block . ................... 3–22
4–1 Successful Power-Up ............................... 4–2
4–2 Unsuccessful Power-Up . . ........................... 4–3
4–3 Successful and Unsuccessful Self Test .................. 4–7
4–4 Utilities List. . . ................................... 4–16
5–1 Location of System Box FRUs ........................ 5–2
5–2 Rear View of the System Box ......................... 5–3
5–3 Right Side View of the System Box . ................... 5–4
5–4 Removing the cover ................................ 5–6
5–5 Removing the RZ23L Hard Disk Drive ................. 5–7
5–6 RZ23L SCSI and Power Cables ....................... 5–8
5–7 RZ23L Disk Drive SCSI ID Jumper Location. . . .......... 5–9
5–8 Power Supply Removal . . ........................... 5–12
5–9 Password Clearing Points ........................... 5–17
Tables
1–1 CPU Restart Codes ................................ 1–8
1–2 Interrupt Signal Sources . ........................... 1–10
1–3 Interrupt Vectors .................................. 1–11
1–4 Graphics Controller Screen Formats ................... 1–16
1–5 Serial Line Usage.................................. 1–17
1–6 Serial Line Controller Register Addresses ............... 1–18
1–7 TOY Chip Register Addresses ........................ 1–19
2–1 Devices and Cable Part Numbers. . . ................... 2–7
2–2 VAXstation 4000 VLC System Box Operating Conditions . . . 2–9
2–3 VAXstation 4000 VLC System Box Electrical
Specifications . . ................................... 2–9
3–1 Directory Type Definitions ........................... 3–14
3–2 Data Path Size Definitions ........................... 3–14
3–3 Flag Definitions ................................... 3–15
4–1 Running Self Test Using the Test Command . . . .......... 4–7
4–2 Device Number and Self-Test Commands ............... 4–8
4–3 SET and SHOW Parameters ......................... 4–18
viii

4–4 Diagnostic Environments . ........................... 4–22
4–5 SET DIAGENV Command ........................... 4–22
5–1 Hard Disk Drive SCSI Jumper Settings................. 5–10
A–1 TOY/NVR Self-Test Error Codes . . . ................... A–1
A–2 DZ Self-Test Error Codes . ........................... A–2
A–3 DZ Suberror Codes ................................. A–3
A–4 Memory Self-Test Error Codes ........................ A–5
A–5 Memory Management Unit Self-Test Error Codes ......... A–6
A–6 Interval Timer Self-Test Error Codes ................... A–7
A–7 System Device Self-Test Error Codes ................... A–7
A–8 SCSI Self-Test Error Codes .......................... A–8
A–9 Audio Self-Test Error Codes .......................... A–17
A–10 FPU Self-Test Error Codes ........................... A–19
A–11 Cache Self-Test Error Codes.......................... A–22
A–12 LCG Self-Test Error Codes ........................... A–23
A–13 NI Self-Test Error Codes . ........................... A–29
B–1 Powerup and Initialization LED Codes ................. B–2
B–2 TOY and NVR LED Codes ........................... B–3
B–3 DZ LED Codes . ................................... B–3
B–4 Memory LED Codes ................................ B–4
B–5 System Device LED Codes ........................... B–4
B–6 SCSI Device LED Codes. . ........................... B–5
B–7 LCG LED Codes................................... B–5
B–8 NI LED Codes . ................................... B–6
B–9 Synchronous Communication Device LED Codes .......... B–7
B–10 Cache LED Codes ................................. B–8
C–1 System Problems .................................. C–3
C–2 Monitor Problems.................................. C–6
C–3 Mouse and Tablet Problems .......................... C–6
C–4 Keyboard Problems ................................ C–7
C–5 Drive Problems ................................... C–7
C–6 Network Problems ................................. C–7
C–7 Expansion Box Problems . ........................... C–9
D–1 FRU Part Numbers ................................ D–2
D–2 Miscellaneous FRU Part Numbers . . ................... D–3
D–3 System and Expansion Box Cables and Terminators ....... D–3
D–4 Expansion Box (SZ03) FRU Part Numbers .............. D–4
ix

D–5 Expansion Box (SZ16) FRU Part Numbers .............. D–4
D–6 VAXstation 4000 VLC Monitors ....................... D–5
D–7 Monitor and Graphic Module Cross Reference . . .......... D–6
x

Preface
This manual is a support and reference document for Digital Service personnel
who perform maintenance tasks on the VAXstation 4000 VLC workstation. It
is also for qualified Digital customers who have a self-maintenance agreement
with Digital Equipment Corporation.
Organization of this Manual
This manual contains the following chapters:
• Chapter 1 - Provides an overview of the VAXstation 4000 VLC system
features, main memory, network interface and SCSI controllers.
• Chapter 2 - Provides configuration information for the VAXstation 4000
VLC system.
• Chapter 3 Presents an overview of the VAXstation 4000 VLC diagnostic
firmware.
• Chapter 4 - Provides information on diagnostic testing.
• Chapter 5 - Provides information on how to remove and replace system
FRUs.
• Appendix A - Contains the Self Test Error tables.
• Appendix B - Contains the Diagnostic LED Error tables.
• Appendix C - Contains the Troubleshooting/Problem Isolation tables.
• Appendix D - Contains the Field Replaceable Unit (FRU) part number
tables.
xi

Associated Documentation
The following documents provide additional information which is closely
related to the VAXstation 4000 VLC system:
•VAXstation 4000 VLC Owner’s Manual
Part number EK-VAXVL-OG
•VAXstation 4000 VLC and Model 60 Operation Installation Guide
Part number EK-PMARI-IG
•VAXstation 4000 VLC Pocket Service Guide
Part number EK-V466H-PS
Conventions
The conventions are used in this manual.
Convention Description
WARNING Contains important information about personal safety.
CAUTION Contains information to prevent damage to the equipment.
NOTE Contain general information.
PN Part number
SHOW ERRORS Commands are shown in all capital letters to distinguish them
from text.
xii

1
VAXstation 4000 VLC System Components
This chapter describes the modules and features of the VAXstation 4000 VLC
system. Information about the central processor (CPU), main memory, network
interface, SCSI controller, and other components of the system are included.
1.1 Overview
The VAXstation 4000 VLC system module (PN 54-20768-01) forms the basis
of the entire system. The VAXstation 4000 VLC system is a single-user
engineering workstation, which includes the following:
• LK401 keyboard
• VSXXX-AA mouse or VSXXX-AB tablet
• Monochrome or color video monitor
• Mass storage device
• SCSI Ethernet controllers
VAXstation 4000 VLC System Components 1–1

VAXstation 4000 VLC System Components
1.1 Overview
Figure 1–1 shows the major components of the system module.
! Base system ROMs
" TOY clock
# SCSI controller
$ S-chip
% SOC chip
& Ethernet address ROM
' Ethernet controller
( VAXstation 4000 VLC ASICs (Application Specific Intregated Circuits)
1–2 VAXstation 4000 VLC System Components

VAXstation 4000 VLC System Components
1.1 Overview
Figure 1–1 System Module Major Components
LJ-00963-TI0
E39
J13
J12
J9
J8
E13
E14
E38
E38
J11
J10
E31
E4
E19
J1
J2
J3
J4
J5
J6
E32
E4
7 6
5
4
3
2
1
8
VAXstation 4000 VLC System Components 1–3

VAXstation 4000 VLC System Components
1.1 Overview
Figure 1–2 shows the internal connector locations of the system module. Section 2.1.3
and Section 2.1.5 describe the system module external connectors.
! Power connector
" Mass storage connector
# SCSI connector
$ Memory module connectors
% Graphics module connector
& NVR reset pads
1–4 VAXstation 4000 VLC System Components

VAXstation 4000 VLC System Components
1.1 Overview
Figure 1–2 System Module Internal Connectors
LJ-00964-TI0
E39
J13
J12
J9
J8
E13
E14
E38
E38
J11
J10
E31
E4
E19
J1
J2
J3
J4
J5
J6
E32
E4
3 2
1
6
4
5
VAXstation 4000 VLC System Components 1–5

VAXstation 4000 VLC System Components
1.2 Central Processor Unit
1.2 Central Processor Unit
The Central Processor Unit (CPU) chip is a 32-bit virtual memory
microprocessor with integral floating point capability and on-chip cache,
derived from the CVAX CPU, CFPA floating point unit and CVAX clock chips.
The CPU key features are
Feature Description
Subset of VAX computer
data types Byte, word, longword, quadword, character string, variable- length bit field, and support for f_floating and g_floating
point data types.
Full base instruction
group Integer and logical, address, variable-length bit field, control, procedure call, queue, character string instructions
CMPC3/CMPC5, LOCC, MOVC3/MOVC5, SCANC, SKPC
and SPANC, and operating system support. f_floating,
The CFP chip supports d_floating and g_floating point
instructions.
Full VAX memory
management Includes a demand paged memory management unit fully compatible with VAX computer memory management.
System space addresses are virtually mapped through
single-level page tables; process space addresses are
virtually mapped through double-level page tables.
Supports four gigabits of virtual memory and up to one
gigabits of physical memory.
On-chip memory cache The CPU chip has 8 Kbytes of on-chip cache to improve
execution times by minimizing the use of the memory
subsystem.
Figure 1–3 is a block diagram of the VAXstation 4000 VLC system module.
1–6 VAXstation 4000 VLC System Components

VAXstation 4000 VLC System Components
1.2 Central Processor Unit
Figure 1–3 VAXstation 4000 VLC System Module Block Diagram
ELC
OSC CDAL
DC7201
SChip Gate Array
MDAL
Control
EDAL
Control
EDAL->NDAL NDAL
System ROM (256 KB)
Video Option Connector
SCSI Port
Cache Invalidate Tag Store
RS-232 Communications Port
Printer Port
Keyboard Mouse/Tablet Connection
Digital Sound Chip
TOY Clock
Data
Control
Address
SOC
Memory Modules
(8-24 MB Parity)
Ethernet
LJ-01060-TI0
VAXstation 4000 VLC System Components 1–7
