Digital Watchdog DWC-V6863WTIRW User manual

Quick Start Guide Quick Start Guide
WHAT’S IN THE BOX
Hex Allen
wrench 1Quick setup guide 1
DC plug
cable 1
Screws
and plastic
anchors
(4pcs)
1 set
Test video
cable 1
Moisture
absorber and
absorber
guide
1 set
Mounting
template 1
1. The mounting surface must withstand five times the weight of your camera.
2. Do not let the cables get caught in improper places or the electric line cover can be damaged. This may cause a
short or fire.
3. Install the moisture packet in the base of the camera’s lens.
a. Remove the moisture absorber from the packaging.
b. Cut the card and folder along the dotted line.
c. Place the moisture absorber behind the camera’s lens module. See the drawing for more information.
4. Detach the camera’s dome cover by loosening the four (4) screws on each side of the dome.
5. Remove the dome protection film before placing the dome back on the camera base.
6. Using the mounting template sheet or the camera itself, mark and drill the necessary holes
in the wall or ceiling.
Pass the wires through the mount bracket and make all necessary connections. Connect the BNC cable and power cables to the camera.
STEP 1 – PREPARING TO MOUNT THE CAMERA
STEP 2 – CABLING THE CAMERA TO EXTERNAL DEVICES
Power Requirements Power Consumption
DC12V/AC24V dual voltage
DC12V (LED o): 4.27W, 356mA
DC12V (LED on): 6.98W, 582mA
AC24V (LED o): 3.96W, 290mA
AC24V (LED on): 6.38W, 440mA
DWC-V6863WTIRW
Torx Wrench DC Plug Cable Test Video Cable
ManualTemplate Sheet Screw & Moisture absorber &
Absorber Guide
Sunshield cover &
Torx Wrench DC Plug Cable Test Video Cable
ManualTemplate Sheet Screw & Moisture absorber &
Absorber Guide
Sunshield cover &
Torx Wrench DC Plug Cable Test Video Cable
ManualTemplate Sheet Screw & Moisture absorber &
Absorber Guide
Sunshield cover &
Torx Wrench DC Plug Cable Test Video Cable
ManualTemplate Sheet Screw & Moisture absorber &
Absorber Guide
Sunshield cover &
Torx Wrench DC Plug Cable Test Video Cable
ManualTemplate Sheet Screw & Moisture absorber &
Absorber Guide
Sunshield cover &
Torx Wrench DC Plug Cable Test Video Cable
ManualTemplate Sheet Screw & Moisture absorber &
Absorber Guide
Sunshield cover &
Torx Wrench DC Plug Cable Test Video Cable
ManualTemplate Sheet Screw & Moisture absorber &
Absorber Guide
Sunshield cover &
Please cut the card type absorber along
a dotted line, overlap and attach them
according to the direction of the arrow.
Please cut the card type absorber along
a dotted line, overlap and attach them
according to the direction of the arrow.
Please cut the card type absorber along
a dotted line, overlap and attach them
according to the direction of the arrow.
Protective
film
Tel: [phone]
Technical Support Hours:
9:00AM – 8:00PM EST, Monday through Friday
digital-watchdog.com
Attention: This document is intended to serve as a quick reference for the
initial setup. It is recommended that the user read the entire instruction
manual for complete and proper installation and usage.
NOTE: Download all your support materials and tools in one place
1. Go to: http://www.digital-watchdog.com/resources
2. Search your product by entering the part number in
the ‘Search by Product’ search bar. Results for
applicable part numbers will populate automatically
based on the part number you enter.
3. Click ‘Search’. All supported materials, including manuals
and quick start guide (QSGs) will appear in the results.

Quick Start Guide
1. Once all cables have been connected, use the screws included with
the camera to properly mount and secure the camera to the mounting
surface.
2. Adjust the camera’s pan, tilt and position to achieve the desired view.
The cameras’ max angles are:
Pan: 0° ~ 360°
Tilt: 0° ~ 90°
Rotation: 0° ~ 360°
3. To adjust the camera’s focus and zoom:
a. Unlock the zoom or focus screws by rotating them
counter-clockwise.
b. Adjust the zoom and focus screws at the base of the camera
module to achieve a clear image.
c. Tighten the screws and close the front case by rotating it
clock-wise.
4. Once the installation is complete, remove the protective film from the
camera’s dome cover.
STEP 4 – INSTALLING THE CAMERA
Copyright © Digital Watchdog. All rights reserved.
Specifications and pricing are subject to change without notice.
Zoom
Focus
Rev Date: 01/20
Mounting template
STEP 3 – CHANGING THE SIGNAL IN
THE CAMERA
1. The camera supports HD-Analog, HD-CVI and HD-TVI signals as
well as CVBS up to 960H. To switch between the signals:
a. Enter the camera’s OSD menu. You can access it locally from
using the camera’s joystick in the body of the camera, or from a
recorder supporting UTC communication.
Go to SETUP > OUTPUT.
b. Set the camera’s resolution from the following options:
- 4K/2160p @15fps.
- 5MP/1440 @30fps.
- 2.1MP/1080p @30fps.
c. Set the camera’s analog signal output from the following options:
- HD-A - HD-Analog
- HD-T - HD-TVI
- HD-C - HD-CVI
- CVBS - legacy analog signal
d. Change CONFIRM to ON to save the changes.
e. Go to the EXIT menu and select SAVE&EXIT to save all changes.
The camera signal automatically.
NOTE: To use your Star-Light Plus™ 4K cameras at a lower
resolution, you must use a VMAX® A1 4K DVR to access the
camera’s menu due to the cameras being set to 4K as the
default. A DVR that does not support 4K resolution may
recognize the camera, but will not deliver a picture.
