Digitool Solutions DWA-2501 User manual

Model Range Square Drive Weight
DWA-2501 250.0 in-lb 1/4inch 1.5 pound
DWA-1002 100.0 ft-lb 3/8 inch 2.2 pound
DWA-2503 250.0 ft-lb 1/2 inch 3.4 pound
Display: 5-digit, alpha-numeric LCD with function and
battery indicator icons.
Accuracy: Torque: within ±1% of Indicated Value of both CW
and CCW directions. (10%-100% of F.S)
Angle: within ± 1° when rotating to 90° at the
speed rate @ 2°/s to 400°/s
Calibration: should be performed once a year or every
15,000 cycles which ever comes first.
Resolution:
Units of measure: ft-lb, in-lb, Nm
Modes of measure: Peak Hold, Angle
Measurement Modes:
ANGLE- 15 seconds display of peak Angle.
Minimum 5% of full scale torque apply before Angle
start measurement.
Example: Model DWA-1002 full scale is 100ft-lb
5% of F.S is 5 ft-lb. when torque reached
Above 5 ft-lb. Angle will start measure.
TORQUE - Display torque value in real time when torque is
loading and display peak torque when released
Visual, Audible Alerts:
Yellow LED and buzzer pulse at 80% - 96% of target torque.
Pulse rate increases as target torque is approached.
Green LED and buzzer on continuously when applied torque
is within 96% - 104% of target torque.
Red LED and buzzer on continuously when applied torque
exceeds >104% target torque or wrench full-scale.
Tactile Vibration when applied torque is within ±4% of
target torque.
Battery Power:
2 AA battery up to 200 hours of continuous operation
Certification:
This device is calibrated at the factory and is certified to meet
International Standards. ISO-6789-2003 and ASME B107-28-
2005 standards compliant. Certificate of N.I.S.T. (National
Institute of Standards Technology). Traceability from 10% to
100% of full scale.
Maintenance:
To clean the wrench, wipe with a lightly dampened cloth.
DO NOT use: solvents, thinners or engine cleaners. DO NOT
immerse in any liquids. It is highly recommended that your
Torque & Angle Wrench be calibrated once a year or every
15,000 cycles, whichever comes first. Contact Digitool Solutions
representatives for repair and calibration services.
Warranty Service and Recalibration
Digitool Solutions provides a 1 year warranty that covers any
Digital Torque & Angle Wrench which fails to give satisfactory
service due to defective workmanship or materials (excluding
calibration) for 12 months from the date of original purchase.
Calibration is only covered by this warranty for each new unused
Torque & Angle Wrench out of box. Products must be returned
with proof of purchase, freight prepaid, to the warranty service
center listed below.
This warranty excludes Torque & Angle Wrench that have been
subjected to abnormal use, accidental damage, neglect, or lack of
maintenance. Any modification or disassembly of this Torque &
Angle Wrench or repair by an unauthorized service center will
void the warranty. This warranty gives you specific rights. You
may also have other rights which vary from state to state. The
foregoing obligation is Digitool Solutions sole liability under this or
any implied warranty and under no circumstances shall Digitool
Solutions be liable for any incidental or consequential damages.
Note: Some states do not allow the exclusion or limitation of
incidental or consequential damages so the above limitation or
exclusion may not apply to you.
For Warranty Service and Recalibration/Certification
Services, contact:
Ratchet head:
1/4” , 3/8” or 1/2” drive 36 teeth
Accuracy:
Torque. ±1% CW & CCW
From 10%-100% of Full scale
Angle. ±1° of 90° rotation
@ speed rate 2°/s - 400°/s
Display:
5-digit, alpha-numeric LCD
With functions, units and
battery indicator icons.
Indicators:
LED Green, Yellow and Red
Buzzer, Vibrator
Power:
Manual/Auto shut off after
5 minutes Idle
Battery:
2 AA size Battery Regular Alkaline
up to 200 hours of continuous operation
Rev.Dec. 2014
Model Drive ft-lb in-lb Nm
DWA-2501 1/4 inch 0.01 ft-lb 0.1 in-lb 0.01 Nm
DWA-1002 3/8 inch 0.1 ft-lb 1 in-lb 0.2 Nm
DWA-2503 1/2 inch 0.2 ft-lb 1 in-lb 0.3 Nm
Specifications:
Digitool Solutions LLC,.
13905 Ramona Ave. Unit #A
Chino, CA 91710
Phone: [phone]
Fax [phone]
Website: digitoolsolutions.com
USER’S GUIDE
ELECTRONIC TORQUE ANGLE
WRENCH
TORQUE, ANGLE INDICATOR
For Models
DWA-2501, DWA-1002,
DWA-2503

Keypad Functions:
Power ON - M key
U - Unit Select - ft-lb, in-lb or Nm
- Zero Tare Torque/Angle (hold key 3 seconds)
M - Mode Select TORQUE, ANGLE
- Manual power off, (hold key 3 seconds)
▲ - Increase TARGET TORQUE / ANGLE value
(Hold for rapid scrolling)
▼ - Decrease TARGET TORQUE / ANGLE value
(Hold for rapid scrolling)
Automatic Power OFF after 5 minutes of idle time.
1. Setup:
a. Turn on the Torque and Angle Wrench by pushing the
M buttons.
b. Press the U key
For Peak to view the units of measure.
Repeatedly push the U key to display the desired units
of measure, ft-lb, in-lb or Nm.
For Angle, pushing the U key will clear the Angle to 0°
c. Press the M key to select the display mode:
TORQUE or ANGLE Mode
d. Push the ▲ or ▼ key to view the TARGET TORQUE
or ANGLE value. Use these same keys to increase or
decrease to the desired value.
While loading in either TORQUE or ANGLE modes, the
Torque and Angle wrench will display applied torque or
angle respectively. The yellow LED and the buzzer will
begin to pulse at 80% of TARGET TORQUE, getting
faster as the TARGET TORQUE value is approached.
2. Application:
a. With the power on, install the Torque and Angle Wrench
insert the driver into the socket.
b. Apply torque load to the fasterner in either CW or CCW
directions. During loading, the Torque and Angle
wrench will display applied torque in real time.
c. When the applied torque is within 4% of the TARGET
TORQUE value in TORQUE modes, the green LED,
buzzer and vibrator (optional) will output continuously.
Stop applying torque, as the installation is complete.
Release Indications:
Should the applied torque exceed the TARGET
TORQUE value by more than 4%, the red LED and
buzzer will alert continuously. If the torque over 125%
of torque range, the display will indicate “OVER
TORQUE.”
Temperature Drift: ± 0.0015%/F
Storage Temperature 0ºF to 125ºF
Operating Temperature 40ºF to 110ºF
Humidity - up to 90% non-condensing
Re-Order Components :
 Torque Angle wrench P/N DWA-XXXX
 User ‘s Guide P/N DTS-UG– DWA
WARNING - Risk of flying particles.
 Read this entire User’s Guide before using the Torque and
Angle Wrench.
 Always follow good professional tool practices.

Wear Safety goggles.
 Insure that all equipment is in good working order and that
ratings of the Torque & Angle Wrench, tools and drives
exceed the torque being applied.
 Never use the Torque & Angle Wrench with the power off.
 Never initiate ZeroTare with torque applied.
 Never use the wrench as a breaker bar to loose nuts, bolts
or fasteners.
 Save these instructions.
The DTS Torque and Angle Wrench provides Torque accuracy
within ±1% both direction CW and CCW of reading between
10% and 100% of full scale and angle accuracy ±1° of 90°
rotation @ speed 2°/s to 400°/s.
The wrench also employs a vibrator, a buzzer, and a 3-color LED.
These indicators alert users when torque or angle approaches its
preset value.
The wrench requires only two AA batteries and can operate up
200 hours of continuous use.
In addition, the DTS Torque and Angle Wrench features three
selectable torque units. They are ft-lb, in-b, and Nm.
Three modes are featured:
 TORQUE - display torque value in real time, and show peak
torque when wrench is released.
 ANGLE - display both maximum Angle & Torque applied for
15 seconds.
.
Important Safety Instructions
Introduction
Operator InstructionsFront Panel Display and Keypad
