Digitrax DN163I1C User manual

DN163I1C
Fits InterMountain N Scale F3 and F7
A & B units
F
Fe ea at tu ur re es s: :
nDigitrax LocoMotion®System-Your locomotives look like the real thing.
The Digitrax LocoMotion System makes them run like the real thing, too!
Torque Compensation for smooth as silk silent operation.
128 Speed Step operation (14 or 28 steps can also be used).
Momentum with acceleration and deceleration.
Normal Direction of Travel is user selectable.
Switching Speed feature for easier and faster access to yard speeds.
3 Step Speed Tables set start, mid and max voltage for custom control.
28 Step Speed Tables with 256 level resolution for precise control.
nScalable Speed Stabilization (Back EMF) with simple setup & 256 level
resolution.
nSuperSonic motor drive for silent operation.
nFX3Functions for prototypical lighting effects:
Constant Brightness Lighting with directional or independent control.
Realistic Effects like Ditch lights, Mars lights, strobes, and many more.
Dynamic and Static Qualifiers operate functions based on direction,
F0 on or off, loco direction and F0, and whether loco is moving.
Function Remapping of 14 functions for custom function setup.
Master Light Switch turns off all lights & functions with one keystroke.
Advanced Consist Function Controls
nPlug ‘N Play design makes installation quick and easy.
nTransponder equipped ready for transponding on your layout.
nAll Mode Programming with Operations Mode Read Back-read back CV
values right on the mainline.
nDecoder Factory CV Reset with or without speed table initialize.
nMotor Isolation Protection prevents damage to your loco and decoder.
nBasic, Advanced & UniVersal Consisting
n2 Digit and 4 Digit Addressing
nDCC Compatible
nFCC Part 15, Class B RFI compliant
©2004 Digitrax, Inc www.digitrax.com 1
D
Di
ig gi it tr ra ax xC
Co
om mm ma an nd dC
Co
on nt tr ro ol l
R
Ru un nY Yo ou ur rT Tr ra ai in ns s, ,N No ot tY Yo ou ur rT Tr ra ac ck k! !
N Scale
Mobile Decoder
Drop In Type
1.5 Amp/2.0 Amp Peak
6 FX3Functions, 0.5 Amp

©2004 Digitrax, Inc www.digitrax.com 2
P
Pa ar rt ts sL Li is st t
1 DN163I1C Decoder 1 Instruction sheet
I
In ns st ta al ll la at ti io on nI In nf fo or rm ma at ti io on n
See the Digitrax Decoder Manual for complete decoder test procedures, instal-
lation instructions, programming and technical information. Digitrax manuals
and instructions are updated periodically. Please visit www.digitrax.com for the
latest versions, technical updates and additional locomotive-specific installation
instructions.
I
In ns st ta al ll la at ti io on nI In ns st tr ru uc ct ti io on ns s- -I In nt te er rM Mo ou un nt ta ai in nF F3 3A AL Lo oc co om mo ot ti iv ve e
1. Carefully remove the
locomotive’s shell from
the frame by inserting
two toothpicks under the
unit’s ladders as shown.
2. Once you’ve positioned
the toothpicks, grasp the
frame and toothpicks
with one hand and the
locomotive’s shell with
the other hand and care-
fully separate the two.
3. Once the shell is off,
remove the existing
lightboard by removing
the two screws located
on the diagonal corners
of the board. The final
step in removing the
lightboard is to carefully
unsolder the two wires
leading from the head-
light assembly.
4. Take the new
DN163I1C decoder and
place it on top of the
frame. Note proper ori-
entation. The decoder’s
brass motor contacts
should fit in the frame
slot as shown.
D
Di
ig gi it tr ra ax xC
Co
om mm ma an nd dC
Co
on nt tr ro ol l
R
Ru un nY Yo ou ur rT Tr ra ai in ns s, ,N No ot tY Yo ou ur rT Tr ra ac ck k! !
Figure 1: Insert
toothpicks as shown
Figure 2: remove
shell from frame.
Toothpicks
inserted
under
center of
body
Figure 3: Unscrew, unsolder and
remove standard lightboard .
Board shown par-
tially removed.

©2004 Digitrax, Inc www.digitrax.com 3
5. Solder headlight
leads to the new
decoder board as
shown If you were
sitting in the cab,
the yellow lead
would be on your
left and the green
lead would be on
your right. The final
step is to secure the
decoder with the
original screws.
Note: the locomo-
tive’s frame halves
may have to be
loosened slightly to
achieve proper
alignment.
CAUTION: When attaching headlight wires, be very careful that the wires
you attach do not come into contact with any other pads or components on
the board where they might create a short circuit.
Installation Notes:
1. Do not exceed the decoder’s 500mA total function output rating.
2. To use a function output with an inductive (coil) type load, see the Digitrax
Decoder Manual for more information to avoid damage to the decoder.
3. See the Digitrax Decoder Manual for full details of wiring 12-16V lamps,
1.5V lamps, and LEDs. Lamps that draw more than 80 mA when running
require a 22 ohm 1/4 watt resistor in series with the directional light func-
tion lead to protect the decoder.
C
Cu us st to om mi iz zi in ng gY Yo ou ur rD De ec co od de er r
Your Digitrax decoder is ready to run and will operate using address 03 with no
additional programming. For a more prototypical railroading experience, your
decoder can be customized for your specific locomotive by programming some
of the Configuration Variables, or CVs, available. See the Digitrax Decoder
Manual or the Digitrax web site for more information.
C
Ch ha an ng gi in ng gt th he eD De ec co od de er rA Ad dd dr re es ss s
The first CV most people change is the decoder address so that the loco can be
independently controlled with it’s own unique address. All Digitrax decoders
445500CCeemmeetteerryySSttrreeeettT T777700--444411--77999922
NNoorrccrroossss,,GGAAUUSSAA3300007711F F777700--444411--00775599
wwwwww..ddiiggiittrraaxx..ccoommE Essaalleess@@ddiiggiittrraaxx..ccoomm
Yellow wire
Green wire
Figure 4: Solder headlight
wires, secure new decoder
with original screws

©2004 Digitrax, Inc www.digitrax.com 4
are shipped with CV01 (AD2), the two digit address, set to 03. See your Starter
Set Manual for complete programming instructions. Following is a brief
description of how to change the decoder address with a DT series throttles.
1. Place the loco on the programming track. Go into Program Mode on your
system. On DT400 press PROG. On DT300, DT100 & DT200 press
RUN/STOP & FN/F0 SIMULTANEOUSLY.
2. Choose AD2 for 2 digit addressing or AD4 for 4 digit addressing (DT300 &
DT400). (Ad for DT100 & DT200, see set system manual for 4 digit
instructions).
3. Choose the address you want to set up for the decoder.
4. Complete address programming. On DT400 press ENTER. On DT300*,
DT100 & DT200 press SEL.
*Note: CV29 must also be programmed to enable 4 digit addressing, this is
done automatically by the pressing the ‘Y’ key when prompted to do so on the
DT300 & DT400 throttles.
D
Di ig gi it tr ra ax xL Lo oc co oM Mo ot ti io on n
®
S
Sy ys st te em m
Your locomotives look like the real thing, now you can make them run like the
real thing, too. Digitrax decoders incorporate torque compensation for smooth
as silk operation. You can also program CVs that control momentum, 3 step
and 128 step speed tables, switching speed, normal direction of travel,
scaleable speed stabilization and more to take full advantage of the Digitrax
LocoMotion System.
M
Mo om me en nt tu um m- -C CV V0 03 3& &C CV V0 04 4
Acceleration is controlled by CV03 and deceleration by CV04. Both come
from the factory set to 000/x00. A range of 000/x00/ to 031/x1F is available for
both accel and decel. We recommend that you try CV03:003/x03 and
CV04:000/x00 as a starting point for experimenting with momentum.
S
Sp pe ee ed dT Ta ab bl le es s- -H Ho ow wt th he eL Lo oc co oR Re es sp po on nd ds st to ot th he eT Th hr ro ot tt tl le e
With Digitrax LocoMotion, there are two types of speed tables: 3 Step Tables
and High Resolution 28 Step Tables. Please see your Decoder Manual for a dis-
cussion of the 28 Step Tables. The 3 Step Tables are set up by programming 3
CVs: Start Voltage (CV02), Mid point Voltage (CV06) and Max Voltage
(CV05). These values are set at 000/x00 at the factory. All have a range of val-
ues from 000/x00 to 255/xFF. We recommend the following CV values as a
starting point for experimenting with speed tables.
D
Di
ig gi it tr ra ax xC
Co
om mm ma an nd dC
Co
on nt tr ro ol l
R
Ru un nY Yo ou ur rT Tr ra ai in ns s, ,N No ot tY Yo ou ur rT Tr ra ac ck k! !

©2004 Digitrax, Inc www.digitrax.com 5
O
Ot th he er rL Lo oc co oM Mo ot ti io on n
®
F
Fe ea at tu ur re es s: :S Sw wi it tc ch hi in ng gS Sp pe ee ed d, ,N No or rm ma al lD Di ir re ec ct ti io on no of f
T
Tr ra av ve el l& &S Sc ca al le ea ab bl le eS Sp pe ee ed dS St ta ab bi il li iz za at ti io on n( (B Ba ac ck kE EM MF F) )F Fe ea at tu ur re es s
Switching speed is controlled by CV54. The factory setting is 000/x00 for
OFF. To turn on the switching speed feature, program CV54 to a value of
001/x01. When this feature is on, use F6 to activate and deactivate switching
speed. When switching speed is ON and F6 is ON, the switching speed feature
is on. With the feature on the throttle’s target speed is effectively reduced by
about 50% and the effects of accel and decel programmed into the decoder are
reduced by 1/4. This is useful for yard switching operations.
Normal Direction of Travel is controlled by CV29. See your decoder manual
for additional information on the settings for CV29.
Scaleable Speed Stabilization (Back EMF) intensity, or droop, is controlled
by CV57. The factory setting for this feature is 006/x06 which is suitable for
most locos. You can adjust this value in the range of 000/x00 for OFF to
015/x0F for the maximum effect. Consult your Digitrax Decoder Manual for
info about CVs 55 & 56 and their effects on scaleable speed stabilization.
S
Su up pe er rS So on ni ic cS Si il le en nt tO Op pe er ra at ti io on na an nd dT To or rq qu ue eC Co om mp pe en ns sa at ti io on n
The factory settings in the decoder provide silent, smooth operation of your
locomotive under most conditions.CV9 controls the supersonic settings. The
decoder’s factory setting is 00 (Supersonic On) To turn supersonic Off set CV9
to 255 For more information about these settings, please see the Digitrax
Decoder Manual or our web site.
445500CCeemmeetteerryySSttrreeeettT T777700--444411--77999922
NNoorrccrroossss,,GGAAUUSSAA3300007711F F777700--444411--00775599
wwwwww..ddiiggiittrraaxx..ccoommE Essaalleess@@ddiiggiittrraaxx..ccoomm
Loco Type V Start V Mid V Max
CV02 CV06 CV05
Switcher
Concentrated low speed. Limited top 002/x02 038/x26 064/x50
speed
Road Switcher
Prototypical top speed w/evenly 002/x02 048/x30 098/x62
distributed curve from 0 to top speed
Mainline Loco
Quick increase to cruising speed then 002/x02 128/x80 154/x9A
levels off to prototypical top speed.

©2004 Digitrax, Inc www.digitrax.com 6
F
Fu un nc ct ti io on nO Ou ut tp pu ut ts so on nt th he eD DN N1 16 63 3I I1 1A A
The DN163I1A is set up at the factory to control six functions. The unit has
two sets of outputs for directional lighting. Pads F0F/F0F+ are for the front
light and F0R/F0R+ for the rear light. Functions F1 , F2 , F3 and F4 can be
used by soldering a wire from the pad for the function you wish to use to the
lamp (or other function) you wish to control.
CAUTION: When adding function wires, be very careful that the wires you add
do not come into contact with any other pads or components on the board
where they might create a short circuit.
All six function outputs can be easily set up with Digitrax FX3lighting effects
or as standard on/off functions with the following operational qualifiers:
1. Forward or Reverse direction of travel, or
2. Whether F0 is on or off, or
3. Both direction of travel and whether F0 is on or off, or
4. Whether the locomotive is stopped or moving.
F
Fu un nc ct ti io on nR Re em ma ap pp pi in ng g
Function remapping allows you to program the function outputs of your
decoder to be controlled by selected function keys on your throttle. Please
consult the Digitrax Decoder Manual or website for information on function
remapping.
D
Di
ig gi it tr ra ax xC
Co
om mm ma an nd dC
Co
on nt tr ro ol l
R
Ru un nY Yo ou ur rT Tr ra ai in ns s, ,N No ot tY Yo ou ur rT Tr ra ac ck k! !
F1 F2 F4
F3
F0R
F0R+
F3+
F1+F4+
F2+
F0F+
F0F

©2004 Digitrax, Inc www.digitrax.com 7
D
Di ig gi it tr ra ax xT Tr ra an ns sp po on nd di in ng gC CV V6 61 1
Digitrax Transponding is controlled by CV61. The default value is 000/x00
for OFF. To turn on transponding, program CV61 to a value of 002/x02. This
allows you to use Digitrax transponding to keep track of your rolling stock.
D
De ec co od de er rR Re es se et tC CV V0 08 8
Decoder reset lets you reset all CV values to the factory default settings. To
reset all CV values, program CV08 to a value of 008/x08. You also have the
option of resetting all values except the 28 speed step tables. To do this, pro-
gram CV08 to a value of 009/x09.
W
Wa ar rr ra an nt ty y& &R Re ep pa ai ir r
All warranties on Digitrax products are limited to refund of purchase price,
repair or replacement at Digitrax’s sole discretion. Except as expressly stated in
the full warranty statement, there are no warranties, express or implied, includ-
ing but not limited to any warranties of merchantability or fitness for a particu-
lar purpose. For complete warranty details see www.digitrax.com.
Damaged decoders should be returned directly to Digitrax for repair.
Digitrax, Inc. is not responsible for unintentional
errors or omissions in this document.
Caution: To prevent damage to your decoder and locomotive, track
voltage used during operation must not exceed the operating parame-
ters of the locomotive and its lighting system in which the decoder is
installed (typically this is 12V DC). For most N scale layouts, Digitrax
recommends using 14 volts DCC or less for operation to avoid damage
to the locomotive shell, lamps and decoder.
445500CCeemmeetteerryySSttrreeeettT T777700--444411--77999922
NNoorrccrroossss,,GGAAUUSSAA3300007711F F777700--444411--00775599
wwwwww..ddiiggiittrraaxx..ccoommE Essaalleess@@ddiiggiittrraaxx..ccoomm

©2004 Digitrax, Inc www.digitrax.com 8
D
Di
ig gi it tr ra ax xC
Co
om mm ma an nd dC
Co
on nt tr ro ol l
R
Ru un nY Yo ou ur rT Tr ra ai in ns s, ,N No ot tY Yo ou ur rT Tr ra ac ck k! !

Made in U.S.A.
307-DN163I1AINST 1K/12/05
450 Cemetery Street
Norcross, GA USA 30071
www.digitrax.com
T770-441-7992
F770-441-0759
E[email protected]
DN163I1A
Fits InterMountain FT A units
