Digitrax DZ123MK1 User manual

D 123MK1
Fits Marklin 88584
+'9:7+8
nDigitrax LocoMotion®System-Your locomotives look like the real thing.
The Digitrax Loco otion System makes them run like the real thing, too!
Torque Compensation for smooth as silk silent operation.
128 Speed Step operation (14 or 28 steps can also be used).
Momentum with acceleration and deceleration.
Normal Direction of Travel is user selectable.
Switching Speed feature for easier and faster access to yard speeds.
3 Step Speed Tables set start, mid and max voltage for custom control.
28 Step Speed Tables with 256 level resolution for precise control.
nScaleable Speed Stabilization (Back EMF) with simple setup & 256 level
resolution.
nSuperSonic motor drive for silent operation.
nFX3Functions for prototypical lighting effects:
Constant Brightness Lighting with directional or independent control.
Dynamic and Static Qualifiers operate functions based on direction,
F0 on or off, loco direction and F0, and whether loco is moving.
Function Remapping of 14 functions for custom function setup.
Master Light Switch turns off all lights & functions with one keystroke.
Advanced Consist Function Controls
nTransponder equipped ready for transponding on your layout.
nAll Mode Programming with Operations Mode Read Back-read back CV
values right on the mainline.
nDecoder Factory C Reset with or without speed table initialize.
nMotor Isolation Protection prevents damage to your loco and decoder.
nBasic, Advanced & Uni ersal Consisting
n2 Digit and 4 Digit Addressing
nDCC Compatible
©2012 Digitrax, Inc www.digitrax.com 1
4251+9+!7'/3439741
:3%4:7!7'/3849%4:7!7')0
Scale
Mobile Decoder
DCC Board Replacement
1 Amp/1.25 Amp Peak
2 FX3Functions, 0.5 Amp

©2012 Digitrax, Inc www.digitrax.com 2
'798/89
1 DZ123 K1 Decoder 1 Instruction sheet
389'11'9/433,472'9/43
For ost Z Scale layouts, Digitrax recommends using 8V DC or less for opera-
tion to avoid damage to locomotive motors & shells. See the Digitrax Decoder
anual for complete decoder test procedures, installation instructions, pro-
gramming and technical information. Digitrax manuals and instructions are
updated periodically. Please visit www.digitrax.com for the latest versions,
technical updates and additional locomotive-specific installation instructions.
389'11'9/433897:)9/438'701/3&
1. Carefully remove the locomo-
tive’s shell from the frame by
holding the exposed lower
frame and pulling the body
shell straight up. Notice the
orientation of the shell for
reinstallation later.
Figure 1.
2. Remove the two screws hold-
ing the factory light board in
place and remove the light
board. Be sure to save the
screws for reinstallation of the
DZ123 K1. Figure 2.
3. Prepare the DZ123 K1 for
installation by using a pair of
needle nose pliers to bend the
motor contacts and light pick-
ups into the proper shape. The
motor contacts should be bent
downwards at a 30 or 45
degree angle through the open
space in the board. The light
pickups should be bent accord-
ing to the bend guide at right,
Figure 3. It may be helpful to
compare the bends to those on
the factory light board and
attempt to match the shape.
Be gentle with bending the
leads to avoid any breakage.
4251+9+!7'/3439741
:3%4:7!7'/3849%4:7!7')0
Figure 1:
Remove loco shell
Figure 2: Remove the two screws holding the
factor light board in place.
Figure 3
Actual size
Bend
Guide

©2012 Digitrax, Inc www.digitrax.com 3
4. Install the DZ123 K1 such
that the square open space in
the center of the board and
motor pickups are positioned
over the resistor. Reinstall the
two screws removed in step
two, insert them through the
DZ123 K1 and tighten them
to the frame. The motor pick-
ups must make contact with
each side of the resistor leads.
This may require additional
bending of the pickup leads to
achieve. If possible, it is rec-
ommended to check for conti-
nuity between the resistor
leads and the motor pickup
using a quality multimeter.
Figure 4.
5. Reinstall the shell, making
sure it is in the proper orienta-
tion. The catenary selector
hole should be oriented over
the top of the DZ123 K1’s
CPU. The first fit will be tight
as the light pickup leads are
further bent into place.
Figure 5.
6. Place the loco on the track and select the default address “03”. Ensure that
the motor runs and that the lights function. If the motor or lights do not
work remove the shell and adjust the pickup wires so that they are making
proper contact.
:8942/?/3-%4:7+)4*+7
Your Digitrax decoder is ready to run and will operate using address 03 with no
additional programming. For a more prototypical railroading experience, your
decoder can be customized for your specific locomotive by programming some
of the Configuration Variables, or CVs, available. See the Digitrax Decoder
anual or the Digitrax web site for more information.
!7'382/99+7* "!9+).8:55479*/-/97'=)42
'3'2'/9>" 7+5'/7*/-/97'=)42
<<<*/-/97'=)42
Figure 4
Figure 5: Reinstall the shell.

©2012 Digitrax, Inc www.digitrax.com 4
.'3-/3-9.++)4*+7**7+88
The first CV most people change is the decoder address. This allows you to
independently control each loco with a unique address. Digitrax decoders are
shipped with CV01 (AD2), the two digit address, set to 03. Following is a brief
description of how to change the decoder address with a Digitrax DT series
throttle. See your Starter Set anual for complete programming instructions.
1. Place the loco on the programming track. Go into Program ode on your system.
On DT400/DT402 press PROG. On DT300, DT100 & DT200 press RUN/STOP &
FN/F0.
2. Choose AD2 for 2 digit addressing or AD4 for 4 digit addressing (DT400/DT402
and DT300). (Ad for DT100 & DT200, see set manual for 4 digit instructions).
3. Choose the address you want to set up for the decoder.
4. Complete address programming. On DT400/DT402 press ENTER. On DT300,
DT100 & DT200 press SEL.
Note: CV29 must also be programmed to enable 4 digit addressing, this is
done automatically by the DT400/DT402 & DT300 but not on earlier throttles.
/-/97'=4)449/43@ >89+2
Your locomotives look like the real thing, now you can make them run like the
real thing, too. Digitrax decoders incorporate torque compensation for smooth
as silk operation. You can also program CVs that control momentum, 3 step
and 128 step speed tables, switching speed, normal direction of travel,
scaleable speed stabilization and more to take full advantage of the Digitrax
Loco otion®System.
42+39:2##
omentum is part of the Loco otion®System. Acceleration is controlled by
CV03 and deceleration by CV04. Both come from the factory set to 000. A
range of 000 to 031 is available for both accel and decel. Try CV03:003 and
CV04:000 as a starting point for experimenting with momentum.
4251+9+!7'/3439741
:3%4:7!7'/3849%4:7!7')0

©2012 Digitrax, Inc www.digitrax.com 5
5++*!'(1+84<9.+4)4+8543*8949.+!.74991+
With Digitrax Loco otion®, there are two types of speed tables: 3 Step Tables
and High Resolution 28 Step Tables. Please see your Decoder anual for a
discussion of the 28 Step Tables. The 3 Step Tables are set up by programming 3
CVs: Start Voltage (CV02), id point Voltage (CV06) and ax Voltage
(CV05). These values are set at 000 at the factory. All have a range of values
from 000 to 255. We recommend the following CV values as a starting point for
experimenting with speed tables.
9.+74)449/43
®
+'9:7+8 </9)./3- 5++*472'1/7+)9/434,
!7';+1 )'1+'(1+ 5++* 9'(/1/?'9/43')0+'9:7+8
Switching speed is controlled by CV54. The factory setting is 000 for OFF. To
turn on the switching speed feature, program CV54 to a value of 001. When
this feature is on, use F6 to activate and deactivate switching speed. With the
feature on the throttle’s target speed is effectively reduced by about 50% and
the effects of accel and decel programmed into the decoder are reduced by 1/4.
This is useful for yard switching operations.
Normal Direction of Travel is controlled by CV29. See your decoder manual
for additional information on the settings for CV29.
Loco Type V Start V Mid V Max
CV02 CV06 CV05
Switcher
Concentrated low speed. Limited top 002 038 064
speed
Road Switcher
Prototypical top speed w/evenly 002 048 098
distributed curve from 0 to top speed
Mainline Loco
Quick increase to cruising speed then 002 128 154
levels off to prototypical top speed.
!7'382/99+7* "!9+).8:55479*/-/97'=)42
'3'2'/9>" 7+5'/7*/-/97'=)42
<<<*/-/97'=)42

©2012 Digitrax, Inc www.digitrax.com 6
:5+7 43/) /1+395+7'9/43'3*!476:+425+38'9/43
The factory settings in the decoder provide silent, smooth operation of your
locomotive under most conditions. For more information about these settings,
please see the Digitrax Decoder anual or our website.
/-/97'=!7'38543*/3-#
Digitrax Transponding is controlled by CV61. The initial factory set value is
000 for OFF. To turn on transponding, program CV61 to a value of 002. This
allows you to use Digitrax transponding to keep track of your rolling stock.
When transponding is enabled, the front light of the locomotive will flicker
slightly to indicate transponding signal is being communicated.
+)4*+7+8+9#
Decoder reset lets you reset all CV values to the initial factory settings. To
reset all CV values, program CV08 to a value of 008. You also have the option
of resetting all values except the 28 speed step tables. To do this,
program CV08 to a value of 009.
'89+7/-.9 </9).
Each of the six function outputs can be programmed to turn on and off with the
F0 ON/OFF key on your throttle, creating a aster Light Switch. The CV
values for creating this effect are listed in the Digitrax Decoder anual in the
section: Setting up FX & FX3Effects On Function Outputs.
:3)9/43+2'55/3-
Function remapping allows you to program the function outputs of your
decoder to be controlled by selected function keys on your throttle. Please
consult the Digitrax Decoder anual or website for information on function
remapping.
$'77'39>+5'/7
Digitrax gives a one year “No Worries" Warranty against manufacturing defects and
accidental customer damage on all Digitrax products.
That's it! A simple, straightforward warranty with no tricky language!
Visit www.digitrax.com for complete warranty details and instructions for returning
items for repair.
Damaged decoders should be returned directly to Digitrax for repair.
4251+9+!7'/3439741
:3%4:7!7'/3849%4:7!7')0

©2012 Digitrax, Inc www.digitrax.com 7
Caution: To prevent damage to your decoder and locomotive, track voltage
used during operation must not exceed the operating parameters of the
locomotive and its lighting system in which the decoder is installed (typi-
cally this is 12 DC). For most N scale layouts, Digitrax recommends using
14 volts DC or less for operation to avoid damage to the locomotive shell,
lamps and decoder. For Most Z Scale layouts, Digitrax recommends using
8 DC or less for operation to avoid damage to locomotive motors &
shells.
Digitrax, Inc. is not responsible for unintentional
errors or omissions in this document.
!7'382/99+7* "!9+).8:55479*/-/97'=)42
'3'2'/9>" 7+5'/7*/-/97'=)42
<<<*/-/97'=)42

Made in U.S.A.
307-DZ123MK1
!7'382/99+74'*
'3'2'/9>
<<<*/-/97'=)42
"!9+).8:55479*/-/97'=)42
7+5'/7*/-/97'=)42
D 123MK1
Fits Marklin 88584
Available
Computer InterfaceComputer Interface
Decoder ProgrammerDecoder Programmer
Sound ProgrammerSound Programmer
TM
E
EMPIREMPIRE B
BUILDER
UILDER
Super
Super
TM
0
00 00 00 0
