Digitus DN-16080 User manual

QUICK INSTALLATION GUIDE
DN-16080
for more product details, please go to www.digitus.info
Package Contents Insert Micro SD Card
Before starting to set up your camera, please make sure
items below are in your box:
Standard package:
Camera Quick Guide Wrench
Optional accessories:
4-pin I/O
terminal block
3-pin I/O
terminal block CD Manual
*
Only selected models are equipped with a micro SD
card slot for local video recording.
The data originally saved in the micro SD card (if any) will
be removed after inserting it to the camera.
The camera doesn’t support hot-swapping. Please insert
or remove the micro SD card with power disconnected.
Please follow the directions in the below graphic to insert a
micro SD card properly:
Camera Overview
Parts Real Panels

I/O Terminal Block
This camera supports external I/O device connection, and an I/O terminal block is supplied with this camera for easy connection.
Below shows which input on the I/O terminal block you should use for wiring when you want to connect an external device to this camera.
3-pin I/O Terminal block 4-pin I/O Terminal block Example of Alarm Out Connection
d
CAMERA CONFIGURATION
For advanced configuration of your DIGITUS camera with
DIGITUS NVR, please refer to below for the connection:
Step1: Connect PC to the HUB connected to your camera(s) with RJ45 network cable.
Step2: Install the “IPScan.exe” from the CD on your computer and use this utility to find the IP address of the camera.
Step3: After searching, set your PC in the same network segment as the specific camera you want to access, such as
“192.168.30.xxx” (xxx could be 0~255) in our example
Step4: Note down the IP address and port number of the camera you want to access, such as “192.168.30.1” and “88” in our
example.
Step5: Open Internet Explorer on the PC, and enter the IP address and port number in the URL column to access the camera. The format is
http://ipaddress:portnum, such as http://192.168.30.1:88 in our example.
