Digium DPMA User manual

Digium Phone Module for Asterisk Users Guide v1.0.0
Overview
DPMA: What is it?
DPMA Compatibility
Certified Asterisk and DigiumPhones Branches
Provisioning
DPMA Concepts
DPMA Configuration
Authentication Options
Registration Server Options
mDNS Discovery Options
Firmware Update Options
Files Options
Other General Options
Phone Configuration Options
Line Configuration Options
External Line Configuration Options
ContactsLoading a Contact List
Rapid Dial Keys
Contacts XML skeleton
Dial Plans
Ringing Types and Intercom
Firmware
Firmware configuration Management
XML Configuration
Setting Elements
Contacts Element
Accounts Element
Codecs Element
Ringtones Element
Firmwares Element
Public Firmwares Element
Appconfig Element
Digium phones when used with the DPMA
SIP Configuration
Voicemail Configuration
Parking
User Presence
Overview
There are myriad VoIP phones on the market that people use with Asterisk. None of them are built specifically for Asterisk, so they don’t take any
particular advantage of Asterisk’s applications. And, each one of them is too difficult to use.
Digium has designed phones to provide a superior user experience for everyone; from the person making the calls, to the person setting up the
phone. Phones aren’t hard, like everyone thinks that are, and they’re not dumb terminals; instead, they’re simple and smart.
A Digium phone can communicate with Asterisk, or with any other SIP-based system. In this respect, a Digium phone is somewhat like other SIP
phones. In order to provide more than just the capabilities of a regular SIP phone, Digium makes available the Digium Phone Module for Asterisk
(DPMA). The DPMA is a binary Asterisk module that provides a secure communications channel for Digium phones and Asterisk. This secure
channel provided by the DPMA is used by Asterisk to provision and manage Digium phones, and by the phones to directly access Asterisk's
internals - leading to a richer set of phone applications, and happier users.
DPMA: What is it?
The DPMA is a binary Asterisk module that provides a secure communications channel between Digium phones and Asterisk. This secure
channel is used to provision and manage the phones and to provide direct access to Asterisk’s internal applications. The DPMA is not required to
use Digium phones, but offers a number of significant advantages. A single, free license is required for each Asterisk system running the DPMA.
For more information on installation and configuration, please see the support pages for Digium phones.
DPMA Compatibility
The DPMA is compatible with the open source Certified Asterisk releases of Asterisk 1.8, beginning with the asterisk-1.8.11-cert1 release. A

1.
2. a.
b. i.
c.
3.
4.
1.
2.
DPMA module for the open source "-digiumphones" branch of Asterisk version 10 will be made available at a later date. The DPMA is not
compatibile with any other open source version of Asterisk.
Certified Asterisk and DigiumPhones Branches
The DPMA is not compatible with mainline releases of Asterisk because of the release policies of open source Asterisk. Per release policy, once a
branch of Asterisk, e.g. 1.4, 1.6.2, 1.8, 10, etc. is created, bugs are fixed, security vulnerabilities are closed, but new features are not added. Over
time, this has proven to be an effective policy at limiting the introduction of regressions and making upgrades between branch versions an easy
process.
Because the Digium Phone module for Asterisk requires new features - APIs, SIP messaging infrastructure, voicemail changes, etc. - that are not
currently available in a mainline version of Asterisk, and because Digium phones will require new changes in the future as additional phone
applications are provided, a new branch was required. For Asterisk 1.8 users, all of the code necessary to support the DPMA, as well as changes
to Asterisk applications, such as voicemail, parking, user presence, etc. is available in the Certified Asterisk releases, beginning with the
asterisk-1.8.11-cert1 release. For more information about Certified Asterisk, please see the overview on the . Support for AsteriskDigium website
10 users will be provided in a 10-digiumphones branch of Asterisk that will track the mainline branch of Asterisk with respect to features and
bugfixes, but also support for the DPMA. As with any other branch of Asterisk, both Certified Asterisk and -digiumphones branches are licensed
under the GPLv2 and are made available for download via subversion, as tarballs, and as packages.
Provisioning
Digium Phones may be assigned SIP account configuration a number of different ways:
Option 66 DHCP directive
The phone’s boot menu
Digium Configuration Server (DPMA, manual address)
Fetch Configuration file from URL
HTTP, HTTPs
Manual SIP account entry
The phone’s web-based configuration tool
DPMA, Bonjour / mDNS
When the phone is configured via Option 66 DHCP directive or it's told to manually fetch its configuration from a URL, the phone will first request
a configuration file matching the name <MAC>.cfg, e.g. 0019159bd025.cfg; and, if that file is not found, will then go on to request a configuration
file named 000000000000.cfg.
When the phone is configured to talk to a Digium Configuration server, either manually by plugging in the address of the server or automatically
through mDNS discovery, the phone will communicate with and retrieve its configuration directly from Asterisk via the DPMA.
DPMA Concepts
DPMA uses two internal concepts:
Phones
Lines
A is a set of configuration parameters that represent the device on your desk. A Phone is abstracted because in most cases, it representsPhone
an individual user’s configuration, e.g. Bob’s Phone. Bob’s Phone has line keys that are specific to Bob, it has a contacts list that’s specific to Bob,
it has Rapid Dial keys that are specific to Bob.
A is a key on phone that is mapped to an Asterisk SIP identity ("friend," technically, since that's a better way to go if you want to assign moreLine
than one SIP identity to the same physical device) and labeled in a particular way. Because, in Asterisk, there’s a one-to-one relationship between
physical device and SIP identity, a Line also maps one-to-one to a SIP identity, since it will only appear on one physical device at a time.
DPMA Configuration
Phones and Lines are configured in the res_digium_phone.conf configuration file – normally located at /etc/asterisk/res_digium_phone.conf. The
file contains one reserved section:
[general]
The section contains settings that are specific to the operation of the DPMA itself.[general]
Two other section types are available for user configuration, each contains a definition. The type definition determines the function of thetype
section. The three are:types
phone
line

external_line
phone sections contain all settings for a phone profile.
sections contain all settings for a to be applied to aline line phone
sections contain all settings for registration to an external SIP server, e.g. another Asterisk machineexternal_line
The phone and lines section of res_digium_phone.conf, are defined by a section identifier encapsulated in square brackets, and are
user-definable.
Example
This is an example, using invalid options and functions, of a res_digium_phone.conf configuration file, displaying the organizational layout. The
various options and functions are described later in this page.
Example res_digium_phone.conf layout.
[general]
; comments are preceded by a comma
;
; the general section contains many options
generaloption=value
generaloption2=othervalue
;
[MyPhone] ; A phone
type=phone
; Phone options go here
phoneoption=value
phoneoption2=othervalue
;
[MyAccount] ; A SIP peer from sip.conf
type=line
; Line options go here
lineoption=value
lineoption2=othervalue
;
[MyExternalAccount] ; An external SIP registration
type=external_line
; External Line options go here
externallineoption=value
externallineoption2=othervalue
;
Authentication Options
The General Section provides the following options related to authentication:
Option Values Description
globalpin integer;
e.g.
10101019
If userlist_auth is set to globalpin, sets the PIN that must be entered on a phone, at boot, in order to retrieve the list
of available phone configurations. If config_auth is set to globalpin, sets the PIN that must be entered on a phone, at
the userlist screen, in order to request a particular phone configuration - note that if the globalpin has already been
entered to authenticate to retrieve the list of available phone configurations, that it will not required a second time in
order to request a particular phone configuration.
userlist_auth disabled,
globalpin Specifies the kind of authentication required to retrieve the list of available phone profiles from the provisioning server. Options are “disabled,” where no authentication is required to retrieve the list of phone profiles; and
“globalpin,” where entry of the Global PIN is required in order to retrieve the list of phone profiles.
config_auth mac, pin,
globalpin,
disabled
Specifies the kind of authentication required to retrieve a phone’s configuration from the provisioning server.
Options are “mac,” where the MAC address of the device requesting the configuration must match the phone profile,
and if it does, the phone will be automatically provisioned with the matching phone profile; “pin” where the entered
PIN must match the phone profile; “globalpin,” where the entered PIN must match the Global PIN; and disabled,
where profiles are served without authentication - with this setting, any phone can pull any phone profile defined in
this configuration file with no authentication challenges.
Registration Server Options
The General Section provides the following options related to the registration server:

Option Values Description
registration_address IP address
or
Hostname
Allows for explicit definition of the address to which phones should register. If the option is not set, then the
address given to the phones to register is the same address that the phone uses in the To: header when
requesting a configuration
registration_port Port, as an
Integer; e.g
5060
The port on which the registration server is running – the same port on which SIP is running on the
Asterisk instance.
mDNS Discovery Options
The General Section provides the following options related to mDNS / Avahi Service Discovery:
Option Values Description
service_name string, e.g. Digium
Phones Config
Server
The name of the service to be used in Avahi service discovery. Defaults to “Digium Phones
Config Server” when service_discovery_enabled, registration_address and registration_port
are set.
service_discovery_enabled yes / no If set to yes, will advertise the config server using Avahi. Defaults to yes. The Discovery
Service will only be enabled when registration_address and registration_port are explicitly
configured.
Firmware Update Options
The General Section provides the following options related to Firmware Update:
Option Values Description
firmware_url_prefix URL, e.g.
http://10.10.10.10/firmware_package_directory Specifies the URL prefix the phone module should use to tell the phones where to retrieve firmware files.
firmware_package_directory file path, e.g.
/var/www/firmware_package_directory Specifies the actual disk location of the firmware package provided by the webserver
Files Options
The General Section provides the following options related to Files:
Option Values Description
file_directory path, e.g.
/var/lib/asterisk/digium_phones Specifies a folder from which phones can retrieve txt and binary files. This directory is primarily used for storing contacts.xml and user-generated phone configuration. Defaults to
/var/lib/asterisk/digium_phones
Other General Options
The General Section provides the following other options:
message_context string, e.g.
dpma_message_context The context matching the sip.conf [general] section definition for outofcall_message_context, defaults to dpma_message_context.
Example
In this example:
The general section has been configured with a Global PIN of 344486 (DIGIUM)
Userlist authentication has been disabled
Config Authorization has been set to MAC with Global PIN
The Registration Server is set to 10.10.10.10 on port 5060
The Avahi service name has been set to “Go 4 Phones” with discovery enabled
Firmware will be retrieved from **which is actually located athttp://10.10.10.10/digium_phones_firmware
/var/www/digium_phones_firmware
Files are stored in /var/lib/asterisk/digium_phones
and the dialplan context used for message handing is dpma_message_context

Example General Section configuration.
[general]
globalpin=344486
userlist_auth=disabled
config_auth=mac_globalpin
registration_address=10.10.10.10
registration_port=5060
service_name=Go 4 Phones
service_discovery_enabled=yes
firmware_url_prefix=http://10.10.10.10/digium_phones_firmware
firmware_package_directory=/var/www/digium_phones_firmware
file_directory=/var/lib/asterisk/digium_phones
message_context=dpma_message_context
Phone Configuration Options
Phones profiles are configured by defining a context with type option equal to “phone.” A Phone profile can have any number of lines associated
with it. Each line defined in the configuration is reflected as a separate line key on the phone; and, when provisioned, is ordered on the phone
itself as it is in the profile configuration.
The first line key associated with a Phone profile is set internally as the phone’s primary line. The primary line is the only one listed in the User list
on boot up. The primary line is also used to automatically match the phone to voicemail boxes.
The following options are provided for Phone configuration:
Option Values Description
mac A MAC address, e.g.
0123456789ab Optional. When set, and when the general config_auth option requires MAC, locks a phone configuration to a device matching this MAC address.
pin integer; e.g. 10101019 Optional. When set, and when the general config_auth option requires PIN, one must enter
this PIN on the phone before being able to pull the phone's configuration
line entity defined as line in
res_digium_phone.conf Maps directly to a sip.conf peer/friend entry. More than one line may be defined for a phone configuration. The first line entry defined is adopted as the phone's primary line.
external_line entity defined as
external_line in
res_digium_phone.conf
Maps directly to an external_line defined in this configuration file. External line are lines not
defined by SIP peers in sip.conf and generally do not register to this instance of Asterisk. If
an external line is defined as the primary extension for a phone, many of the advanced phone
application features will be disabled
config_file file, e.g.
mycustomconfig.xml The phone module automatically generates a configuration file for each phone based on the lines assigned to it; but, it is possible to supply a custom configuration file instead. Using this
option will direct the DPMA to serve up the specified file, as found in the file_directory defined
directory, to the phone. For information about custom configuration files, see .[\#xmlconfig|]
Note that using a custom configuration file, as opposed to the provisioning generated by the
DPMA, precludes the phone's use of DPMA-specific applications, e.g. voicemail, parking,
user status, etc. This option allows users to make use of the DPMA's mDNS provisioning
capabilities, providing a simpler alternative to HTTP and Option 66 provisioning, but sacrifices
the DPMA-specific features.
full_name string, e.g. Bob
Johnson The full name of the person who will be using this phone, and what will appear in the user list that the phone pulls
contact file, e.g. contacts.xml An xml file in the file_directory containing a list of contacts to serve to the phone. Multiple
contact options can exist in a single phone configuration.
blf_contact_group string, a group from
contacts Every contacts xml file will have at least one group defined in it. This setting controls which loaded group the phone should subscribe to for its Rapid Dial (BLF) keys.
timezone Timezone String, e.g.
America/Chicago Sets the timezone used for the clock on this phone.
ntp_server hostname, IP address,
e.g.
ntp.mycompany.com
Defines the NTP server to which phones will synchronize themselves
ntp_resync seconds as integer,
e.g. 86400 Defines the interval between NTP synchronization

parking_exten extension, e.g. 700 Sets the extension used for parking calls. When this option is set, and the phone has an
in-progress call, it will display a "Park" softkey, allowing for one touch parking.
parking_transfer_type blind / attended The type of transfer to perform when parking a call using the "Park" softkey.
ringtone Alarm, Chimes,
Digium, GuitarStrum,
Jingle, Office2, Office,
RotaryPhone,
SteelDrum, Techno,
Theme, Tweedle,
Twinkle, Vibe
Sets the default ringtone for the phone, defaults to Digium.
web_ui_enabled no / yes By default, when using the Digium Phone Module for Asterisk, the phone's built-in Web UI is
disabled. To override this and enable the Web UI anyway, which may result in unpredictable
behavior if user settings conflict with the settings provided by the DPMA, enable this option.
blf_unused_linekeys no / yes Digium phones, by default, place BLF keys on the sidecar, not on unused line keys. To
disable this behavior and allow BLF keys to start mapping from the next available unused line
key, enable this option.
d40_logo_file string The idle screen image for a D40 model phone in PNG format, 150x45 pixels, 8-bit depth, a
color type without alpha transparency and less than 10k in size. Loaded from the directory
specified by the option. The D40 and D50 screen size is the same; therefore itfile_directory\
is permissible to re-use the same logo file for both.
d50_logo_file string The idle screen image for a D50 model phone in PNG format, 150x45 pixels, 8-bit depth, a
color type without alpha transparency and less than 10k in size. Loaded from the directory
specified by the option. The D40 and D50 screen size is the same; therefore itfile_directory\
is permissible to re-use the same logo file for both.
d70_logo_file string The idle screen image for a D70 model phone in PNG format, 205x85 pixels, 8-bit depth, a
color type without alpha transparency and less than 10k in size. Loaded from the directory
specified by the option.file_directory\
Example
In this example:
the phone configuration is set for a phone whose MAC address matches 01:23:45:67:89:ab
the phone configuration has a PIN of 10101019
the phone's primary line is a SIP peer named bob101
the phone's secondary line is a SIP peer named bob102
the phone has an external line called bobexternal
the phone does not load an external configuration file
the full name of the phone is Bob's Phone
the phone loads a contacts XML file named bobscontacts.xml
the phone uses a contact group, from bobscontacts.xml, named "RapidDial" for its BLF keys
the phone is set for the "America/Los_Angeles" timezone
the phone's NTP server is set to 0.digium.pool.ntp.org
the phone's NTP resynchronization time is 86400
the phone will blind transfer parked calls to extension 700
the phone's ringtone is a Guitar Strum
the phone's Web UI is disabled
the phone's Rapid Dial keys will begin from the side car
if the phone claiming the profile is a D40, it will use the logo file d40_logo.png
if the phone claiming the profile is a D50, it will use the logo file d50_logo.png
if the phone claiming the profile is a D70, it will use the logo file d70_logo.png

Example Phone Configuration.
[bobsphone]
type=phone
mac=0123456789ab
pin=10101019
line=bob101
line=bob102
external_line=bobexternal
;config_file
full_name=Bob's Phone
contact=bobstonctacts.xml
blf_contact_group=RapidDial
timezone=America/Los_Angeles
ntp_server=0.digium.pool.ntp.org
ntp_resync==86400
parking_exten=700
parking_transfer_type=blind
ringtone=GuitarStrum
web_ui_enabled=no
blf_unused_linekeys=no
Line Configuration Options
Internal lines are SIP peers (friends), but there is Digium Phone-specific data associated with lines that does not otherwise exist in the sip.conf
entry. Because of this, advanced line features must be defined separately from sip.conf, here, in res_digium_phone.conf. Advanced line
configuration is not a requirement to get a line to work, it only acts as a method of setting advanced phone features to an already-defined sip.conf
entry.
Option Values Description
exten string, e.g.
1000 When the sip peer name is different than the actual extension used to contact this line, this option should be set to the line's dialable extension. By default it is assumed that the sip peer name is
actual extension, which is true for most Asterisk distributions such as FreePBX and AsteriskNOW,
but is not considered a best practice for use of generic Asterisk.
digit_map Digit mapping,
see
[\#dialplans|]
The digit mapping to use for this line.
line_label string, e.g.
MD 123 The line label to display on the phone for this line's line key.
language string, e.g.
en_US The preferred language to use for this line. Currently, only US English is supported.
mailbox mailbox from
voicemail.conf The voicemail box associated with the line. When not set, this will default first to the mailbox defined for the sip peer associated with the line, and second to a mailbox entry in voicemail.conf
matching the name of the line. IF neither of these are found and this option is not set, the line does
not have a mailbox and visual voicemail will not be enabled.
voicemail_uri string,
sip:user@host If the phone's Msgs button should dial a SIP URI rather than opening the visual voicemail application, this option specifies what URI the Msgs button should dial. Setting this option on a
phone's primary lie will disable visual voicemail.
outboundproxy_address Host / IP
address The Outbound SIP proxy address this line should use
outboundproxy_port Port as
integer The port of the Outbound SIP proxy; defaults to 5060 when outboundproxy_address is set
transport udp, tcp SIP transport method this line should use. Defaults to udp
reregistration_timeout integer, e.g.
300 The number of seconds before re-registering

registration_retry_interval integer, e.g.
25 The number of seconds to wait before retrying to register after registration fails.
registration_max_retries integer, e.g. 5 The number of times the phone will attempt to retry registering after registration fails.
Example
In this example:
the Digit Mapping for the phone is set to [0-8]xxx
The Label for the line, as it appears on the phone is BobbyJ
The Mailbox for the line is bob101
The Voicemail URI (number to be dialed) is 8000 at the 10.10.10.10 PBX.
The Outbound Proxy is 10.10.10.1 and its port is 5060.
The Transport type for the signaling is TCP
The Re-registration timeout is 300 seconds
The Registration Retry Interval is 25 seconds
The Maximum Registration Retries is 5 times
Example Line Configuration.
[bob101]
type=line
digit_map=[0-8]xx
line_label=BobbyJ
mailbox=bob101
voicemail_uri=sip:[email protected]
outboundproxy_address=10.10.10.1
outboundproxy_port=5060
transport=tcp
reregistration_timeout=300
registration_retry_interval=25
registration_max_retries=5
If SIP peers are configured using Asterisk Realtime, then the parameter, as noted in the External Line section, must besecret
populated for standard lines, with the secret used by the actual peer.
External Line Configuration Options
External lines are external to this Asterisk instance; they are lines that are not entries in sip.conf. The external line concept exists to work around
the forcing of lines as sip.conf peers. Since external lines are not SIP peers, they require more information than normal line configurations. Here
are the external line-specific configuration options.
Note that all internal line options are also available for external lines; but, any internal line options specific to applications on the
phone, such as mailbox to enable visual voicemail, will not work unless the server-side component resides on Asteriskthis
instance.
Configuring an external line as the primary line for a phone will result in the advanced PBX features being disabled for the
phone
Option Values Description
server_address string, e.g.
otherpbx.othercompany.com The address this line should contact for registration and outbound calls
server_port integer, e.g. 5060 The port this line should contact for registration and outbound calls. Defaults to
5060
secondary_server_address string, e.g.
backuppbx.othercompany.com The address this line should contact for registration and outbound calls if the primary server is not available
secondary_server_port integer, e.g. 5060 The port this line should contact for registration and outbound calls if the
primary server is not available

secondary_server_transport tcp or udp The transport type used for registration and calling to/from the secondary server
userid string, e.g. bob1234 This line's SIP username. Defaults to the line's name
authname string, e.g. bob1234 SIP authorization name if different than userid. If blank, defaults to userid.
secret string, e.g. mymagicpassword The SIP secret this line should used
register yes / no Indicates whether or not this line should register
callerid string Caller ID field to use for this line
*Example: *
In this example:
The address of the external registration server is otherpbx.mycompany.com
The contact port of the external registration server is 5061
The transport method of the external registration server is TCP
The address of the secondary external registration server is otherpbx2.company.com
The contact port of the secondary registration server is 5061
The transport method of the secondary external registration server is UDP
The SIP username is bob1234
The SIP authname is bob4321
The SIP password (secret) is mymagicalpassword
Registration is enabled
Caller ID is set to "Bob Jones <555-1234>"
Example External Line Configuration.
[bob1234]
type=external_line
server_address=otherpbx.mycompany.com
server_port=5061
transport=tcp
secondary_server_Address=otherpb2.mycompany.com
secondary_server_port=5061
secondary_server_transport=udp
userid=bob1234
authname=bob4321
secret=mymagicalpassword
registration=yes
callerid=Bob Jones <555-1234>
Contacts
Digium Phones provide a Contacts application that integrates speed-dial, device busy-lamp field and user presence. The Contacts application is
related to the Status application in that both are concerned with presence. The Status application is concerned only with setting the local user's
presence. The Contacts application is concerned with the presence status of other users - those to which it's been programmed to subscribe.
Contacts without presence subscriptions may be loaded locally onto the phone by the phone's user. Most deployments of Digium phones will see
the administrator specifying XML lists of contacts to load onto phones. Here, we will discuss the methods to direct the phone to load contacts as
well as the contents of the contacts XML files.
Loading a Contact List
Contacts files that the phone should load are defined in the phone's configuration XMl file and are served up by the DPMA. Contact file are
specified for a phone configuration using the phone configuration parameter:
contact
as noted above. Multiple "contact" lines may be used for each phone configuration.
Rapid Dial Keys
Rapid Dial, or BLF, keys are set using the phone configuration parameter:
blf_contact_group

The order of the contacts in this group is important. Those contacts fill in the BLF-keys in the same order as given in the xml, and those contacts
are subscribed to, in order, up to a maximum of 40.
Contacts XML skeleton
A basic Contacts XML structure is defined here:
Contactx XML Structure example
<phonebooks>
<contacts>
<contact>
<numbers>
<number />
</numbers>
<emails>
<email />
</emails>
</contact>
</contacts>
</phonebooks>
And, a more fleshed-out example looks like:
XML Contact Example
<phonebooks>
<contacts group_name="PBX Directory" editable="0">
<contact
prefix="Mr"
first_name="Robert"
second_name="Davis"
last_name="Jones"
suffix="III"
contact_type="sip"
organization="Digium"
job_title="Direction Manager"
location="East Texas"
notes=""
account_id="104"
subscribe_to="sip:[email protected]"
>
<numbers>
<number dial="104" dial_prefix="" label="Extension" primary="1" />
<number dial="8005551234" dial_prefix="9" label="Mobile" />
</numbers>
<emails>
<email address="[email protected]" label="Work" primary="1" />
</emails>
</contact>
</contacts>
<contacts group_name="Default" editable="1" id="1">
....
</contacts>
<contacts group_name="Family Members" editable="1" id="2">
....
</contacts>
</phonebooks>
Dial Plans
The dial plan includes settings that specify the behavior of the phone as a user enters a number in off-hook dialing mode.
The digit map is the setting that describes different patterns of numbers. When a number matches a pattern, the number is sent to Asterisk to

place the call. The pattern may include a timer at the end. If no numbers are entered before the time expires, the number matching the pattern will
be sent. If additional numbers are entered before the time elapses, the pattern no longer matches.
The syntax of a digit map is:
Digit Map Syntax
digitmaplist := digitmap ( '|' digitmap )*
digitmap := digitstring | digitstring timer
digitstring := atom+
atom := literal | class | wildcard
literal := digit | '*' | '#'
digit := '0' | '1' | '2' | '3' | '4' | '5' | '6' | '7' | '8' | '9'
class := '[' range+ ']'
wildcard := '.'
range := digit | digit '-' digit
timer := T digit*
A digit map with a timer, but no specified time value, defaults to 4 seconds.
Example:
The following example assumes the following dials will be completed:
Dial four digit extensions from 0000-8999 after the default timeout.
Dial 911 immediately
Dial 9911 immediately
Dial 411 immediately
Dial 611 immediately
Dial numbers beginning with 011 followed by at least 4 more digits after a delay of 3 seconds.
Dial numbers beginning with 1 followed by 10 digits immediately
Dial numbers beginning with 2-9 followed by 6 digits immediately
Dial any three digit number after a delay of 3 seconds.
Digit Map Example.
[0-9]xxx|911|9911|411|611|011xxxx.T3|1xxxxxxxxxx|[2-9]xxxxxx|*xx.T3
Note that the phone will attempt to immediately dial any pattern that does not have a matching rule
Ringing Types and Intercom
Digium phones support several different types of ringing:
Normal Ringing - normal
One Ring followed by automated Answer - ring-answer
Immediate Answer, No ringing - intercom
Visual only, No ringing sound - visual
When an incoming call is received, the phone will look for an ALERT_INFO SIP header, and compare the received header against its
configuration, as parsed from its Config XML.
Affecting the ring tone from the Asterisk dialplan requires use of the alert_info SIP header. This header should be added into the dialplan before
executing a dial to the phone, as such:

Selecting a Ringtone from the Dialplan
exten => 100,1,SIPAddHeader("Alert-Info: normal")
exten => 100,n,Dial(SIP/mypeer)
Alert-Info elements encapsulated in angle brackets are currently not parsed correctly by the Digium phones. As such, users who
require use of angle brackets for the first Alert-Info element, and who are using their own generated configurations, not provided
by the DPMA, must use the escaped characters directly in the alert definition.
Firmware
Firmware configuration Management
Firmware configuration is handled globally for the DPMA. When a firmware package directory is set in res_digium_phone.conf, the firmware
associated with that package becomes the firmware every phone configured with the DPMA will run from then on. Phones already configured with
the DPMA before a firmware package change will have to be sent a reconfigure message or manually restarted to receive the firmware changes.
In res_digium_phone.conf the directory of a firmware package is pointed to. In that firmware package directory there will be a
digium_phones_firmware.conf that maps all the firmware (.eff) files in the directory to a phone model and a firmware version.
Example: Example digium_phones_firmware.conf file in a Digium maintained firmware package.
[D40]
version=1_0_3_45441
file=1_0_3_45441_D40_firmware.eff
[D50]
version=1_0_3_45441
file=1_0_3_45441_D50_firmware.eff
[D70]
version=1_0_3_45441
file=1_0_3_45441_D70_firmware.eff
Each context in that config file represents a specific Digium Phone model along with what firmware to upload to that module and the version
associated with it. When a phone requests its config, the DPMA advertises the available firmware version and where to retrieve that firmware.
XML Configuration
This section describes the formatting and options available when creating XML-based configuration files for provisioning Digium phones. Users
choosing this method of configuration forgo use of the DPMA, and instead are provisioning phones for use with Asterisk versions that do not
support the DPMA.
The configuration elements provided in this section are subject to change between Digium Phone firmware releases.
A Complete XML Configuration Example
A Complete XML Configuration Example
<?xml version="1.0" ?>
<config>
<setting id="login_password" value="789" />
<setting id="time_zone" value="America/Los_Angeles" />
<setting id="time_source" value="ntp" />
<setting id="ntp_server" value="0.digium.pool.ntp.org" />
<setting id="ntp_resync" value="86400" />

<setting id="accept_local_calls" value="any" />
<setting id="transport_udp_enabled" value="1" />
<setting id="transport_udp_port" value="5060" />
<setting id="transport_tcp_enabled" value="1" />
<setting id="transport_tcp_port" value="5060" />
<setting id="logo_file" value="user" path="/user_image.png"
url="https://server.example.com/mylogo.png" md5="126cd744583eeea1ab7e44ed8af3d39c" />
<setting id="display_mc_notifications" value="1" />
<setting id="brightness" value="10" />
<setting id="contrast" value="10" />
<setting id="dim_backlight" value="1" />
<setting id="backlight_timeout" value="30" />
<setting id="backlight_dim_level" value="2" />
<setting id="ringer_volume" value="5" />
<setting id="speaker_volume" value="5" />
<setting id="handset_volume" value="5" />
<setting id="headset_volume" value="5" />
<setting id="reset_call_volume" value="0" />
<setting id="default_ringtone" value="Digium" />
<setting id="active_ringtone" value="Digium" />
<setting id="headset_answer" value="0" />
<setting id="desi_strip_enable" value="1" />
<setting id="enable_blf_on_unused_line_keys" value="0" />
<setting id="name_format" value="first_last" />
<setting id="contacts_max_subscriptions" value="40" />
<setting id="blf_contact_group" value="Default" />
<setting id="network_enable_dhcp" value="1" />
<setting id="network_static_ip_address" value="" />
<setting id="network_subnet_mask" value="" />
<setting id="network_default_gateway" value="" />
<setting id="network_domain_name" value="" />
<setting id="network_primary_dns_server" value="" />
<setting id="network_secondary_dns_server" value="" />
<setting id="network_vlan_discovery_mode" value="NONE" network="10.10.0.0/16" />
<setting id="network_vlan_qos" value="0" />
<setting id="network_vlan_id" value="44" />
<setting id="log_level" value="debug" />
<setting id="enable_logging" value="0" />
<setting id="log_server" value="10.1.2.3" />
<setting id="log_port" value="514" />
<setting id="web_ui_enabled" value="1" />
<setting id="sip_dscp" value="24" />
<setting id="rtp_dscp" value="46" />
<contacts url="https://server.example.com/myfile.xml" id="internal" md5="abcd123" />
<accounts>
<account index="0" status="1" register="1" account_id="100" username="100" authname="100"
password="100" passcode="100" line_label="100 Alligator" caller_id="100 Alligator"
dial_plan="[0-8]xxxxx|911|9411|9611|9011xxx.T3|91xxxxxxxxxx|9[2-9]xxxxxx|*xx.T3|[0-8]xx.T3"
visual_voicemail="0" voicemail="sip:[email protected]" outbound_proxy="" outbound_port=""
conflict="replace">
<host_primary server="10.10.2.108" port="5060" transport="udp" reregister="300"
retry="25" num_retries="5" />
<permission id="record_own_calls" value="0" />
</account>
</accounts>
<codecs>
<codec id="PCMU" priority="255" packetization="20" jitter_min="0" jitter_max="0"
jitter_target="0" enabled="1" />
<codec id="PCMA" priority="13" packetization="20" jitter_min="0" jitter_max="0"
jitter_target="0" enabled="1" />
<codec id="G722" priority="11" packetization="20" jitter_min="0" jitter_max="0"
jitter_target="0" enabled="1" />
<codec id="G726-32" priority="7" packetization="20" jitter_min="0" jitter_max="0"
jitter_target="0" enabled="1" />
<codec id="G729" priority="4" packetization="20" jitter_min="0" jitter_max="0"
jitter_target="0" enabled="1" />
<codec id="L16" priority="2" packetization="20" jitter_min="0" jitter_max="0"
jitter_target="0" enabled="1" />
<codec id="L16-256" priority="1" packetization="20" jitter_min="0" jitter_max="0"
jitter_target="0" enabled="1"/>

</codecs>
<ringtones>
<tones>
<tone id="Alarm" display="Alarm" type="phone"/>
<tone id="Chimes" display="Chimes" type="phone"/>
<tone id="Digium" display="Digium" type="phone"/>
<tone id="GuitarStrum" display="Guitar Strum" type="phone"/>
<tone id="Jingle" display="Jingle" type="phone"/>
<tone id="Office" display="Office" type="phone"/>
<tone id="Office2" display="Office 2" type="phone"/>
<tone id="RotaryPhone" display="Rotary Phone" type="phone"/>
<tone id="SteelDrum" display="Steel Drum" type="phone"/>
<tone id="Techno" display="Techno" type="phone"/>
<tone id="Theme" display="Theme" type="phone"/>
<tone id="Tweedle" display="Tweedle" type="phone"/>
<tone id="Twinkle" display="Twinkle" type="phone"/>
<tone id="Vibe" display="Vibe" type="phone"/>
</tones>
<alerts>
<alert alert_info="normal" ringtone_id="Digium" ring_type="normal" />
<alert alert_info="ring-answer" ringtone_id="Digium" ring_type="ring-answer" />
<alert alert_info="intercom" ringtone_id="" ring_type="answer" />
<alert alert_info="visual" ringtone_id="" ring_type="visual" />
</alerts>
</ringtones>
<appconfig id="appscreen">
<application id="contacts" />
</appconfig>
<appconfig id="contacts">
<settings use_local_storage="1" can_transfer_vm="0" />
</appconfig>
<firmwares>
<firmware model="D50" version="1_0_3_45441"
url="http://10.10.4.11/firmware/1_0_3_45441_D50_firmware.eff" />
<firmware model="D70" version="1_0_3_45441"
url="http://10.10.4.11/firmware/1_0_3_45441_D70_firmware.eff" />
<firmware model="D40" version="1_0_3_45441"
url="http://10.10.4.11/firmware/1_0_3_45441_D40_firmware.eff" />
</firmwares>
<public_firmwares>
<public_firmware model="D50" version="1_0_3_45441"
url="http://firmware.example.com/1_0_3_45441_D50_firmware.eff" />
<public_firmware model="D70" version="1_0_3_45441"
url="http://firmware.example.com/1_0_3_45441_D70_firmware.eff" />
<public_firmware model="D40" version="1_0_3_45441"

url="http://firmware.example.com/1_0_3_45441_D40_firmware.eff" />
</public_firmwares>
</config>
Setting Elements
XML Setting Elements
XML Setting Elements
<?xml version="1.0" ?>
<config>
<setting id="login_password" value="789" />
<setting id="time_zone" value="America/Los_Angeles" />
<setting id="time_source" value="ntp" />
<setting id="ntp_server" value="pool.ntp.org" />
<setting id="ntp_resync" value="86400" />
<setting id="accept_local_calls" value="any" />
<setting id="transport_udp_enabled" value="1" />
<setting id="transport_udp_port" value="5060" />
<setting id="transport_tcp_enabled" value="1" />
<setting id="transport_tcp_port" value="5060" />
<setting id="logo_file" value="user" path="/user_image.png"
url="https://server.example.com/mylogo.png" md5="126cd744583eeea1ab7e44ed8af3d39c" />
<setting id="display_mc_notifications" value="1" />
<setting id="brightness" value="10" />
<setting id="contrast" value="10" />
<setting id="dim_backlight" value="1" />
<setting id="backlight_timeout" value="30" />
<setting id="backlight_dim_level" value="2" />
<setting id="ringer_volume" value="5" />
<setting id="speaker_volume" value="5" />
<setting id="handset_volume" value="5" />
<setting id="headset_volume" value="5" />
<setting id="reset_call_volume" value="0" />
<setting id="default_ringtone" value="Digium" />
<setting id="active_ringtone" value="Digium" />
<setting id="headset_answer" value="0" />
<setting id="desi_strip_enable" value="1" />
<setting id="enable_blf_on_unused_line_keys" value="0" />
<setting id="name_format" value="first_last" />
<setting id="contacts_max_subscriptions" value="40" />
<setting id="blf_contact_group" value="Default" />
<setting id="network_enable_dhcp" value="1" />
<setting id="network_static_ip_address" value="" />
<setting id="network_subnet_mask" value="" />
<setting id="network_default_gateway" value="" />
<setting id="network_domain_name" value="" />
<setting id="network_primary_dns_server" value="" />
<setting id="network_secondary_dns_server" value="" />
<setting id="network_vlan_discovery_mode" value="NONE" network="10.10.0.0/16" />
<setting id="network_vlan_qos" value="0" />
<setting id="network_vlan_id" value="44" />
<setting id="log_level" value="debug" />
<setting id="enable_logging" value="0" />
<setting id="log_server" value="10.1.2.3" />
<setting id="log_port" value="514" />
<setting id="web_ui_enabled" value="1" />
<setting id="parking_lot_extension" value="700" />
<setting id="parking_lot_enable_blind_transfer" value="0" />
<setting id="sip_dscp" value="24" />
<setting id="rtp_dscp" value="46" />
</config>
Each <setting> element represents at least an and pair of attributes. Some <setting> tags may have additional attributes.id value

General (Login)
Option Values Description
login_password String, e.g.
789 Sets the Admin Password for logging into Web UI or Admin Settings Section on Phone Menu, defaults to 789
General (Time)
time_zone Timezone String, e.g. America/Chicago Sets the time zone for the phone
time_source ntp Sets the time source for the phone
ntp_server Hostname or IP address, e.g.
0.digium.pool.ntp.org Sets the NTP server to which the phone will synchronize itself, defaults to 0.digium.pool.ntp.org
ntp_resync Seconds as integer, e.g. 86400 Sets the interval between NTP synchronization
General (SIP)
accept_local_calls any / host Sets whether to accept calls from any source or only from hosts to which the phone is
registered
transport_udp_enabled boolean Sets whether to enable UDP transport, defaults to 1
transport_udp_port Valid integer for ports
(1-65535) Sets the local UDP SIP port, defaults to 5060
transport_tcp_enabled boolean Sets whether to enable TCP transport, defaults to 1
transport_tcp_port Valid integer for ports
(1-65535 ) Sets the local TCP SIP port, defaults to 5060
Preferences (Idle Screen)
logo_file as factory / user; as location on disk of file - /factory_asterisk.png for defaultvalue path
and /user_image.png for custom ; as optional location to fetch a logo; as optionalurl md5
when url is used to determine if logo has changed to avoid re-fetching
Sets the idle screen
logo, defaults to
display_mc_notifications boolean Disables / Enables
display of missed calls
on the phone, defaults
to 1
Preferences (Display)
brightness integer
(0-10) Sets the LCD screen brightness, defaults to 5
contrast integer
(0-10) Sets the LCD screen contrast, defaults to 5
dim_backlight boolean enable backlight dimming where 1 dims the screen after backlight timeout has been reached and phone is
otherwise idle, defaults to 1
backlight_timeout integer
(0-3200) Time, in seconds, before backlight is set to backlight_dim_level while phone is idle; setting to 0 disables backlight timeout, defaults to 0
backlight_dim_level integer
(0-10) Brightness level dims to when when dim_backlight is 1, defaults to 2
Preferences (Sounds)
ringer_volume integer (0-10) Sets the ringer volume, defaults to 5
speaker_volume integer (0-10) Sets the speaker volume, defaults to 5

handset_volume integer (0-10) Sets the handset volume, defaults to 5
headset_volume integer (0-10) Sets the headset_volume, defaults to 5
reset_call_volume boolean If 1, volume changes made during a call do not persist to the next call, defaults
to 0
default_ringtone Tone ID from <tones> provided to
phone Sets the default phone ringtone, defaults to Digium
active_ringtone Tone ID from <tones> provided to
phone Sets the current user-selected ringtone, defaults to Digium
Preferences (Answering Calls)
headset_answer boolean Sets whether to use the headset, rather than the speaker, for answering all calls, defaults to 0
Contacts
desi_strip_enable boolean Applies to D50 and D70 models, enables / disables sidecar, defaults to 1
enable_blf_on_unused_line_keys boolean If 1, assigns BLFs beginning with first empty line key. If 0, assigns BLFs
beginning with first sidecar key. Defaults to false.
name_format first_last, last_first Formats the display of contact names, defaults to first_last
contacts_max_subscriptions integer (0-40) Sets the maximum number of subscriptions for presence indications - 0 disables
presence subscriptions. Defaults to 40
blf_contact_group Any Group ID from the
loaded contacts The ID of the contact list group to use for the rapid dial list
Network (IP Settings)
network_enable_dhcp boolean Disable or Enable DHCP network configuration, defaults to 1
network_static_ip_address IPv4 address Defines the network address for the phone
network_subnet_mask IPv4 netmask Defines the netmask for the phone
network_default_gateway IPv4 address Defines the network gateway for the phone
network_primary_dns_server IPv4 address Defines the primary DNS server for the phone
network_secondary_dns_server IPv4 address Defines the secondary DNS server for the phone
Network (Virtual LAN)
network_vlan_discovery_mode of NONE, MANUAL, LLDP;value as IP masknetwork Sets use of none, manual, or LLDP discovered VLAN and, if MANUAL,
defines the network; defaults to LLDP
network_vlan_qos integer (0-7) Sets the VLAN QOS level
network_vlan_id integer (0-4095) Sets the VLAN ID
Logging
log_level error, warning, debug, info Sets the logging level, defaults to error
log_server IPv4 address of syslog server Specifies remote syslog server
log_port port as integer Specifies port of remote syslog server
enable_logging boolean Disables or Enables remote syslog, defaults to 0
Miscellaneous

web_ui_enabled boolean Disables, Enables the phone's web user interface, defaults to 1 (Enabled)
sip_dscp integer (0-63) Specifies the DSCP field of the DiffServ byte for SIP Signaling QoS, defaults to 24
rtp_dscp integer (0-63) Specifies the DSCP field of the DiffServ byte for RTP Media QoS, defaults to 46
Contacts Element
Contacts Element Example
Contacts Element Example
<?xml version="1.0" ?>
<config>
<contacts url="https://server.example.com/myfile.xml" id="internal" md5="abcd123" />
</config>
Any number of contacts elements may be present directly under the config element.
These <contacts> elements have attributes, most importantly url which allow contacts xml sheets to be downloaded via the DPMA.
Option Values Description
contacts as file link, as unique identifier, asurl id md5
the md5sum of the xml file Specifies the contacts XML file to be retrieved by the phone and identifies that file;
more than one contacts parameter may be used
Accounts Element
Accounts Element Example
Accounts Element Example
<?xml version="1.0" ?>
<config>
<accounts>
<account index="0" status="1" register="1" account_id="100" username="100" authname="100"
password="100" passcode="100" line_label="100 Alligator" caller_id="100 Alligator"
dial_plan="[0-8]xxxxx|911|9411|9611|9011xxx.T3|91xxxxxxxxxx|9[2-9]xxxxxx|*xx.T3|[0-8]xx.T3"
visual_voicemail="0" voicemail="sip:[email protected]" outbound_proxy="" outbound_port=""
conflict="replace">
<host_primary server="10.10.2.108" port="5060" transport="udp" reregister="300"
retry="25" num_retries="5" />
<permission id="record_own_calls" value="0" />
</account>
</accounts>
</config>
Option Values Description
index integer (0-5) Defines the line key to which the account will be mapped
status boolean Enables the line key; if false, will not display the line on the phone or register with the primary host
register boolean If 1, then this account will attempt to register with the primary host
account_id string SIP username
username string SIP username
authname string SIP authname
password string SIP password
passcode string SIP password
line_label string The text that shows up next to the line key for this account
caller_id Name
<Number> Outgoing caller id displayed for this account

dial_plan Digit mapping,
see
[\#dialplans|]
The dial plan / digit mapping for this account
visual_voicemail boolean Only valid on account with index of 0. Only valid for phones provisioned by Switchvox or the DPMA. If this
is set to 1 then the Msgs button action will open the voicemail app. Otherwise it will dial the voicemail
extension.
voicemail digits or SIP
URI A SIP URI or extension to be dialed for voicemail pertaining to this account.
outbound_proxy IP address /
Hostname Outbound proxy for this account
outobund_port port Port for the outbound proxy
conflict replace
Host Primary: Child Element of <account>
Option Values Description
server Hostname or IPv4 Address Sets the server to which calls for this account are directed
port integer (1-65535) Sets the server's SIP port
transport udp, tcp Sets the transport type, UDP or TCP
reregister integer in seconds Sets the re-registration interval
retry integer Specifies the number of time to attempt re-registration if registration fails
num_retries integer Specifies the number of retries to attempt if registration fails
Permission: Child Element of <account>
Defines line/account based permissions for various phone functions with an and pair.id value
Option Values Description
record_own_calls boolean If 1, allows the user to record their own calls using a soft-key. Note that this feature can only enabled when using
the DPMA. Users manually provisioning Digium phones should set this to 0 in order to ensure that a
non-functional (because the DPMA is not being used) call recording softkey does not appear.
Codecs Element
Codecs Element Example

1.
2.
Codecs Element Example
<?xml version="1.0" ?>
<config>
<codecs>
<codec id="PCMU" priority="255" packetization="20" jitter_min="0" jitter_max="0"
jitter_target="0" enabled="1" />
<codec id="PCMA" priority="13" packetization="20" jitter_min="0" jitter_max="0"
jitter_target="0" enabled="1" />
<codec id="G722" priority="11" packetization="20" jitter_min="0" jitter_max="0"
jitter_target="0" enabled="1" />
<codec id="G726-32" priority="7" packetization="20" jitter_min="0" jitter_max="0"
jitter_target="0" enabled="1" />
<codec id="G729" priority="4" packetization="20" jitter_min="0" jitter_max="0"
jitter_target="0" enabled="1" />
<codec id="L16" priority="2" packetization="20" jitter_min="0" jitter_max="0"
jitter_target="0" enabled="1" />
<codec id="L16-256" priority="1" packetization="20" jitter_min="0" jitter_max="0"
jitter_target="0" enabled="1"/>
</codecs>
</config>
The codecs element contains all available codecs. each described by an individual <codec> element and its attributes.
Each <codec> element is described by the following attributes:
Option Values Description
id PCMU, PCMA, G722, G726-32, G729, L16,
L16-256 A codec supported by the phone
priority integer (1-255) Priority of the codec where higher numbers mean the codec is more
favored
packetization integer in 10ms increments per RFC codec
guidelines Packetization (ptime) rate for the specified codec, defaults to 20
jitter_min integer in ms Sets the minimum size of the codec jitter buffer
jitter_max integer in ms Sets the maximum size of the codec jitter buffer
jitter_target integer in ms Sets the target size of the codec jitter buffer
enabled boolean Disables / Enables a codec
Ringtones Element
This section has two primary child elements:
tones, which are the actual sounds heard when a call is made
alerts, which map to a tone and represent a certain call condition
Tones: Child element of <ringtones>
Tones Element Example
