Diivoo WT-02 User manual

Automatic Water Timer
More effectively manage your garden
USER MANUAL
WT-02
Press the " " button to set the time to start
watering, and press " " button to confirm.
Start Time
Press the " " to set the time to end watering,
and press " " button to confirm.
· It will stop working when end time reaches, unless
exist other program.
· Please make sure the end time is later than start time.
End Time
Press the " " to set the time of watering duration,
and press " " to confirm.
Watering can be customized to run from 1 min to
23hours 59 mins.
How long
1. Press the " ", the " " points to Set Time.
2. Press the " " to set the current hour and
minute. Press " " to confirm.
3. Press the " " to set the current day of the
week. Press " " to save changes and moving
to next setting, Program.
Please set the end time is later than start time.
Please confirm your watering schudule before multiple
program settings. The start time of P2 is later than end
time of P1. The start time of P3 is later than end time
of P2.
Please follow the steps to set a watering program,
if not, “Conflict setting” flashes and program
cannot be saved.
Please make sure the timer is in AutoRun states
when set Rain Delay or Children Lock.
2
4
3
Need Help?
Thank You!1. Product Appearance 3. Automatic Watering Program Setting
Attention
Program Logic
2. Indicators Introduction
Children Lock
Rain Delay
Watering State
Battery Indicator
Program (P1/P2/P3) Closed
Program (P1/P2/P3)
Running
The Next
Watering Time
3 Separate Watering
Programs Button
Increase Button
Decrease Button
Confirm Button
Manual Watering Button
Setting Button
Program is not completed
Hose Faucet Connection
Outlet
Fitting NH3/4”
AUTOAUTOAUTO
AUTO
Note:
1Set Time - Set the current week and time
1. Press the " ", the "▲" points to Program. P1
have been selected and Press " " if switch to
P2/P3.
2. Press the " " to set P1 state to ON, press
" " to confirm.
Program 1 State
1
AUTO
2Set Program
·The Water days can be cancelled when press " "
button again if the week has been selected.
·The day will come with a 【】 if be selected.
Press the " " button to set the time of watering
frequency and press " " to complete P1. The P1
will be saved as your set.
· The watering frequency ranging from 1min, 5min,
15min, 30min, 1H, 2H...... 23H
· If the start time of P1/P2/P3 is the same, it will be
executed in the order of P1→P2→P3.
1. Press " " to select P2/P3 and press
" " to confirm.
2. Follow the steps likes P1 setting to set P2/P3.
(State→ Start Time→ End Time→ How Long→ How Oen)
Please make sure the start time of P2 is later than end
time of P1. The start time of P3 is later than end
time of P2.
How often
P2/P3 Setting
5
1. Press the " ", the " " points to Water Days
2. Press the " " to choose the day of the week
you would watering, and press " " to confirm.
AUTO
Note:
Note:
Note:
3Set Water Days
P1
P2
... ...
P3
... ...
Step1: SET TIME
Step2: SET PROGRAM
Step3: SET WATER DAYS
AutoRun
Set the P1 is Running or Not
Set the time to start watering
Set the time to end watering
Set how long to watering
Set how oen to watering
Set the days of the week to run
It will not water when the end time
reaches unless there are other schedules
State: ON/OFF
Start Time: 00:00-23:59
End Time: 00:00-23:59
How Long: Minutes or hours
How Oen: Minutes or hours
The same as P1
The same as P2
Start
Set the current week and time
Filter
[e-mail]
If you have any questions, please feel free to contact us first.
We are always here for you.
6
The start time of next schedule is the start time of last
schedule plus one interval time and one watering time.
NEXT 【 】【 】 【 】【 】【 】【 】【 】【 】【 】【 】
