Tiger 6020009 Service manual

PARTS LISTING WITH
MOUNTINGAND OPERATING
INSTRUCTIONS
TWIN ROTARY
ASSEMBLIES
Ford TS 100-110A
CAB, WOC
06020009
Tiger Corporation
3301 N. Louise Ave.
Sioux Falls, SD 57107
1-800-843-6849
1-605-336-7900
www.tiger-mowers.com
Current as of 02/23/2010

TO THE OWNER / OPERATOR / DEALER
All implements with moving parts are potentially hazardous. There is no substitute for a cautious,
safe-minded operator who recognizes the potential hazards and follows reasonable safety practices.
The manufacturer has designed this implement to be used with all its safety equipment properly
attached to minimize the chance of accidents.
BEFORE YOU START!! Read the safety messages on the implement and shown in this manual.
Observe the rules of safety and use common sense!
READ AND UNDERSTAND THIS MANUAL! Non–English speaking operators will need to GET
THE MANUAL TRANSLATED as needed!
Warranty Information: Read and understand the complete Warranty Statement found in this manual. Fill out the
Warranty Registration form in full and return it within 90 days. Make certain the Serial Number of the machine is
recorded on the Warranty Card, and form that you retain.

FORWARD
Thismanualcontainsinformationaboutmanyfeaturesof the Tiger mowing
androadsidemaintenanceequipment. Someoftheseinclude:Safetyprecautions,
Assemblyinstructions,Operations,Maintenanceand Parts.Thismanualwillalso
assistyou intheproperbreak-in,dailycare,andtroubleshooting ofyour new
mower.
Werecommendthatyoureadcarefullytheentiremanualbeforeoperatingthe
unit. Also,time spentin becomingfullyacquaintedwithitsperformance features,
adjustments,andmaintenancescheduleswillbe repaid in alongand satisfactory
lifeof theequipment.
Troubleshooting-Please, before youcall,helpus to helpyou!
Pleaselookattheequipmenttoobservewhat ishappening,then:
•Classifythe problem
• Hydraulic,electricalormechanical- Readthetroubleshootingsection
• Tractor orTruck chassis- Contactvehicle dealer
•Ifunable tocorrectthe problemyourself,contactyour localTigerDealer after
gathering:
• Machinemodel _______________________
•Serialnumber ________________________
• Dealername _________________________
• Detailedinformationabouttheproblemincludingresultsoftroubleshooting
AttentionOwner/ Operator /Dealer: Itisyourobligationtoread,andunderstand,
thewarrantyinformationsectionlocatedat thebackofthismanualdenotingthatthe
purchaserunderstandsthesafetyissues relatingtothismachineand hasreceived
andwill readacopy ofthismanual.
Ifatany time, youhavea service problemwithyourTiger mower,Contact
yourlocal dealerforservice andpartsneeded.
MANUFACTURED BY: DISTRIBUTED BY:
TigerCorporation _____________________
3301 N. LouiseAve. _____________________
SiouxFalls, SD57107 1-_____-_____-________
1-800-843-6849 1-_____-_____-________
1-605-336-7900
www.tiger-mowers.com

TABLE OFCONTENTS
SAFETY_____________________________________________ 1-1
Safety Information__________________________________ 1-2
ASSEMBLY / MOUNTING SECTION_______________________2-1
OPERATION SECTION_________________________________ 3-1
MAINTENANCE SECTION______________________________ 4-1
PARTS SECTION_____________________________________ 5-1
Parts Ordering Guide_______________________________ 5-2
PartsTableofContents______________________________ 5-3
Common Parts Section____________________________ 6-1
WARRANTY INFORMATION_____________________________ 7-1
Thissymbolmeans:
CAUTION – YOUR SAFETY IS AT RISK!
When you see this symbol, read and
followtheassociated instructionscarefully
orpersonal injuryor damagemay result.
Tigerisa registeredtrademark.

Twin Rtry Safety Section 1-1
SAFETY
SAFETY
SECTION

Twin rtry Safety Section 1-2
SAFETY
Indicates an imminently hazardous situation that, if not avoided, WILLresult in DEATH
OR VERYSERIOUS INJURY.
Indicates an imminently hazardous situation that, if not avoided, COULD result in
DEATH OR SERIOUS INJURY.
Indicates an imminently hazardous situation that, if not avoided, MAY result in MINOR
INJURY.
Identifies special instructions or procedures that, if not strictly observed, could result
in damage to, or destruction of the machine, attachments or the enviroment.
NOTE: Identifies points of particular interest for more efficient or convienient operation or
repair. (SG-1)
General Safety Instructions and Practices
A safe and careful operator is the best operator. Safety is of primary importance to the
manufacturerand shouldbe to the owner /operator. Most accidentscanbe avoidedby being
awareofyour equipment,your surroundings, andobserving certainprecautions. Thefirst
sectionof thismanual includesa listof SafetyMessages that, iffollowed, willhelp protectthe
operatorand bystandersfrom injuryordeath. Read andunderstand theseSafety Messages
beforeassembling, operatingor servicingthis mower. Thisequipment should only be
operatedby thosepersons whohave readthe Manual, whoare responsibleand trained,and
whoknow howto do sosafely andresponsibly.
TheSafetyAlertSymbol combinedwith a SignalWord,as seen below,is used
throughoutthismanual andon decals whichare attachedtothe equipment. The
SafetyAlertSymbolmeans: “ATTENTION! BECOMEALERT! YOUR SAFETYIS
INVOLVED!” The symboland signalword areintended towarn the owner/
operatorof impendinghazards andthe degreeof possibleinjury whenoperating
thisequipment.
Practice all usual and customary safe working precautions and
above all -- remember safety is up to YOU! Only YOU can
prevent serious injury or death from unsafe practices.
READ, UNDERSTAND, and FOLLOW the following Safety Messages.
Serious injury or death may occur unless care is taken to follow the
warnings and instructions stated in the Safety Messages. Always use
good common sense to avoid hazards. (SG-2)
IMPORTANT!

Twin Rtry Safety Section 1-3
SAFETY
DANGER! Never operate the Tractor or Implement until you have read and
completelyunderstandthisManual,theTractorOperator’s Manual,
andeachoftheSafetyMessagesfoundintheManualorontheTractor
andImplement. Learnhowtostopthetractorenginesuddenlyinan
emergency. Never allow inexperienced or untrained personnel to
operatetheTractorandImplementwithoutsupervision. Makesure
the operator has fully read and understands the manuals prior to
operation. (SG-4)
WARNING! Always maintain the safety decals in good readable condition. If the
decalsaremissing,damaged,orunreadable,obtainandinstallreplace-
ment decals immediately. (SG-5)
WARNING! Make certain that the “Slow Moving Vehicle” (SMV) sign is installed in
such a way as to be clearly visible and legible. When transporting the
EquipmentusetheTractorflashingwarninglightsandfollowalllocaltraffic
regulations.(SG-6)
WARNING! Operate this Equipment only with a Tractor equipped with an
approved roll-over-protective system (ROPS). Always wear seat
belts. Serious injury or even death could result from falling off the
tractor--particularly during a turnover when the operator could be
pinned under the ROPS. (SG-7)
WARNING! DonotmodifyoralterthisImplement. Donotpermitanyonetomodify
or alter this Implement, any of its components or any Implement
function. (SG-8)
DANGER! BEFOREleavingthetractorseat,alwaysengagethebrakeand/orset
thetractortransmissioninparkinggear,disengagethePTO,stopthe
engine,removethekey,andwaitforallmovingpartstostop. Placethe
tractorshiftleverintoalowrangeorparkinggeartopreventthetractor
fromrolling. NeverdismountaTractorthatismovingorwhiletheengine
is running. Operate the Tractor controls from the tractor seat only.
(SG-9)
!
Si no lee Ingles, pida ayuda a alguien que
si lo lea para que le traduzca las medidas
de seguridad. (SG-3)
PELIGRO! LEA EL
INSTRUCTIVO!

Twin rtry Safety Section 1-4
SAFETY
DANGER! NeverallowchildrenorotherpersonstorideontheTractororImplement.
Falling off can result in serious injury or death. (SG-10)
DANGER! Neverallowchildren to operateorride on theTractororImplement.
(SG-11)
WARNING! Donotmountthetractorwhilethetractorismoving. Mountthetractor
only when the tractor and all moving parts are completely stopped.
(SG-12)
DANGER! Start tractor only when properly seated in the tractor seat. Starting a
tractor in gear can result in injury or death. Read the tractor operators
manual for proper starting instructions. (SG-13)
DANGER! NeverworkundertheImplement,theframework,oranyliftedcompo-
nent unless the Implement is securely supported or blocked up to
preventsuddenorinadvertentfallingwhichcouldcauseseriousinjury
or even death. (SG-14)
DANGER! Do not operate this Equipment with hydraulic oil leaking. Oil is
expensiveanditspresencecouldpresentahazard. Donotcheckfor
leakswithyourhand! Useapieceofheavypaperorcardboard. High-
pressureoil streamsfrom breaksin theline couldpenetrate the skin
andcausetissuedamageincludinggangrene. Ifoildoespenetratethe
skin, have the injury treated immediately by a physician knowledge-
able and skilled in this procedure. (SG-15)

Twin Rtry Safety Section 1-5
SAFETY
WARNING! Transport only at safe speeds. Serious accidents and injuries
can result from operating this equipment at unsafe speeds.
Understand the Tractor and Implement and how it handles before
transporting on streets and highways. Make sure the Tractor
steering and brakes are in good condition and operate properly.
Before transporting the Tractor and Implement, determine
the safe transport speeds for you and the equipment. Make
sure you abide by the following rules:
Be aware of the operating conditions. Do not operate the Tractor
with weak or faulty brakes. When operating down a hill or on wet
or rain slick roads, the braking distance increases: use extreme
care and reduce your speed. When operating in traffic always use
the Tractor’s flashing warning lights and reduce your speed. Be
aware of traffic around you and watch out for the other guy. (SG-19)
Test the equipment at a slow speed in turns. Increase the speed
through the turn only after you determine that it is safe to operate
at a higher speed. Use extreme care and reduce your speed
when turning sharply to prevent the tractor and implement from
turning over. Determine the maximum safe turning speed for you
and this equipment before operating on roads or uneven ground.
Only transport the Tractor and Implement at the speeds that you
have determined are safe and which allow you to properly
control the equipment.
Test the tractor at a slow speed and increase the speed slowly.
Apply the brakes smoothly to determine the stopping characteristics
of the Tractor and Implement. As you increase the speed of the
Tractor the stopping distance increases. Determine the maximum
safe transport speed for you and this equipment.
2.
1.
3.
CAUTION! PROLONGEDEXPOSURETOLOUD NOISE MAY CAUSE PERMA-
NENT HEARING LOSS! Tractors with or without an Implement at-
tached can often be noisy enough to cause permanent hearing loss.
Werecommendthat you alwayswearhearing protection ifthenoise in
the operator’s position exceeds 80db. Noise over 85db over an ex-
tended period of time will cause severe hearing loss. Noise over 90db
adjacent to the operator over an extended period of time will cause
permanent or total hearing loss. Note: Hearing loss from loud noise
[fromtractors, chainsaws, radios,and othersuch sourcesclose to the
ear]iscumulativeoveralifetimewithout hope of natural recovery. (SG-I7)
WARNING! The operator and all support personnel should wear hard hats,
safety shoes, safety glasses, and proper hearing protection at all
timesforprotectionfrominjuryincludinginjuryfromitemsthrownby
theequipment. (SG-16)

Twin rtry Safety Section 1-6
SAFETY
WARNING! Never attempt to lubricate, adjust, or remove material from the
Implementwhileitisinmotionorwhiletractorengineisrunning. Make
sure the tractor engine is OFF before working on the Implement.
(SG-20)
WARNING! Periodically inspect all moving parts for wear and replace when
necessary with authorized service parts. Look for loose fasteners,
worn or broken parts, and leaky or loose fittings. Make sure all pins
areproperlysecured. Seriousinjurymayoccurfromnotmaintaining
this machine in good working order. (SG-21)
WARNING! Always read carefully and comply fully with the manufacturers instruc-
tions when handling oil, solvents, cleansers, and any other chemical
agent. (SG-22)
DANGER! Never run the tractor engine in a closed building or without adequate
ventilation. The exhaust fumes can be hazardous to your health.
(SG-23)
DANGER! KEEPAWAYFROMROTATING ELEMENTStoprevententanglement
andpossible seriousinjury ordeath. (SG-24)
DANGER! NeverallowchildrentoplayonoraroundTractororImplement. Children
can slip or fall off the Equipment and be injured or killed. Children can
causetheImplement toshiftorfallcrushingthemselvesorothers. (SG-25)

Twin Rtry Safety Section 1-7
SAFETY
DANGER! NEVER use drugs or alcohol immediately before or while operating the
Tractor and Implement. Drugs and alcohol will affect an operator’s
alertness and coordination and therefore affect the operator’s ability to
operate the equipment safely. Before operating the Tractor or Imple-
ment,an operatoron prescriptionor over-the-counter medication must
consult a medical professional regarding any side effects of the medi-
cation that would hinder their ability to operate the Equipment safely.
NEVER knowingly allow anyone to operate this equipment when their
alertness or coordination is impaired. Serious injury or death to the
operator or others could result if the operator is under the influence of
drugs or alcohol. (SG-27)
DANGER!
OperatetheTractorand/orImplementcontrolsonlywhileproperlyseated
in the Tractor seat with the seat belt securely fastened around you.
Inadvertent movement of the Tractor or Implement may cause serious
injury or death. (SG-29)
WARNING! Mow only in conditions where you have clear visibility in daylight or with
adequate artificial lighting. Never mow in darkness or foggy conditions
whereyoucannotclearlyseeatleast100yardsinfront and to the sides of
the tractor and mower. Make sure that you can clearly see and identify
passersby,steepslopes,ditches,drop-offs,overheadobstructions,power
lines,debrisand foreign objects. Ifyouareunable to clearly seethistype
ofitemsdiscontinuemowing. (SGM-1)
DANGER!
Thereareobviousandhiddenpotentialhazardsintheoperationofthis
Mower. REMEMBER! Thismachineisoftenoperatedinheavybrush
and in heavy weeds. The Blades of this Mower can throw objects if
shields are not properly installed and maintained. Serious injury or
evendeathmay occurunlesscareistakento insurethesafetyofthe
operator, bystanders, or passersby in the area. Do not operate this
machinewithanyonein the immediatearea. Stopmowingifanyone
is within 100 yards of mower. (SGM-2)
All Safety Shields, Guards and Safety devices including (but not limited
to)-theDeflectors,SteelGuards,GearboxShields,PTOintegralshields,
and Retractable Door Shields should be used and maintained in good
working condition. All safety devices should be inspected carefully at
leastdaily formissing or broken components. Missing, broken,or worn
itemsmustbereplacedatoncetoreducethepossibilityofinjuryordeath
from thrown objects, entanglement, or blade contact. (SGM-3)
DANGER!

Twin rtry Safety Section 1-8
SAFETY
WARNING! Extremecareshouldbetakenwhenoperatingnearlooseobjectssuch
as gravel, rocks, wire, and other debris. Inspect the area before
mowing. Foreignobjectsshouldberemovedfromthesitetoprevent
machinedamageand/orbodilyinjuryorevendeath. Anyobjectsthat
cannotberemovedmustbeclearlymarkedandcarefullyavoidedby
the operator. Stop mowing immediately if blades strike a foreign
object. Repair all damage and make certain rotor or blade carrier is
balancedbeforeresumingmowing.(SGM-5)
WARNING! Many varied objects, such as wire, cable, rope, or chains, can become
entangledintheoperatingpartsofthemowerhead. Theseitemscould
thenswingoutsidethehousingatgreatervelocitiesthantheblades. Such
a situation is extremely hazardous and could result in serious injury or
even death. Inspect the cutting area for such objects before mowing.
Remove any like object from the site. Never allow the cutting blades to
contact such items. (SGM-6)
WARNING! Mowatthespeedthatyoucansafelyoperateandcontrolthetractorand
mower. Safemowingspeeddependsonterrainconditionandgrasstype,
density,andheightofcut. Normalgroundspeedrangeisfrom0to5mph.
Use slow mowing speeds when operating on or near steep slopes,
ditches,drop-offs,overheadobstructions,powerlines,orwhendebrisand
foreign objects are to be avoided. (SGM-7)
WARNING! Avoid mowing in reverse direction when possible. Check to make sure
there are no persons behind the mower and use extreme care when
mowinginreverse. Mowonlyataslowgroundspeedwhereyoucansafely
operateandcontrolthetractorandmower. Nevermowanarea thatyou
havenotinspected and removeddebrisorforeign material. (SGM-8)
DANGER! Replacebentorbrokenbladewithnewblades. NEVERATTEMPTTO
STRAIGHTEN OR WELD ON BLADES SINCE THIS WILL LIKELY
CRACK OR OTHERWISE DAMAGE THE BLADE WITH SUBSE-
QUENTFAILUREANDPOSSIBLESERIOUSINJURYFROMTHROWN
BLADES. (SGM-10)
WARNING! Do not mow with two machines in the same area except with Cab tractors
with the windows closed. (SGM-11)
DANGER! Therotatingpartsofthismachinehavebeendesignedandtestedfor
ruggeduse. However,thebladescouldfailuponimpactwithheavy,
solidobjectssuchasmetalguardrailsandconcretestructures. Such
impactcould cause thebroken objects tobe thrown outwardat very
highvelocities. Toreducethepossibilityofpropertydamage,serious
injury,or evendeath, neverallow the cutting blades tocontact such
obstacles. (SGM-4)
WARNING! Donot puthandsor feetunder mower decks. BladeContact can result
seriousinjuryorevendeath. Stayawayuntilallmotionhas stoppedand
the decks are securely blocked up. (SGM-9)

Twin Rtry Safety Section 1-9
SAFETY
DANGER! RotaryMowersarecapableunderadverseconditionsofthrowing
objectsfor greatdistances (100yards ormore) and causing serious
injury or death. Follow safety messages carefully.
STOPMOWINGIFPASSERSBY ARE WITHIN 100 YARDS UN-
LESS: -FrontandRearDeflectorsare installed and ingood,
working condition;
-MowerHeadis running closetoandparallel to theground
without exposed Blades;
-Passersbyare outsidethe existing thrown-objectzone;
-Allareashave beenthoroughlyinspectedandallforeign
material such as rocks, cans, glass, and general debris
has been removed.
NOTE: Where there are grass and weeds high enough to hide debris
that could be struck by the blades, the area should be: in-
spected and large debris removed, mowed at an intermediate
height, inspected closely with any remaining debris being re-
moved,andmowedagainatdesired final height. (SFM-6)
WARNING! EachRearWheelmusthaveaminimumof1,000poundscontactwith
the surface to prevent lateral instability and possible tip-over which
couldresultinseriousbodilyinjuryorevendeath. Widenthewheel
treadandaddweightsifneeded. Refertothemountinginstructions
orcallCustomerServiceifyouneedassistancewithCounterweight
Procedure. (SFL-3)
WARNING!
DonotoperateMowerifexcessivevibrationexists. ShutdownPTO
andtheTractorengine. InspecttheMowertodeterminethesource
of the vibration. If Mower blades are missing or damaged replace
themimmediately. Donotoperatethemoweruntilthebladeshave
been replaced and the Mower operates smoothly. Operating the
Mower with excessive vibration can result in component failure and
brokenobjectstobethrownoutwardatveryhighvelocities. Toreduce
thepossibilityofpropertydamage,seriousinjury,orevendeath,never
allow the Mower to be operated with blades missing. (SFL-4)
WARNING! Do not let the Blades turn when the Mower Deck is raised for any
reason, including clearance or for turning. Raising the Mower
deck exposes the Cutting Blades which creates a potentially
serious hazard and could cause serious injury or even death from
objects thrown from the Blades. (SRM-7)
WARNING! NeverleaveTractorandImplementunattendedwhiletheimplementisin
theliftedposition. Accidentaloperationofliftingleverorahydraulicfailure
may cause sudden drop of unit with injury or death by crushing. To
properly parktheimplementwhendisconnectingitfromthetractor,lower
the stand and put the retaining pin securely in place, or put a secure
supportundertheA-Frame. Lowertheimplementcarefullytotheground.
Do not put hands or feet under lifted components. (SPT-1)

Twin rtry Safety Section 1-10
SAFETY
WARNING! The rotating parts of this machine continue to rotate even after the Tractor has been
turned off. The operator should remain in his seat for 60 seconds after the brake
has been set, the PTO disengaged, the tractor turned off, and all evidence of
rotation has ceased. (SBM-5)
“Wait a minute...Save a life!”
WARNING!
Be particularly careful when transporting the Implement with the Tractor. Turn
curves or go up hills only at a low speed and using a gradual steering angle. Rear
mounted implements move the center of gravity to the rear and remove weight from
the front wheels. Make certain, by adding front ballast, that at least 20% of the
tractor’s weight is on the front wheels to prevent rearing up, loss of steering control
or Tractor tip-over. Slow down on rough or uneven surfaces to prevent loss of
steering control which could result in property damage or possible injury. Do not
transport unless 3-Point lift lever is fully raised and in the latched transport position.
Dropping implement in transport can cause serious damage to the tractor and/or
Implement and possibly cause the operator or others to be injured or killed. (S3PT-2)
DANGER! Thereareobviousandhiddenpotentialhazardsintheoperationofthis
Implementasinallpower-drivenorpulledequipment. REMEMBER!
Thismachineisoftenoperatedinroughterrainconditionsthatincludetall
grass, weeds, gullies, holes, slopes, hidden obstructions and the like.
Seriousinjuryorevendeathmayoccurunlesscareistakentoassurethe
safetyof the operatorandbystanders inthearea. Do not operate this
machine with anyone in the immediate area. (S3PT-7)
WARNING! Relieve hydraulic pressure prior to doing any maintenance or repair work
on the Implement. Place the Implement on the ground or securely
blocked up, disengage the PTO, and turn off the tractor engine. Push
and pull the Remote Cylinder lever in and out several times prior to
starting any maintenance or repair work. (S3PT-9)
DANGER! ThisImplementiswiderthantheTractor. Becarefulwhenoperating
ortransportingthisequipmenttopreventtheImplementfromrunning
into or striking sign posts, guard rails, concrete abutments or other
solidobjects. SuchanimpactcouldcausetheImplementandTractor
topivotviolentlyresultinginlossofsteeringcontrol,seriousinjury,or
evendeath. NeverallowtheImplementtocontactobstacles. (S3PT-12)
DANGER! Theflail cutter shaftisdesigned for standardrotation(same
rotation as the tractor wheels during forward travel). Never operate the
cutter shaft in the reverse rotation. Operatingthis mower in reverse
rotation may cause objects to be thrown out the front of the mower
head.

Twin Rtry Safety Section 1-11
SAFETY
WARNING!
In addition to the design and configuration of this Implement, including Safety Signs and Safety
Equipment, hazard control and accident prevention are dependent upon the awareness,
concern, prudence, and proper training of personnel involved in the operation, transport,
maintenance, and storage of the machine. Refer also to Safety Messages and operation
instruction in each of the appropriate sections of the Tractor and Equipment Manuals. Pay
close attention to the Safety Signs affixed to the Tractor and Equipment. (SG-18)
Tiger mowers use balanced and matched system components for blade carriers, blades, cutter-
shafts, knives, knife hangers, rollers, drive-train components and bearings. These parts are made and
tested to Tiger specifications. Non-genuine “will fit” parts do not consistently meet these specifications.
The use of “will fit” parts may reduce mower performance, void mower warranties and present a safety
hazard. Use genuine Tiger mower parts for economy and safety.
SEE YOUR DEALER
Engine Exhaust, some of its constituents, and certain components contain or
emitchemicalsknowntothestateofCaliforniatocausecancerandbirthorother
reproductiveharm.
WARNING! Battery posts, terminals and related accessories contain lead and lead
compounds, chemicals known to the state of California to cause cancer and
birth or other reproductive harm. Wash hands after handling!

Twin rtry Safety Section 1-12
SAFETY
22840
INSIDE OF CAB
22839
MOWER DECK
24028
MOWER DECK
10” x 5.5” 31522
MOWER DECK
18.25” x10” 31523
HYDRAULICTANK
PARTNO.
LOCATION

Twin Rtry Safety Section 1-13
SAFETY
33743
INSIDE OF CAB
42350
MOWER DECK
42399
MOWER DECK
42400
MOWER DECK
PARTNO.
LOCATION

Twin rtry Safety Section 1-14
SAFETY
6T3219
INSIDE OF CAB
6T3217
MOWER DECK
6T3220
FRONTPUMPMOUNT
6T3221
INSIDE OF CAB
PARTNO.
LOCATION
