Dikai IT Series Installation and operating instructions

WUHAN DIKAI OPTOETECTRONIC TECHNOLOGY. Co., LTD
Wuhan Dikai optoelectronics technology Co., ltd Post code: 430073
Address: No 709, street of Xiongchu, Wuhan Fax: [phone]
Tel: [phone] 87509105 http://www.dkoe.com
IT Series Infrared thermometer
Using manual
Wuhan Dikai Optic-electronic Technology Co., ltd

WUHAN DIKAI OPTOETECTRONIC TECHNOLOGY. Co., LTD
Wuhan Dikai optoelectronics technology Co., ltd Post code: 430073
Address: No 709, street of Xiongchu, Wuhan Fax: [phone]
Tel: [phone] 87509105 http://www.dkoe.com
Before using the thermometer, please read the manual carefully, for the
purpose of better exert its function and prolong service life. Please keep the
manual carefully for consult later.
If appear these problems：
Appearing the abnormality, please turn off the power, and contact us in time.
That take apart yourself will not have after service and won’t have servicing for
free
If this manual altered, forgive us won’t inform you

WUHAN DIKAI OPTOETECTRONIC TECHNOLOGY. Co., LTD
Wuhan Dikai optoelectronics technology Co., ltd Post code: 430073
Address: No 709, street of Xiongchu, Wuhan Fax: [phone]
Tel: [phone] 87509105 http://www.dkoe.com
Catalogue
1 Summary
2 Technology parameter
3 Figure structure
4 Model naming and selection
5 Usages
6 Maintenance and molar assurance
7 Notice
8 Selection of infrared thermometer
Attach: the emissivity list of familiar materials on temperature measuring

WUHAN DIKAI OPTOETECTRONIC TECHNOLOGY. Co., LTD
Wuhan Dikai optoelectronics technology Co., ltd Post code: 430073
Address: No 709, street of Xiongchu, Wuhan Fax: [phone]
Tel: [phone] 87509105 http://www.dkoe.com
1 Summary
IT series infrared thermometer has the same optical axis on the measurement and
collimation. For satisfying the different requirements of customers, the meter can be
segmented between 300 and 3000 discretionally. Because of using SMT on the part of℃℃
circuit transformation and MCU on the part of data processing, the accuracy and
Repeatability can be guarantee better. Especially, the meter is suit to locomotors objects,
electriferous conductors’ vacuum environment or other objects that have special request to
be non-contact measured. The measure is without influence to the temperature field.
The product can be applied to foundry, powder metallurgy, steel rolling, power supply,
chemical industry, glass, ceramic production, heat treatment, intermediate/high frequency
induction heating, wire production, sinter, hot-pressing sinter, jointing industry and so on.
2 Technology parameter
Measuring range 300℃～3000℃（subsection）
Measuring accuracy ±0.5%，±0.2%(Reading)
Measuring distance 0.2m～5m
Mini object φ2mm（298mm）,φ0.5mm
（80mm）
Distance coefficient 145:1,160:1
Repeatability ±0.2
Response time <10 ms
Resolution 0.5℃
Sighting system Laser sighting
Sensing head size φ50×100mm
1.0,0.9,0.8,0.7 (IT-6)
Emissivity 0.10～1.00 (IT-8)
Output 0～5V,4～20mA
Power ±12VDC
Weight 0.5kg
Working environment 0℃～60℃,Humidity<90%
Installation 1/4 inch bolt
Communication RS485(IT-8)

WUHAN DIKAI OPTOETECTRONIC TECHNOLOGY. Co., LTD
3 Figure structure
IT－6
unit：mm
IT-6 Back cover ：
IT－8
unit：mm
Wuhan Dikai optoelectronics technology Co., ltd Post code: 430073
Address: No 709, street of Xiongchu, Wuhan Fax: [phone]
Tel: [phone] 87509105 http://www.dkoe.com

WUHAN DIKAI OPTOETECTRONIC TECHNOLOGY. Co., LTD
IT-8 Back cover：
Key-press definition:
“SET” key: using for parameter setting, on the state of waiting or working, press the key
for 5 sec, enter the state of parameter setting , on the course of parameter setting, press the
key for 5 sec, back to the state of temperature displaying. Without any action for 15 min, the
display will shut down automatically. On the state of blank screen, pressing the key can
activate the temperature display.
“”key：On the state of parameter, using the key for moving radix point, meanwhile, the
position of radix point effect.
“”key：Using for program the position of selected.
Wuhan Dikai optoelectronics technology Co., ltd Post code: 430073
Address: No 709, street of Xiongchu, Wuhan Fax: [phone]
Tel: [phone] 87509105 http://www.dkoe.com
Parameter setting manual table
Parameter Meaning Range Default
E1 Emissivity 1
0.01～1.00 1.00
E2 Emissivity 2
0.01～1.00(ITW only) 1.00
AHd Peak value
keeping time
0～120 sec 0
dEFd Difference value
keeping time
0～120 sec 0
CoEF Filter coefficient
0～20 0
Ad Interface address 1～100 1
rAd Measuring mode 0:Continious measuring;1:Peak
measuring ;2:Difference measuring
0
4 Model naming and selection
（1）Model naming
IT– ＸＸＸＸ
English Letter output sorts V：0～5V；I：4～20mA
Number Temperature range 1: 400℃～1200℃
Number Accuracy level 1：0.5 level
Number Series code 6: no laser collimation;
8: laser collimation
English abbreviate（Infrared-Thermometer）

WUHAN DIKAI OPTOETECTRONIC TECHNOLOGY. Co., LTD
Wuhan Dikai optoelectronics technology Co., ltd Post code: 430073
Address: No 709, street of Xiongchu, Wuhan Fax: [phone]
Tel: [phone] 87509105 http://www.dkoe.com
express：lentoid infrared thermometer
Example：IT–612V means：no laser collimation 0.5 level 800℃~2500℃output 0~5V
lentoid infrared thermometer
（2）Selective list
Model Manual Remark
IT- Infrared English abbreviate
6 Ordinary
Sort 8 Enhanced Emissivity can be adjusted
peak value can be kept
0 1 level(FS%1) Tiptop 0.2 level(FS% 0.2)
Precision 1 0.5 level (FS% 0.5)
0 300～800
1 400～1200
2 500～1400
3 600～1400
4 800～1800
5 800～2500
Range（℃）
6 1000～3000
Can be disjoined at will
between 300～3000℃
V 0～5VDC
Output I 4～20mA
Communication
interface c RS485/RS232
5 Usages
（1）Installation：fixing by the 1/4 inch bolt
（2）Derivative wire defined:
Derivative wire
defined
Link
spinouts
Derivative
wire color Simulate
output RS485
1 Red +12V +12V
2 Blue -12V -12V
3 Black Terra terra
4 Yellow Output A
5 Green B
Shielded wire link to the shell of the meter, or can be linked to the earth of the
equipment. When it is unable to link, can be linked to the terra of power。

WUHAN DIKAI OPTOETECTRONIC TECHNOLOGY. Co., LTD
Wuhan Dikai optoelectronics technology Co., ltd Post code: 430073
Address: No 709, street of Xiongchu, Wuhan Fax: [phone]
Tel: [phone] 87509105 http://www.dkoe.com
（3）Output selection
Simulate signal output：0~5VDC、4~20mA
RS485（IT－8）
Serial interface’s usage：
The sending mode of serial interface is simplex system, speed: 9600 baud
When process controlling or long distance communicating ，RS485 serial interface It
need the RS485 RS232 conversion machine w◇hen need to communicate to
calculator
6 Maintenance and quality guarantee
（1）In the normal conditions, the thermometer need not special maintenance, keep off
dampness please. And clean the lens surface of the thermometer regularly
（using lens paper or soft cloth, wipe carefully and do not hurt the lens）;
（2） When the thermometer is not used, cut off the power and cover the lens saving
in the dry and clean circumstances。
（3） The malfunction causing by quality problem of products，free repair within 12
month after leave the factory。Repair lifetime。
7 Notices
（1）When setup the thermometer，the light axis must be vertical to the object,
otherwise will causing measuring error。
（2） The effective distance of laser aim is no more than0.3m。
（3） The thermometer has good response speed and good sensitivity, when the heat
source（object）is instable，it’s normal that the display meter of thermometer will
move up and down follow;
（4）The thermometer needs fixed, avoiding vibration。
8 Selection of infrared thermometer
Confirming the range of measuring: The range of measuring is one of the
thermometer’s most important capability quota, every type of thermometer has each
special range of temperature measuring. Narrower the thermometer’s range is, the monitor
temperature output signal resolution is higher, and the reliability is resolved easily. That the
range is too wide will lower the accuracy of temperature measuring.
Size of object: According to the principle of infrared thermometer, it’s divided into
homochrome infrared thermometer and bicolor infrared thermometer When using
homochrome infrared thermometer, it’s better that the area of object exceed the sight-field
by 50%。And to the small and moving or vibrant object, bicolor infrared thermometer is the
best choice.

WUHAN DIKAI OPTOETECTRONIC TECHNOLOGY. Co., LTD
Wuhan Dikai optoelectronics technology Co., ltd Post code: 430073
Address: No 709, street of Xiongchu, Wuhan Fax: [phone]
Tel: [phone] 87509105 http://www.dkoe.com
Distance coefficient(optical resolution)：distance coefficient is the ratio of “D” (the
distance between head and the object) and the diameter of the object. If the distance to the
object is far, and the object is small, you should choose the high distance coefficient
thermometer, on the other hand, you should choose low distance coefficient thermometer.
Confirming response time:：Response time express the response speed that the
infrared thermometer responses to the temperature being measured, defined as the time
needed that arrive 95% of the last reading power It has relations with photo-electric
detector, signal process circuit and the time constant of display system If the speed of
moving object is very quick and measuring the object that heated quickly, you should
choose the high-speed response infrared thermometer, otherwise, it won’t achieve the
enough signal response speed and will lower the measuring accuracy. But not all of
applications need quick response infrared thermometer. To the quiescent object or the
object that on the course of heat has heat inertia, the response time can be loosen.
Therefore, the infrared thermometer’s selection must be adapted to the state of the
object.
Confirming circumstance：The circumstance of the thermometer will affect the
measuring result a lot., so the problem should be considered and be solved properly,
otherwise, this will affect the accuracy of thermometer even damage the thermometer。
On the conditions of high temperature, existing dust, smoke and steam, you should
choose the accessories supplied by factory such as protect cover, water-cool, air-cool,
air-cool system, air-blow etc These accessories can solve circumstance influence
effectively and protect the thermometer, realizing temperature measuring exactly. When
choosing accessory, you should request standard service as far as possible to reduce the
cost of setup. It would be the best to choose bicolor infrared thermometer on the
conditions of smoke, dust or other situation that grain will lower the power of measuring
signal. Also, on the conditions of noisy, electromagnetic field, shaking or the circumstance
that difficult to be closed or other bad conditions, bicolor infrared thermometer is the best.
On the conditions of bad and complex, choosing the system that the thermometer head
and the monitor is divided is convenience to setup and equip. You should choose the
signal modality that matching the control equipment actual
Emissivity of material(emissivity)：When there are many kinds of material measured
and their emissivity is different, it’s better to choose the infrared thermometer that the
emissivity is adjustable.

WUHAN DIKAI OPTOETECTRONIC TECHNOLOGY. Co., LTD
Wuhan Dikai optoelectronics technology Co., ltd Post code: 430073
Address: No 709, street of Xiongchu, Wuhan Fax: [phone]
Tel: [phone] 87509105 http://www.dkoe.com
Attach: the emissivity list of familiar materials on temperature measuring
Material Emissivity Material Emissivity
polished 0.04～
0.06 Asbestos 0.95
Anode
oxidized 0.55 Asphaltum 0.95
Aluminum
Oxidized 0.11～
0.25 Paper 0.70～
0.90
Polished 0.02～
0.05 Concrete 0.92
Unoxidized 0.20 Water、
icewater 0.95
Brass
Oxidized 0.6～0.88 Gypsum 0.80～
0.90
Polished
board 0.10 Skin 0.98
Steel
Slab 0.40～
0.60 Carbon 0.95
Tungsten 0.05 Paint
0.80～
0.98
Electroplate
polished 0.05 Soil
0.90～
0.98
Electroplate
unpolished 0.11 Rubber 0.95
Nickel
Oxidized 0.30～
0.50 Ceramic 0.93
Polished 0.05～
0.07 Wood 0.93
Roughened 0.40 Ice 0.98
plumbum
Oxidized 0.30～
0.60 Fiberboard 0.95
Unoxidized 0.05 Lampblack 0.96
Metal
Zinc Galvanized
iron plate 0.25
Non-
metal
Sand 0.90
