DikaSun DSG-A33B User manual

DikaSun DSG-A33B Assembly Instructions
1: Step 1-Build An Upper Frame
Parts Required List:
Part Code
Quantity
A
4
B
4
C
4
H
8
Assembly formula: B+A+C
TIPS: Assemble B+A+C, fix with H, build 4 groups of B+A+C on the four corners

TIPS: Connect B and C of each group

2: Step 2- Build Main Frame Roof
Parts Required List:
Part Code
Quantity
G
1
M
1
F
4
F1
4
Please note that G has four long sides and four short sides. We need to connect the short sides in
this part, otherwise the next part will not be able to continue.
Tips:
Screw M to G,
Insert F into the 4 short sides of G

Tips:
Connect F and F1,
Insert F1 into the jack between BC
3: Step 3-Build 4 Corner Frames
Parts Required List:
Part Code
Quantity
D
4
E
4
E1
4
Assembly formula: D+E+E1
TIPS:
Assemble D+E+E1,
Insert D to G,
Insert E1 to the four corners

4: Step 4-Connect the upper and lower columns
5：Step 5-Put on curtains and mosquito nets
Parts Required List:
Part Code
Quantity
J
1
J1
1
K
4
L
32
I
8

TIPS:
Put on J1 first,
Put on J, E1 can be shortened as much as possible through its own jumping beads, and then
pulled out after the tent is successfully set
Hang L on the beam of BC,
Hang up the curtains K
Insert I into the hole at the bottom of A1,fix the gazebo to the grass
