Dimension One Spas Arena User manual

Page 1 of 2
Note: 1. Subject to change without notice.
Specification, 2006, Arena
Doc-1516 Rev -A Rev Date: 10/31/05
2006 Arena Specifications Dimension One Spas
Sha
p
e Round
Seatin
g
Ca
p
acit
y
7+
Shell Material Ultralife™ / Granitex™
Dimensions 87" Diameter x 36" H /
(
221cm Diameter x 91cm H
)
Corner Radii n/a
Water Ca
p
acit
y
340 Gallons
(
1287 Liters
)
Dr
y
Wei
g
ht 560 lbs
(
254 k
g)
Shi
pp
in
g
Wei
g
ht Domestic 560 lbs
(
254 k
g)
- Ex
p
ort 610 lbs
(
277 k
g)
Full Wei
g
ht 3395 lbs
(
1540 k
g)
Skirt Material Wood
Pol
y
Floor Yes
Water Treatment S
y
stem Cr
y
stal Zone™
Plumbin
g
S
y
stems 2
Filters/Covera
g
e 1 / 75 s
q
. ft.
Gate Valves 2
VCR Jet® - Air Ad
j
ustable/Directional 2
VCR Jet® - Rotator 6
VCR Jet® - Dual Rotator 0
VCR Jet® - Multi Port S
p
inner 0
VCR Jet® - Mini Rotator 2
VCR Jet® - Mini Directional 2
VCR Jet® - Euro Directional 0
VCR Jet® - Euro Rotator 0
VCR Jet® - Mini Directional in NFJ 0
T
yp
hoon Jet 2
Ozone Jet 1
Heater Return Jet 1
Pum
p
Returns 2
Diverter Valves 1
Floor Drains 1
Skimmer 8” Weir
D
y
namic Massa
g
e Se
q
uencer w/ control
p
anel No
NeckFlex® Jet Pillows 0
Headrest Pillows 0
Stereo s
y
stem not available
Water Feature n/a
Water Feature Volume control n/a
Cu
p
Holders 0
Tactile Thera
py
Floor
p
edastal
Pump Information Domestic
(
60Hz
)
Export
(
50Hz
)
Motor Size – Peak
(
Continuous
)
HP 4.0
(
2.5
)
H
p
3.6
(
2.0
)
HP
Jet Pum
p
s # of Pum
p
s/S
p
eed One / Dual One / sin
g
le
Circulation
p
um
p
11
Fountain
p
um
p
n/a n/a
Electrical S
y
stem Domestic
(
60Hz
)
Export
(
50Hz
)
Volta
g
e 240 240
Am
p
era
g
e 40/30 1X16 / 2X16 / 1X32
Heater FastFlo 2.7
,
4.0
,
5.5 kW FastFlo 2.9 kW
Thermostat Electronic Electronic
Li
g
ht 1 with o
p
tional LED Multi color LED
Control S
y
stem MSPA-MP-D12 MSPA-MP-D11-CE
U
pp
er Control Scrollin
g
Messa
g
e Center Scrollin
g
Messa
g
e Center
Auxiliar
y
U
pp
er Control No No
Pro
g
rammable Yes Yes
General
Water System
Special Features

Note: 1. Subject to change without notice.
Specification, 2006, Arena
Doc-1516 Rev -A Rev Date: 10/31/05
2006 Arena Specifications Dimension One Spas
2006 Arena
THIS 3 FOOT SQUARE AREA
IS TO BE SUPPORTED
CONSISTENT WITH THE
EDGES OF THE SPA BASE.
Top View of Spa
87 in [221 cm]
Shell
See Caution
86 3/8 in [219 cm]
Skirt
34 5/8 in [88 cm]
Hose Bib/
Water Drain
43 1/8 in [110 cm]
Recommended location for
Electrical
Inlet
78 in [198.12 cm]
Vent Typ 2 PL
Control Panel
36 in [91 cm]
33 1/4 in [84.46 cm]
32 5/8 in [82.87 cm]
87 in [221 cm]
86 3/8 in [219.39 cm]
37 1/4 in [94.61 cm]
Door Extends
Under Spa Lip
Spa Lip
Pedestal Base
3 1/2 in [9 cm]
Control Panel Front Side of Spa
Equipment
Compartment
2. Engineering specs may differ slightly from brochure.
3. For E-Z lifter installation allow 18” clearances on the backside of the spa.
4. Alternative cabinets may add significant weight. Ask your dealer for exact details
5. This is the approximate location for drilling a hole if you must bring the power line in through the bottom of the spa.
Be careful not to puncture a plumbing line inside the equipment compartment(drill from the inside compartment out).
Page 2 of 2
Architectural Specification
Caution:
Due to manufacturing tolerances there could be some
minor differences between the actual spa and the drawing above.
If site planning is critical to such tolerances, be sure to measure your actual spa.
See Note 5
