Specification, 2005, Diplomat
Doc-1212 Rev -B Rev Date: 1/31/04
2005 Diplomat Specifications Dimension One Spas
General Domestic (60Hz) Part # Export (50Hz) Part #
Shape Square Square
Ultralife™ / Granitex™ Ultralife™ / Granitex™
/ Geloy® / Geloy®
Height 35 ½ in. 90 cm
Width 91 ½ in. 232 cm
Length 91 ½ in. 232 cm
Corner Radii 16 in. 41 cm
Seating Capacity 5 5
Water Capacity 325 Gallons 1230 Liters
Dry Weight 900 lbs 408 kg
Shipping Weight 900 lbs 431 kg
Full Weight 3610 lbs 1638 kg
Skirt Material W ood or Synthetic W ood or Synthetic
Poly Floor Yes Yes
Water System
Motor Size – Peak (Continuous) HP 4.0 (2.5) HP 3.6 (2.0) HP
# Pumps/Speed Two / Dual 01562-23A/B Two / single 01562-29A/B
Plumbing Systems 4 4
Pump Returns 4 01510-559 4 01510-559G
Typhoon Jets 1 01510-436 1 01510-436G
VCR Jet®- Air Adjustable/Directional 8 01510-418 8 01510-418G
VCR Jet®- Rotator 12 01510-415 12 01510-415G
VCR Jet®- Mini Rotator 4 01510-445 4 01510-445G
VCR Jet®- Mini Directional 10 01510-444 10 01510-444G
VCR Jet®- Mini Directional in NFJ 8 01510-595 8 01510-595G
VCR Jet®- Euro Directional 0 0
Ozone Jet 1 01510-201 1 01510-201G
Heater Return Jet 1 01510-275 1 01510-275G
Filters/Coverage 2 / 75 sq. ft. (2) 01561-00 2 / 6.97 sq. meters (2) 01561-00
Water Treatment System Ultra Pure™ Ultra Pure™
Gate Valves 4 01522-30 4 01522-30
Diverter Valves 2 01522-50 2 01522-50G
Floor Drains 1 01510-231 1 01510-231G
Skimmer 8” Weir 01510-137 20 cm W eir 01510-137G
Electrical System
Voltage 240 240
Amperage 50/40/30 1X16 / 2X16 / 1X32
Heater FastFlo 2.7,4.0,5.5 kW 01781-20 FastFlo 2.9 kW 01781-20
Thermostat Electronic Electronic
Light 1 with optional LED 01512-003 (O) 1 with optional LED 01512-003 (O)
Control System MSPA-MP-D12 01710-1008 MSPA-MP-D11-CE 01710-1008E
Upper Control Scrolling Message Center 01580-0001 Scrolling Message Center 01580-0001
Auxiliary Upper Control Yes Yes
Programmable Yes Yes
Special Features
Dynamic Massage Sequencer
w/ control panel
NeckFlex®Jet Pillows 2 01510-598 2 01510-598
Headrest Pillows 1 01510-593 1 01510-593
Cup Holders 2 2
Tactile Therapy Foot & hand Foot & hand
Shell Material
No No

2005 Diplomat
Specification, 2005, Diplomat
Doc-1212 Rev - B Rev Date: 1/31/05
2005 Diplomat Specifications Dimension One Spas
Note: 1. Subject to change without notice.
Top View of Spa
THE EDGES OF SPA BASE.
SUPPORTED CONSISTENT WITH
ON BOTTOM OF SPA, TO BE
THIS 3 FOOT SQUARE AREA,
91 1/2 in [232 cm]
Shell
See Caution
91 in [231 cm]
Skirt
89 in [225 cm]
Pedestal
Base
16 in [41 cm]
16 in [41 cm]
23 1/2 in [60 cm]
34 1/2 in [88 cm]
56 1/2 in [143 cm]
67 1/2 in [171 cm]
27 in [67 cm]
Recommended location
Electrical
Inlet
11 in [28 cm]
Hose Bib/
Water Drain
Vent
Equipment Compartment
Vent Vent
See Note 5
Control
32 in [81 cm]
16 in [41 cm]
75 in [191 cm]
Spa Lip
Pedestal Base
Front View of Spa
91 in [231 cm]
Hose Bib/
Water
Drain
Door Extends
Under Spa Lip
91 1/2 in [232 cm]
89 in [225 cm]
SIS Compartment
19 in [48 cm] 18 1/2 in [47 cm]
12 in [31 cm]
35 1/2 in [90 cm]
R16 in [R41 cm]Shell
R16 in [R40 cm]
3 1/2 in [9 cm]
2. Engineering specs may differ slightly from brochure.
3. For E-Z lifter installation allow 18” (45.7cm) clearances on the backside of the spa.
4. Alternative cabinets may add significant weight. Ask your dealer for exact details
5. This is the approximate location for drilling a hole if you must bring the power line in through the bottom of the spa.
Be careful not to puncture a plumbing line inside the equipment compartment(drill from the inside compartment out).
Caution:
Due to manufacturing tolerances there could be some
minor differences between the actual spa and the drawing above.
If site planning is critical to such tolerances, be sure to measure your actual spa.
Architectural Specification
Page 2 of 2
