Doc-538 Rev-C Specification, 2003, Aurora HP
2003 Aurora HP Specifications Dimension One Spas
Note: Subject to change without notice
Domestic ( 60Hz) Part # Export (50Hz) Part #
Shape Square Square
Shell Material Ultralif e/Granitex Ultralif e/Granitex
Length 83 1/4 in 211 cm
Width 83 1/4 in 211 cm
Height 35 1/2 in 90 cm
Corner Radii 16 in 41 cm
Water Capaicity 300 Gallons 1136 Liters
Seating Capacity 5+ 5+
Dry Weight 610 lbs 277 kg
Full Weight 3100 lbs 1406 kg
Pump Brand HydraMax by Sta-Rite Aqua-flo
Pump Motor Size 3.0 Hp 2.0 Hp
Pumps/Speed Two/Dual 01562-22A/B Two/Single 01562-29A/B
Light 01512-003 (O) 01512-003 (O)
Control System MSPA-MP-D12 01710-1008 MSPA-MP-D11-CE 01710-1008E
Upper Control Programmable Digital 01560-320 Programmable Digital 01560-320
Auxiliary Upper Control No No
Programmable Yes Yes
Heater FastFlo 2.7, 4.0, 5.5 kW 01781-20 FastFlo 2.9 Kw 01781-20
Voltage 240 240
Amperage 50/40/30 16/2X16/32
Thermostat Electronic Electronic
Skirt Wood or Synthetic Wood / Synthetic
Poly Floor Yes Yes
Gate Valves 401522-30 401522-30
Selector Valve 00
Plumb Systems 22
Drains 4+Floor (4) 01510-559
(1) 01510-231
4+Floor (4) 01510-559
(1) 01510-231
Skimmer 8" Weir 01510-137 8" Weir 01510-137
VCR Jet-Air Adjustable 201510-418 201510-418
VCR Jet - Rotator 601510-415 601510-415
Mini Directional in NFJ 00
VCR Mini Directional 11 01510-444 11 01510-444
VCR Mini Rotator 201510-445 201510-445
Non-Adjustable Euro Jet 201510-438 201510-438
Ozone 101510-201 101510-201
Typhoon Jet 101510-436 101510-436
Total Jets 25 25
Filter 1 X 75 01561-00 1 x 75 01561-00
Water Treatment System 03200-06 03200-06E
Pillows 301510-420 301510-420
NeckFlex Jet 00
Dynamic Massage Sequencer No No
Crystal Zone W ater
Management System
Crystal Zone W ater
Management System
1 with optional Dynam ic
Lighting
1 with optional Dynam ic
Lighting
Rev Date: 3/03/03

Top View of Spa
THE EDGES OF SPA BASE.
SUPPORTED CONSISTENT WITH
ON BOTTOM OF SPA, TO BE
THIS 3 FOOT SQUARE AREA,
Note:
1. Subject to change without notice.
2. Engineering specs may differ slightly from brochure.
3. For E-Z Lifter installation allow 18" clearance on the backside of the spa.
4. Alternative cabinets may add significant weight. Ask your dealer f or exact detail s.
5. This is the approximate location for drilling a hole if you must bring the power
line in throu gh the b ottom of the spa. Be caref ul not to puncture
a plumbing li ne insi de the eq uipm ent compar tment (drill from the i nside C ompart ment ou t)
Caution:
Due to manufacturing tolerances there could be some minor differences between the actual spa and the
drawi ng abov e. If sit e planni ng is cri tical t o such tol eranc es, be su re to m easure y our act ual spa.
2003 Aurora HP, Architectural Specification
Dimension One Spas
2003 Aurora HP Specifications
Page 2 of 5
Specification, 2003, Aurora HP
Doc-538 Rev-C Rev Date: 3/03/03
