CADET™ 5' x 36"
WHIRLPOOL AND BATHING POOL
HIGH GLOSS
Revised 2/08
CADET™ 5' X 36" WHIRLPOOL AND
BATHING POOL
❏ 2771.018W Whirlpool featuring System I
• Acrylic with berglass reinforcement
• Pre-leveled tub bottom
• Form-tted backrest position
• Dual, molded in arm rests
• 1.6 HP single speed, self-draining pump/motor
• Factory installed power cord with plug
• Eight multi-directional and ow-adjustable
jets including:
- Two Ideal-ow jets
- Four body massage jets
- Two recessed back-rest jets
• Deck-mounted air switch On/Off
• Two silent air volume controls
• Quick Connect Safe-T-Heater
connection system
• Factory installed and tested whirlpool system
❏ 2771.018WC EverClean® Whirlpool
Featuring System I:
• Same as 2771.018W except with the
EverClean System
❏ 2771.002 Bathing Pool only
Nominal Dimensions:
1524 x 914 x 502mm
(60" x 36" x 19-3/4")
Compliance Certications -
Meets or Exceeds the Following Specications:
• Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
American Standard whirlpools and air baths with
EverClean® incorporate a patented silver-ion
additive right into the circulation piping to protect
the pipes from mold, mildew, algae and fungus that
could cause deterioration or staining of the pipes.
SEE REVERSE FOR PRODUCT DIMENSIONS
AND SPECIFICATIONS
To Be Specied - Required:
❏ Color:
❏ Bath Filler: (specify nish)
❏ Bath Drain: 1583.470 (specify nish)
To Be Specied - Optional:
❏ Safe-T-Heater*: 9075.120
❏ 5 Foot Acrylic Apron: 9360.018 (specify color)
❏ 5 Foot Apron: 9260.018 (specify color)
❏ Jet Trim Ring Kit: 9860.200-two per kit (specify nish)
❏ Universal Tile Bead Kit: 751755-100
❏ Grab Bar Kit: 9822.200-two per kit (specify nish)
For color/nish availability and other faucet choices, please
see the Product Selector and Pricing Guide.
* NOTE: the Safe-T-Heater is designed to maintain water
temperature during operation. It will not heat cold water to
desired bathing temperature.
H61

H62
© 2008 AS America Inc.
CADET™ 5' x 36"
WHIRLPOOL AND BATHING POOL
HIGH GLOSS
Revised 2/08
RECOMMENDED FITTING LOCATION
64 X 330mm (2-1/2 x 13")
FOR PIER OR ISLAND
INSTALLATIONS ONLY
ALT. FITTING
LOCATION #1
464 mm
(18-1/4)
38 mm
(1-1/2)
502 mm
(19-3/4)
1-1/2 O.D.TAILPIECE
LEVELING
STRINGER
NOT FOR
SUPPORT
SAFE-T-HEATER
REMOVABLE
BLANK
ROUGH
FLOOR
1524 mm
(60)
914 mm
(36)
OUTLINE OF CUTOUT
1486 mm x 876 mm
(58-1/2 X 34-1/2)
457 mm
(18)
235 mm
(9-1/4)
305 mm
(12)
57 mm
(2-1/4)
(8) JETS
76 mm
(3)
CUTOUT IN FLOOR
FOR DRAIN
PUMP
FINISHED
WALL
305 mm
(12)
OPTIONAL TO
FINISHED FLOOR
USUALLY BETWEEN
1651 & 1981mm
(65 & 78) C/L OF
OVERFLOW
102 mm
(4)
C/L OF
SPOUT
C/L OF
VALVES
C/L OF
SHOWER ARM
70 mm
(2-3/4) 117 mm
(4-5/8)
1-1/2 N.P.T.M.
THREADS
19 mm
(3/4)
229 mm
(9)
C/L OF
SUPPLIES
C/L OF DRAIN
SEE FITTING
SPECS FOR
DIMENSIONS
(2) AIR VALVES
ON/OFF
SWITCH
PROVIDE ACCESS TO PUMP FOR
SERVICING ON ALL INSTALLATIONS
INTEGRAL
SUPPORT
FEET
RECOMMENDED FITTING LOCATION
64 X 330mm (2-1/2 x 13")
FOR PIER OR ISLAND
INSTALLATIONS ONLY
ALT. FITTING
LOCATION #1
ALT. FITTING
LOCATION #2
64 x 330mm
(2-1/2 x 13")
OUTLINE OF CUTOUT
1486 mm x 876 mm
(58-1/2 X 34-1/2)
464 mm
(18-1/4)
38 mm
(1-1/2)
502 mm
(19-3/4)
1-1/2 O.D.TAILPIECE
INTEGRAL
SUPPORT
FEET
LEVELING STRINGER
NOT FOR SUPPORT
ROUGH
FLOOR
1524 mm
(60)
914 mm
(36)
457 mm
(18)
235 mm
(9-1/4)
305 mm
(12)
57 mm
(2-1/4)
67 mm
(2-5/8)
CUTOUT IN FLOOR
FOR DRAIN
FINISHED
WALL
305 mm
(12)
OPTIONAL TO
FINISHED FLOOR
USUALLY BETWEEN
1651 & 1981mm
(65 & 78) C/L OF
OVERFLOW
102 mm
(4)
C/L OF
SPOUT
C/L OF
VALVES
C/L OF
SHOWER ARM
70 mm
(2-3/4) 117 mm
(4-5/8)
1-1/2 N.P.T.M.
THREADS
19 mm
(3/4)
229 mm
(9)
C/L OF
SUPPLIES
C/L OF DRAIN
SEE FITTING
SPECS FOR
DIMENSIONS
60 x 36 x 19-3/4 In.(1524 x 914 x 502mm)
95 Lbs. (43 Kg.)
587 Lbs. (267 Kg.)
59 Gal. (224 L.)
48 Gal. (182 L.)
40 x 22 In. (1016 x 559mm)
52 x 29 In. (1321 x 737mm)
13-1/4 In. (337mm)
39 Lbs./Sq. Ft. (188 Kgs/Sq. m.)
23.8
44.5
GENERAL SPECIFICATIONS FOR 2771 WHIRLPOOL
INSTALLED SIZE
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
MIN. OPERATING GAL.
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
PTS.
CUBE (FT3)
WHIRLPOOL ELECTRICAL SPECIFICATIONS
1.6 HP, 9.7 AMPS, 120V.SYSTEM I PUMP
60 x 36 x 19-3/4 In.
(1524mm x 914 mm x 502mm)
70 Lbs. (32 Kg.)
562 Lbs. (255 Kg)
59 Gal. (224 L.)
40 x 22 In. (1016mm x 559mm)
52 x 29 In. (1321mm x 737mm)
13-1/4 In. (337mm)
37 LBS./Sq. Ft. (180 Kgs/Sq. m.)
23.8
44.5
GENERAL SPECIFICATIONS FOR 2771 BATHING POOL
INSTALLED SIZE
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
PTS.
CUBE (FT3)
NOTES:
BATH CAN BE INSTALLED EITHER ABOVE OR BELOW FLOOR LINE AS PIER, ISLAND, OR PENINSULA TYPE INSTALLATION. SUMP OF
BATH IS SUPPORTED BY INTEGRAL FEET. NO ADDITIONAL SUPPORT REQUIRED. ENCLOSING MATERIAL BY OTHERS.
■ REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH WHIRLPOOL FOR ADDITIONAL INFORMATION.
OPTIONAL 3 WALL TILING BEAD. KIT AND APRON NO. 9260.018 OR 9360.018 AVAILABLE AND MUST BE ORDERED SEPARATELY.
● FITTINGS NOT INCLUDED AND MUST BE ORDERED SEPARATELY.
PROVIDE SUITABLE REINFORCEMENT FOR ALL SUPPORTS.
● IF INSTALLING A DECK-MOUNTED FITTING, BEFORE DRILLING ANY HOLES: CHECK FOR INTERFERENCE WITH CIRCULATING
SYSTEM PIPING, DRAIN OVERFLOW, AND APRON INSTALLATION. MOUNTING HOLES DRILLED BY INSTALLER.
IMPORTANT: Dimensions of xtures are nominal and may vary within the range of tolerances established by ANSI Standard Z124.1
These measurements are subject to change or cancellation. No responsibility is assumed for use of superseded or voided leaet.
