Dimplex DXDH10T User manual



ContactDetails

Pleasenotethatsomeofthecontactdetailson
thisPDFdocumentmaynotbecurrent.

Pleaseusethefollowingdetailsifyouneedto
contactus:

Telephone:08448793588
Email:[email protected]


Thecustomersupportsectionofourwebsitealsofeaturesawide
rangeofinformationwhichmaybeofusetoyouandisavailable
24hoursaday.Itincludes:

•Operatingandinstallationinstructions
•Easy‘Howtouse’guidesforstorageheaters
•Serviceandrepairs
•Wheretobuyourproducts
•Literaturedownloads
•Heatingrequirementcalculator

Visit‐www.dimplex.co.uk/support
A division of GDC Group Ltd
Millbrook House Grange Drive Hedge End Southampton SO30 2DF
www.dimplex.co.uk
Re
g
istered No: 1313016 En
g
land
VAT GB 287 1315 50004
EEE Producer Registration Number –
WEE/GE0057TS
Paper from sustainable sources

Please read this instruction manual carefully before operating your appliance
and keep it in a safe place for future reference.
Specifications
~ Automatic defrosting incorporated. Suitable for use in ambient temperatures
6from 5
o
C~35
o
C.
~ Dehumidification capacity: 10 litres per day at 30
o
C, 80% R.H.
~ Supply: 220~240V, 50Hz
~ Power consumption: 195W
~ Auto pause when water tank is full
~ Net weight: 10.5 kg
~ Dimensions (mm): 323H x530W x175D
~ Refrigerant: R134a
Key Features
~ Suitable for hanging on a wall, free standing on a table or window sill.
~ Can be directed to help dry items, such as wet laundry.
~ Besides the nylon filter, an activated charcoal filter can be used for removing
dust, smoke and unpleasant odoursr
~ Automatic controls with 8 hours timer or continuous operation.
~ Automatic defrost function.

Wall mounting your appliance:
This dehumidifier can be hung on a wall or used freestanding on a flat level
surface. It is suggested to hang it on the wall with more than 150cm above
ground, so that infants won't play with it.
Place the dehumidifier in a location that does not restrict air flow into the air inlet
or out of the air outlet. Make sure there are no curtains, blinds or furniture blocking
the front or back of the dehumidifier.
The dehumidifier must be operated in an enclosed space to be most effective.
Close all doors, windows to the room for effective operation.
Important Safety Information
~ Read All Instructions Carefully Before Using.
~ Use this appliance only for its intended purpose as described in this manual.
~ This appliance is not intended for use by children or other persons without
assistance or supervision if their physical, sensory or mental capabilities prevent
them from using it safely.
~ Children should be supervised to ensure that they do not play with the appliance.
~ This appliance must be properly installed and located in accordance with the
location Instructions before it is used.
~ Do not attempt to stand or sit on the appliance. Doing so may result in bodily
injury or damage to the product.
~ Do not allow children to play with this appliance or tamper with the controls.
~ Keep fingers out of pinch point areas.
~ Unplug the appliance before cleaning and making repairs.
~ Note: All servicing of the appliance must be performed by properly qualified
service personnel.
~ Never unplug your appliance by pulling on the power cord. Always grip the plug
firmly and pull straight out from the outlet.
~ When moving the appliance be careful not to roll over or damage the power cord.
~ Warning! This appliance must be earthed.
~ Please refer to the rating plate on the product for the correct voltage, wattage
and frequency.
~ The power cord of this appliance is equipped with an earthing plug which mates
with a standard earthed wall outlet to minimise the possibility of electric hazard
from this appliance.
~ Have the wall outlet and circuit checked by a qualified electrician to make sure
the outlet is properly earthed.
~ This appliance is fitted with a special mains lead. Should it need replacing at
any time please contact a qualified technician.

Identification of Parts
Wall-mounting instruction:
A wall mounting bracket is supplied on the back of the heater for installation.
Freestanding Operation
The unit must be placed on a stable, level and horizontal surface , otherwise
water may leak out when operating.
NOTE: When in use you must ensure that the air inlet and air outlet of the
appliance are not obstructed
Fitting the Water Tank:
The water tank must be fitted properly. When the tank is full or is not in place
correctly the" FULL" indication lights and the unit stops or won’t start operating.
Set the wall plat
e against the wall so that the unit will
have a floor clearance of at least 150cm. Ensure it is
horizontal and mark the 2 fixing locations through the
keyhole slots on the plate.
emove plate and drill 2 x 6mm diameter holes 20mm
deep and fit the wall plugs supplied, realign the plate
and fit the 2 screws supplied tightly in position.
Note that 4 additional holes are provided and one or
all can be used to permanently fix with steel nails.
The appliance is now simply hung onto the bracket by
aligning the back panel location to the wall plate and
dropping the product onto the plate while pushing it
against the wall to ensure it locates properly.

NORMAL OPERATION
Controls are located at the bottom
right hand corner of the appliance.
On the left are indicator lights and
on the right is a dual option simple
rotary control knob for selecting the
operation required.
Timer Control Options:
1) Turn the control knob counter-clockwise to " CONT " for continuous
dehumidifying. Alternatively set to " OFF " and the unit turns off.
2) Turn clockwise to select and set the runback time to automatic shut off. " 1 "
stands for one hour and " 8 " for eight hours. (Set to " 0 " the unit turns off).
Indicators:
1) "DEHUMIDIFY " indicator : it lights up to indicate the unit running
dehumidification.
2) "DEFROST " indicator : blinks when defrosting. It will automatically return to
dehumidification. (To maintain the efficiency of dehumidification, the defrosting
time is controlled to be less than one third of the running time.)
3) " FULL" indicator : This lights up when the water tank is full of water or out of
position. To restart please empty the tank and / or refit the tank correctly.
Note:
This appliance can be used in ambient temperatures between 5
o
C and 35
o
C.
Do not operate the unit in temperatures below 5
o
C, this could cause ice to
accumulate in the unit.
To Empty the Water Tank:
When the tank is full the " FULL " indicator lights and the unit stops automatically.
Wait a few minutes as the appliance is still working or just stopping otherwise some water
may spill or drip out.
To remove the tank, pull the lower handle gently, carefully support the tank upright and
horizontally with two hands and remove to empty. After pouring out the water, clean the
tank and replace it on the appliance.
Indicators Timer control

Direct Draining Of Water
Water can be automatically emptied from the appliance
directly to a drain by attaching a length of thin-wall rubber
or plastic tubing with an inside diameter of 6 mm (1/4 inch).
Use a screwdriver to remove the knock-out at the back.
Attach the tubing to the connector through the hole. The
tubing should run to the drain with no sharp bends.
Activated Charcoal Filter
NOTE: Don’t leave a dirty charcoal filter in the unit or malfunction may occur.
Normal Maintenance
See next page for details on where you can obtain replacement filters.

Replacement Filters:
Spare filters can be purchased from Dimplex by contacting Tel: [phone] (after
sales), alternatively spare filters may be available from the retailer / supplier where you
bought your appliance.
General cleaning of the appliance:
Clean the air inlet and outlet regularly with a soft damp (not wet) cloth as these
areas accumulate dust normally.
Do not use petrol or solvents or caustic or abrasive cleaning agents.
Before Storing:
- Disconnect and wind the power cord up and fit into the cord storage cabinet at
the back of the appliance.
- Clean the filter.
- Empty, clean and dry the water tank.
- Cover the unit to prevent it from gathering dust.
- Store in a cool and dry place.

TROUBLESHOOTING ADVICE
Notes
1) When the appliance is first plugged in and switched on only the Fan will be
running, this is normal and continues for about 3 minutes before it will
automatically switch to DEHUMIDIFY operation.(This is a design feature to
improve the reliability of the product.)
2) When the appliance is operating the surrounding air becomes slightly warmer
due to the heating effect of the dehumidifying unit, this is normal and helps to
further reduce the relative humidity of the surrounding air.
3) Before you call for service please check the following typical problem list for a
cause and solution:
PROBLEM POSSIBLE CAUSES WHAT TO DO
Dehumidifier won’t start The unit is unplugged Make sure the plug is
correctly fitted to the outlet
The fuse is blown or circuit
breaker is tripped
Check the house fuse/
circuit breaker box and
replace fuse or reset the
breaker
The water tank is full or not
located correctly
Empty the tank.
Check tank is fitted
correctly.
No water or just a little water
is generated
The control may not be set
correctly (timer setting is
reached)
Select high hours to run or
‘CONT’ continuous setting
operation
Airflow is restricted Make sure there is nothing
blocking the air inlet and air
outlet.
The filter is dirty Clean and replace the filter
(see page 7)
Room temperature or
humidity is too low
This is normal. Defrosting
will take place when
temperature is low.
Water is produced but
humidity does not seem to
be reducing.
Doors and windows are
open
Close all doors and
windows to control local
environment
Steam is being generated in
the room
Moisture laden air should be
vented to outside the room.
Area to be dehumidified is
too large for the unit.
Check if the unit capacity is
adequate.
Noise occurs The unit is not located
securely
Relocate the unit or tighten
the wall fixings.
The filter is dirty. Clean and replace the filter.
Water on floor The unit is not located
correctly
Relocate the unit , check
wall mounting is level.
The drainage is blocked Clean and repair it (page 6)
Should there still be a problem, please unplug the unit and contact your supplier.
