Dimplex DCACE20R User manual

DCACE20R
Air Circulator w/Electronic
Controls, Timer & Remote
www.dimplex.com.au
INSTRUCTION MANUAL
PLEASE READ THE INSTRUCTION MANUAL CAREFULLY BEFORE USING THE UNIT.

www.dimplex.com.au
CONTENTS
WARNINGS AND PRECAUTIONS 1
STRUCTURE 3
OPERATION 4
CLEANING AND MAINTENANCE 7
TECHNICAL REFERENCE DATA 9
WARRANTY 9

1
Warnings
• Never place the unit near gas appliances, ames or
• ammable liquids.
• Never hit or shake the unit. Doing so may cause damage.
• Never cover or obstruct the air inlet or outlet.
• Doing so may cause overheating.
• Never spray water on or place the unit near water.
• Doing so may cause electric shock.
• Never connect other appliances to the same power outlet.
• Never connect or disconnect the power plug with wet hands.
• Doing so may cause electric shock.
• Never insert ngers or objects through the guards when the unit is
operating.
• Never use an extension cord.
• Always have a professional technician, manufacturer or service agent
replace a damaged power cord.
Precautions
• This appliance is for indoor use only.
• Do not use the unit near windows or where water collects. Rain and
water collection may lead to a risk of re or electric shock.
• Do not place the unit in a damp place or where humidity is high (such
as a bathroom).
• Do not leave the unit operating while unattended.
• Do not place the unit in direct sunlight to avoid surface discolouration.
WARNINGS & PRECAUTIONS

2
• This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety.
• Children should be supervised to ensure they do not play with the
appliance.
• Avoid electromagnetic interference. Keep the unit at least 1 metre away
from electric appliances such as televisions and radios.
• Avoid scratching and damaging the surface. Do not use chemical
solvents (i.e. Benzene, alcohol) to clean the surface.
• Place the unit on a stable surface when operating.
• Unplug the unit before cleaning, servicing or maintenance.
• Electrical connections must be in accordance with National or
• Local Codes.
• The rear of the unit must be at least 50cm away from the wall.
• If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualied persons in order to avoid a hazard.
WARNINGS & PRECAUTIONS

3
1. Base
2. Buttons
3. LED indicator light
4. Remote receiver
5. Brand badge
6. Front grille
7. Remote control/holder
8. Rear housing
9. Fan body
10. Fan body
11. Power cord
STRUCTURE

4
CONTROL PANEL & REMOTE
OPERATION
Oscillation
button
Fan Speed
button
Timer
button
Mode
button
On/Off
button
INDICATOR LIGHTS
Oscillation
indicator
Fan Speed
indicator
Timer
indicator
Mode
indicator
On/Off
indicator
红线充鼓包范围
图案丝印颜色Pantone Coolgray 6c
白色White
循环扇白色遥控器 DF-EF0816V 肖超 2017/01/12
红线充鼓包范围
Pantone 877C
黑色Black
Pantone 877C
Pantone Coolgray 6c
Background (White)
Background (Black)
循环扇黑色遥控器 DF-EF0816V 肖超 2017/01/12
注：
1，此遥控器PVC为白色，表面喷消光油
2，背面备胶
3，按键冲鼓包，直径为10mm
注：
1，此遥控器PVC为白色，表面喷消光油
2，背面备胶
3，按键冲鼓包，直径为10mm

5
OPERATION
REMOTE CONTROL
The remote control can be used to operate all functions.
1. Remove the battery cover at the back of remote control (Picture 2).
2. Insert the 3V CR2032 battery.
3. Replace the battery cover.
ON / OFF
This button is used to switch the unit on and off. By simply pressing the
button, you can turn the unit on or off. Once turned on, default mode is
Normal Mode & Low Speed.
FAN SPEED
This button is used to select the desired fan speed – Low, Med, or High.
The fan speed indicator light will illuminate indicating what speed has been
selected. Press once for low speed, press twice for medium speed, press
three times for high speed. Pressing again in high speed, will return to low
speed.

6
OPERATION
MODE
This button is used to switch between pre-set operating modes. By simply
pressing the button, you can regulate the mode from NORMAL, NATURAL
or SLEEP depending on your needs. The unit automatically starts in
NORMAL mode.
Normal Mode: Operates normally with the selected wind speed –
Low, Med, High.
Natural Mode: The fan speeds automatically shift through High,
Med, Low speed to imitate a natural wind speed rhythm.
Sleep Mode: The fan automatically lowers the set wind speed
in 30 minute intervals. E.g. High speed: 30mins -> Med speed
30mins -> Low speed 30 mins.
TIMER
This air circulator comes with an 8 hour timer that allows you to pre-set the
unit to switch off automatically, in intervals of 1, 2, 4 or 8 hours.
To operate, simply select the number of hours ahead you wish the unit to
switch off and the respective indicator lights will illuminate. If you’d like the
unit to run continuously, ensure no timer indicator lights are illuminated.
OSCILLATION
Press the oscillation button to activate 360° Horizontal oscillation. Press
again to deactivate.
90° VERTICAL OSCILLATION
Tilt the fan head to achieve up to 90° angled oscillation. Ensure the fan is
OFF when adjusting the fan head position.

7
OPERATION
1. Remove the unit from its packaging
2. Plug the unit into a power outlet, a ‘beep beep’ will sound and the unit
will be in standby mode.
3. Press the “On/Off” button to turn the unit On.
4. Press the “Fan Speed” button to change the fan speed (low, med, high).
5. The unit defaults in “Normal” mode. Press the mode button to change
to Natural or Sleep Mode.
6. The unit will operate initially on a continual basis. If a set period of
operation is required, please follow “TIMER” instructions on page 6.
7. To activate 360° oscillation, press the oscillation button. To turn off
oscillation, press again.
8. To switch the unit off at any time, press the “On/Off” button.

8
CLEANING & MAINTENANCE
CLEANING
Over time, dust can accumulate on the rear grille cover and fan blades,
which can affect the fans performance. It is recommended to clean the fan
at least once a month.
1. Turn the unit OFF and disconnect the appliance from the power supply.
2. Remove any dust build up with a soft brush.
3. Wipe the surface of the unit with a soft damp cloth. Mild detergent can
be used for any stubborn marks.
IMPORTANT
The control panel and other parts must not come into contact with water or
any other liquids.
• Do not dispose of electrical appliances as unsorted municipal waste.
• Use separate collection facilities.
• Contact your local government for information regarding the collection
systems available.
• If electrical appliances are disposed of in landlls or dumps, hazardous
substances can leak into the ground water, polluting the food chain and
damaging health and well-being.
MAINTENANCE
If the unit fails to operate efciently, is broken or other problems arise,
unplug and do not operate. Ask for advice by calling your local after sales
service agent or the Customer Care Centre on 1300 556 816 (AU) / 0800
666 2824 (NZ).

9
TECHNICAL & REFERENCE DATA
WARRANTY
The warranty period is 12 months from the date of purchase. For service
advice, please contact the Customer Care Centre on 1300 556 816 (AU) /
0800 666 2824 (NZ).
Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd
1340 Ferntree Gully Road, 38 Harris Road, East Tamaki,
Scoresby 3179, Victoria Auckland 2013
Australia New Zealand
Ph: 1300 556 816 Ph: 0800 666 2824
MODEL NO. DCACE20R
Rated Power 45W
Voltage/Frequency 220-240V/50Hz
Net Weight 1.9kg
Dimensions Body (HxWxDmm) 340 x 225 x 203.5
Dimensions Packaging (HxWxDmm) 350 x 240 x 240
RCM
