DINA SAFEONE DNSR-2R2 Series User manual

dina.de
SAFEONE
DNSR-2R2
Time Delay Relay
Hardware
Switching device for enabling and time delayed
enabling of control circuits

DINA Elektronik GmbH
Esslinger Straße 84
72649 Wolfschlugen
Germany
Phone [phone]
Fax [phone]
Mail inf[email protected]
Web www.dina.de
© Copyright by DINA Elektronik GmbH 2021
All parts of this documentation are protected by copyright.
Any use beyond that permitted under copyright law is not permitted without express written con-
sent from the publisher. This applies in particular to the reproduction, distribution and translation
of this documentation or parts thereof, as well as the storage and processing of this content using
electronic data processing systems.
The information contained in this documentation corresponds to the technical state of the product
at the time these operating instructions were published.
This documentation applies to:
Designation ID no.
DNSR-2R2 33SR15-18
DNSR-2R2 33SR20
Legal information
Handbook: Hardware
Target group: Electricians, electrical designers
Editor: DINAElektronik GmbH
File name: BA_DNSR-2R2_zeitrelais-d-V01
Language: EN
Publication as at: July 9, 2021

Hardware Manual SAFEONE DNSR-2R2 Time Delay Relay 
Table of Contents
Table of Contents
1Structure of the document 
1.1 Conventions 
1.1.1 Emphasizing information 
1.1.2 Emphasizing paragraphs using typography 
2Safety 
2.1 Warnings 
2.1.1 Function of warnings 
2.1.2 Design of warnings 
2.1.3 Hazard symbols 
2.2 Qualification of personnel 
2.2.1 Electrician 
2.2.2 Electrical designers 
2.3 Intended use and improper use 
2.3.1 Certification data 
2.4 Documentation 
2.5 Safety regulations 
2.5.1 Retrofitting and conversion 
2.5.2 Basic safety regulations 
2.6 Working on live parts 
3 EC declaration of conformity
4 Product description 
4.1 Pin assignment 33SR15 to 33SR18 
4.2 Functional specification for 33SR15 to 33SR18 
4.2.1 Application example for control input PG1 
4.3 Pin assignment 33SR20 
4.4 Functional specification for 33SR20 
4.5 Setting the delay times 
5 Diagnostics and switching status displays 
5.1 LED indicators 
6 Order information 

Hardware Manual SAFEONE DNSR-2R2 Time Delay Relay 
Table of Contents
7 Technical data 
7.1 Supply 
7.2 Digital inputs 
7.3 Voltage outputs 
7.4 Contact outputs 
7.5 General data 
7.6 Connection data 
7.7 Environmental conditions 
7.8 Dimensions 
7.9 Safety technical data 
7.10 Safety-related parameters in accordance with DIN EN ISO 13849-1:2016-06 
7.11 Contact life 
8 Installation and removal 
8.1 Installing a module 
8.1.1 Overview

8.2 Removing a module 

Hardware Manual SAFEONE DNSR-2R2 Time Delay Relay 
1 Structure of the document
1Structure of the document
1.1 Conventions
Information of particular important is emphasized in this documentation through the use
of symbols, typography or formulations.
1.1.1 Emphasizing information
The following symbols indicate important information:
Degree of hazard (e. g. WARNING):
Triangular symbols indicate the degree of hazard in warnings.
Type of hazard (e.g. electrical shock – dangerous voltage):
Triangular symbols indicate the type of hazard in warnings.
Information: Additional clarification
Tip: Additional information to help optimize the workflow.
1.1.2 Emphasizing paragraphs using typography
The following typography is used to emphasize paragraphs with special functions:
3Indicates an instruction.
7Indicates an expected reaction.
5Indicates an unexpected reaction.
•Indicates an item in a list.
1.1.3 Emphasizing words using typography
The following typography is used to emphasize words with special functions:
1Represents a numbered item in a figure.
RIndicates a cross-reference to another page, figure or document.

Hardware Manual SAFEONE DNSR-2R2 Time Delay Relay 
2 Safety
1.2 We value your opinion!
We do all we can to provide complete, accurate documentation for the product. If you have any
suggestions for improvement or advice for us, please share your thoughts with us. Send us your
comments by e-mail to the following address.
E-Mail: [email protected]

Hardware Manual SAFEONE DNSR-2R2 Time Delay Relay 
2 Safety
2Safety
2.1 Warnings
2.1.1 Function of warnings
Warnings warn users about hazards when handling the product. The hazards are classified,
specified, described and supplemented with information about how to avoid them.
• If there is a warning before a list of instructions, the hazard is present throughout
the entire activity.
• If there is a warning immediately before an instruction, the hazard is present during
the next step.
2.1.2 Design of warnings
All warnings are indicated by a signal word and a warning symbol. The different combinations
of the signal word and warning symbol indicate the degree of danger.
DANGER
For an immediate hazard that will result in severe injuries or death.
WARNING
For an immediate hazard that could result in severe injuries or death.
CAUTION
For a potentially hazardous situation that could result in injuries.
CAUTION
For a potentially harmful situation in which the product or an item near it could be damaged.
CAUTION
For a hazard that could cause environmental damage.

Hardware Manual SAFEONE DNSR-2R2 Time Delay Relay 
2 Safety
2.1.3 Hazard symbols
Note
The warning symbol may be present alongside another hazard symbol that represents
the type of hazard, in order to attract the reader's attention.
Hazard symbols are indicated by a triangular symbol in the context of warnings. The following
hazard symbols are used in this documentation:
Electric shock – dangerous voltage!
2.2 Qualification of personnel
DINA Elektronik GmbH distinguishes between specialist staff with different qualifications when
it comes to carrying out work on the product. The minimum required qualifications are specified
for each task and are defined as follows:
2.2.1 Electrician
Specialist who installs, maintains and repairs the electrical system in the product. A specialist is
a person whose specialist training means that they have the knowledge and experience, includ-
ing knowledge of relevant regulations, necessary to assess the work assigned to them and the
potential hazards.
Note
When evaluating a person’s specialist training, multiple years of work in the relevant field may
also be taken into account.
RDIN VDE 1000-10 Requirements for persons working in a field of electrical engineering
2.2.2 Electrical designers
Specialists who design the electrical system and the product. A specialist is a person whose
specialist training means that they have the knowledge and experience, including knowledge of
relevant regulations, necessary to assess the work assigned to them and the potential hazards.
Note
When evaluating a person’s specialist training, multiple years of work in the relevant field may
also be taken into account.
RDIN VDE 1000-10 Requirements for persons working in a field of electrical engineering

Hardware Manual SAFEONE DNSR-2R2 Time Delay Relay 
2 Safety
2.3 Intended use and improper use
The product has exclusively been developed for use for the purpose described here. The
specifications set out in these operating instructions must be strictly complied with.
• The DNSR-2R2 is a switching device for enabling and time delayed enabling of control circuits.
• The safety module is intended for use on machines and plants to prevent hazards
from arising.
Any other form of use is regarded as improper use.
If the product is
• not used as intended,
• improperly maintained or
• incorrectly operated,
the manufacturer will not assume any liability for any damage that results. In this case,
the risk shall be borne exclusively by the user.
2.3.1 Certification data
The product is certified as safety equipment in accordance with:
• DIN EN ISO 13849-1:2016-06,
Category 3, PLd
• DGUV Test: GS-ET-20:2016-10
• EC type examination certificate
Notified body:
DGUVTest
Prüf- and Zertifizierungsstelle
Elektrotechnik, Fachbereich: ETEM
Gustav-Heinemann-Ufer 130
50968 Cologne, Germany
(Reg. no.: 0340)
• EMC Directive Certified by:
ELMAC GmbH Bondorf
• CNL, USL FileE227037
• QM system certified as per
DIN EN ISO 9001:2015
Certified by:
DQS GmbH
60433 Frankfurt am Main, Germany
NOTE
You can download the certificates from our website:
Rhttps://www.dina.de/downloads

Hardware Manual SAFEONE DNSR-2R2 Time Delay Relay 
2 Safety
2.4 Documentation
Operating instructions contain instructions on how to use a product safely, correctly and cost-
effectively. Follow the instructions in these operating instructions in order to prevent hazards,
avoid repair costs and standstill, and improve the reliability and service life of the product.
You must read the operating instructions and ensure that you understand them.
3Before working with the product, read the operating instructions that come with the product.
3Always ensure that the operating instructions are available where the product is in use.
2.5 Safety regulations
The safety regulations listed below must always be complied with. In the event that these safety
regulations are not complied with or the device is used improperly, DINA Elektronik GmbH accepts
no liability for any resulting injury or damage.
• The product must only be installed and commissioned by a skilled electrician or a trained,
instructed person, who is familiar with these operating instructions and the applicable
specifications regarding occupational health and safety and accident prevention.
WARNING
Danger to persons and materials! In the event that specifications are not complied with, this
can result in death, severe injuries or significant material damage.
3Observe VDE, EN and local regulations, in particular with regard to protective measures.
• If the emergency stop is used, either the integrated restart prevention function must be used
or the machine must be prevented from restarting automatically using a superordinate control
system.
• When installing the device, the required distances as per DIN EN 50274, VDE 0660514 must
be taken into account.
3
During transport, storage and operation, comply with the conditions set out
in EN 60068-2-1, 2-2.
3
Assemble the device in a control cabinet with at least IP54 degree of protection. Otherwise,
dust and moisture can impair the functions. The device must be installed in a control cabinet.
3
Ensure that the output contacts have sufficient protective circuitry for capacitive
and inductive loads.
3
Follow the specifications in the general technical data.

Hardware Manual SAFEONE DNSR-2R2 Time Delay Relay 
2 Safety
Note
More detailed information can be found in the RTechnical data section.
WARNING
Electric shock – dangerous voltage! During operation, switching devices conduct dangerous
voltages.
Never remove protective covers from electrical switching devices during operation.
3Replace the device the first time a fault occurs.
Dispose of the device in accordance with nationally applicable environmental regulations.
2.5.1 Retrofitting and conversion
• Unauthorized conversion voids any warranty. This can cause hazards that can lead to severe
or even fatal injury.
2.5.2 Basic safety regulations
The safety regulations listed below must always be complied with. In the event that these safety
regulations are not complied with or the device is used improperly, DINA Elektronik GmbH
accepts no liability for any resulting injury or damage.
• The product described here has been developed to perform safety-related functions as part
of an entire system.
• The entire system is made up of sensors, analysis units, reporting units and safe switch-off
concepts.
• It is the manufacturer’s responsibility to ensure that a system or machine is functioning
correctly as a whole.
• The manufacturer of the system is obligated to check and document the efficacy of the
implemented safety concept within the entire system. This documentation must be produced
again every time the safety concept or safety parameters are modified.
• The manufacturer’s specifications for the system or machine with regard to maintenance
intervals must be complied with.

Hardware Manual SAFEONE DNSR-2R2 Time Delay Relay 
2 Safety
• DINA Elektronik GmbH is not able to make any guarantees regarding the properties
of an overall system not designed by the company.
• DINA Elektronik GmbH accepts no liability for any recommendations given or implied
in the following description.
• No new guarantee, warranty or liability claims that go beyond DINA Elektronik GmbH’s
general delivery conditions can be derived from the following description.
• To prevent EMC disturbances, the physical environmental and operating conditions where
the product is installed must correspond to the EMC section of DIN EN 60204-1.
• If contact outputs are used, the safety function must be requested at least once per month
for Performance Level (e) and once per year for Performance Level (d).
2.6 Working on live parts
WARNING
Electric shock – dangerous voltage! Touching live components can cause severe or even fatal
injury, depending on circumstances, as a result of an electric shock.
3Never assume that a circuit is dead.
3Always check circuits as a safety precaution! Components being worked on may only be
live if this is absolutely necessary and stipulated.
3Accident prevention regulations (e.g. VBG4 and VDE 105) must be observed during all work.
3Only use suitable, intact tools and measuring equipment.

Hardware Manual SAFEONE DNSR-2R2 Time Delay Relay 
3 EC declaration of conformity
3 EC declaration of conformity
Original EG-Konformitätserklärung
(gemäß der Richtlinie 2006/42/EG, Anhang II, 1A)
Original EC-Declaration of Conformity
(according to Directive 2006/42 / EC, Annex II, 1A)
Wir erklären, dass folgendes Produkt allen einschlägigen Bestimmungen der Richlinie 2006/42/EG entspricht.
We declare, that the following product fulfils all the relevant provisions of Directive 2006/42 / EC.
Stefan Najib
Geschäftsführer/CEO Wolfschlugen, 01.10.2021
DINA Elektronik GmbH
Esslinger Str. 84
72649 Wolfschlugen
Deutschland
Produkt/Product Funktion/Function
DNSR-2R2
Sicherheitsschaltgerät/safety switching device
ID-No. 33SR15, 33SR16, 33SR17, 33SR18, 33SR20
Zeitrelais/time relay
Weitere EU-Richtlinien/Further EC- directives
2014/30/EU EMV-Richtlinie/EMC-Directive
2011/65/EU RoHS Richtlinie/RoHS-Directive
Benannte Stelle/Notified Body EG Baumusterprüfbescheinigung/EC Type-Examination certificate
DGUVTest
Prüf- und Zertifizierungsstelle, Elektrotechnik,
Fachbereich: Energie, Textil, Elektro, Medienerzeugnisse
Gustav-Heinemann-Ufer 130
D-50968 Köln
Kenn-Nr.: 0340
Reg.-Nr./No.: ET 21047
Bevollmächtigter für die Zusammenstellung der technischen Unterlagen/
Authorized representative for the compilation of the technical documents
DINA Elektronik GmbH
Esslinger Str. 84
72649 Wolfschlugen
Deutschland

Hardware Manual SAFEONE DNSR-2R2 Time Delay Relay 
4 Product description
4 Product description
The DNSR2R2 is a switching device for enabling and time delayed enabling of control circuits.
The switching device has two separate starting circuits.
Secure digital inputs and contact outputs are available for this.
The operational readiness and switching status of the contact outputs are displayed using LEDs.
The time delay relays are available in different versions with different time delays.
NOTE
Potential overvoltages and overcurrents are monitored.
4.1 Pin assignment 33SR15 to 33SR18
The pin assignment shown also relates to switching devices 33SR16, 33SR17 and 33SR18.
A1 Operating voltage +24VDC
A2 Operating voltage 0 V
S11 Output control voltage 15 V
S21 Output control voltage 12 V
S12 Input starting circuit 1
S22 Input starting circuit 2
PG1 Control input for starting contact 13/14
PG2 Control input for starting contact 23/24
13/14 Starting contact (1 NO contact), controllable via PG1
23/24 Starting contact (1 NO contact), controllable via PG2
17/18 Enabling contact (2 NO contacts), off delay (t1)
27/28 Enabling contact2 (2 NO contacts), off delay (t2)
LED ON PWR on/off
LED K1 Relay 17/18 status display
LED K2 Relay 27/28 status display
A1 A2 13 14
S11S12 23 24
S21 S22 PG1PG2
17 18 27 28
DNSR-2R2
ID-No. 33SR15
ON
K1
K2

Hardware Manual SAFEONE DNSR-2R2 Time Delay Relay 
4 Product description
4.2 Functional specification for 33SR15 to 33SR18
The DNSR-2R 33SR15 to 33SR18 switching devices have two separate starting circuits, each with
an off delay contact to release the control circuits.
• The inputs are controlled via the internal 15 V voltage at S11 and 12 V voltage at S21.
• The start buttons must be connected between S11 and S12 (starting circuit 1)
and between S21 and S22 (starting circuit 2).
• An external control can be built into the starting circuits via the PG1 and PG2
control inputs and the 13/14 or 23/24 relay contacts.
• The delay times of these devices vary.
3Close starting circuit 1 (S11–S12)
7Enabling contact 17/18 closes without delay.
3Open starting circuit 1 (S11–S12)
7Enabling contact 17/18 opens with a delay.
3Close starting circuit 2 (S21–S22)
7Enabling contact 27/28 closes without delay.
3Open starting circuit 2 (S21–S22)
7Enabling contact 27/28 opens with a delay.
Delay times 33SR15 33SR16 33SR17 33SR18
t1 (off delay) for 17/18 1.5 s 1.5 s 12 s 12 s
t2 (off delay) for 27/28 45 s 100 s 5 s 5 s
NOTE
The delay time can be retriggered.
4.2.1 Application example for control input PG1
3Connect PG1 to 24 V
7Starting contact 13/14 closes without delay.
3Close starting circuit 1 (S11, S12, 13/14)
7Enabling contact 17/18 closes without delay.
Enabling contact 17/18 opens with a delay when the starting circuit
is opened or the control input deactivated.

Hardware Manual SAFEONE DNSR-2R2 Time Delay Relay 
4 Product description
4.3 Pin assignment 33SR20
A1 Operating voltage +24VDC
A2 Operating voltage 0 V
S11 Output control voltage 15 V
S21 Output control voltage 12 V
S12 Input starting circuit 1
S22 Input starting circuit 2
PG1, PG2 PG1 and PG2 bridged: Enable time setting for t1/t2
15/16 Diagnostic contact (1 NO contact), on delay (t1)
25/26 Diagnostic contact (1 NO contact), off delay (t2)
17/18 Enabling contact (2 NO contacts), off delay (t1)
27/28 Enabling contact2 (2 NO contacts), off delay (t2)
LED ON PWR on/off
LED K1 Relay 17/18 status display
LED K2 Relay 27/28 status display
NOTE
Diagnostic contacts 15/16 and 25/26 close approximately three seconds after the operating
voltage is applied. If the starting circuits are already closed, this is detected and the diagnostic
contacts are reopened.
4.4 Functional specification for 33SR20
The DNSR-2R 33SR20 switching device has two separate starting circuits with enabling and
time-delayed enabling contacts to enable control circuits.
• The inputs are controlled via the internal 15 V voltage at S11 and 12 V voltage at S21.
• The start buttons must be connected between S11 and S12 (starting circuit 1)
and between S21 and S22 (starting circuit 2).
• Diagnostic contacts 15/16 and 25/26 close approximately three seconds
after the operating voltage is applied.
• The delay times can be set using the front potentiometer.

Hardware Manual SAFEONE DNSR-2R2 Time Delay Relay 
4 Product description
3Close starting circuit 1 (S11–S12)
7Enabling contact 17/18 closes without delay.
7Diagnostic contact 15/16 opens without delay.
3Open starting circuit 1 (S11–S12)
7Enabling contact 17/18 opens with a delay.
7Diagnostic contact 15/16 closes with a delay.
3Close starting circuit 2 (S21–S22)
7Enabling contact 27/28 closes with a delay.
7Diagnostic contact 25/26 opens with a delay.
3Open starting circuit 2 (S21–S22)
7Enabling contact 27/28 opens without delay.
7Diagnostic contact 25/26 closes without delay.
NOTE
The delay time cannot be retriggered.
4.5 Setting the delay times
Delay times t1 and t2 can be set using the front potentiometer. The following times can be set:
Delay times
Off delay time t1 0.5s–3s
On delay time t2 30s–100s
3
Inputs S12 and S22 must not be connected.
3
Bridge terminals PG1 and PG2.
3
Set the times on the potentiometers.
3
Remove the bridge from PG1 and PG2.
7
The settings are permanently saved in the device.
CAUTION
Validate the time delays after entering each setting!

Hardware Manual SAFEONE DNSR-2R2 Time Delay Relay 
5 Diagnostics and switching status displays
5 Diagnostics and switching status displays
The module has an LED display indicating
• Operational readiness
• Enabling contact status
5.1 LED indicators
Key
LED on
LED off
LED flashing – Contact our support team at [email protected]
SAFEONE DNSR2R State
LED
ON Power off
Power on
K1 Enabling circuit 17/18 open
Enabling circuit 17/18 closed
1 per second: Delay time t1 counting down
2 per second: Fault
K2 Enabling circuit 27/28 open
Enabling circuit 27/28 closed
1 per second: Delay time t2 counting down
2 per second: Fault

Hardware Manual SAFEONE DNSR-2R2 Time Delay Relay 
6 Order information
6 Order information
Description Product ID no.
DNSR-2R2 Time Delay Relay SAFEONE DNSR-2R2
33SR15
33SR16
33SR17
33SR18
33SR20
7 Technical data
7.1 Supply
Operating voltage UB24VDC (±10%)
Current consumption at 24 V 70 mA in rest position
90 mA in working position
Power consumption on A1/A2 1.7 W (rest position), 2.2 W (working position)
7.2 Digital inputs
Inputs S12 S22
Input voltage range 15V DC ± 0.5V 12V DC ± 0.5V
7.3 Voltage outputs
Outputs S11 S21
Voltage 15V DC ± 0.5V 12V DC ± 0.5V

Hardware Manual SAFEONE DNSR-2R2 Time Delay Relay 
7 Technical data
7.4 Contact outputs
Outputs 17/18, 27/28 15/16, 25/26 13/14, 23/24
Contact material Ag alloy
Output guidance
Minimum switching current
see Contact service life section 3mA 3mA 3mA
Maximum switching current
* construction-related limitation
6 A*
1 A 0.5A 0.5A
Switching capacity in accordance
with IEC 60947-5-1
For 17/18 and 27/28 only
DC13: 1.5 A/30 V
AC15: 1.5 A/250 V
Mechanical service life 5 x 107switching cycles
Contact fuse 3A gL/gG
Typical response/release time 10ms/10ms
7.5 General data
Type of protection (housing and terminals) IP20
Type of protection (place of installation) Min. IP54
Clearance and creepage distances
between circuits in accordance with DIN EN 50178
Rated insulation voltage 17/18, 27/28
250V AC
15/16, 25/26
30V AC
13/14, 23/24
Rated surge voltage/insulation 4 kV
Degree of contamination 2
Overvoltage category III
Housing material Polyamide (PA), not reinforced
