About this guide
This guide provides site preparation recommendations, step-by-step procedures for rack
mounting and desk mounting, inserting modules, and connecting to a power source.
CAUTION: To avoid electrostatic discharge (ESD) damage, wear grounding wrist
straps when handling this equipment.
WARNING: Only trained and qualied personnel can install this equipment. Read
this guide before you install and power up this equipment. This equipment contains
two power cords. Disconnect both power cords before servicing.
WARNING: This equipment contains optical transceivers, which comply with the
limits of Class 1 laser radiation.
Figure 1. Class 1 laser product tag
WARNING: When no cable is connected, visible and invisible laser radiation may be
emitted from the aperture of the optical transceiver ports. Avoid exposure to laser
radiation and do not stare into open apertures.
Regulatory
• Marketing model S5232F-ON is represented by the regulatory model E21W and the
regulatory type E21W005.
• Marketing model S5248F-ON is represented by the regulatory model E21W and the
regulatory type E21W002.
1
About this guide 5

• Marketing model S5224F-ON is represented by the regulatory model E21W and the
regulatory type E21W003.
• Marketing model S5296F-ON is represented by the regulatory model E26W and the
regulatory type E26W001.
• Marketing model S5212F-ON is represented by the regulatory model E29W and the
regulatory type E29W001.
Topics:
• Related documents
• Information symbols
Related documents
For more information about the S5200F-ON Series (S5232F-ON, S5248F-ON, S5296F-
ON, S5224F-ON, and S5212F-ON) switches, see the following documents.
•OS10 Enterprise Edition Release Notes
•OS10 Enterprise Edition User Guide
•S5200F-ON Series Installation Guide
•S5200F-ON Series Release Notes
•S5200-ON Series BMC User Guide
•Open Networking Hardware Diagnostic Guide
NOTE: For the most recent documentation, see the support site: www.dell.com/
support.
Information symbols
This book uses the following information symbols:
NOTE: The Note icon signals important operational information.
CAUTION: The Caution icon signals information about situations that could result in
equipment damage or loss of data.
WARNING: The Warning icon signals information about hardware handling that
could result in injury.
WARNING: The ESD Warning icon requires that you take electrostatic precautions
when handling the device.
6 About this guide

Site preparations
The 5200F-ON Series (S5232F-ON, S5248F-ON, S5296F-ON, S5224F-ON, and S5212F-
ON) switch is suitable for installation as part of a common bond network (CBN).
You can install the switch in:
• Network telecommunication facilities
• Data centers
• Other locations where the National Electric Code (NEC) applies
For more information about the S5200F-ON Series switch specications, see
Specications.
NOTE: Install the switch into a rack or cabinet before installing any additional
components such as cables or optics.
Topics:
• Site selection
• Cabinet placement
• Rack mounting
• Switch ground
• Fans and airow
• Power
• Storing components
Site selection
Install your equipment in restricted access areas. A restricted access area is one where
service personnel can only gain access using a special tool, lock, key, or other means of
security. The authority responsible for the location controls access to the restricted area.
2
Site preparations 7

Ensure that the area where you install your switch meets the following safety requirements:
• Near an adequate power source. Connect the switch to the appropriate branch circuit
protection according to your local electrical codes.
• Environmental—switch location—continuous temperature range is from 0°C to 45°C
(32°F to 113°F).
• Operating humidity is from 5 to 85 percent noncondensing, continuous.
• In a dry, clean, well-ventilated, and temperature-controlled room, away from heat
sources such as hot cooling vents or direct sunlight
• Away from sources of severe electromagnetic noise
• Positioned in a rack or cabinet, or on a desktop with adequate space in the front, back,
and sides for proper ventilation and access
• Install the switch in information technology rooms in accordance with Article 645 of the
National Electrical Code and NFPA 75.
For more information about switch storage and environmental temperatures, see
Specications.
Cabinet placement
Install the S5200F-ON Series switch only in indoor cabinets designed for use in a controlled
environment.
Do not install the switch in outside cabinets. For cabinet placement requirements, see Site
selection.
The cabinet must meet minimum size requirements. Airow must be in accordance with the
Electronic Industries Alliance (EIA) standard. Ensure that there is a minimum of 5 inches
(12.7 cm) between the intake and exhaust vents and the cabinet wall.
Rack mounting
When you prepare your equipment rack, ensure that the rack is grounded. Ground the
equipment rack to the same ground point the power service in your area uses. The ground
path must be permanent.
Switch ground
Dell EMC recommends grounding your switch. Use the S5200F-ON Series switch in a CBN.
8Site preparations

Fans and airow
Fan installation is completed as part of the Factory Install based on the stock keeping unit
(SKU) type. The S5200F-ON Series switch has SKUs that support the following
congurations:
• AC PSU with fan airow from the I/O to the PSU—normal
• AC PSU with fan airow from the PSU to the I/O—reverse
• DC fan unit with airow from the I/O to the PSU—normal
• DC fan unit with fan airow from the PSU to the I/O—reverse
Be sure to order the fans suitable to support your site’s ventilation. Use a single type of
airow fan in your switch. Do not mix reverse and normal airows in a single switch.
For proper ventilation, position the switch in an equipment rack or cabinet with a minimum
of 5 inches (12.7 cm) of clearance around the exhaust vents. The fan speed varies based on
internal temperature monitoring. The switch never intentionally turns o the fans.
Power
To connect the switch to the applicable power source, use the appropriate power cable. An
AC power cable is included with the switch.
When installing AC or DC switches, follow the requirements of the National Electrical Code
ANSI/NFPA 70, where applicable.
The switch is powered-up when the power cable is connected between the switch and the
power source.
CAUTION: Always disconnect the power cable before you service the power supply
slots. The switch has multiple power cables. Before servicing, ensure that all power
cables are disconnected.
CAUTION: On the AC switch, use the power supply cable as the main disconnect
device. Ensure that the socket-outlet is located/installed near the equipment and is
easily accessible.
NOTE: Module power is software controlled. You do not see module LEDs when the
switch powers up in the open network install environment (ONIE).
Site preparations 9

Storing components
If you do not install your S5200F-ON Series switch and components immediately, properly
store the switch and all components following these guidelines:
• Storage location temperature must remain constant. The storage range is from -40° to
70°C (-40° to 158°F).
• Store on a dry surface or oor, away from direct sunlight, heat, and air conditioning
ducts.
• Store in a dust-free environment.
NOTE: ESD damage can occur when components are mishandled. Always wear an
ESD-preventive wrist or heel ground strap when handling the switch and its
accessories. After you remove the original packaging, place the S5200F-ON Series
switch and its components on an anti-static surface.
10 Site preparations

S5200F-ON Series switch
Installation
To install the S5200F-ON Series (S5232F-ON, S5248F-ON, S5296F-ON, S5224F-ON, and
S5212F-ON) switch, complete the installation procedures in the order presented in this
section.
Always handle the switch and its components with care. Avoid dropping the switch or any
eld replaceable units (FRUs).
NOTE: ESD damage can occur if components are mishandled. Always wear an ESD-
preventive wrist or heel ground strap when handling the switch and its components.
As with all electrical devices of this type, take all the necessary safety precautions
to prevent injury when installing this switch.
Topics:
• Unpack
• Ground cable
• Rack or cabinet installation
• One-half U front-rack installation
• One U ReadyRails installation
• Two U four-post rack assembly
• DC power connections
• S5212F-ON only DC power connections
• Optics installation
• Switch power-up
• After switch installation
3
S5200F-ON Series switch Installation 11

Unpack
NOTE: Before unpacking the switch, inspect the container and immediately report
any evidence of damage.
NOTE: For the S5212F-ON and S5296F-ON switches only: the USB extension
cable is packaged separately. Do not throw it away.
When unpacking the switch, ensure that the following items are included:
• One S5200F-ON Series switch
• Two sets of rail kits, no tools needed
• One RJ-45 to DB-9 female cable
• S5232F-ON, S5248F-ON, S5296F-ON, and S5224F-ON: Ground lug kit
• S5232F-ON, S5248F-ON, S5296F-ON, and S5224F-ON: Two hot-swappable PSUs
• S5232F-ON, S5248F-ON, S5296F-ON, and S5224F-ON: Four hot-swappable fan units
• S5212F-ON: Two xed PSUs
• S5212F-ON: one USB extension cable; male to female
• S5212F-ON: Two xed fan units
• S5296F-ON: one USB extension cable; male to female
• Two country- and region-specic AC power cables
•S5200F-ON Series Set-up Guide
•Safety and Regulatory Information
•Warranty and Support Information
1 Place the container on a clean, at surface and cut all straps securing the container.
2 Open the container, or remove the container top.
3 Carefully remove the switch from the container and place it on a secure and clean
surface.
4 Remove all packing material.
5 Inspect the product and accessories for damage.
12 S5200F-ON Series switch Installation

Ground cable
To attach a ground cable to the switch, use the included M4 screws.
NOTE: For an AC-powered switch, although the third conductor of the AC power
cord provides a ground path, Dell EMC recommends grounding your switch with a
dedicated ground wire.
NOTE: For a DC-powered switch, the only way to safely ground your switch is to
attach a dedicated ground wire. The ground lug kit ships in a plastic bag placed with
the other accessories inside the shipping box. The ground lug bracket screws ship
attached to the switch. Before you install the DC switch in the dual-tray, attach the
ground lug and bracket to the switch using the included screws and then attach the
DC ground wire to the ground lug.
The ground cable is not included. The grounding lugs must be a UL-recognized, crimp-type
lug.
CAUTION: Grounding conductors must be made of copper. Do not use aluminum
conductors.
NOTE: Coat the one-hole lug with an anti-oxidant compound before crimping. Also,
bring any unplated mating surfaces to a shiny nish and coat with an anti-oxidant
before mating. Plated mating surfaces must be clean and free from contamination.
NOTE: The rack installation ears are not suitable for grounding.
To connect the ground cable to the switch:
1 Cut the user-supplied ground cable to the desired length.
The cable length must facilitate proper operation of the fault interrupt circuits. Use the
shortest cable route allowable.
2 Crimp the ground cable inside the pre-installed ground lug.
3 Attach the other end of the ground cable to a suitable ground point such as the rack or
cabinet.
The rack installation ears are not a suitable grounding point.
Rack or cabinet installation
You may either place the switch on a rack shelf or mount the switch directly into a 19" wide,
EIA-310- E-compliant rack. Rack mounting for the S5232F-ON, S5248F-ON, and S5224F-
S5200F-ON Series switch Installation 13

ON switches includes four-post, two-post, round threaded holes, or square holes. The
ReadyRails system is provided for 1U front-rack and two-post installations.
Do not use the ReadyRails system for the S5296F-ON or S5212F-ON switches. For the
S5296F-ON switch, see Two U four-post rack assembly. For the S5212F-ON switch, see
One-half U front-rack installation.
The ReadyRails system includes two separately packaged rail assemblies. To begin
installation, separate each rail assembly by sliding the inside rail out of the outside rail.
WARNING: This guide is a condensed reference. Read the safety instructions in
your Safety, Environmental, and Regulatory information booklet before you begin.
NOTE: The illustrations in this section are not intended to represent a specic
switch.
NOTE: Do not the use the mounted ReadyRails as a shelf or a workplace.
Rack mount safety considerations
• Rack loading—Overloading or uneven loading of racks may result in shelf or rack failure,
possibly damaging the equipment and causing personal injury. Stabilize racks in a
permanent location before loading begins. Mount the components starting at the
bottom of the rack, then work to the top. Do not exceed your rack’s load rating.
• Power considerations—Connect only to the power source specied on the unit. When
you install multiple electrical components in a rack, ensure that the total component
power ratings do not exceed the circuit capabilities. Overloaded power sources and
extension cables are re and shock hazards.
• Elevated ambient temperature—If you install the switch in a closed rack assembly, the
operating temperature of the rack environment may be greater than the room ambient
temperature. Use care not to exceed the 45°C (113°F) maximum ambient temperature
of the switch.
• Reduced airow—Do not compromise the amount of airow needed for safe operation
of the equipment. Install the equipment in the rack so that the equipment constantly
has the correct amount of airow surrounding it.
• Reliable earthing—Maintain reliable earthing of rack-mounted equipment. Pay particular
attention to the supply connections other than the direct connections to the branch
circuit, for example: use of power strips.
• Do not mount the equipment with the fan panel facing in the downward position.
14 S5200F-ON Series switch Installation

One-half U front-rack installation
Install the S5212F-ON switch using the following installation instructions.
NOTE: To install the S5232F-ON, S5248F-ON, or S5224F-ON switch, see One U
ReadyRails installation. To install the S5296F-ON switch, see Two U four-post rack
assembly.
The dual-tray mounting rails ship with the dual tray, not with the switch. You must supply
eight rackmount screws for this installation.
To install the one-half U switch:
• Attach the rails to the dual tray.
• Install the dual tray in the four-post rack.
• (Recommended) Attach the ground cable to the switch.
• Install the switch in the dual tray.
NOTE: Do not install the dual tray in a two-post rack.
1 Remove the dual tray and the rails from the shipping packaging and place them on a
clean antistatic surface.
2 Line up the three holes on the inner switch rail with the dual-tray mounting heads.
Figure 2. Dual-tray and rack mounting rail
3 Attach the rail to the dual tray. Slide the rail back until it locks into place.
4 Repeat with the other side.
S5200F-ON Series switch Installation 15

Figure 3. Attach dual-tray and rack mounting rails
5 Install the dual tray inside the four-post rack. Rackmount screws are not included.
6 Attach the front dual-tray switch rails to the four-post rack from the front. Secure the
dual tray to the rack using two user-supplied screws for each rack post.
Figure 4. Attach the dual-tray front to the four-post rack front
7 Attach the rear dual-tray switch rails to the four-post rack from the rear. Secure the
dual tray to the rack using two user-supplied screws for each rack post.
16 S5200F-ON Series switch Installation

Figure 5. Attach the dual-tray rear to the four-post rack rear
8 Tighten all mounting screws to securely mount the dual tray into the four-post rack.
Figure 6. Secure the dual-tray in the four-post rack
One-half U switch installation
Install one or two half-U switches in the four-post rack-mounted dual tray.
1 Install one switch into either dual-tray slot from the front.
S5200F-ON Series switch Installation 17

Figure 7. Install one-half U switch
The switch is fully inserted when it presses the stop feature on the dual tray. The front
switch latch snaps the switch into place.
Figure 8. Dual-tray stop feature
2 Insert the second switch in the open dual-tray slot if you are installing two switches.
18 S5200F-ON Series switch Installation

One-half U switch removal
Remove the S5212F-ON switch from the dual tray from the front of the four-post rack.
NOTE: To remove the S5232F-ON, S5248F-ON, or S5224F-ON switch, see One U
ReadyRails installation. To remove the S5296F-ON switch, see Two U four-post
rack assembly.
Push in the front switch latches according to the latch arrows and pull out the switch.
Figure 9. Switch release latches
Figure 10. Switch release arrow
One U ReadyRails installation
For the S5248F-ON, S5232F-ON, and S5224F-ON switches, you can install the ReadyRails
system using the 1U tool-less square-hole method or one of three possible 1U threaded
S5200F-ON Series switch Installation 19

round-hole methods. The tooled installation methods include two-post ush mount, two-
post center mount, or four-post threaded mount.
NOTE: To install the S5212F-ON switch, see One-half U front-rack installation. To
install the S5296F-ON switch, see Two U four-post rack assembly.
To begin installation, separate each rail assembly by sliding the inside rail out of the outside
rail.
NOTE: For more installation instructions, see the installation labels attached to the
rail assembly.
Figure 11. Separate rails
20 S5200F-ON Series switch Installation
