H3C S6520X-EI Series User manual

1 Product models and technical
specifications
Product models
H3C S6520X-EI switch series includes the following models:
•
S6520X-30QC-EI
•
S6520X-54QC-EI
•
S6520X-30HC-EI
•
S6520X-54HC-EI
•
S6520X-30HF-EI
•
S6520X-54HF-EI
H3C S6520X-HI switch series includes the following models:
•
S6520X-30QC-HI
•
S6520X-54QC-HI
•
S6520X-30HC-HI
•
S6520X-54HC-HI
•
S6520X-30HF-HI
•
S6520X-54HF-HI
Technical specifications
Table1-1 Technical specifications (1)
Item S6520X-30QC-EI
S6520X-30QC-HI
S6520X-54QC-EI
S6520X-54QC-HI
S6520X-30HC-EI
S6520X-30HC-HI
S6520X-54HC-EI
S6520X-54HC-HI
Dimensions
(H × W × D)
43.6 × 440 × 360 mm
(1.72 × 17.32 × 14.17
in)
43.6 × 440 × 360
mm (1.72 × 17.32 ×
14.17 in)
43.6 × 440 × 360 mm
(1.72 × 17.32 × 14.17
in)
43.6 × 440 × 360
mm (1.72 × 17.32 ×
14.17 in)
Weight ≤7.0 kg (15.43 lb) ≤7.2 kg (15.87 lb) ≤7.4 kg (16.31 lb) ≤7.6 kg (16.75 lb)
Console port
•1 × micro USB console port
•1 × serial console port
Only the micro USB console port is available when you connect both ports.
USB port 1 1 1 1
Management
Ethernet port 1 1 1 1
QSFP+ port 2 2 N/A N/A
SFP+ port 24 48 24 48
QSFP28 port N/A N/A 2 2
Expansion
2, on the rear panel 2, on the rear panel 2, on the rear panel 2, on the rear panel

Item S6520X-30QC-EI
S6520X-30QC-HI
S6520X-54QC-EI
S6520X-54QC-HI
S6520X-30HC-EI
S6520X-30HC-HI
S6520X-54HC-EI
S6520X-54HC-HI
slot
Power supply
slot 2, on the rear panel 2, on the rear panel 2, on the rear panel 2, on the rear panel
Fan tray slot 2, on the rear panel 2, on the rear panel 2, on the rear panel 2, on the rear panel
Input voltage
•AC input for the PSR250-12A/PSR250-12A1 power supply:
Rated voltage range: 100 to 240 VAC @ 50/60 Hz
Max voltage range: 90 to 264 VAC @ 47 to 63 Hz
•High-voltage DC input for the PSR250-12A/PSR250-12A1 power supply:
Rated voltage range: 240 VDC
Max voltage range: 180 to 320 VDC
•PSR450-12D power supply:
Rated voltage range: –48 to –60 VDC
Max voltage range: –36 to –72 VDC
Minimum
power
consumption
•38 W with one
PSR250-12A/P
SR250-12A1
•43 W with two
PSR250-12A/P
SR250-12A1
•40 W with one
PSR450-12D
•45 W with two
PSR450-12D
•39 W with one
PSR250-12A/
PSR250-12A1
•44 W with two
PSR250-12A/
PSR250-12A1
•41 W with one
PSR450-12D
•46 W with two
PSR450-12D
•38 W with one
PSR250-12A/P
SR250-12A1
•43 W with two
PSR250-12A/P
SR250-12A1
•40 W with one
PSR450-12D
•45 W with two
PSR450-12D
•44 W with one
PSR250-12A/P
SR250-12A1
•49 W with two
PSR250-12A/P
SR250-12A1
•46 W with one
PSR450-12D
•51 W with two
PSR450-12D
Maximum
power
consumption
•179 W with one
PSR250-12A/P
SR250-12A1
•183 W with two
PSR250-12A/P
SR250-12A1
•181 W with one
PSR450-12D
•185 W with two
PSR450-12D
•231 W with
one
PSR250-12A/
PSR250-12A1
•234 W with
two
PSR250-12A/
PSR250-12A1
•233 W with
one
PSR450-12D
•236 W with
two
PSR450-12D
•197 W with one
PSR250-12A/P
SR250-12A1
•200 W with two
PSR250-12A/P
SR250-12A1
•199 W with one
PSR450-12D
•202 W with two
PSR450-12D
•249 W with one
PSR250-12A/P
SR250-12A1
•251 W with two
PSR250-12A/P
SR250-12A1
•251 W with one
PSR450-12D
•253 W with two
PSR450-12D
Melting
current of
power supply
fuse
•PSR250-12A/PSR250-12A1:
AC input: 6.3 A/250 VAC
High-voltage DC input: 6.3 A/250 VDC
•PSR450-12D: 20 A/125 V
Operating
temperature –5°C to +45°C (23°F to 113°F)
Humidity 5% RH to 95% RH, noncondensing
Security
compliance UL 60950-1/EN 60950-1/IEC 60950-1/GB4943.1

Table1-2 Technical specifications (2)
Item S6520X-30HF-EI S6520X-54HF-EI S6520X-30HF-HI S6520X-54HF-HI
Dimensions
(H × W × D)
44 × 440 × 360 mm
(1.73 × 17.32 ×
14.17 in)
44 × 440 × 360 mm
(1.73 × 17.32 ×
14.17 in)
44 × 440 × 360 mm
(1.73 × 17.32 ×
14.17 in)
44 × 440 × 360 mm
(1.73 × 17.32 ×
14.17 in)
Weight ≤5.5 kg (12.13 lb) ≤6.0 kg (13.23 lb) ≤6.0 kg (13.23 lb) ≤6.5 kg (14.33 lb)
Console port 1 × serial console port
Management
Ethernet port 1 1 1 1
USB port 1 1 1 1
SFP+ port 24 48 24 48
QSFP28 port 6 6 6 6
Fan tray slot 3 3 3 3
Power supply
slot 2 2 2 2
Input voltage AC input for the PSR180-12A-F/PSR180-12A-B power supply:
•Rated voltage range: 100 to 240 VAC @ 50/60 Hz
•Max voltage range: 90 to 264 VAC @ 47 to 63 Hz
Minimum
power
consumption
•29 W with one
PSR180-12A-F
/PSR180-12A-
B
•35 W with two
PSR180-12A-F
/PSR180-12A-
B
•29 W with one
PSR180-12A-F
/PSR180-12A-
B
•36 W with two
PSR180-12A-F
/PSR180-12A-
B
•38 W with one
PSR180-12A-F
/PSR180-12A-
B
•46 W with two
PSR180-12A-F
/PSR180-12A-
B
•36 W with one
PSR180-12A-F
/PSR180-12A-
B
•44 W with two
PSR180-12A-F
/PSR180-12A-
B
Maximum
power
consumption
•131 W with one
PSR180-12A-F
/PSR180-12A-
B
•134 W with two
PSR180-12A-F
/PSR180-12A-
B
•162 W with one
PSR180-12A-F
/PSR180-12A-
B
•163 W with two
PSR180-12A-F
/PSR180-12A-
B
•143 W with one
PSR180-12A-F
/PSR180-12A-
B
•145 W with two
PSR180-12A-F
/PSR180-12A-
B
•176 W with one
PSR180-12A-F
/PSR180-12A-
B
•177 W with two
PSR180-12A-F
/PSR180-12A-
B
Melting
current of
power supply
fuse
6.3 A @ 250 VAC
Operating
temperature –5°C to +45°C (23°F to 113°F)
Humidity 5% RH to 95% RH, noncondensing
Safety
specification
compliance UL 62368-1/EN 62368-1/IEC 62368-1/UL 60950-1/EN 60950-1/IEC 60950-1/GB4943.1

2 Chassis views
S6520X-30QC-EI & S6520X-30QC-HI
Figure2-1 Front panel
(1) SFP+ port
(2) SFP+ port LED
(3) Management Ethernet port
(4) Console port (CONSOLE)
(5) Micro USB console port
(6) Mode LED (MODE)
(7) USB port
(8) Mode button
(9) System status LED (SYS)
(10) Expansion card 2 status LED (SLOT2)
(11) Expansion card 1 status LED (SLOT1)
(12) Power supply 2 status LED (PWR2)
(13) Power supply 1 status LED (PWR1)
(14) QSFP+ port LED
(15) QSFP+ port
(16) Management Ethernet port LED (ACT/LINK)
Figure2-2 Rear panel
(1) Grounding screw
(2) Fan tray 1 (FAN1)
(3) Expansion card 1 (SLOT1)
(4) Expansion card 2 (SLOT2)
(5) Fan tray 2 (FAN2)
(6) Power supply 1 (PWR1)
(7) Power supply 2 (PWR2)
The S6520X-30QC-EI and S6520X-30QC-HI switches come with power supply slot PWR1 empty
and power supply slot PWR2 installed with a filler panel. You can install one or two power supplies for
the switch as required. In Figure2-2, two PSR250-12A1 power supplies are installed in the power
supply slots.
The S6520X-30QC-EI and S6520X-30QC-HI switches come with the two fan tray slots empty. You
must install two fan trays of the same model for the switch. In Figure2-2, two LSWM1FANSCBE fan
trays are installed in the fan tray slots.
The S6520X-30QC-EI and S6520X-30QC-HI switches come with a filler panel in each expansion
slot. You can select expansion cards for the switch as required. In Figure2-2, two LSWM4SP8PM
interface modules are installed in the expansion slots.
123456
7
12
11
10
8
13
14
15
9
16
1 2 3 4 5 6 7

S6520X-54QC-EI & S6520X-54QC-HI
Figure2-3 Front panel
(1) SFP+ port
(2) SFP+ port LED
(3) Management Ethernet port
(4) Console port (CONSOLE)
(5) Micro USB console port
(6) Mode LED (MODE)
(7) USB port
(8) Mode button
(9) System status LED (SYS)
(10) Expansion card 2 status LED (SLOT2)
(11) Expansion card 1 status LED (SLOT1)
(12) Power supply 2 status LED (PWR2)
(13) Power supply 1 status LED (PWR1)
(14) QSFP+ port LED
(15) QSFP+ port
(16) Management Ethernet port LED (ACT/LINK)
Figure2-4 Rear panel
(1) Grounding screw
(2) Fan tray 1 (FAN1)
(3) Expansion card 1 (SLOT1)
(4) Expansion card 2 (SLOT2)
(5) Fan tray 2 (FAN2)
(6) Power supply 1 (PWR1)
(7) Power supply 2 (PWR2)
The S6520X-54QC-EI and S6520X-54QC-HI switches come with power supply slot PWR1 empty
and power supply slot PWR2 installed with a filler panel. You can install one or two power supplies for
the switch as required. In Figure2-4, two PSR250-12A1 power supplies are installed in the power
supply slots.
The S6520X-54QC-EI and S6520X-54QC-HI switches come with the two fan tray slots empty. You
must install two fan trays of the same model for the switch. In Figure2-4, two LSWM1FANSCBE fan
trays are installed in the fan tray slots.
The S6520X-54QC-EI and S6520X-54QC-HI switches come with a filler panel in each expansion
slot. You can select expansion cards for the switch as required. In Figure2-4, two LSWM4SP8PM
interface modules are installed in the expansion slots.
1
12
11
10
8
7
6
234 5
13
14
15
16
9
1 2 3 4 5 67

S6520X-30HC-EI & S6520X-30HC-HI
Figure2-5 Front panel
(1) SFP+ port
(2) SFP+ port LED
(3) Management Ethernet port
(4) Console port (CONSOLE)
(5) Micro USB console port
(6) Mode LED (MODE)
(7) USB port
(8) Mode button
(9) System status LED (SYS)
(10) Expansion card 2 status LED (SLOT2)
(11) Expansion card 1 status LED (SLOT1)
(12) Power supply 2 status LED (PWR2)
(13) Power supply 1 status LED (PWR1)
(14) QSFP28 port LED
(15) QSFP28 port
(16) Management Ethernet port LED (ACT/LINK)
Figure2-6 Rear panel
(1) Grounding screw
(2) Fan tray 1 (FAN1)
(3) Expansion card 1 (SLOT1)
(4) Expansion card 2 (SLOT2)
(5) Fan tray 2 (FAN2)
(6) Power supply 1 (PWR1)
(7) Power supply 2 (PWR2)
The S6520X-30HC-EI and S6520X-30HC-HI switches come with power supply slot PWR1 empty
and power supply slot PWR2 installed with a filler panel. You can install one or two power supplies for
the switch as required. In Figure2-6, two PSR250-12A1 power supplies are installed in the power
supply slots.
The S6520X-30HC-EI & S6520X-30HC-HI switches come with the two fan tray slots empty. You
must install two fan trays of the same model for the switch. In Figure2-6, two LSWM1FANSCBE fan
trays are installed in the fan tray slots.
The S6520X-30HC-EI & S6520X-30HC-HI switches come with a filler panel in each expansion slot.
You can select expansion cards for the switch as required. In Figure2-6, two LSWM4SP8PM
interface modules are installed in the expansion slots.
123456
7
12
11
10
8
13
14
15
9
16
1 2 3 4 5 6 7

S6520X-54HC-EI & S6520X-54HC-HI
Figure2-7 Front panel
(1) SFP+ port
(2) SFP+ port LED
(3) Management Ethernet port
(4) Console port (CONSOLE)
(5) Micro USB console port
(6) Mode LED (MODE)
(7) USB port
(8) Mode button
(9) System status LED (SYS)
(10) Expansion card 2 status LED (SLOT2)
(11) Expansion card 1 status LED (SLOT1)
(12) Power supply 2 status LED (PWR2)
(13) Power supply 1 status LED (PWR1)
(14) QSFP28 port LED
(15) QSFP28 port
(16) Management Ethernet port LED (ACT/LINK)
Figure2-8 Rear panel
(1) Grounding screw
(2) Fan tray 1 (FAN1)
(3) Expansion card 1 (SLOT1)
(4) Expansion card 2 (SLOT2)
(5) Fan tray 2 (FAN2)
(6) Power supply 1 (PWR1)
(7) Power supply 2 (PWR2)
The S6520X-54HC-EI and S6520X-54HC-HI switches come with power supply slot PWR1 empty
and power supply slot PWR2 installed with a filler panel. You can install one or two power supplies for
the switch as required. In Figure2-8, two PSR250-12A1 power supplies are installed in the power
supply slots.
The S6520X-54HC-EI and S6520X-54HC-HI switches come with the two fan tray slots empty. You
must install two fan trays of the same model for the switch. In Figure2-4, two LSWM1FANSCBE fan
trays are installed in the fan tray slots.
The S6520X-54HC-EI and S6520X-54HC-HI switches come with a filler panel in each expansion slot.
You can select expansion cards for the switch as required. In Figure2-4, two LSWM4SP8PM
interface modules are installed in the expansion slots.
1
12
11
10
8
7
6
2345
13
14
15
16
9
1 2 3 4 5 67

S6520X-30HF-EI & S6520X-30HF-HI
Figure2-9 Front panel
(1) SFP+ port
(2) SFP+ port LED
(3) QSFP28 port
(4) QSFP28 port LED
(5) System status LED (SYS)
Figure2-10 Rear panel
(1) Management Ethernet port
(2) Console port (CONSOLE)
(3) USB port
(4) Fan tray 1 (FAN1)
(5) Fan tray 2 (FAN2)
(6) Fan tray 3 (FAN3)
(7) Power supply 1 (PWR1)
(8) Power supply 2 (PWR2)
(9) Reset button (RESET)
(10) Management Ethernet port LED (ACT/LINK)
(11) Grounding screw
The S6520X-30HF-EI and S6520X-30HF-HI switches come with power supply slot PWR1 empty
and power supply slot PWR2 installed with a filler panel. You can install one or two power supplies for
the switch as required. In Figure2-10, two PSR180-12A-B power supplies are installed in the power
supply slots.
The S6520X-30HF-EI and S6520X-30HF-HI switches come with the three fan tray slots empty. You
must install three fan trays of the same model for the switch. In Figure2-10, three LSPM1FANSB-SN
fan trays are installed in the fan tray slots.
The S6520X-30HF-EI and S6520X-30HF-HI switches come with a reset button RESET. You can
press the button to reboot the device.

S6520X-54HF-EI & S6520X-54HF-HI
Figure2-11 Front panel
(1) SFP+ port
(2) SFP+ port LED
(3) QSFP28 port
(4) QSFP28 port LED
(5) System status LED (SYS)
Figure2-12 Rear panel
(1) Management Ethernet port
(2) Console port (CONSOLE)
(3) USB port
(4) Fan tray 1 (FAN1)
(5) Fan tray 2 (FAN2)
(6) Fan tray 3 (FAN3)
(7) Power supply 1 (PWR1)
(8) Power supply 2 (PWR2)
(9) Reset button (RESET)
(10) Management Ethernet port LED (ACT/LINK)
(11) Grounding screw
The S6520X-54HF-EI and S6520X-54HF-HI switches come with power supply slot PWR1 empty
and power supply slot PWR2 installed with a filler panel. You can install one or two power supplies for
the switch as required. In Figure2-12, two PSR180-12A-B power supplies are installed in the power
supply slots.
The S6520X-54HF-EI and S6520X-54HF-HI switches come with the three fan tray slots empty. You
must install three fan trays of the same model for the switch. In Figure2-12, three LSPM1FANSB-SN
fan trays are installed in the fan tray slots.
The S6520X-54HF-EI and S6520X-54HF-HI switches come with a reset button (RESET). You can
press the button to reboot the device.

3 Removable components and
compatibility matrixes
Table3-1 Compatibility matrix between switches and removable components
FRU
model
S6520X-30QC-EI
S6520X-30QC-HI
S6520X-54QC-EI
S6520X-54QC-HI
S6520X-30HC-EI
S6520X-30HC-HI
S6520X-54HC-EI
S6520X-54HC-HI
S6520X-30HF-EI
S6520X-54HF-EI
S6520X-30HF-HI
S6520X-54HF-HI
Removable power supplies
PSR250-12
A Supported Supported Not supported
PSR250-12
A1 Supported Supported Not supported
PSR450-12
D Supported Supported Not supported
PSR180-12
A-F Not supported Not supported Supported
PSR180-12
A-B Not supported Not supported Supported
Removable fan trays
LSWM1FAN
SCE Supported Supported Not supported
LSWM1FAN
SCBE Supported Supported Not supported
LSPM1FAN
SA-SN Not supported Not supported Supported
LSPM1FAN
SB-SN Not supported Not supported Supported
Expansion cards
LSWM2QP2
P Supported Supported Not supported
LSWM2SP8
P Supported Supported Not supported
LSWM4SP8
PM Supported Supported Not supported
LSWM2ZQP
2P Not supported Supported Not supported
LSWM2ZSP
8P Not supported Supported Not supported
LSPM6FWD Supported Supported Not supported
LSPM6FWD
Supported Supported Not supported

FRU
model
S6520X-30QC-EI
S6520X-30QC-HI
S6520X-54QC-EI
S6520X-54QC-HI
S6520X-30HC-EI
S6520X-30HC-HI
S6520X-54HC-EI
S6520X-54HC-HI
S6520X-30HF-EI
S6520X-54HF-EI
S6520X-30HF-HI
S6520X-54HF-HI
8
LSWM2XM
GT8P Supported Supported Not supported
LSWM2MG
T8P Supported Supported Not supported
LSWM2ZSP
2P Supported Supported Not supported
LSWM2SP2
PB Supported Supported Not supported
LSWM2SP4
PB Supported Supported Not supported
Removable power supplies
The switch uses removable power supplies and supports the PSR250-12A, PSR250-12A1,
PSR450-12D, PSR180-12A-F, and PSR180-12A-B power supplies.
You can install one power supply, or two power supplies in 1+1 redundancy for the switch.
Table3-2 Power supplies available for the switch
Power supply
model AC or DC input Specifications Reference
PSR250-12A
PSR250-12A1
AC input
•Rated input voltage range: 100 to
240 VAC @ 50/60 Hz
•Max input voltage range: 90 to 264
VAC @ 47 to 63 Hz
•Max output power: 250 W H3C PSR250-12A &
PSR250-12A1 Power
Modules User Manual
High-voltage
DC input
•Rated input voltage range: 240
VDC
•Max input voltage range: 180 to
320 VDC
•Max output power: 250 W
PSR450-12D DC input
•Rated input voltage range: –48 to –
60 VDC
•Max input voltage range: –36 to –
72 VDC
•Max output power: 450 W
H3C PSR450 Power Supply
Series User Guide
PSR180-12A-F AC input
•Rated input voltage range: 100 to
240 VAC @ 56/60 Hz
•Max input voltage range: 90 to 264
VAC @ 47 to 63 Hz
•Max output power: 180 W
•Melting current of power supply
fuse: 6.3 A/250 V
H3C PSR180-12A &
PSR180-12D Power Supply
Series User Manual
PSR180-12A-B AC input •
Rated input voltage range: 100 to
H3C PSR180-12A &

Power supply
model AC or DC input Specifications Reference
240 VAC @ 56/60 Hz
•Max input voltage range: 90 to 264
VAC @ 47 to 63 Hz
•Max output power: 180 W
•Melting current of power supply
fuse: 6.3 A/250 V
PSR180-12D Power Supply
Series User Manual
Removable fan trays
CAUTION:
You can power on the switch only when the switch has all fan trays of the same model installed.
The switch uses removable fan trays and supports the LSWM1FANSCE, LSWM1FANSCBE,
LSPM1FANSA-SN, and LSPM1FANSB-SN fan trays.
Table3-3 LSWM1FANSCE and LSWM1FANSCBE fan tray specifications
Item Specifications
Dimensions (H × W × D) 40 × 40 × 56 mm (1.57 × 1.57 × 2.20 in)
Fan speed 21000 R.P.M
Max airflow 26 CFM
Input voltage 12 V
Maximum power consumption 27.72 W
Airflow direction •LSWM1FANSCE—From the power supply side to the port side
•LSWM1FANSCBE—From the port side to the power supply side
Reference H3C LSWM1FANSCE & LSWM1FANSCBE Fan Trays User Guide
Table3-4 LSPM1FANSA-SN and LSPM1FANSB-SN fan tray specifications
Item Specifications
Dimensions (H × W × D) 40 × 40.6 × 105 mm (1.57 × 1.60 × 4.13 in)
Fan speed 20000 R.P.M
Max airflow 20 CFM
Input voltage 12 V
Maximum power consumption 9.8 W
Airflow direction •LSPM1FANSA-SN—From the power supply side to the port side
•LSPM1FANSB-SN—From the port side to the power supply side
Reference H3C LSPM1FANSA-SN & LSPM1FANSB-SN Fan Trays User Guide

Expansion cards
Table3-5 Expansion card specifications
Item Specifications
LSWM2QP2P
Description 2-port 40GE QSFP+ interface module
Port type and quantity Two 40 Gbps QSFP+ fiber ports
Available transceiver modules
and cables QSFP+ transceiver modules and cables described in Table4-9, Table4-10, and Table4-11.
Reference H3C LSWM2QP2P Interface Card User Manual
LSWM2SP8P
Description 8-port 10GE SFP+ interface module
Port type and quantity Eight 1/10 Gbps SFP+ fiber ports
Available transceiver modules
and cables
See GE SFP transceiver modules and cables described in Table4-3 and
10-GE SFP+ transceiver modules and cables described in Table4-4 and
Table4-5.
Reference H3C LSWM2SP8PM & LSWM2SP8P Interface Cards User Manual
LSWM4SP8PM
Description 8-port 10GE SFP+ interface module
Port type and quantity Eight 1/10 Gbps SFP+ fiber ports
Available transceiver modules
and cables
See GE SFP transceiver modules and cables described in Table4-3 and
10-GE SFP+ transceiver modules and cables described in Table4-4 and
Table4-5.
Reference H3C LSWM4SP8PM Interface Card User Manual
LSWM2ZQP2P
Description 2-port 100GE QSFP28 interface module
Port type and quantity Two 40/100 Gbps QSFP28 fiber ports
Available transceiver modules
and cables
See QSFP+ transceiver modules and cables described in Table4-9,
Table4-10, and Table4-11 and QSFP28 transceiver modules and cables
described in Table4-13, Table4-14, and Table4-15.
Reference H3C LSWM2ZQP2P Interface Card User Manual
LSWM2ZSP8P
Description 8-port 25GE SFP28 interface module
Port type and quantity Eight 25 Gbps SFP28 fiber ports
Available transceiver modules
and cables See SFP28 transceiver modules and cables described in Table4-7 and Table4-8.
Reference H3C LSWM2ZSP8P Interface Card User Manual
LSPM6FWD
Description The card is a fourth-generation high performance firewall module. It
provides features including firewall, VPN, content filtering, content
identification, URL filtering, and NAT. By using this card on a switch, you

Item Specifications
can enhance the switch security capabilities without changing the network
topology.
Reference H3C LSPM6FWD Card Manual
LSPM6FWD8
Description
The card is a fourth-generation high performance firewall module. It
provides features including firewall, VPN, content filtering, content
identification, URL filtering, and NAT. By using this card on a switch, you
can enhance the switch security capabilities without changing the network
topology.
Reference H3C LSPM6FWD8 Card Manual
LSWM2XMGT8P
Description 8-port 1/2.5/5/10GBASE-T interface module
Port type and quantity Eight 10G/5G/2.5G/1000BASE-T autosensing Ethernet ports
Port specifications See Table4-16 for the port specifications.
Reference H3C LSWM2MGT8P & LSWM2XMGT8P Interface Cards User Manual
LSWM2MGT8P
Description 8-port 1/2.5/5GBASE-T interface module
Port type and quantity Eight 5G/2.5G/1000BASE-T autosensing Ethernet ports
Port specifications See Table4-17 for the port specifications.
Reference H3C LSWM2MGT8P & LSWM2XMGT8P Interface Cards User Manual
LSWM2ZSP2P
Description 2-port 25G SFP28 Ethernet optical interface module
Port type and quantity Two 25G SFP28 fiber ports
Available transceiver modules
and cables See the 25G SFP28 transceiver modules and SFP28 cables described in Table4-7 and Table4-8.
Reference H3C LSWM2ZSP2P Interface Card User Manual
LSWM2SP2PB
Description 2-port 10G SFP+ Ethernet optical interface module
Port type and quantity Two 1G/10G SFP+ fiber ports
Available transceiver modules
and cables
•See the GE SFP transceiver modules and SFP cables described in
Table4-3.
•See the 10-GE SFP+ transceiver modules and SFP+ cables
described in Table4-4, Table4-5, and Table4-6.
Reference H3C LSWM2SP2PB & LSWM2SP4PB Interface Cards User Manual
LSWM2SP4PB
Description 4-port 10G SFP+ Ethernet optical interface module
Port type and quantity Four 1G/10G SFP+ fiber ports
Available transceiver modules
and cables
•See the GE SFP transceiver modules and SFP cables described in
Table4-3.
•See the 10-GE SFP+ transceiver modules and SFP+ cables

Item Specifications
described in Table4-4, Table4-5, and Table4-6.
Reference H3C LSWM2SP2PB & LSWM2SP4PB Interface Cards User Manual
Connecting cables to the ports on interface modules
To connect cables to the ports on interface modules, follow these guidelines:
•
Do not bundle cables in their first 20 m (65.62 ft).
•
Separate power cords and twisted pair cables at and around the distribution frame.
•
For ports adjacent to one another on the device, the peer ports on the distribution frame is
preferably not adjacent, for example:
•
If the device connects to one distribution frame, connect port 1 on the device to port 1 on the
distribution frame and port 2 on the device to port 3 on the distribution frame.
•
If the device connects to two distribution frames, connect port 1 on the device to port 1 on
distribution frame 1 and port 2 on the device to port 1 on distribution frame 2.
•
Keep the device and cables away from the interference source, such as a two-way radio and a
high-power variable-frequency drive.

4 Ports and LEDs
Ports
Console port
Table4-1 Console port specifications
Item Serial console port Micro USB console port
Connector type RJ-45 Micro USB Type B
Compliant standard EIA/TIA-232 USB 2.0
Transmission baud rate 9600 bps (default) to 115200 bps
Services
•Provides connection to an ASCII
terminal.
•Providesconnection to the serial port
of a local PC running terminal
emulation program.
Provides connection to the USB port
of a local PC running terminal
emulation program.
Compatible devices All device models.
•S6520X-30QC-EI
•S6520X-54QC-EI
•S6520X-30HC-EI
•S6520X-54HC-EI
•S6520X-30QC-HI
•S6520X-54QC-HI
•S6520X-30HC-HI
•S6520X-54HC-HI
You cannot use both console ports at the same time. Only the Micro USB console port works when you
connect both ports.
Management Ethernet port
You can connect the management Ethernet port to a PC or management station for loading and
debugging software or remote management.
Table4-2 Management Ethernet port specifications
Item Specification
Connector type RJ-45
Port transmission rate •10/100 Mbps, half/full duplex, MDI/MDI-X autosensing
•1000 Mbps, full duplex, MDI/MDI-X autosensing
Transmission medium and max
transmission distance 100 m (328.08 ft) over category-5 twisted pair cable
Functions and services Switch software and Boot ROM upgrade, network management
Compatible devices All device models

USB port
The switch has one OHC-compliant USB2.0 port that can upload and download data at a rate up to
480 Mbps. You can use this USB port to access the file system on the flash of the switch, for example,
to upload or download application and configuration files.
NOTE:
USB devices from different vendors vary in compatibilities and drivers. H3C does not guarantee the
correct operation of USB devices from all vendors on the switch. If a USB device fails to operate on
the switch, replace it with one from another vendor.
SFP+ port
The switch provides fixed SFP+ ports on the front panel. The LSWM2SP2PB, LSWM2SP4PB,
LSWM4SP8PM, and LSWM2SP8P interface modules also provide SFP+ ports. To connect peer
SFP+ ports over a long distance, use SFP/SFP+ transceiver modules and fibers. To connect peer
SFP+ ports over a short distance, use SFP/SFP+ cables. You can install GE SFP transceiver
modules and cables in Table4-3, 10-GE SFP+ transceiver modules in Table4-4, and 10-GE SFP+
cables in Table4-5 in the SFP+ ports.
Table4-3 GE SFP transceiver modules and cables available for the SFP+ ports
GE SFP
transceiver
module and
cable
Central
wavelength
(nm) Connector Cable/Fiber
type and
diameter (µm)
Modal
bandwidth
(MHz × km)
Max
transmission
distance
GE SFP transceiver modules
SFP-GE-T N/A RJ-45 Twisted pair
cable N/A 100 m (328.08 ft)
SFP-GE-T-D N/A RJ-45 Twisted pair
cable N/A 100 m (328.08 ft)
SFP-GE-SX-M
M850-A 850 LC
Multi-mode,
50/125 500 550 m (1804.46 ft)
400 500 m (1640.42 ft)
Multi-mode,
62.5/125 200 275 m (902.23 ft)
160 220 m (721.78 ft)
SFP-GE-SX-M
M850-D 850 LC
Multi-mode,
50/125 500 550 m (1804.46 ft)
400 500 m (1640.42 ft)
Multi-mode,
62.5/125 200 275 m (902.23 ft)
160 220 m (721.78 ft)
SFP-GE-SX-M
M850-S 850 LC
Multi-mode,
50/125 500 550 m (1804.46 ft)
400 500 m (1640.42 ft)
Multi-mode,
62.5/125 200 275 m (902.23 ft)
160 220 m (721.78 ft)
SFP-GE-LX-SM
1310-A 1310 LC Single-mode,
9/125 N/A 10 km (6.21 miles)
Multi-mode,
500 or 400 550 m (1804.46 ft)

GE SFP
transceiver
module and
cable
Central
wavelength
(nm) Connector Cable/Fiber
type and
diameter (µm)
Modal
bandwidth
(MHz × km)
Max
transmission
distance
50/125
Multi-mode,
62.5/125 500 550 m (1804.46 ft)
SFP-GE-LX-SM
1310-D 1310 LC Single-mode, 9/125 N/A 10 km (6.21 miles)
SFP-GE-LX-SM
1310-S 1310 LC Single-mode, 9/125 N/A 10 km (6.21 miles)
SFP-GE-LH20-
SM1310-I 1310 LC Single-mode, 9/125 N/A 20 km (12.43 miles)
SFP-GE-LH40-
SM1310 1310 LC Single-mode, 9/125 N/A 40 km (24.86 miles)
SFP-GE-LH40-
SM1310-D 1310 LC Single-mode, 9/125 N/A 40 km (24.86 miles)
SFP-GE-LH40-
SM1550 1550 LC Single-mode, 9/125 N/A 40 km (24.86 miles)
SFP-GE-LH40-
SM1310-I 1310 LC Single-mode, 9/125 N/A 40 km (24.86 miles)
SFP-GE-LH80-
SM1550 1550 LC Single-mode, 9/125 N/A 80 km (49.71 miles)
SFP-GE-LH80-
SM1550-D 1550 LC Single-mode, 9/125 N/A 80 km (49.71 miles)
SFP-GE-LH100
-SM1550 1550 LC Single-mode, 9/125 N/A 100 km (62.14 miles)
SFP-GE-LX-SM
1310-BIDI TX: 1310
RX: 1490 LC Single-mode,
9/125 N/A 10 km (6.21 miles)
SFP-GE-LX-SM
1490-BIDI TX: 1490
RX: 1310 LC Single-mode,
9/125 N/A 10 km (6.21 miles)
SFP-GE-LH40-
SM1310-BIDI TX: 1310
RX: 1550 LC Single-mode,
9/125 N/A 40 km (24.86
miles)
SFP-GE-LH40-
SM1550-BIDI TX: 1550
RX: 1310 LC Single-mode,
9/125 N/A 40 km (24.86
miles)
SFP-GE-LH70-
SM1490-BIDI TX: 1490
RX: 1550 LC Single-mode,
9/125 N/A 70 km (43.50 miles)
SFP-GE-LH70-
SM1550-BIDI TX: 1550
RX: 1490 LC Single-mode,
9/125 N/A 70 km (43.50
miles)
GE SFP cable
SFP-STACK-Kit N/A N/A N/A N/A 1.5 m (4.92 ft)

IMPORTANT:
T
he SFP-GE-LX-SM1310-BIDI and SFP-GE-LX-SM1490-BIDI transceiver modules, the
SFP
-GE-LH40-SM1310-BIDI and SFP-GE-LH40-SM1550-BIDI transceiver modules, and the
SFP
-GE-LH70-SM1490-BIDI and SFP-GE-LH70-SM1550-BIDI transceiver modules must be used
in pairs. For example, if one end uses the
SFP-GE-LX-SM1310-BIDI
transceiver module, the other
end must use the SFP-GE-LX-SM1490-BIDI transceiver module.
Table4-4 10-GE SFP+ transceiver modules available for the SFP+ ports
10-GE SFP+
module
Central
wavelength
(nm) Connector Fiber
diameter
(µm)
Modal
bandwidth
(MHz × km)
Max
transmission
distance
SFP-XG-SX-M
M850-A 850 LC
Multi-mode,
50/125
2000 300 m (984.25 ft)
500 82 m (269.03 ft)
400 66 m (216.54 ft)
Multi-mode,
62.5/125 200 33 m (108.27 ft)
160 26 m (85.30 ft)
SFP-XG-SX-M
M850-D 850 LC
Multi-mode,
50/125
2000 300 m (984.25 ft)
500 82 m (269.03 ft)
400 66 m (216.54 ft)
Multi-mode,
62.5/125 200 33 m (108.27 ft)
160 26 m (85.30 ft)
SFP-XG-SX-M
M850-E 850 LC
Multi-mode,
50/125
2000 300 m (984.25 ft)
500 82 m (269.03 ft)
400 66 m (216.54 ft)
Multi-mode,
62.5/125 200 33 m (108.27 ft)
160 26 m (85.30 ft)
SFP-XG-SX-M
M850-S 850 LC
Multi-mode,
50/125
2000 300 m (984.25 ft)
500 82 m (269.03 ft)
400 66 m (216.54 ft)
Multi-mode,
62.5/125 200 33 m (108.27 ft)
160 26 m (85.30 ft)
SFP-XG-LX-S
M1310-D 1310 LC Single-mode,
9/125 N/A 10 km (6.21 miles)
SFP-XG-LX-S
M1310-E 1310 LC Single-mode,
9/125 N/A 10 km (6.21 miles)
SFP-XG-LX-S
M1310-S 1310 LC Single-mode,
9/125 N/A 10 km (6.21 miles)
SFP-XG-LH40
-SM1550 1550 LC Single-mode,
9/125 N/A 40 km (24.86 miles)
SFP-XG-LH40
-SM1550-D 1550 LC Single-mode,
9/125 N/A 40 km (24.86 miles)
SFP-XG-LH80 1550 LC Single-mode, N/A 80 km (49.71 miles)

10-GE SFP+
module
Central
wavelength
(nm) Connector Fiber
diameter
(µm)
Modal
bandwidth
(MHz × km)
Max
transmission
distance
-SM1550
9/125
SFP-XG-LH80
-SM1550-D 1550 LC Single-mode, 9/125 N/A 80 km (49.71 miles)
SFP-XG-LX-S
M1270-BIDI TX: 1270
RX: 1330 LC Single-mode,
9/125 N/A 10 m (32.81 ft)
SFP-XG-LX-S
M1330-BIDI TX: 1330
RX: 1270 LC Single-mode,
9/125 N/A 10 m (32.81 ft)
SFP-XG-LH40
-SM1270-BIDI TX: 1270
RX: 1330 LC Single-mode,
9/125 N/A 40 km (24.86 miles)
SFP-XG-LH40
-SM1330-BIDI TX: 1330
RX: 1270 LC Single-mode,
9/125 N/A 40 km (24.86 miles)
SFP-XG-LH80
-SM1490-BIDI TX: 1490
RX: 1550 LC Single-mode,
9/125 N/A 80 km (49.71 miles)
SFP-XG-LH80
-SM1550-BIDI TX: 1550
RX: 1490 LC Single-mode,
9/125 N/A 80 km (49.71 miles)
IMPORTANT:
•
The SFP-XG-LX-SM1270-BIDI and SFP-XG-LX-SM1330-BIDI transceiver modules must be
used in pairs. For example, if one end uses an SFP-XG-LX-SM1270-BIDI transceiver module,
the other end must use an SFP-XG-LX-SM1330-BIDI transceiver module.
•
The SFP-XG-LH40-SM1270-BIDI and SFP-XG-LH40-SM1330-BIDI transceiver modules must
be used in pairs. For example, if one end uses an SFP-XG-LH40-SM1270-BIDI transceiver
module, the other end must use an SFP-XG-LH40-SM1330-BIDI transceiver module.
•
The SFP-XG-LH80-SM1490-BIDI and SFP-XG-LH80-SM1550-BIDI transceiver modules must
be used in pairs. For example, if one end uses an SFP-XG-LH80-SM1490-BIDI transceiver
module, the other end must use an SFP-XG-LH80-SM1550-BIDI transceiver module.
Table4-5 SFP+ copper cables available for the SFP+ ports
SFP+ copper cable Cable length
LSWM1STK 0.65 m (2.13 ft)
LSWM2STK 1.2 m (3.94 ft)
LSWM3STK 3 m (9.84 ft)
LSTM1STK 5 m (16.40 ft)
Table4-6 SFP+ fiber cables available for the SFP+ ports
SFP+ fiber cable Cable length
SFP-XG-D-AOC-7M 7 m (22.97 ft)
SFP-XG-D-AOC-10M 10 m (32.81 ft)
SFP-XG-D-AOC-20M 20 m (65.62 ft)
