1 Overview
In these documents information about of LoRa Module DF702 Trash Bin Sensor are given
with detailed.
The function of device
Hardware interface
How to set LoRa module parameters
Equipment parameters (full height value, upload interval data etc)
Equipment upgrades
For more information if you have any questions, please contact us first.
2 Device Function Descriptions
Note
Device will upload data when its power is activated it can send us data automatically to the
user through LoRa Module.
Main Function of Device
LoRa Module DF702 Sensor can give detailed about the using place for example Trash Bin
its full Detection, fire detection, fall Detection , Full ,Half and Empty Condition of Device and
about the power Detection of Sensor.
Notes: the standard version does not have the fall detection, only the enhanced
version has this function.

Beijing Dingtek Technology Corp., Ltd. Tel:[phone]
http://www.dingtek.com E-mail: [e-mail]
Room A209, Flounder Business Park, Shunbai Road 12, Chaoyang District, Beijing, China 100022 Page 5
Data Time Intervals
For example Test time data every 10 minutes, when a change of state is detected the data
will be upload, the state remains unchanged in next intervals, and no data will be uploaded.
The data will be uploaded periodically like as heartbeat the data interval default 4 hours can
be modified, specific reference to the agreement.
State change means:
From full to not from
Not from to full
Main
Function
Functional
Descriptio
n
Default Alarm
Threshold
Whether the
data will be
reported
immediately
when the
alarm
condition is
reached
Remarks
Full
Check if the
Trash bin is
full
30cm
(Can be
modified)
No
The Device will detect
the Distance between
sensor and garbage if
this Distance is more
Then 30cm no alarm
if less than 30 cm
alarm will be
activated.
Fire
Detect if a
fire has
been
occurred
75℃
(Can be
modified above
75℃
Fire alarm will
be activated )
Yes
Detected temperature
is less than 75℃
above this
Temperature sensor
will activate the
alarm.
Fall
Check
whether the
trash Bin
can fallen
any side
This feature is
available in enhanced
version not in
slandered version.
Battery
Check if the
battery is
about to run
out
20%
(Can be
modified)
No
It will detect the
power of battery
more than 20% no
alarm less than 20%
alarm will be
activated.

Beijing Dingtek Technology Corp., Ltd. Tel:[phone]
http://www.dingtek.com E-mail: [e-mail]
Room A209, Flounder Business Park, Shunbai Road 12, Chaoyang District, Beijing, China 100022 Page 6
For example: Time State Upload data or no
10:10 full Yes (Battery Should be connected)
10:20 full No
10:30 not full Yes
10:40 not full No
10:50 full Yes
3 The Main LoRa Band Introduction
The main LoRa band are used given below CN470, EU868, US915, AU915, AS923.
4 Device Interface Definition
In the given figure, the power interface, module configuration debugging, interface, device
parameter configuration and upgrade interface are introduced respectively with detailed.
In figure 4.1 PCB board is shown and all connecting parts are also shown which part where
will be placed.
4.1 Connection of Hollow Sockets
Power socket: connect the battery
Hollow positions: Configure the LoRa module parameters or debug module the
jumper cap should be placed in a hollow position.
Solid position: The default position the device to transmit data/configure device
parameters such as data upload interval and full height the jumper cap should be
placed at right side a solid position.
Band
The default uplink
frequency
The default downlink
frequency(RXWIN1)
The default
downlink
frequency
（RXWIN2）
CN470
(470-510MHz)
470.3,470.5,470.7,470.9,
471.1,471.3,471.5,471.7,
500.3,500.5,500.7,500.
9
501.1,501.3,501.5,501.
7
505.3
EU868
(863-870MHz)
868.1,868.3,868.5
868.1,868.3,868.5
869.525
US915
(902-928MHz)
902.3,902.5,902.7,902.9,
903.1,903.3,903.5,903.7
923.3,923.9,924.5,925.
1
925.7,926.3,926.9,927.
5
923.3
AU915
(915-928MHz)
915.2,915.4,915.6,915.8
916.0,916.2,916.4,916.6
923.3,923.9,924.5,925.
1
925.7,926.3,926.9,927.
5
923.3
AS923
(915-928MHz)
923.2,923.4
923.2,923.4
923.2

Beijing Dingtek Technology Corp., Ltd. Tel:[phone]
http://www.dingtek.com E-mail: [e-mail]
Room A209, Flounder Business Park, Shunbai Road 12, Chaoyang District, Beijing, China 100022 Page 7
Figure4.1
4.2 Reverse side of picture of PCB board ( open the Screws of PCB Board) as shown in
figure 4.2.
TX
RX
GND
Hollow position
Solid position
Black part of the jumper cap,
the default in this position
This interface can be used to
modify Lora parameters as well
as debug module
This power socket is
used to connect the
Battery
+
-

Beijing Dingtek Technology Corp., Ltd. Tel:[phone]
http://www.dingtek.com E-mail: [e-mail]
Room A209, Flounder Business Park, Shunbai Road 12, Chaoyang District, Beijing, China 100022 Page 8
Figure4.2
5 Configure LoRa parameters
LoRa can be configured according to the relevant parameters such as devaddr, deveui and
nwkskey are helpful in configuration process.
Required tools for configuration of LoRa Device
TTL and its cable
Serial software
LoRa instruction manual
Equipment
TTL and cable for the goods accessories
Please check these two items when you receive package from company as shown in Figure
5.1 and Figure5.2.
GND
TX
RX
This interface is used to
configure device parameters
(data upload interval, full
height value, etc.), device
upgrade, or device
debugging.

Beijing Dingtek Technology Corp., Ltd. Tel:[phone]
http://www.dingtek.com E-mail: [e-mail]
Room A209, Flounder Business Park, Shunbai Road 12, Chaoyang District, Beijing, China 100022 Page 9
Figure5.1
Figure5.2
Serial software:
5.2 Connect TTL to sensor
Device Serial Port connection GND, TX, and RX locations have been marked on the diagram
as shown in Figure5.3.
TTL
TTL
Cable

Beijing Dingtek Technology Corp., Ltd. Tel:[phone]
http://www.dingtek.com E-mail: [e-mail]
Room A209, Flounder Business Park, Shunbai Road 12, Chaoyang District, Beijing, China 100022 Page 10
Figure5.3
Connect TTL to device, as shown in Figure 5.4.
Figure5.4
Steps
1 Change jumper cap to hollow position (default it is in the solid position) as shown in
figure5.5.
2 Connect the TTL to the device as shown in figure 5.4.
3 Connect the device's power supply, as shown in figure5.6.
GND
RX
TX

Beijing Dingtek Technology Corp., Ltd. Tel:[phone]
http://www.dingtek.com E-mail: [e-mail]
Room A209, Flounder Business Park, Shunbai Road 12, Chaoyang District, Beijing, China 100022 Page 11
Figure5.5
Figure5.6
5.3 Environment to Configuration of Device
1 Open the serial software when opening, the default information of serial port software is
shown in figure 5.7.
Jumper cap is in
hollow position

Beijing Dingtek Technology Corp., Ltd. Tel:[phone]
http://www.dingtek.com E-mail: [e-mail]
Room A209, Flounder Business Park, Shunbai Road 12, Chaoyang District, Beijing, China 100022 Page 12
Figure5.7
2 Select the serial of configuration of serial software
Port number ( you can select port Number from device manager of your system)
Set the baud rate: 115200, (DF702 is 115200 baud rate and DO100 is 9600)
Parity bit: NONE
Data bits: 8
Stop bit: 1
As shown in figure 5.8 you can follow the given instruction.

Beijing Dingtek Technology Corp., Ltd. Tel:[phone]
http://www.dingtek.com E-mail: [e-mail]
Room A209, Flounder Business Park, Shunbai Road 12, Chaoyang District, Beijing, China 100022 Page 13
Figure5.8
3 when you send as related commandos of configuration and related parameters to the
serial software, such as devaddr, nwkskey, etc. (please refer to the specific instruction format
LoRa instruction manual).
Sending First Command
send input command:AT+ID, (read all) as shown in figure5.8.
Response of Device
+ID: DevAddr, 01:7D:53:74
+ID: DevEui, 47:68:B2:69:00:2A:00:43
+ID: AppEui, 52:69:73:69:6E:67:48:46
Sending Second Command
AT+KEY=NWKSKEY,"6132f00ad1efd2d4af5e12f8ef745d8b" (set nwkskey),as shown in
figure5.9.
Response of Device
+KEY: NWKSKEY 6132F00AD1EFD2D4AF5E12F8EF745D8B
As shown below:

Beijing Dingtek Technology Corp., Ltd. Tel:[phone]
http://www.dingtek.com E-mail: [e-mail]
Room A209, Flounder Business Park, Shunbai Road 12, Chaoyang District, Beijing, China 100022 Page 14
Figure5.9
Reference instruction:
Set DEVADDR：
AT+ID=DevAddr, “4 bytes length hex identifier”
eg: AT+ID=DevAddr, "01234567"
Set DEVEUI：
AT+ID= DevEui, “8 bytes length hex identifier (64bits)”
eg: AT+ID=DevEui, "0123456789ABCDEF"
Set NWKSKEY：
AT+KEY=NWKSKEY, “16 bytes length key”
eg: AT+KEY=NWKSKEY,"2B7E151628AED2A6ABF7158809CF4F3C"
Set APPSKEY
AT+KEY=APPSKEY, “16 bytes length key”
eg:
AT+KEY=APPSKEY,"2B7E151628AED2A6ABF7158809CF4F3C"
Detailed instructions, please refer to the [RHF-PS01509] LoRawan Class AC AT Command
Specification - v4.3.pdf document
Note: If you are facing following problems you can overcome easy way.

Beijing Dingtek Technology Corp., Ltd. Tel:[phone]
http://www.dingtek.com E-mail: [e-mail]
Room A209, Flounder Business Park, Shunbai Road 12, Chaoyang District, Beijing, China 100022 Page 15
Make sure the position of the jumper cap is switched to the hollow position. If it is
placed at solid position module configuration cannot be completed.
Check if TTL and device RX, TX connection is correct, if the connection is wrong,
there will be no reply sending instructions.
Confirm the baud rate is the correct choice of baud rate, the correct should be
115200.
5.4 Video link
Configuration of Lora parameter DF702 Smart Trash Bin Sensor is shown with detailed you
can follow these instructions as well as click at video link .
https://youtu.be/nklTd88SPXI
6 Configurations of Relevant Parameters of Device
Through the configuration, you can also modify the relevant parameters of the device such
as alarm height value, temperature value, battery level and etc.
6.1 Required tools
A TTL and cable
Serial software
Equipment
Protocol manual
Figure6.1

Beijing Dingtek Technology Corp., Ltd. Tel:[phone]
http://www.dingtek.com E-mail: [e-mail]
Room A209, Flounder Business Park, Shunbai Road 12, Chaoyang District, Beijing, China 100022 Page 16
Figure6.2
Serial software :
6.2 Connect TTL to sensor
Device serial port GND, TX and RX positions have been marked on the diagram.Upper
diagram the connection of RX,TX,and GND is given with detailed if you not connect properly
then you cannot configure your device properly.

Beijing Dingtek Technology Corp., Ltd. Tel:[phone]
http://www.dingtek.com E-mail: [e-mail]
Room A209, Flounder Business Park, Shunbai Road 12, Chaoyang District, Beijing, China 100022 Page 17
Figure6.3
TTL and Device ports connection are shown in the figure 6.4.
Figure6.4
Steps:
1 Confirm that the jumper cap is at the solid position (jumper cap defaults to solid position)
as shown in figure6.5.
Figure6.5
2 Connect TTL to sensor, as shown in figure6.4 and figure6.6
Jumper cap is
in solid position

Beijing Dingtek Technology Corp., Ltd. Tel:[phone]
http://www.dingtek.com E-mail: [e-mail]
Room A209, Flounder Business Park, Shunbai Road 12, Chaoyang District, Beijing, China 100022 Page 18
Figure6.6
6.3 Use serial software to configure
Open the serial software
Select the serial port number
Set the baud rate: 115200
Parity bit: NONE
Data bits: 8
Stop bit: 1
Connect the device's power
When you see the serial port output sending instructions are in Hexadecimal then we
will change the format of serial software sending option .
Data is sent in hexadecimal format (please refer to instruction format for details) .

Beijing Dingtek Technology Corp., Ltd. Tel:[phone]
http://www.dingtek.com E-mail: [e-mail]
Room A209, Flounder Business Park, Shunbai Road 12, Chaoyang District, Beijing, China 100022 Page 19
Figure6.7
Note
Before sending the command, please first click the "enter" and then click Send .
Example 1: change upload time to an hour the instruction is: 99990101 as shown in Figure
6.8.

Beijing Dingtek Technology Corp., Ltd. Tel:[phone]
http://www.dingtek.com E-mail: [e-mail]
Room A209, Flounder Business Park, Shunbai Road 12, Chaoyang District, Beijing, China 100022 Page 20
Figure6.8
Note: For the format of the instruction, please refer to the protocol document of the
corresponding equipment.
Notes:
1. When the device is at Sleep mode sending instructions will be invalid.
2. Before sending instructions please click enter, and then send.
3. The command is sent in hexadecimal format except for configuring APN for details refer
to the protocol.
4. Check whether the RX and TX of the TTL and the device are correctly connected. If the
connection is reversed no output is displayed on the serial port after the device is powered
on, and the device cannot be configured.
