Diode Dynamics STAGE Series User manual

[phone] WWW.DIODEDYNAMICS.COM
PAGE 1
SS12 12” Light Bar
Features
Advanced TIR (total internal reection) optics
High intensity 6000K Lumileds LEDs
Slim design, for easy mounting
Durable aluminum extrusion
Pressure equalizing vent to eliminate condensation
8
year
warranty
Kit Includes: 12” LED Light Bar, Mounting Hardware, Deutsch DT Connector
Input Voltage: 9-24VDC
Input Power: 58.8 watts
Current Draw: 4.2 amps @ 14V
Operating Temperature: -40° to 185°F
Weight: 2.2 lbs
Specications
Mounting
If you wish, you may use the included hardware to mount your light bar. A number of fasteners
are included, and can be used as you see t. The most common mounting style is shown below.
Stage Series Light Bars are also compatible with most standard mounting brackets on the market.
Reference the dimensions on opposite side to determine the best mounting solution for your
application.
Wiring
Connect the red wire to positive supply, and black wire to negative or common ground.
Please note: This auxiliary lamp draws high current, and requires adequately-sized wiring for safe
operation. If you are not using a Diode Dynamics wire harness, use wire sized 16 AWG or larger.
Please be mindful of current ratings and wire size, especially if splitting power signals to multiple light
bars, or using switches. If you have any questions, please feel free to contact us for assistance.
A
B
C
F
G
H
E
A
B
F
C
D
E
B
G
H
D

[phone] WWW.DIODEDYNAMICS.COM
PAGE 2
Dimensions
3”
1.125”
1.625”
2.75 ”
1.875”
13.75”
13 ”
14.5”
15.25”
2. 5”
* PEAK BEAM INTENSITY
White Driving
White Wide
Lens Color/Optics cd*
1,110
260
110,000
26,000
332 660
161 320
Amber Driving
Amber Wide
660
148
66,000
14,800
257 510
122 240
A B C
Illuminance (lx)
SS12 12” Light Bar
Measured Output Output Color
2,800 lumens
2000K Amber
2,800 lumens
1,600 lumens
1,600 lumens 2000K Amber
6000K White
6000K White
White Flood 404,000 63 130 2,800 lumens 6000K White
Amber Flood 242,400 49 100 1,600 lumens 2000K Amber
DD5015S SS12 White Driving Light Bar (single)
DD5015P SS12 White Driving Light Bar (pair)
DD5023S SS12 White Wide Light Bar (single)
DD5023P SS12 White Wide Light Bar (pair)
DD6033S SS12 White Flood Light Bar (single)
DD6033P SS12 White Flood Light Bar (pair)
This installation guide is for the following SKU:
PP0039
DD5037S SS12 Amber Driving Light Bar (single)
DD5037P SS12 Amber Driving Light Bar (pair)
DD5045S SS12 Amber Wide Light Bar (single)
DD5045P SS12 Amber Wide Light Bar (pair)
DD6041S SS12 Amber Flood Light Bar (single)
DD6041P SS12 Amber Flood Light Bar (pair)
Output
A - lux at 10 meters
B - Distance (m) with 1 lux
C - Distance (m) with .25 lux
Driving
Wide
A B C
Flood
A B CA B C
