Thank you for your purchase of our new SS3 Dual-Pod
Bracket Kit. This frame allows you to mount two SS3
LED Pods together as one unit. Basic installation
instructions are included below.
Please contact us if you have any questions.
See back for further instructions.
2. Place the Dual-Pod Frame upside down on a at
surface. Wearing gloves, carefully remove the lens
and o-ring from the SS3.
3. Place the lens and o-ring face down into the frame.
Ensure the alignment notch on each lens is at the top
of the frame.
Tools Needed: Screwdriver with T10 Torx Bit, Latex
gloves (prevents ngerprints/grease on the lens)
Dual-Pod Bracket Kit
SS33” LED Pod
1. Remove the front bezel from the pod by placing the
SS3 face down and removing the four T10 Torx screws.
Repeat for the second pod.
NOTE: These screws won’t be reused.
4. Place the SS3 castings on top of the lenses.
NOTE: The DT-plug should be towards the bottom. The
lens alignment notch will mate with the SS3 casting.

[phone] WWW.DIODEDYNAMICS.COM
PAGE 2
PP0153
Please contact Diode Dynamics should you have any questions about the installation
or wiring process, at 314-205-3033 (10a-5p CST) or [email protected].
This installation guide is for the following SKU:
DD6610 SS3 Dual-Pod Bracket Kit
GUARANTEE
100% SATISFACTION 8
year
warranty
1
2
34 3
1
2
4
5. Using the T10 screws provided with the frame,
tighten them in a “plus pattern” (top-bottom-left-right)
to ensure the o-ring around the optic creates an even
seal with the frame.
6. Place the included nuts in the outermost mounting
points on each pod.
NOTE: The nylon portion of the nut should face
inward.
7. Attach the U-bracket to the pods using the included
screws and washers. Hand tighten only.
8. Mount the U-bracket to the vehicle using the
supplied hardware. Adjust and aim the bracket. Then
fully tighten the side bolts to complete the installation.
Refer to the Universal Bracket Info/Mounting Guide for
wiring and specications.
