Direct PDC1000 User manual

4-Camera Day/Night H.264 Security System
Quick Installation and Setup Guide
Products: PDC1000, PDC1000LCD
PLEASE READ THIS MANUAL BEFORE USING YOUR SYSTEM, and always follow the
instructions for safety and proper use. Save this manual for future reference.
SCD_PDC1000_SQ
5/3/12

ii www.SecurityCamerasDirect.com
Revision History
Date Reason for Change
10/18/10 Initial release.
3/30/11 Includes iPhone® software.
1/12/12 Includes updated system software.
5/3/12 Includes warranty policy change for removing cover and HDD installation procedure.
CAUTION
Operate this system only in environments where the temperature and humidity is within the recommended range.
Operation in temperatures or at humidity levels outside the recommended range may cause electric shock and shorten the
life of the product. Refer to the specications for each system component for more information.
LEGAL NOTICE
Security Cameras Direct products are designed to meet safety and performance standards with the use of specic
Security Cameras Direct authorized accessories. Security Cameras Direct disclaims liability associated with the use
of non-Security Cameras Direct authorized accessories.
The recording, transmission, or broadcast of any person’s voice without their consent or a court order is strictly
prohibited by law.
Security Cameras Direct makes no representations concerning the legality of certain product applications such
as the making, transmission, or recording of video and/or audio signals of others without their knowledge and/or
consent. We encourage you to check and comply with all applicable local, state, and federal laws and regulations
before engaging in any form of surveillance or any transmission of radio frequencies.
Microsoft, Windows, and Internet Explorer are either registered trademarks or trademarks of Microsoft Corporation in
the United States and/or other countries. Android is a trademark of Google Inc. Use of this trademark is subject to
Google Permissions. Apple, iPhone, iPod touch, and iPad are registered trademarks of Apple Inc.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks
and names or their products. Security Cameras Direct disclaims any proprietary interest in trademarks and trade
names other than its own.
No part of this document may be reproduced or distributed in any form or by any means without the express written
permission of Security Cameras Direct
© 2010, 2011, 2012 Security Cameras Direct. All rights reserved.
Security Cameras Direct
1 Security Cameras Direct Way, Luling, TX 78648
For Sales and Support, please contact your distributor.

iii
4-Camera H.264 Security System Setup Guide
Table of Contents
SECTION 1 Systems Overview ...................................................................1
1.1 About this document .................................................................1
SECTION 2 Getting Started .....................................................................2
2.1 Unpacking the equipment .............................................................2
2.2 What you need ......................................................................3
SECTION 3 Installing Your System ...............................................................4
3.1 Camera installation ..................................................................4
3.1.1 Camera placement ...............................................................4
3.1.2 Mounting ......................................................................5
3.2 DVR installation .....................................................................6
3.2.1 DVRs without an HDD ............................................................6
3.2.2 DVR placement ..................................................................6
3.2.3 Controls and connectors ..........................................................7
3.2.4 Connect alarm in, alarm out, PTZ devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
3.3 Connecting the system together. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
3.4 Using the remote control and mouse ...................................................10
SECTION 4 DVR Setup ........................................................................12
4.1 Login to the DVR ...................................................................12
4.2 Conguring the system ..............................................................13
4.2.1 Setting the screen language and video system format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
4.2.1 Setting the system time .........................................................14
4.2.2 Change the Admin and user1 passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
4.2.3 Add users to the system .........................................................17
4.2.4 Set HDD overwrite option ........................................................18
4.3 Record conguration settings .........................................................19
4.4 Video conguration settings ..........................................................21
4.4.1 Video setup ....................................................................22
4.5 Network conguration settings .......................................................24
4.6 Alarm conguration settings .........................................................24
4.6.1 Motion detection setup .........................................................26
SECTION 5 Networking Your DVR ...............................................................28
5.1 Congure the DVR for access on your home network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
5.1.1 Verify local network connectability with IE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

iv www.SecurityCamerasDirect.com
TABLE OF CONTENTS
5.2 Accessing your DVR from the Internet ..................................................38
SECTION 6 Accessing Your DVR With a Web Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
6.1 Connecting to your DVR with IE .......................................................40
6.2 Live screen .........................................................................41
6.3 Replay window .....................................................................42
6.4 Remote window ....................................................................42
6.5 Local setting .......................................................................43
6.6 Logout ............................................................................44
SECTION 7 KWeye Smartphone App ............................................................45
7.1 Installing KWeye ....................................................................45
7.1.1 Installing KWeye in iPhone .....................................................45
7.1.2 Installing KWeye in Android .....................................................47
7.2 Set up access to a DVR ...............................................................47
7.3 Using KWeye .......................................................................48
SECTION 8 DVR System Menus Reference ........................................................51
8.1 Menu tree .........................................................................51
8.1.1 Tool Bar .......................................................................52
8.1.2 Menu options ..................................................................53
8.2 System menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
8.2.1 Language .....................................................................54
8.2.2 Video System ..................................................................54
8.2.3 Time Setup ....................................................................54
8.2.4 User management ..............................................................55
8.2.5 VOLUME .......................................................................58
8.2.6 HDD ..........................................................................58
8.2.7 Maintenance ...................................................................59
8.2.8 Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
8.3 Record ............................................................................60
8.3.1 Record Channel ................................................................61
8.3.2 Record ........................................................................61
8.3.3 Bit-rate .......................................................................61
8.3.4 Resolution ....................................................................61
8.3.5 Frame Rate ....................................................................61
8.3.6 Audio .........................................................................61
8.3.7 Packtime ......................................................................62

v
4-Camera H.264 Security System Setup Guide
TABLE OF CONTENTS
8.3.8 Record Mode ...................................................................62
8.4 Video .............................................................................63
8.4.1 Video Channel .................................................................63
8.4.2 Name .........................................................................63
8.4.3 Position .......................................................................63
8.4.4 Live ..........................................................................64
8.4.5 Audio .........................................................................64
8.4.6 Color .........................................................................64
8.4.7 Record Time ...................................................................64
8.4.8 Margin ........................................................................64
8.4.9 Video Setup ...................................................................64
8.5 Network ...........................................................................65
8.5.1 Network Setup .................................................................66
8.5.2 DDNS Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
8.5.3 Email Setup ....................................................................68
8.5.4 Mobile Monitor ................................................................69
8.6 Alarm .............................................................................70
8.6.1 OUTPUT .......................................................................71
8.6.2 DURATION .....................................................................71
8.6.3 BUZZER .......................................................................71
8.6.4 PRERECORD ....................................................................71
8.6.5 EXCEPTION ....................................................................71
8.6.6 I/O Alarm ......................................................................72
8.6.7 Motion Detection ...............................................................73
8.7 PTZ ...............................................................................74
8.7.1 Channel .......................................................................75
8.7.2 Protocol .......................................................................75
8.7.3 Baud Rate .....................................................................75
8.7.4 Data Bit .......................................................................75
8.7.5 Stop Bit .......................................................................75
8.7.6 Parity .........................................................................75
8.7.7 Address .......................................................................75
SECTION 9 Cleaning ..........................................................................76
APPENDIX A O-loaded Video Files ..............................................................77
APPENDIX B Troubleshooting ...................................................................78

vi www.SecurityCamerasDirect.com
APPENDIX C HDD Installation ...................................................................82
C.1 DVR compatible HDDs ...............................................................82
C.2 HDD Installation ....................................................................82
APPENDIX D Compatible USB DVD Recorders ......................................................86

1
4-Camera H.264 Security System Setup Guide
SECTION 1: SYSTEM OVERVIEW
SECTION 1
Systems Overview
Congratulations on purchasing your 4-Camera Day/Night H.264 Security System! Your system includes:
• 4 – weatherproof 65’ day/night-vision color cameras. These cameras use the latest technology no-dye infrared (IR) LED
contrast-ltered glass to eliminate all IR bounceback, one of the common problems with IR cameras, giving you a clear view
under any lighting conditions. The weatherproof housings can withstand the harshest environments and work awlessly
throughout the life of the camera.
• 4–camera networkable digital video recorder (DVR) with a pre-installed 500GB hard drive. The DVR can be congured
and controlled locally, using the operator control panel and mouse or remote control, or across the Internet through the
Microsoft® Internet Explorer® (IE) browse.
• The DVR includes state-of-the-art H.264 compression technology to maximize your recording time and optimize your video
quality. H.264 compression saves hard drive space and supports faster data transfer. Data stored in the DVR can easily be
o-loaded via USB or across your network. (See the User Manual for more information.)
• Apple® iPhone®, iPad®, and iPod Touch®, Google Android™, Symbian™, Windows® Mobile, and Blackberry® smartphones app
that let you monitor your home or business on the go from anywhere
1.1 About this document
This document includes a detailed guide to setting up a basic system. For specic instructions about installing your cameras, refer to
the documentation included with them.

2www.SecurityCamerasDirect.com
SECTION 2: GETTING STARTED
SECTION 2
Getting Started
2.1 Unpacking the equipment
Your system includes:
• 1 – 4 channel H.264 networkable DVR and power adapter (DVR4090N)
• 4 – IR Bullet Cameras w/ Brackets (CFC6042IR)
• 4 – 60’ video/power extension cables
• 1 – Camera power adapter with 5-way splitter
• 1 – User guide,
• 1 – USB mouse
• Stand-alone User Manual
• Mini-CD with smart phone applications
• This document
Remove the equipment from its packaging and place it on a at, clean surface. Inspect each item. If any visible damage is present,
contact your supplier or SCD for a replacement. Verify that your order is complete.
Cameras
Camera Mounting
Brackets
5-way
Splitter
Mouse
Remote
Control
Video/Power
Extension Cables
DVR
Power
Adapter

3
4-Camera H.264 Security System Setup Guide
SECTION 2: GETTING STARTED
2.2 What you need
Although each security system installation is dierent, most require the following items not included with your system
components:
• Tools to install the cameras and route power and video cables
• Fasteners to attach the cameras to the mounting surfaces
• A display device and cabling to connect it to the DVR. The DVR will connect directly to a VGA video monitor, or to a TV with a
BNC to RCA adapter and RCA cable. The display device is usually needed only for system setup. It can be disconnected when
the DVR is networked for access across a LAN or Internet.
• Uninterruptible power supply (UPS). This device is used to ensure system stability during voltage surges, sags, and outages. If
a UPS is not available, a power strip with strong surge protection is highly recommended.
• If you purchased your DVR without a hard disk drive (HDD), you must install one. See “APPENDIX C HDD Installation” on
page 82 for more information.

4www.SecurityCamerasDirect.com
SECTION 3: INSTALLING YOUR SYSTEM
SECTION 3
Installing Your System
3.1 Camera installation
Your CFC6042IR camera is a precision instrument that will provide years of quality service when used properly. Included with each
camera is:
• An adjustable mounting bracket that can be attached to either the bottom or back of the camera.
• 60’ video and power cable
Adjustable
Sun Shield
Lens
Mounting
Bracket
Assembly
Lock
Nuts
IR Array
Light
Level
Sensor
Mounting
Plate
3.1.1 Camera placement
Plan your camera installation carefully. Identify the locations where cameras will provide the best coverage, considering:
• Field of view – Cameras must be positioned so they can eectively view the entire area that must be monitored, and in a
location that makes tampering with it dicult.
• Lighting – Direct sunlight shining on the camera lens or bright reections from shiny objects in the eld of view can
diminish video quality and camera performance. Mount the camera in shaded areas, if possible, or where these inuences
can be minimized.
• Ease of installation – Must be able to install the camera at the location, considering mounting hardware requirements,
temperature, dust, moisture, etc.

5
4-Camera H.264 Security System Setup Guide
SECTION 3: INSTALLING YOUR SYSTEM
About weatherproof cameras
Weatherproof cameras can be mounted in any open area, such as on a telephone pole or on the side of a building. However, for best
results, we recommend you mount your cameras in a sheltered area, such as under the eave or roof of a building. Point the camera
in the direction you wish to observe. When routing cable near the camera, allow enough slack to form a U-shaped “drip loop” to
help direct moisture or rain water, that accumulates on the cable, away from the camera.
Drip Loop
Drop
Cable
NOTE Cable connections are not weatherproof.
Video/power cables can be run almost anywhere, and are frequently routed through attics or above drop/acoustic ceilings because
of the ease of installation. For added security, we recommend you run your cables in areas with limited access to prevent tampering.
Avoid running the cable near high voltage appliances such as uorescent lighting. Electrical noise and magnetic elds produced by
these devices may aect video signal quality.
A 60’ video/power extension cable is shipped with every camera in your system. 100’ and custom-length cables are also available
from Security Cameras Direct.
3.1.2 Mounting
1. Using the camera bracket mounting assembly plate as a template, mark the location of the holes for the mounting screws on
the mounting surface.
2. Drill holes into the mounting surface for the mounting screws, wall inserts, or other attachment hardware as needed.
3. If you are routing the video/power drop cable through the mounting surface, drill a ¾” hole near the mounting plate for the
drop cable.
4. Attach the mounting bracket to the mounting surface using appropriate fasteners.
5. Attach the camera with the mounting bracket.

6www.SecurityCamerasDirect.com
SECTION 3: INSTALLING YOUR SYSTEM
6. Point the camera at your surveillance target, then tighten the lock nuts to hold it in place. (Note: The direction the camera is
pointing may need correction when video from the camera is observed.)
7. Route the camera drop cable through the hole drilled for it in the mounting surface, if used. If the camera is installed where
moisture may accumulate on it, leave a “drip loop” in the cable so that beads of water on the cable slide away from the
camera and the drop cable connectors.
8. Attach a video/power extension cable to the camera drop cable (see diagram below). Note: When connecting the video
cables, fully rotate the lock ring to hold them together.
Extension
Cable
Camera
Drop Cable
Power
Video
Lock Ring
If the connectors might be exposed to moisture or other contaminants, seal them with electrical tape or use an equivalent
method.
9. Route the other end of the video/power extension cable to the DVR backpanel.
10. Repeat this procedure for all of the cameras you are installing.
3.2 DVR installation
3.2.1 DVRs without an HDD
DVRs are usually pre-congured with an internal hard disk drive (HDD) by request of the purchaser. If you purchased a DVR without
an HDD, or want to upgrade the HDD in your DVR, follow the guidelines in “APPENDIX C HDD Installation” on page 87 to install one.
3.2.2 DVR placement
Your monitoring and recording equipment is central to constant surveillance and the reliable capture of video evidence. SCD strongly
suggests that it be installed in a secure location with access limited to authorized personnel.

7
4-Camera H.264 Security System Setup Guide
SECTION 3: INSTALLING YOUR SYSTEM
DVRs generate heat and should be placed in a ventilated area. A high temperature environment will reduce the life span and
reliability of the equipment. Additionally, the DVR is not weatherproof, so avoid exposure to liquids and excessive dust. Do not place
objects along the sides or behind the DVR that will block airow through the unit.
Uninterruptible power supplies
It is strongly suggested that power to the system be routed through an uninterruptible power supply (UPS). These devices will keep
your security system running through most power outages, in addition to providing excellent surge and sag protection. The UPS
should support your video recorder and all cameras to ensure normal operation during abnormal power conditions.
3.2.3 Controls and connectors
DVR Front Panel
Single/Multi Camera
Display Toggle
tqpu Menu
Navigation
Buttons
Enter
Escape
Menu
Play/Pause
Record
CH1 .. CH4
Camera Select
Infrared
Sensor
Pan/Tilt/Zoom
Control
Backup
Button Usage
o / Toggles between single camera, multi-camera display.
CH1 .. CH4 Used to select the camera on channel 1, 2, 3, or 4.
Enter Press to conrm a menu choice.
Infrared Sensor Sensor for the remote control.
MENU Opens the main menu window
ESC Press to exit any active window.
REC Use to start and stop manual recording.
BACKUP Opens a video search and playback menu.
u/II When a recorded le is selected, press this button to play. then press it again to pause playback.
PTZ Used for pan/tilt/zoom control of cameras with this feature.
t q p uUse these buttons to navigate through the menu system. Generally, use the t u buttons to move to selection boxes,
and use the q p to select submenu parameters.

8www.SecurityCamerasDirect.com
SECTION 3: INSTALLING YOUR SYSTEM
DVR Backpanel
IN1 - IN4
Audio In
CH1 - CH4
Video In
Audio Out LAN Main Out
(BNC)
Power
Alarm In/Out,
RS422/RS485
Connections
Main Out
(VGA)
USB Power DC 12V
Connector Usage
USB - MOUSE Use these USB ports to connect a mouse, or a backup device such as a ash drive or DVD recorder.
AUDIO OUT Audio output from channel AUDIO IN channels 1, 2, 3, or 4.
IN1 .. IN4 AUDIO IN RCA audio input to audio channels 1, 2, 3, and 4.
CH1 .. CH4 VIDEO IN BNC video input to video channels 1, 2, 3, and 4.
MAIN OUT BNC composite video output to display device (75 Ω, 1 V p-p).
MAIN OUT VGA Standard VGA output to a display device, such as a computer monitor.
LAN Standard RJ-45 Ethernet 10BASE-T, 100BASE-T port with auto detect.
ALARM IN, ALARM OUT,
RS422 RS485
Use these connectors to attach external sensor devices, alarm reporting devices, and devices with an RS422 or RS485 control
interface, such as PTZ cameras.
DC 12V Connect to 12 Vdc power adapter.
POWER Power switch to turn the unit on and o.
3.2.4 Connect alarm in, alarm out, PTZ devices
Alarm in, alarm out, and PTZ device cabling terminates on the wire terminal block on the back of the DVR. These terminal blocks are
dierent for each DVR model. See below.

9
4-Camera H.264 Security System Setup Guide
SECTION 3: INSTALLING YOUR SYSTEM
The DVR4090N provides four alarm inputs (“1” .. “4”) with ground terminals (labeled “G”), and one alarm output (labeled “-” and
“+”). RS422/RS485 terminations are labeled TX+, TX-, RX+, RX-.
3.3 Connecting the system together
All connections to the DVR are made on the back of the unit.
Video/Power
Extension Cable
VGA Cable
5-way
Power
Splitter To 120 Vac
Monitor Power
Power Adapter
Mouse
Camera
Drop Cable
To UPS/
120 Vac
Interconnection Diagram
1. Connect the system mouse to the USB connector labeled MOUSE.
2. Connect the camera video signal cables (BNC connectors) to the VIDEO IN CH1 to CH4 connectors

10 www.SecurityCamerasDirect.com
SECTION 3: INSTALLING YOUR SYSTEM
3. Connect a display device to the DVR. If using a VGA monitor for a display, connect it to the VGA MAIN OUT connector. If using
the BNC MAIN OUT connector to drive a display such as a TV, attach the appropriate cables between the BNC MAIN OUT and
your display device.
4. Connect the 5-way power splitter to the power adapter, then:
a. Connect the lead marked DVR POWER to the DC 12V connector on the DVR backpanel. Ensure that the POWER
switch on the DVR is o.
b. Connect the other leads of the splitter to the mating connectors on the video/power extension cables routed to the
cameras.
5. Connect the power cord to the power adapter and plug it into a standard grounded 120 Vac power source through a UPS or
surge protector.
6. Power on your display device.
7. Power on the DVR using the POWER switch on the backpanel. A startup “Loading” screen will appear on the display. After a
few seconds, the screen will change to the camera view screen.
..
Note: The images you see from your cameras may be dierent from those shown here.
3.4 Using the remote control and mouse
The enter key on the remote control or the front panel has the same function as a mouse left click. The IR Range of the remote
control is 10 meters. The buttons on the remote control correspond with the buttons on the front panel.

11
4-Camera H.264 Security System Setup Guide
SECTION 3: INSTALLING YOUR SYSTEM
Item Function
2
3
1
8
9
7
5
6
4
11
12
13
10
1Stop: Stop playback
2Play/Pause: Opens video search and playback menu. In playback mode, press this
button to play/pause playback.
3t q p u Move selected item in menu.
4ENTER: This button is used as the “enter” key for most operations.
5Menu (MENU/ESC): Displays/exits the main menu.
6Lock: If the password is enabled, press it to logout the system.
7Numerical Button: Use buttons 1, 2, 3, or 4 to select the channel to display.
8REC: Start or Stop manual recording.
9Quad: Press this button to switch display modes from single channel display to a
multi-channel display.
10 Mute: Not used.
11 Spot View: Press to enable auto sequencing.
12 Fast Forward: Fast forward video during playback.
13 Rewind: Rewind video during playback.
Mouse control
The mouse operates just like a mouse on a Windows PC. Connect the mouse to the USB connector in the back panel.
Action Eect
Right click In live display mode, right click to either display or hide the tool bar.
In main menu or sub menu mode, right click to exit the current menu. Note that the settings will not be saved after right clicking.
Left click
On menu unlock mode, in the tool bar left click on the SYSTEM SETTINGS icon, , to enter into the main menu.
After entering main menu, left click to enter sub menus.
In menu mode, left click the PLAY icon, , to review video les.
Left click to select values in edit boxes or pull-down menus. The system supports special symbols, numbers and letters.
Left click the PLAY icon, , to enter playback mode. Left click >> to control the forward function, << reverse function, >>I Slow play
function, I> frame play function, > Play function, and X exit function.
In the VIDEO | VIDEO SETUP | COLOR SETUP conguration window, you can left click to adjust color control bar and screen control bar.
In the main menu, sub menu or playback view, left click “x” to exit/close the current menu.
In the ALARM |MOTION | MD AREA conguration window, left click an area segment to select/deselect it for motion sensing.
Double click In live view or during video playback, double-click to maximize channel on the screen.
Mouse drag
In the ALARM |MOTION | MD AREA conguration window, press the left mouse button and drag to frame an area to sense for motion detec-
tion.
Use the mouse to select menu items.

12 www.SecurityCamerasDirect.com
SECTION 4: DVR SETUP
SECTION 4
DVR Setup
Setting up your DVR includes logging into your DVR, setting the clock, setting administrator and user account passwords, and
setting up scheduled and/or automated motion recording.
4.1 Login to the DVR
Two access accounts are preset in your system: Admin and user1. With the Admin login, you can make conguration changes to
the system, create user accounts and passwords, and control the privileges allotted to each account. With the factory default user1
account login you cannot make conguration changes or create accounts, but can change your own password. The factory default
Admin and user1 account passwords are:
Admin: 888888
user1: 666666
To log into the system:
1. Power on the DVR and wait until it advances to the camera view screen. A typical camera view screen is shown below.
Image from
Channel 1
Camera
2. Press the MENU button on the front panel twice, or right-click the mouse twice anywhere on the screen. An Input
Password window will appear.

13
NVR and hDVR Systems Setup Guide
SECTION 4: DVR SETUP
Conrm entry
3. Click the q icons to the right of the User Name eld parameter eld and select Admin. To make conguration changes to
the system, you must login to the Admin account.
4. Using the mouse, click the entry eld on the PASSWORD line, then click the number buttons that appear to enter the account
password. For example, to enter the default Admin password, 888888, click the “8” button six times.
5. Click the a (check mark) icon in the lower right corner of the window to conrm your entry and enter the login information.
A tool bar icon strip will appear at the bottom of the screen.
4.2 Conguring the system
Basic system conguration settings include setting the screen language, video system format, system time, creating users,
initializing the hard disk drive (HDD), and setting up automated recording.
1. If the system is not running, power on the DVR and wait until it completes initialization.
2. Right-click anywhere on the desktop, or press the MENU button. A status bar will appear.
3. Compare the DVR system date and time shown on the Status Bar with an accurate clock.
System Date and Time Remaining HDD Recording TIme
Status Bar
Note: To see an accurate clock, access a reliable Internet time server, such as tf.nist.gov
4. Right-click the mouse anywhere on the screen again. The Status bar will change to a Tools Bar or a login window. If a LOGIN
window opens, log in to the system as an Admin (see above).

14 www.SecurityCamerasDirect.com
SECTION 4: DVR SETUP
14
System Settings
EZoomPTZPlay
Manual Record /
Stop Manual Record
Auto
Sequence AdvanceKeylock
Mute On/O
Tool Bar
5. Click the Settings button on the Tool Bar.
4.2.1 Setting the screen language and video system format
1. In the Settings window SYSTEM tab, click the q icon at the right end of the LANGUAGE line. Select (click) the screen
language you prefer from the dropdown list.
2. If the VIDEO SYSTEM option does not indicate NTSC, click the q icon at the right end of the VIDEO SYSTEM line, then
select NTSC from the dropdown list.
4.2.1 Setting the system time
1. On the TIME line, click the >> icon to open the TIME SETUP window.
