DirectConnect DCHS41M User manual

H
He el lp pi in ng g y yo ou u a ac ch hi ie ev ve e y yo ou ur r i in ns st ta al ll la at ti io on n n ne ee ed ds s! !
D
Di ir re ec ct t C Co on nn ne ec ct t ®
is one of the largest manufacturers of products specifically for the custom installation
of audio, video, security, telecom and data networking industry.
O
Ou ur r e ex xt te en ns si iv ve e p pr ro od du uc ct t l li in ne e
offers items in the categories of bulk wire and cable, connectors, installation hardware,
interconnect cables, distribution panels, a/v transceivers, cameras, media servers,
baluns, mounts, tools and wall plates—virtually everything a custom installer needs!
S
Si in nc ce e 1 19 99 96 6, , D Di ir re ec ct tC Co on nn ne ec ct t®
has offered unique products that provide solutions to everyday installation headaches.
How do we come up with these ideas? By listening to you, the professional, who battles
in the field and is looking for someone on the front line he can rely on.
DirectConnect®
Houston, Texas 77027
Phone 800 –531 - 3224
Would it make your day to know that someone is waiting to hear from you?
We are. Your DirectConnect
®
representative is ready to take your call.
Or if you prefer, contact us online at …
http://www.directconnecthome.com
4
4x x1 1 H HD DM MI I™
™
A Am mp pl li if fi ie ed d
S
Sw wi it tc ch he er r w wi it th h R Re em mo ot te e
D
DC CH HS S4 41 1M M.17934
4-PORT HIGH SPEED HDMI™ ULTRA HIGH PERFORMANCE
AMPLIFIED SWITCHER
USER MANUAL
This intelligent DirectConnect®High Speed
HDMI™ Ultra High Performance Amplified
Switcher allows four HDMI™ source
devices to be switched into one HDTV
monitor or projector. It not only has the wireless IR remote function, but also has
an intelligent function. Controls via included wireless IR remote or a newly
adopted high tech touch button design for soft touch switching. This device also
has been upgraded to be intelligent by routing high-definition video (in multiple
resolutions up to 1080P) and digital audio from any one of four sources to a high-
definition display. All four inputs accommodate the simultaneous connections of HD
sources, such as Blu-ray®, satellite, and cable. Quite different than other switchers,
this intelligent DirectConnect®ultra high-performance amplified switcher has one
input port on the front panel. This not only reduces the switcher to an ideal small size
but also is more convenient for users to connect additional source devices.
Easy to install and simple to use
Multifunctional switching methods: intelligent, IR remote, or by touch button
Supports HDMI™up to full 1080P resolutions and HDCP pass-through
12bit per channel (36bit all channel) deep color
Supports 250MHz/2.5Gbps per channel (7.5Gbps all channel) bandwidth
Supports uncompressed audio such as LPCM
Supports compressed audio such as DTS Digital, Dolby Digital
(Including DTS-HD and Dolby True HD)
IMPORTANT:If you do not understand any installation instructions,
please consult your installation specialist.
The Finest Name in Audio/Video Products and Accessories
8 / 8

T
Th ha an nk k y yo ou u f fo or r c ch ho oo os si in ng g D Di ir re ec ct tC Co on nn ne ec ct t®
®
P Pr ro od du uc ct ts s
D
De ea ar r C Cu us st to om me er r
Thank you for purchasing this DirectConnect®product. For optimum performance
and safety, please read these instructions carefully before connecting, operating, or
adjusting this product. Please keep this manual for future reference.
Table of Content
1.0 Features ……………………………………… 3
1.1 Intelligent function ………………..…… 3
2.0 Specifications ……………………………… 4
3.0 Package Contents…………………………… 4
4.0 Panel Descriptions…………………………… 4
5.0 Connect and Operate……………….............. 5
5.1 Connection Diagram ……………….............. 5
6.0 Troubleshooting………………………….…… 6
6.1 Non-HDCP Compliant Devices …….……… 6
7.0 Limited Warranty……………………………... 7
Liability Statement
1. Every effort has been made to ensure that this product is free of defects.
DirectConnect®cannot be held liable for the use of this hardware or any
direct or indirect consequential damages arising from its use. It is the
responsibility of the user of the hardware to check that it is suitable for
his/her requirements and that it is installed correctly. All rights reserved. No
parts of this manual may be reproduced or transmitted by any form or means
electronic or mechanical, including photocopying, recording or by any
information storage or retrieval system without the written consent of the
publisher.
2. DirectConnect®reserves the right to revise any of its hardware and software
following its policy to modify and/or improve its products where necessary or
desirable. This statement does not affect the legal rights of the user in any
way.
3. All third-party trademarks and copyrights are recognized.
IMPORTANT:If you do not understand any installation instructions,
please consult your installation specialist
* DirectConnect® is a registered trademark.
*UL®is as registered trademark of Underwriters Laboratories. ©Copyright
7.0 LIMITED WARRANTY
Should any consumer product from DirectConnect®fail due to defects in materials
or workmanship within two years from the date of the original sale to the end-user,
DirectConnect®guarantees replacement of the defective product at no cost. Freight
charges for the replacement unit will be paid by the customer. A copy of the invoice
showing the item number and date of purchase (proof-of-purchase) must be
submitted with the defective unit to constitute a valid in-warranty claim.
Units that fail after the warranty period has expired may be returned to the factory
for repair at a nominal charge, if not damaged beyond the point of repair. All freight
charges for out-of-warranty returns for repair are the responsibility of the customer.
Units returned for repair must have a Return Authorization Number assigned by
DirectConnect®.
This is a limited warranty and is not applicable for products which, in our opinion,
have been damaged, altered, abused, misused, or improperly installed.
DirectConnect®makes no other warranties either expressed or implied, including
limitation warranties as to merchantability or fitness for a particular purpose.
Additionally, there are no allowances or credits available for service work or
installation performed in the field by the end user.
T
Th ha an nk k y yo ou u f fo or r c ch ho oo os si in ng g D Di ir re ec ct tC Co on nn ne ec ct t®
®
p pr ro od du uc ct ts s
IMPORTANT:If you do not understand any installation instructions,
please consult your installation specialist
* HDMI™ is a registered trademark.
* DirectConnect® is a registered trademark.
*DPL Rating™ is a registered trademark.
*UL®is as registered trademark of Underwriters Laboratories.
2 / 8
7 / 8

2.0 SPECIFICATIONS
Signal Inputs/Output
Input Video Signal
0.5-1.0 volts p-p
Input DDC Signal
5 volts p-p (TTL)
Maximum Signal Link Range
1920X1080P
Output Video
HDMI™+HDCP1.0/1.1
Video format supported
DTV/HDTV
480i/576i/480p/576p/720p/1080i/1080P
Digital Signal I/O
HDMI™Compliance
Yes
Operating Frequency
Frequency
Up to 250MHz
Vertical Frequency Range
50/60Hz
Video Amplifier Bandwidth
2.5Gpbs/250MHz
Resolutions (HDTV)
Interlaced(50&60Hz)
480i,576i,1080i
Progressive(50&60Hz)
480p,576p,720p,1080p
Mechanical
Size(H-W-D)
6.1” x 2.76 ” x ”0.76 (155 x 70 x 19mm)
Weight(Net)
9.17 oz. (260grams)
Warranty
Limited Warranty
2 Year Parts and Labor
Environmental
Operating Temperature
320F - 1580F (00C + 700C)
Operating Humidity
10% to 85 % RH (no condensation)
Storage Temperature
140F - 1760F (-100C + 800C)
Storage Humidity
5% to 90% RH (no condensation)
Power Requirement
US standard
5 Volt DC Power Adapter (Included)
5V DC@2A 5 Watts
Accessories
IR Wireless Remote control
Credit Card size
User Manual
English Version
Note: Specifications are subject to change without notice.
3.0 PACKAGE CONTENTS
Before attempting to use this DirectConnect®unit, please check the packaging and
make sure the following items are contained in the shipping carton:
4 X 1 HDMI™Switcher - Main unit.
IR Wireless Remote
5VDC 2A Power Supply
User's Manual
Note:
Please retain the original packing material in case you need to return the unit. If you
find any items missing, contact DirectConnect®immediately (800.531.3224). Please
have the model number, serial number, and invoice available for reference when you call.
4.0 PANEL DESCRIPTIONS
5.0 CONNECT AND OPERATE
1) Connect the HDMI™ input ports of this switcher to each HDMI™ source device.
(Input cables are optional and an optional extender may be needed for runs greater than 6 feet)
*Please refer to connection diagram section.
2) Connect the HDMI™output port of this Switcher to the HDTV device or display.
3) Insert the DC side of 5v power supply into the HDMI™switch and then connect
the AC side of the power supply into the wall outlet.
4) Turn on the power.
Attention: Insert/Remove cables gently & avoid twisting/kinking your HDMI™ cables.
5.1 CONNECTION DIAGRAM
5 / 8
4 / 8

6.0 TROUBLESHOOTING
If this DirectConnect®product does not appear to be functioning, please make
certain that the source and the destination device connected to the unit are
functioning correctly. If other problems exist please check the conditions below carefully.
Without LED light
Is the power adapter connected? If a power strip
is used, is the ON/OFF switch in “ON” position?
No display
Is the display unit turning on? Are cables
connected properly? Please refer to the
connection diagram.
Without sound
1) Check the display volume
2) Turn off the HDMI™source (DVD, PS3 etc.)
and power on again. If it’s still not ok, then
3) Turn off the switch box and turn on again
4) Repeat step 2 again if still not working
Note: Some HDMI™devices without ATC certified and
DPL ratings may have such problems.
Poor picture quality
(snow, sparkles, banding, etc)
Examine the HDMI™ cable and replace with
new cables if possible. To ensure that the
Distribution Amplifier is operating correctly, test
with the shortest HDMI™ cable possible.
Longer or inferior/ damaged cables will
compromise image quality.
Remote not working
Replace the battery of the remote control
DO NOT open the HDMI™switch box. There are no user repairable parts inside.
Once opened, DirectConnect®is not responsible. For other problems, please
contact DirectConnect®at 800.531.3224. http://www.directconnecthome.com
6.1 NON-HDCP-COMPLIANT DEVICES
If a DVI device does not appear to work, make certain that the device is HDCP-
compliant. A non-HDCP-compliant DVI device will not work with a signal that has
HDCP encoding present.
Notice
DirectConnect®reserves the right to make changes in the hardware, packaging
and/or any accompanying documentation without prior written notice.
.
1.0 FEATURES
This DirectConnect®HDMI™Automatic/Manual Switcher has many features that
enable it to perform in a superior manner. Among those features you will find:
Easy to install and simple to use.
One HDMI™input port on the front panel is available for additional devices
Switch manually or via supplied wireless IR remote between four HDMI™sources.
Multi-switching methods: intelligent, IR remote, or by touch button
Supports HDMI™, highest video resolution 1080P, and HDCP pass-through
Multifunctional on switching: intelligent or mechanical
Supports 250MHz/2.5Gbps per channel (7.5Gbps all channel) bandwidth
Optional HDMI™extender may be needed for longer HDMI™runs
Supports 12bit per channel (36bit all channel) deep color.
Supports uncompressed audio such as LPCM.
Supports compressed audio such as DTS Digital, Dolby Digital
(Including DTS-HD and Dolby True HD )
1.1 INTELLIGENT FUNCTION
This is intelligent HDMI™4X1 Amplified Switcher allows four HDMI™source
devices switched into one HDTV monitor or projector. The adopted touch button
design lets you enjoy the high technology and easy switching life. This intelligent
Switcher is quite different from other switchers; it has one HDMI™ input port on the
front panel which reduces the switcher to an ideal small size but also is more
convenient for users to connect additional source devices.
1) When supplied with power, this switcher will select the power-on source device
depending on the sequence automatically (input1>input2>input3>input4)
2) Once the source device is turned on or plugged in (should stay power-on mode), the
switcher will automatically select this source.
3) Once the source device is turned off or unplugged, the switcher will automatically
select the next power-on source depending on the sequence (input1>input2>input3>input4)
4) Once the touch button been touched, this switcher will automatically select the
next power-on source depending on the sequence (input1>input2>input3>input4)
Please Note:
1) When the source devices are on the stand-by mode, its power supply should be turned off, otherwise
this switcher cannot meet intelligent function.
2) When plugged in or out, this switcher is completely intelligent.
3 / 8
6 / 8
